IHDP56LS2WCDMA/GSM TRANSCEIVER WITH BT & WLAN

58The above gives an example of a typical Product Approval Number.You can view your product’s Declaration of Conformity (DoC) to Directive 1999/5/EC (to R&TTE Directive) at www.motorola.com/rtte . To find your DoC, enter the Product Approval Number from your product’s label in the “Search” bar on the Web site. FCC Notice to UsersFCC NoticeThe following statement applies to all products that have received FCC approval. Applicable products bear the F CC logo, and/or an FCC ID in the format FCC ID:xxxxxx on the product label. Motorola has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. See 47 CFR Sec. 15.21.This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3).This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by 0168 Product Approval Nu m ber turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:• Reorient or relocate the receiving antenna. • Increase the separation between the equipment and the receiver. • Connect the equipment to an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. For products that support W-Fi 802.11a (as defined in the product specifications available at www.motorola.com ), the following information applies. This equipment has the cap ability to operate Wi-Fi in t he 5 GHz Unlicensed National Information Infrastructure (U-NII) band. Because this band is shared with MSS (Mobile Satellite Service), the FCC has restricted such devices to indoor use only (see 47 CFR 15.407(e)). Since wireless hot spots operating in this band have the same restriction, outdoor services are not offered. Nevertheless, please do not operate this device in Wi-Fi mode when outdoors. GPS & AGPSGPS & AGPSYour mobile device can use Global Positioning System (GPS) signals for location-based applications. GPS uses satellites controlled by the U.S. government that are subject to changes implemented in accordance with the Department of Defense policy and the Federal Radio Navigation Plan. These changes may affect the performance of location technology on your mobile device.Your mobile device can also use Assisted Global Positioning System (AGPS), which obtains information from the cellular network to improve GPS performance. AGPS uses your wireless service provider's network and therefore airtime, data charges, and/or additional charges may apply in accordance with your service plan. Contact your wireless service provider for details. Your LocationLocation-based information includes information that can be used to determine the approximate location of a mobile device. Mobile devices which are connected to a wireless network transmit location-based information. Devices enabled with GPS or AGPS technology also transmit location-based information. Additionally, if you use applications that require location-based information (e.g. driving directions), such

