IHDP56MC1Mobile Phone

XT319 1Congratulations Congratulations MOTOROLA XT318/XT319 Yo u r M O T O R O L AXT318/XT319 phone delivers more for your work and play! •Search: Touch Search to search across your apps, contacts, web, and maps—or just enter the address for a place or a web page. •Apps: Open Market to download games for fun, social networking apps to keep in touch (like Facebook™ or Twitter), or find something else you like with “Apps” on page 6. •Touchscreen: Browse the web and pinch-to-zoom on the touch display in “Web” on page 18. •Camera: Capture photos and videos with the 3MP auto-focus camera in “Photos & videos” on page 20. Note: Some apps and features might not be available in all countries. Caution: Before assembling, charging, or using your phone for the first time, please read the important legal and safety information packaged with your product. More • Support: Phone updates, PC software, online help and more at www.motorola.com/support. • Accessories: Find accessories for your phone at www.motorola.com/products. 2Your phone Your phone the important keys & connectors Front Camera Notification Light Flash=missed call, new message, or other notification. Micro USB Microphone Volume Keys Camera Key Power/Sleep Key Press=sleep Hold=power Menu Open options. Home Touch= home screen Hold= recent apps Search Touch=text Hold=voice Back Go back one screen. 3.5mm OMTP Headset Jack (XT319 only). Camera Lens Speaker To open the stand, pull outwards. 3Let’s go Contents Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Home screen & apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Personalize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Music. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Bluetooth™, Wi-Fi, & cable connections . . . . . . . . . . . . . . . . 23 Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Let’s go let’s get you up and running Assemble & charge 1Cover off2SIM in 3microSD in (may already be inserted) 4Battery in 5Cover on6Charge up 3-6H 4Let’s go Caution: Please read “Battery Use & Safety” on page 31. Tip: To save battery life, see “Battery tips” on page 28. Set up & go Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details. When you turn on your new phone, you can create or enter a Google™ account so that you can download apps, use Gmail™, and much more: 1Press and hold Power to turn on your phone. 2Touch the Android™ image to begin setup. 3Touch a button to Create a Google account, Sign in with one you have, or Skip. You can log into your account from a computer at accounts.google.com. 4Enter details to create or sign into your account. When your phone confirms the account, it shows account sync options. •To change whether your phone shows the Google account’s contacts, Gmail™, and calendar, touch the Google account name. Power Key •To add another account, touch Add account. For details, see “Email” on page 14. •To exit setup touch Home. If your phone cannot connect, you can touch Menu > Wireless settings to change mobile network settings. sleep & wake up Your screen sleeps when you hold it to your ear during a call, or when it is inactive. To change the sleep delay, touch Menu > Settings > Display > Screen timeout. Silence Unlock Power/Sleep Key Press=sleep or wake up Hold=power 5Home screen & apps Keys Use your phone’s keys to navigate and open options at any time. Press the volume keys to change the ringer volume (in the home screen), or the earpiece volume (during a call). From any screen, press the camera key on the right side of the phone to open the camera. Touch Home to return to the home screen. Touch and hold Home to see your recent apps. Camera Key Volume Keys Home screen & apps a few essentials Use your home screen for quick access to apps, search, and more. Download social networking apps (like Facebook™ or Twitter) to keep in touch! Quick start: Home screen You’ll see the home screen when you turn on the phone or touch Home from a menu: 11:19 BrowserContactsMarketMaps Notifications Flick down for details. Status Indicators Shortcuts Open the app menu. Widgets Touch to open. Touch & hold to move or delete. Drag or flick to open panels (or scroll in lists). 6Home screen & apps •To open shortcuts or widgets, touch them. Touch Home to return to the home screen. When you open shortcuts or widgets, touch Menu for options. •To move or delete shortcuts or widgets, touch and hold them until you feel a vibration, then drag it to another spot, another panel, or at the bottom. In lists like Contacts, touch and hold list items for options. •To add shortcuts, w…

Text truncated - open the document above for the full version.

10Calls Conference calls To start a conference call, call the first number. After they answer, touch Add call and call the next number. When the next number answers, touch Merge calls. To remove individual callers, touch Manage. Call waiting If you are on a call and a new call arrives: •With call waiting on, you can drag to the right to answer the new call and put the old call on hold. Then, touch Swap to switch between calls, or Merge calls to combine them. •With call waiting off, the new call goes straight to your voicemail. To turn on call waiting, touch Menu> Settings > Call settings > Additional settings > Call waiting. Call forwarding To forward calls, touch Menu > Settings > Call settings > Call forwarding. You can forward calls all the time, or only when your phone is busy, unanswered, or unreachable (not on the network) Restricted calls To restrict your phone so that it can only dial a few numbers, touch Menu> Settings > Call settings > Fixed Dialing Numbers . •To turn fixed dialing on, touchFDN activation. •To add or delete the allowed numbers, touch FDN list. Your phone number To show your phone number, touch Menu > Settings > About phone > Status > My phone number. Your caller ID To hide your number from the people you call, touch Menu> Settings > Call settings > Additional settings > Caller ID. Cool down In very limited circumstances, such as where your phone has been exposed to extreme heat, you may see “Cool Down” messages. To avoid possible damage to your battery and phone, you should follow these instructions until the phone is within its recommended temperature range. When your phone is in “Cool Down” mode, only emergency calls can be made. 11Contacts Emergency calls Note: Your service provider programs one or more emergency phone numbers that you can call under any circumstances, even when your phone is locked. Emergency numbers vary by country. Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues. 1Open the phone, then touch (if your phone is locked, touchEmergency Call). 2Enter the emergency number. 3To uc hCall to call the emergency number. Note: Your mobile device can use AGPS satellite signals to help emergency services find you (“Location Services (GPS & AGPS)” on page 35). Contacts contacts like you’ve never had before Keep each friend’s email, phone number, and even address all in your Contacts for quick access. Quick start: Contacts From the home screen, touch > Contacts. •To create a contact, touch > Contacts > Menu > New contact, choose where you want to store the Phone Displaying 20 contacts Contacts Favorites Call log A B C Arthur Baudo Barry Smyth Cheyenne Medina Christine Fanning Search New contact Accounts Import/Export More Display options Drag or flick to scroll. Switch to the dialer, recent calls, or favorites. Touch to search, create, and more. 12Contacts contact, then enter details (to close the display keyboard, touch Back). Contacts shows the contacts from your Google™ account, which you can open from any computer at contacts.google.com (or open your contacts within mail.google.com). To stop synchronizing with your account, touch > Contacts > Menu > Accounts, touch your Google account, then uncheck Sync Contacts. •To call, text, or email a contact, touch > Contacts, touch the contact, then touch (call), (text), or (email). •To edit or delete a contact, touch > Contacts, touch the contact, then touch Menu. Favorites For quick access to a favorite contact, open the contact, then touch the star next to their name. To show your favorites, touch and touch Favorites at the top. To add a shortcut to your favorites, touch and hold a blank spot on your home screen, then touch Folders > Starred contacts . You can also add a shortcut for an individual contact: Touch and hold a blank spot on your home screen, then choose Shortcuts > Contacts. Storage & transfer When you create a new contact, your phone asks if you want to store it in your Google™ account, phone memory, or SIM card. Contacts in all three places appear in your Contacts list, but if you change phones: •Contacts in your Google™ account can download when you log into your Google account on a new Android™ device. You can open these contacts from any computer at contacts.google.com. •Contacts on your SIM card can load to a new device when you insert your SIM card. •Contacts in your phone memory stay in your old phone, unless you export them. To import or export contacts between your phone memory and a SIM or memory card, touch > Contacts, then touch Menu > Import/Export. 13Messaging Messaging sometimes it’s best to text or email... Send and receive text with photos or other attachments, in quick text messages or full emails. Quick start: Text messaging From the home screen, touch > Messaging. Tip: To see more messages, flick or drag up. •To create a text message, touch > Messaging > New message. For options like attaching files, touch Menu. Messaging New message Compose new message 12254558787 14447772222 You had 1 missed call from 122545458787 ... 17 Aug Wanna catch something to eat tonight? How about ... 17 Aug 12223334545 Ha! Thanks. 16 Aug Settings Delete threads Search Compose Drag or flick to scroll. Touch to change settings and more. •To open text messages, touch > Messaging, then touch the sender’s name. When you see in the status bar at the top of your screen, flick down the status bar and touch the new message to open it. •To respond to a text message, just open it and enter your response in the text box at the bottom. •To forward, copy, and more, touch > Messaging, touch the sender’s name, then touch and hold the message. Attachments To send a file in a text message, touch > Messaging > New message, then touch Menu > Attach. When you open a message with an attachment, touch Download to download it. Touch the downloaded attachment to open it, then touch it again to save…