APPLICANT MOTOROLA INC. FCC ID: IHDP56LS2 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 MOTOROLA ATRIX ™ 1 Welcome WelcomeMOTOROLA AT R I X It’s not part computer, it’s leave-your-computer-behind.• A computer that doubles as a phone: Built with PC-like dual-core technology, the MOTOROLA AT R I X also comes packing 1GB of RAM. You’ll see everything in crisp, rich 24-bit color with the world’s first qHD smartphone display. With the support of up to 48GB memory, you’ll be able to store thousands of songs, photos, and files. • A phone that acts like a computer: With the revolutionary webtop, you now have the freedom to access and manage your files, photos, emails and web on a larger screen virtually anywhere you go. Just connect your AT R I X using the optional Laptop Dock or HD Multimedia Dock (page 38). Note: Certain apps and features may not be available in all countries. Caution: Before assembling, charging, or using your phone for the first time, please read the important legal and safety information packaged with your product. More•Answers: To u ch > Help Center . You can also flick your home screen left or right to show the Getting Started and Tips & Tricks widgets. •Updates: Get phone updates, PC software, online help and more at www.motorola.com/myatrix . •MOTOBLUR: After you create a MOTOBLUR account, open it at www.motorola.com/mymotoblur . • Accessories: Find accessories for your phone at www.motorola.com/products . 2 Your phone Your phonethe important keys & connectors Browser Market 11:35 H is attending the World Music Festival! 10:14 AM 1 hour ago Natanya RayHey, I'm just backfrom my trip, want to grab a coffee? Dylan Foster1 more day beforeI hit those slopes! 9 minutes ago GPS Nav TV & Radio TRANS CANADA Br o w se r Ma rk et 11 : 3 5 H th e Wor ld Music t g t n i s atten d i n F estival ! 10:10: 1 hour a go to grab a cof to grab a cofN atanya R a H ey, I'm ju s f rom my tri p bf :: ff a s p fff a s p f 14 AM 14 AM ffee?f a s p f p 9 m i nutes ag o ffee? a p f I hit those slopes ! a y t b a ck p , wa nt ff Dy l an Fost er 1 more day be f or e I hit those slopes ! G P S N av TV & R ad i o T RAN S C ANADA M ic ro p hone M ic ro USB Volume 3.5mm He a dset We bca m Mess ag e L ig ht Se a r c h B ac k Menu Power / Slee p Hold= power Press= sleep HDMI Home Note: Your phone might look a little different. ZXCVBNM ASDFGH J KL QW E R T Y U I O P . ?123 :-) DELDEL Done Enter message here 11:35 H Delete Emot ic ons Press=s m iley Hold=icon m enu Sym b ols Press=sy m bols Hold=settings Sh i ft Vo ic e 3 Let’s go ContentsLet’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 6Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9Apps & updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 12Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 26Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35Entertainment Center . . . . . . . . . . . . . . . . . . . . . . . 37Webtop application . . . . . . . . . . . . . . . . . . . . . . . . . 38Wireless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39Memory card & file transfer . . . . . . . . . . . . . . . . . . 42Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 51Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 52 Let’s golet’s get you up and runningAssemble & charge Caution: Please read “Battery Use & Safety” on page 52.To save battery life, see “Battery tips” on page 25. 1 Cover off 2 SIM in 3 Battery in 4 Cover on 5 Charge up 6 Power up, log in 3H 4 Let’s go Set up & goNote: To use MOTOBLUR, please read the terms and conditions during registration and, if you agree, choose to continue.Create or log into a MOTOBLUR account to get your contacts, email, messages, and status information, for all your accounts, all in one place. Registration is secure and should only take a few minutes.Note: This phone supports apps and services that use a lot of data, so make sure your data plan meets your needs. For details, contact your service provider. 1 Tu r n o n . 2 Select a language. 3 Register or log in.If you have not created a MOTOBLUR account, you’ll need to register: Enter your name, your current email address (where MOTOBLUR can send account information), and a new MOTOBLUR password. 4 Add your accounts to MOTOBLUR.To add an account, touch it. Then, enter the user name or email and password that you set up on that account. Tip: For more, or to add accounts anytime, go to “Add accounts” on page 12. 5 When your phone shows your home screen, import your SIM contacts: Touch Contacts , then touch Menu > More > Import/Export > Import contacts from: SIM card . Touch OK to confirm. Your MOTOBLUR accountOnly MOTOBLUR syncs contacts, posts, feeds, messages, emails, photos, and much more—from sources like Facebook™, Twitter, MySpace, your work email, Picasa™, and Photobucket™—and serves them up just t…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907 2.1. Specification Compliance Transceiver type described herein (IHDP56LS2) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Matthew Biggerstaff SIGNATURE: /s/ Matthew Biggerstaff DATE: 16 Feb 2011 TITLE: Engineering Manager 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDP56LS2) is in compliance with all applicable parts of the FCC Rules. NAME: John Lewczak SIGNATURE: DATE 27 April 2011 TITLE: Engineering Manager, Product Safety and Compliance Page 2 - 1 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 2 2.3. Attestation Statement (Bluetooth/Wi-Fi) This device contains an embedded Bluetooth device, Wi-Fi device, and MOTOtalk capabilities that Motorola Mobility confirms are compliant with the applicable Part 15C regulations. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Matthew Biggerstaff SIGNATURE: /s/ Matthew Biggerstaff DATE: 16 Feb 2011 TITLE: Engineering Manager APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com 2.4. Attestation Statement (U-NII Wi-Fi) This device contains an embedded U-NII Wi-Fi device that Motorola Mobility confirms to be compliant with the applicable Part 15E regulations. 15.407(c) The device will automatically discontinue transmission in case of either the absence of information to transmit or operational failure. Details of how this is implemented can be found in Exhibit 12. 15.407(h)(1) This device does not operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, and as such Transmit Power Control (TPC) is not required. 15.407(h)(2) This device does not operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, and as such Radar Detection Function of Dynamic Frequency Selection (DFS) is not required. NAME: Matthew Biggerstaff SIGNATURE: /s/ Matthew Biggerstaff DATE: 16 Feb 2011 TITLE: Engineering Manager 2.5. Attestation of Maximum Power and Power Reductions Employed Motorola Mobility attests that those maximum power levels, and any reduced power levels implemented under software control, reported in Section 2.2 of the RF Exposure report (Exhibit 11) are the maximum powers for this product. All units will be tuned in the Factory to levels consistent with these. No unit will be tuned to power levels higher than indicated, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: John Lewczak SIGNATURE: DATE 27 April 2011 TITLE: Engineering Manager, Product Safety and Compliance Page 2 - 3