Text truncated - open the document above for the full version.

19Location •To f in d a n address, enter it in the search box at the top. The map moves to show the address. Tip: You can touch and hold a spot on the map to show the nearest address. •To find stores, restaurants, and other places near you, touch at the top. •To ge t directions, find an address on the map, touch it, then touch . •To save an address for later, touch it, then touch the star by its name to add it to your Starred Places. •For help, touch Menu > More > Help. Google Maps™ Navigation Google Maps Navigation is an Internet-connected GPS navigation system with voice guidance. To open navigation, touch > Navigation. Follow the prompts to speak or type your destination. For more, go to www.google.com/mobile/navigation. Google Latitude™ Google Latitude lets you see where your friends and family are on Google Maps™. Plan to meet up, check that they got home safely, or just stay in touch. Don’t worry, your location is not shared unless you agree to it. After you join Google Latitude, you can invite your friends to view your location, or accept their invitations. Touch > Maps and then: •To join Google Latitude, touch Menu > Join Latitude . Read the privacy policy and, if you agree with it, choose to continue. •To add friends, touch Menu > Latitude > Menu > Add friends. Touch Select from Contacts or Add via email address, then touch a contact and Add friends. Your friend will receive an email notice. •To remove friends, touch Menu > Latitude to show your friends list. Touch a name, then touch Remove. •To share your location when you receive a request, you can choose Accept and share back (show your location and see theirs), Accept, but hide my location (hide your location, but see theirs), or Don’t accept (hide both locations). •To hide your location, touch Menu > Latitude to show your friends list. Touch your contact name, then touch Menu > Settings > Do not detect your location. •To sign out, touch Menu > Latitude to show your friends list. Touch Menu > Settings > Sign out of Latitude . 20Photos & videos Photos & videos see it, capture it, share it! Capture photos and videos to send them to friends or save them for later. Quick start: Photos & videos From any screen, press the Camera Key on the right side of the phone to open the camera. •To t ak e a photo, open the camera, then press the Camera Key. •To record a video, open the camera, then touch the camcorder icon to switch to the camcorder. Press the Camera Key to start and stop recording. •To open photos and videos, touch > My Gallery, then touch a photo or video for options like Share. Open your last photo or video. Switch resolution & more. Store photo location. Set white balance for your lighting. Zoom. Choose front or back camera. Choose camera or camcorder. Capture. Tip: For the clearest photos and videos, clean the lens with a soft, dry cloth. View & share photos & videos From the home screen, touch > My gallery. Flick left and right to show folders. Touch a folder to show its photos or videos, then touch a thumbnail image to open, share, or delete it. Tip: From the viewfinder, you can touch the thumbnail in the top right to open your last photo or video. •To zoom in, touch the screen with two fingers and then drag them apart. To zoom out, drag your fingers together. •To send or post the photo or video, touchShare. To use a Bluetooth or cable connection, see “Bluetooth™, Wi-Fi, & cable connections” on page 24. •To delete the photo or video, touchDelete. •To set a photo as your wallpaper or a contact photo, touch More > Set as. •To crop or rotate a photo, touch More. 21Music •To play a video, touch . Tip: Turn the phone sideways for a widescreen view. YouTube™ The YouTube user-generated content website lets you share videos with YouTube users everywhere. You don’t need a YouTube account to browse and view videos. From the home screen, touch > YouTube. •To watch videos, touch a category like Top rated or touch Search to find a video. Touch a video to watch it. For more video categories, touch Menu > Categories. To watch a video in high quality, touch Menu > Settings > High quality video. •To share a video, touch it to open it, touch More at the top, choose Share, then choose how you want to share it. •To upload a video from your phone to your YouTube account, touch > YouTube > Menu > Upload. Touch the video, then touch Upload. To sign into your YouTube account, touch > YouTube > Menu > My account. Note: If you don’t have an account, touch the link to create one. For more, visit www.youtube.com . Music when music is what you need... Keep your music with you! Put music on your phone so you can listen and create playlists anytime. Quick start: Music From the home screen, touch > Music, then choose a song to play it: •To a dj us t volume, use the volume keys. Music Artist Album Title Song Title 0:263:27 11:19 Open Playlist Shuffle On/Off Repeat Off/All/Current Music Controls Total Song Time Progress Bar 22Music •When a song is playing, you touch Menu to add it to a playlist or use it as a ringtone. To edit, delete, or rename playlists, touch > Music touch the Playlists tab, then touch and hold the playlist name. •To hide the player and use other apps, touch Home. Your music keeps playing. To return to the player, flick down the status bar and touch. Tip: For quick music player controls, touch and hold an empty spot in your home screen, then choose Widget > Music. •To stop the player, touch. •Before a flight, turn off network and wireless connections so that you can keep listening to music: Press and hold Power > Airplane mode. Note: When you select airplane mode, all wireless services are disabled. You can then turn Wi-Fi and/or Bluetooth back on, if permitted by your airline. Other wireless voice and data services (such as calls and text messages) remain off in airplane mode. Emergency calls to your region's emergency number can still be made. You can use your phone’s 3.5mm OMTP headset jack to connect wired headphones, or go wire…

Text truncated - open the document above for the full version.

FCC IDs: IHDP56MC1 Motorola Mobility, Inc., 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33022, USA Pag e 13a - 1 19 July 2011 Authorization of Agent Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 RE: Grantee Code IHD . Authorization: I, John Lewczak, the FCC contact for Grantee Code “IHD,” hereby authorize the following company (agent) to act on behalf of Motorola Mobility, Inc. for the application specified below. This includes: • Form 731, Attestation Statement Exhibit, and Confidentiality Request Signatures. • Technical Contact. • Non-Technical Contact. • Test Firm Contact Information. The grant should still be mailed to the applicant of record for Grantee Code “IHD,” and any audit requests should also be directed to the applicant of record. Authorized Agent: Jones Tsai Sporton International, Inc. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Specific Application: FCC ID: IHDP56MC1 Contact Information: Please contact me by telephone at (954) 723-6272, or by e-mail ([email protected] ), if there are questions or additional information needed concerning this authorization Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd, Suite A Plantation, FL 33022

SCS-F18: Project and Product Certification Representative Authorization Letter Page 1 of 2 Rev 2.0 2206 Ringwood Avenue San Jose, CA 95131 Tel: 408-526-1188 Fax: 408-526-1088 Email: [email protected] Project and Product Certification Representative Authorization Letter Reason for Amendment (current / obsolete) Revision History Approved Date From To Initial Release (current) 1.0 1.0 August 2, 2011 SCS-F18: Project and Product Certification Representative Authorization Letter Page 2 of 2 Rev 2.0 Sporton International Inc. August 2, 2011 To: SIEMIC, INC. 2206 Ringwood Avenue, San Jose, CA 95131 USA Dear Sir/Madam, Re: Project and Product Certification Representative Authorization Letter We, _Sporton International Inc._hereby authorize SIEMIC, INC. to act as a Certification Body for certifying for the following project(s): Product description: Mobile Phone Model name: XT319 We affirm that between SIEMIC and __Sporton Internationl Inc.___, any difference in understanding, including test plan, measurement methods, applicable standards and relevant procedures and processes have been resolved prior to commencement of testing activities. Sincerely, Client’s signature: Client’s name / title: Jones Tsai / Director Contact information / address: No.52, HwaYa 1st Rd., Kwei-Shan Hsiang, Taoyuan Hsien 333, Taiwan, R.O.C.