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 January 29, 2011 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Dear Sir/Madame: Pursuant to sections 0.457 & 0.49 of the commission’s rules, Motorola Mobility, Inc., 600 N. U.S. Highway 45, Libertyville, Illinois 60048 herein submit s Application for Equipment Authorization for Certification of a Cellular/PCS Transceiver, FCC ID: IHDP56LS2. Motorola Mobility is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission’s rules (CFR 47), Motorola Mobility requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola’s trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in the Cellular 850 and PCS 1900 MHz band. It also operates in WCDMA 850/1900 network, contains 2.4 GHz Bluetooth and WiFi functions (part 15.247) as well as 5GHz UNII sub-bands I & IV non-DFS WiFi function (part 15.407). The unit may also be connected to a computer via a USB connection. (Part 15B Computing Device Peripheral). Note: This device also contains functions that are not operational in the U.S. territories. This filing is only applicable for US operations. Contact Information: If there are any further questions or additional information needed concerning this filing, please contact me, John Lewczak, by telephone at (954) 723-6272 or via E-mail at: [email protected] . Rega rds, FCC Liaison Motorola Mobility, Inc. 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13 1 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS1 Exhibit 13 2 E-mail: [email protected]

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDP56LS2 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Pursuant to sections 0. 457 & 0.49 of the commission’s rules, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (954) 723-6272, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, John Lewczak FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

APPLICANT: MOTOROLA, INC. FCC ID: IHDP56LS2 EXHIBIT 3 Equipment ID Label Location APPLICANT: MOTOROLA, INC. FCC ID: IHDP56LS2 EXHIBIT 3 LEFT SIDE RIGHT SIDE TOP SIDE BOTTOM SIDE APPLICANT: MOTOROLA, INC. FCC ID: IHDP56LS2 EXHIBIT 3

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDP56LS2

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 GPSAntenna FCC ID Label Location WLAN/BTAntenna MainAntenna EXHIBIT 9 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 GPSAntenna WLAN/BT Antenna Main Antenna TOP SIDE BOTTOM SIDE EXHIBIT 9 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 Main Antenna BO TTOM SIDE EXHIBIT 9 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56LS2 EXHIBIT 9 TOP SIDE WLAN/BT Diversity Antenna BOTTOM SIDE