1/1 Sporton International Inc. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Tel: 886-3-327-3456 ; Fax: 886-3-328-4978 Date: July 7, 2011 Federal Communications Commission Authorization and Evaluation Division RE : Certification Application FCC ID : IHDP56MC1 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days:  External Photos (file: XT319_ExtPho.pdf)  Internal Photos (file: XT319_IntPho.pdf)  Test Setup Photos (file: XT319_Tsup.pdf)  User Manual (file: XT319_UserMan.pdf) The application contains technical information, which Sporton International Inc. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Sincerely, Jones Tsai

Rev. 1/1/03 Sporton International Inc. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Tel: 886-3-327-3456 ; Fax: 886-3-328-4978 Date: July 7, 2011 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: IHDP56MC1 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (file: XT319_Schem.pdf) Block Diagram (file: XT319_BlkDia.pdf) Parts List (file: XT319_PartsLst.pdf) Operation Description (file: XT319_OpDes.pdf) Tune up Procedure (file: XT319_TunPro.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, ________________________ Jones Tsai

Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 1 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 1. External Photograph of EUT Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 2 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 720510 Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 3 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 List of Accessory: Specification of Accessory AC Adapter Brand Name Motorola Model Name SPN5440B Battery Brand Name Motorola Model Name BP6X(SNN5843A) Earphone Brand Name Motorola Model Name SJYN0759A USB Cable Brand Name Motorola Model Name SKN6378A LCD Panel Brand Name Wintek Model Name SLTWDF32X00 Camera Brand Name Chicony Model Name CBSA31220004090LH Remark: For accessories equipped with this EUT, please refer to the following photos. 2. Photograph of Accessory Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 4 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 720510 Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 5 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 6 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 7 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1

1 XT319 Label 2 XT319 Label Location

Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 8 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 3. Internal Photograph of EUT Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 9 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 720510 Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 10 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 WWAN Antenna Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 11 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 WLAN & Bluetooth Antenna Photographs of EUT Report No.: EP153127 Brand Name: MOTOROLA / Model Name: XT319 SPORTON INTERNATIONAL INC. Page Number : 12 of 12 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 GPS Antenna

SPORTON INTERNATIONAL INC. Page Number : 1 of 21 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 FCC Test Report Report No. : FC153127A FCC Test Report APPLICANT : Motorola Mobility, Inc. EQUIPMENT : Mobile Phone BRAND NAME : MOTOROLA MODEL NAME : XT319 GPPD Number : 3014 FCC ID : IHDP56MC1 STANDARD : FCC 47 CFR FCC Part 15 Subpart B CLASSIFICATION : Certification The product was received on May 31, 2011 and completely tested on Jun. 27, 2011. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures given in ANSI C63.4-2003 and shown the compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 21 TEL : 886-3-327-3456 Report Issued Date : Jun. 30, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDP56MC1 FCC Test Report Report No. : FC153127A TABLE OF CONTENTS REVISION HISTORY .......................................................................................................................................... 3 SUMMARY OF TEST RESULT ......................................................................................................................... 4 1. GENERAL DESCRIPTION .......................................................................................................................... 5 1.1. Applicant ............................................................................................................................................ 5 1.2. Manufacturer ..................................................................................................................................... 5 1.3. Feature of Equipment Under Test ..................................................................................................... 5 1.4. Test Site ............................................................................................................................................ 6 1.5. Applied Standards ............................................................................................................................. 6 1.6. Ancillary Equipment List .................................................................................................................... 6 2. TEST CONFIGURATION OF EQUIPMENT UNDER TEST ........................................................................ 7 2.1. Test Mode ......................................................................................................................................... 7 2.2. Connection Diagram of Test System ................................................................................................ 9 2.3. Test Software .................................................................................................................................. 10 3. TEST RESULT ........................................................................................................................................... 11 3.1. Test of AC Conducted Emission Measurement .............................................................................. 11 3.2. Test of Radiated Emission Measurement ..............................…