Date/Time: 4/26/2011 9:22:12 PM Test Laboratory: Motorola - GSM 850 with Accessory DUT: TA014000R5; FCC ID: IHDP56LS2 Procedure Notes: Pwr Step: 5; Antenna Position: Internal; Battery Model #: SNN5865A Accessory Model: SJYN0737A (S/N AC023B66D) Device Position: Body Worn, Bottom Surface of Accessory with DUT attached, 0 mm from Phantom Communication System: GPRS 850 Cl 10; Frequency: 836.6 MHz; Channel Number: 190; Duty Cycle: 1:4.15 Medium: Low Freq Body Medium parameters used: f = 835 MHz; σ = 0.97 mho/m; ε r = 53.8; ρ = 1000 kg/m 3 DASY4 Configuration: z Probe: ES3DV3 - SN3124; ConvF(5.86, 5.86, 5.86); Calibrated: 8/11/2010 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn434; Calibrated: 1/13/2011 z Phantom: R#4 Glycol SAM (extended range), Rev.1 (25-Mar-05); Type: SAM v4.0; Serial: TP-1250; z Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 SAM DUT Against Flat Section/Area Scan - Normal Body (15mm) (21x6x1): Measurement grid: dx=15mm, dy=15mm; Maximum value of SAR (measured) = 0.330 mW/g SAM DUT Against Flat Section/5x5x7 Zoom Scan (<=3GHz) (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 17.6 V/m; Power Drift = -0.128 dB; Peak SAR (extrapolated) = 0.572 W/kg SAR(1 g) = 0.314 mW/g; SAR(10 g) = 0.176 mW/g; Maximum value of SAR (measured) = 0.342 mW/g Page 1 of 1 Date/Time: 4/26/2011 10:55:07 PM Test Laboratory: Motorola - WCDMA 850 with Accessory DUT: TA014000R5; FCC ID: IHDP56LS2 Procedure Notes: Pwr Step: All Up Bits; Antenna Position: Internal; Battery Model #: SNN5893A Accessory Model: SJYN0737A (S/N AC023B66D) Device Position: Body Worn, Bottom Surface of Accessory with DUT attached, 0 mm from Phantom Communication System: WCDMA 850; Frequency: 836 MHz; Channel Number: 4180; Duty Cycle: 1:1 Medium: Low Freq Body Medium parameters used: f = 835 MHz; σ = 0.97 mho/m; ε r = 53.8; ρ = 1000 kg/m 3 DASY4 Configuration: z Probe: ES3DV3 - SN3124; ConvF(5.86, 5.86, 5.86); Calibrated: 8/11/2010 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn434; Calibrated: 1/13/2011 z Phantom: R#4 Glycol SAM (extended range), Rev.1 (25-Mar-05); Type: SAM v4.0; Serial: TP-1250; z Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 SAM DUT Against Flat Section/Area Scan - Normal Body (15mm) (21x6x1): Measurement grid: dx=15mm, dy=15mm; Maximum value of SAR (measured) = 0.192 mW/g SAM DUT Against Flat Section/5x5x7 Zoom Scan (<=3GHz) (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 13.5 V/m; Power Drift = 0.037 dB; Peak SAR (extrapolated) = 0.250 W/kg SAR(1 g) = 0.187 mW/g; SAR(10 g) = 0.128 mW/g; Maximum value of SAR (measured) = 0.198 mW/g Page 1 of 1 Date/Time: 4/26/2011 11:56:22 PM Test Laboratory: Motorola - GSM 1900 with Accessory DUT: TA014000R5; FCC ID: IHDP56LS2 Procedure Notes: Pwr Step: 0; Antenna Position: Internal; Battery Model #: SNN5893A Accessory Model: SJYN7037A (S/N AC023B66D) Device Position: Body Worn, Bottom Surface of Accessory with DUT attached, 0 mm from Phantom Communication System: GPRS 1900 Cl 10; Frequency: 1880 MHz; Channel Number: 661; Duty Cycle: 1:4.15 Medium: Regular Glycol Body 1750/1880 Medium parameters used: f = 1880 MHz; σ = 1.59 mho/m; ε r = 51; ρ = 1000 kg/m 3 DASY4 Configuration: z Probe: ES3DV3 - SN3183; ConvF(4.84, 4.84, 4.84); Calibrated: 7/14/2010 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE4 Sn702; Calibrated: 4/14/2011 z Phantom: R1_ Glycol, SAM (extended range), Rev.1 (25-Mar-05); Type: SAM v4.0; Serial: TP-1139; z Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 SAM DUT Against Flat Section/Area Scan - Normal Body (15mm) (21x6x1): Measurement grid: dx=15mm, dy=15mm; Maximum value of SAR (measured) = 0.070 mW/g SAM DUT Against Flat Section/5x5x7 Zoom Scan (<=3GHz) (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 6.21 V/m; Power Drift = 0.249 dB; Peak SAR (extrapolated) = 0.107 W/kg SAR(1 g) = 0.068 mW/g; SAR(10 g) = 0.041 mW/g; Maximum value of SAR (measured) = 0.074 mW/g Page 1 of 1 Date/Time: 4/27/2011 12:56:27 AM Test Laboratory: Motorola - WCDMA 1900 with Accessory DUT: TA014000R5; FCC ID: IHDP56LS2 Procedure Notes: Pwr Step: All Up Bits; Antenna Position: Internal; Battery Model #: SNN5865A Accessory Model: SJYN7037A (S/N AC023B66D) Device Position: Body Worn, Bottom Surface of Accessory with DUT attached, 0 mm from Phantom Communication System: WCDMA 1900; Frequency: 1880 MHz; Channel Number: 9400; Duty Cycle: 1:1 Medium: Regular Glycol Body 1750/1880 Medium parameters used: f = 1880 MHz; σ = 1.59 mho/m; ε r = 51; ρ = 1000 kg/m 3 DASY4 Configuration: z Probe: ES3DV3 - SN3183; ConvF(4.84, 4.84, 4.84); Calibrated: 7/14/2010 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE4 Sn702; Calibrated: 4/14/2011 z Phantom: R1_ Glycol, SAM (extended range), Rev.1 (25-Mar-05); Type: SAM v4.0; Serial: TP-1139; z Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 SAM DUT Against Flat Section/Area Scan - Normal Body (15mm) (21x6x1): Measurement grid: dx=15mm, dy=15mm; Maximum value of SAR (measured) = 0.143 mW/g SAM DUT Against Flat Section/5x5x7 Zoom Scan (<=3GHz) (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 8.31 V/m; Power Drift = 0.001 dB; Peak SAR (extrapolated) = 0.210 W/kg SAR(1 g) = 0.131 mW/g; SAR(10 g) = 0.077 mW/g; Maximum value of SAR (measured) = 0.142 mW/g Page 1 of 1 Date/Time: 4/26/2011 6:04:16 PM Test Laboratory: Motorola - Wi-Fi 2450 with Accessory DUT: TA0140008Z; FCC ID: IHDP56LS2 Procedure Notes: Pwr Step: N/A; Antenna Position: Internal; Battery Model #: SNN5893A Accessory Model: SJYN7037A (S/N AC023B66D) Device Position: Body Worn, Bottom Surface of Accessory with DUT attached, 0 mm from Phantom Device Mode: 802.11b mode, 5.5 Mbps data rate Communication System: Wi-Fi 2450; Frequency: 2462 MHz; Channel Number: 11; Duty Cycle…

Text truncated - open the document above for the full version.

MOTOROLA MOBILITY, INC. Portable Cellular Phone SAR Test Report Number: 24400-1F Rev. F FCC ID: IHDP56LS2 Exhibit 11 Appendix 8 Dipole Characterization Certificate Page A125 Page A126 Page A127 Page A128 Page A129 Page A130 Page A131 Page A132 Page A133 Page A134 Page A135 Page A136 Page A137 Page A138 Page A139 Page A140 Page A141 Page A142 Page A143 Page A144 Page A145 Page A146 Page A147 Page A148 Page A149 Page A150 Page A151 Page A152 Page A153 Page A154 Page A155 Page A156 Page A157 Page A158 Page A159 Page A160 Page A161 Page A162 Page A163 Page A164 Page A165 Page A166 Page A167 Page A168 Page A169

MOTOROLA MOBILITY, INC. Portable Cellular Phone SAR Test Report Number: 24400-1F Rev. F FCC ID: IHDP56LS2 Exhibit 11 Appendix 1 SAR distribution comparison for the system accuracy verification Page A1 Date/Time: 2/25/2011 8:35:12 AM Test Laboratory: Motorola - Feb-25-2011 835 MHz DUT: Dipole 835 MHz; Type: D835V2; Serial: D835V2 - SN: 425TR; FCC ID: IHPD56LS2 Procedure Notes: 835 MHz System Performance Check; Dipole Sn# 425TR; Input Power = 200 mW Sim.Temp@meas = 20.2C; Sim.Temp@SPC = 20.3C; Room Temp @ SPC = 20.2C Communication System: CW - Dipole; Frequency: 835 MHz; Duty Cycle: 1:1 Medium: VALIDATION Only Medium parameters used: f = 835 MHz; σ = 0.91 mho/m; ε r = 41.6; ρ = 1000 kg/m 3 DASY4 Configuration: z Probe: ES3DV3 - SN3124; ConvF(5.89, 5.89, 5.89); Calibrated: 8/11/2010 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn434; Calibrated: 1/13/2011 z Phantom: R#4 Sugar SAM (extended range), Rev.1 (25-Mar-05); Type: SAM v4.0; Serial: TP-1131; z Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Daily SPC Check/Dipole Area Scan (4x9x1): Measurement grid: dx=15mm, dy=15mm; Maximum value of SAR (measured) = 1.92 mW/g Daily SPC Check/0-Degree, 5x5x7 Cube (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 48.4 V/m; Power Drift = -0.028 dB; Peak SAR (extrapolated) = 2.91 W/kg SAR(1 g) = 1.95 mW/g; SAR(10 g) = 1.27 mW/g; Maximum value of SAR (measured) = 2.10 mW/g Daily SPC Check/Z-Axis Retraction (1x1x31): Measurement grid: dx=20mm, dy=20mm, dz=5mm Page 1 of 2 Page A2 Page 2 of 2 Page A3 Date/Time: 2/27/2011 3:47:15 AM Test Laboratory: Motorola - Feb-27-2011 835 MHz DUT: Dipole 835 MHz; Type: D835V2; Serial: D835V2 - SN: 425TR; FCC ID: IHDP56LS2 Procedure Notes: 835 MHz System Performance Check; Dipole Sn# 425TR; Input Power = 200 mW Sim.Temp@meas = 20.5C; Sim.Temp@SPC = 20.5C; Room Temp @ SPC = 20.3C Communication System: CW - Dipole; Frequency: 835 MHz; Duty Cycle: 1:1 Medium: VALIDATION Only Medium parameters used: f = 835 MHz; σ = 0.91 mho/m; ε r = 40.7; ρ = 1000 kg/m 3 DASY4 Configuration: z Probe: ES3DV3 - SN3124; ConvF(5.89, 5.89, 5.89); Calibrated: 8/11/2010 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn434; Calibrated: 1/13/2011 z Phantom: R#4 Sugar SAM (extended range), Rev.1 (25-Mar-05); Type: SAM v4.0; Serial: TP-1131; z Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Daily SPC Check/Dipole Area Scan (4x9x1): Measurement grid: dx=15mm, dy=15mm; Maximum value of SAR (measured) = 1.90 mW/g Daily SPC Check/0-Degree, 5x5x7 Cube (5x5x7)/Cube 0: Measurement grid: dx=8mm, dy=8mm, dz=5mm Reference Value = 49.1 V/m; Power Drift = -0.091 dB; Peak SAR (extrapolated) = 2.95 W/kg SAR(1 g) = 1.97 mW/g; SAR(10 g) = 1.28 mW/g; Maximum value of SAR (measured) = 2.13 mW/g Daily SPC Check/Z-Axis Retraction (1x1x31): Measurement grid: dx=20mm, dy=20mm, dz=5mm; Maximum value of SAR (measured) = 2.11 mW/g Page 1 of 2 Page A4 Page 2 of 2 Page A5 Date/Time: 2/28/2011 8:04:34 AM Test Laboratory: Motorola - Feb-28-2011 835 MHz DUT: Dipole 835 MHz; Type: D835V2; Serial: D835V2 - SN: 425TR; FCC ID: IHDP56LS2 Procedure Notes: 835 MHz System Performance Check; Dipole Sn# 425TR; Input Power = 200 mW Sim.Temp@meas = 21.3C; Sim.Temp@SPC = 21.3C; Room Temp @ SPC = 20.5C Communication System: CW - Dipole; Frequency: 835 MHz; Duty Cycle: 1:1 Medium: VALIDATION Only Medium parameters used: f = 835 MHz; σ = 0.92 mho/m; ε r = 41.5; ρ = 1000 kg/m 3 DASY4 Configuration: z Probe: ES3DV3 - SN3124; ConvF(5.89, 5.89, 5.89); Calibrated: 8/11/2010 z Sensor-Surface: 4mm (Mechanical Surface Detection) z Electronics: DAE3 Sn434; Calibrated: 1/13/2011 z Phantom: R#4 Sugar SAM (extended range), Rev.1 (25-Mar-05); Type: SAM v4.0; Serial: TP-1131; z Measurement SW: DASY4, V4.7 Build 80; Postprocessing SW: SEMCAD, V1.8 Build 186 Daily SPC Check/Dipole Area Scan (4x9x1): Measurement grid: dx=15mm, dy=15mm; Maximum value of SAR (measured) = 2.00 mW/g Daily SPC Check/0-Degree, 5x5x7 Cube (5x5x7)/Cube 0: Measurement gr…

Text truncated - open the document above for the full version.
