IHDP6MC1SF500

Motorola Mobility LLC

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Oct 17, 2011
Application Purpose: Original Equipment
Date of Application: Oct 17, 2011
Equipment Note: SF500
Frequency Range: 2402.00000000 - 2480.00000000
Company: Motorola Mobility LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

MOTOROLA SF500 EN Phelps HeadsetGSGEN2 011 O ct 05 1EN Check it out here’s what you can do Your MOTOROLA SF500 headset gives you rich premium sound and integrated heart rate monitoring. Using innovative sensor technology, the SF500 provides audible readouts of your heart rate. Strong bass and crystal clear sound keep you moving to your favorite music. Go ahead, check it out: At a glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Connect & go. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Advanced . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Connect with Motorola . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Caution: Please read the important safety, regulatory and legal information at the back of this guide. 2At a glanceEN At a glance The important bits, quick and easy Note: See “Connect with Motorola” on page 7 to learn more about connecting Bluetooth devices and compatibility, as well as heart rate training. Note: Your battery is designed to last the life of your product. It should only be removed by a recycling facility. Any attempt to remove or replace your battery will damage your headset. Heart Rate Button Mic Multi- function Button Connect Fitness Device Heart Rate Status Light Clip Heart Rate Monitor Music and Calls Connect Phone Music Device Calls Music Phone Ear Tip Ear Loop 2 Replace ear gel 1 Choose ear gel style and size Best for premium sound use Best for ambient sound use 3 Wearing Place on ear (loop rotates for a good fit). Charging Red charging Green fully charged 3ENConnect & go Connect & go let’s get you connected Note: Motorola SF500 is a Bluetooth® Smart heart rate monitor. Wireless connection to a Bluetooth® Smart Ready device enables transmission of heart rate data. Check your phone or device manual for Bluetooth compatibility. Tip: Wireless connection is setup by the Bluetooth® Smart Ready device (no action is required on the SF500). 1 Status Light - Green Flash Press Heart Rate button to turn on. Wireless connection (optional).W 3 Voice prompt: “Welcome to the Motorola SF500. Calibrate heart rate sensor to get started.” 2 Press Heart Rate button to calibrate. Status Light - Yellow Flash Voice prompt: “Sensor calibration successful.” Status Light - Green Flash (Follow setup instructions by the Bluetooth® Smart Ready device.) 4BasicsEN Basics standard features, advanced quality Heart Rate Monitor Note: The heart rate monitor can be used at anytime. It does not require the headphones to be plugged in to a device. 1 Status Light - quick green flash Press Heart Rate button to turn on. 2 Press Heart Rate button to hear heart rate. Voice prompt: “(your heart rate)” 3 Status Light - Solid Green for 2 seconds. Press and hold Heart Rate button to turn off. 5ENBasics Music and Calls Note: Operation of the MFB button for calls and music may differ among devices. Press once to answer or end a call Calls Music Play/Pause one press Next track two presses Previous track three presses Fast forward two presses and hold Power song* one press and hold (*Motorola fitness devices only) 6AdvancedEN Advanced more clever stuff Status light An easy way to check your heart rate monitor. ReCalibrate Your SF500 automatically recalibrates every two months. To manually recalibrate, turn off and press and hold the Heart Rate button until you hear voice prompt instructions. status lightheadset three rapid green flashes turning on green flashheart rate monitor on with a wireless connection active yellow flashin calibrating mode or heart rate monitor on with no wireless connection active solid greenturning off quick red flashin a low battery state 7ENConnect with Motorola Connect with Motorola Get what you need: • Answers: User guides, online help and more at www.motorola.com/support . • Bluetooth: If you have questions or need assistance, contact us at 1-877-MOTOBLU, or visit www.motorola.com/bluetoothsupport or www.motorola com/bluetoothconnect . • Heart Rate Training; To learn more about heart rate training with your device, visit www.motoactv.com . • Accessories: Find more accessories at www.motorola.com/products . • Social: The latest news, tips & tricks, videos and so much more—join us on: YouTube™ www.youtube.com/motorola Facebook™ www.facebook.com/motorola Twitter www.twitter.com/motomobile 8 Safety, Regulatory & Legal Battery Use & Safety DON’Ts • Don’t let the product come in contact with liquids.* Liquids can get into the product’s circuits, leading to corrosion. • Don’t place your product near a heat source.* High temperatures can cause the battery to swell, leak, or malfunction. • Don’t dry a wet or damp product with an appliance or heat source, such as a hair dryer or microwave oven. DOs • Do avoid leaving your product in your car in high temperatures.* • Do avoid dropping the product.* Dropping your product, especially on a hard surface, can potentially cause damage.* • Do contact your retailer or Motorola if your product has been damaged by dropping, liquids or high temperatures. Warning: Never dispose of battery powered products in a fire because they may explode. Battery Charging Battery Charging Notes for charging your product’s battery: • During charging, keep your battery and charger near room temperature for efficient battery charging. •New batteries are not fully charged. •New batteries or batteries stored for a long time may take more time to charge. •Motorola batteries and charging systems have circuitry that protects the battery from damage from overcharging. Third Party Accessories Use of third party accessories, including but not limited to batteries, chargers, headsets, covers, cases, screen protectors and memory cards, …

Text truncated - open the document above for the full version.

Cover Letter(s)

VERIFICATION OF COMPLIANCE This Verification of Compliance is hereby issued to the below named company. The test results of this report relate only to the tested sample identified in this report. Technical Standard: FCC Part 15 Class B (DoC) IC ICES-003 Issue 4 General Information Applicant: Motorola Mobility Inc. 8000W.Sunrise Blvd;Suite A. Plantation,FL 33322 U.S.A. Product Description EUT Description: SF500 Model Number: SF500 Trade Name: MOTOROLA Laboratory Name: Compliance Certification Services Inc. ( Hsin-Chu Lab). NO. 989-1 Wen Shan Rd., Shang Shan Village, Qionglin Shiang Hsinchu County 30741, Taiwan, R.O.C Tel: +886-3-5921698 / Fax: +886-3-5921108 This device has been shown to be in compliance with and was tested in accordance with the measurement procedures specified in the Standards & Specifications listed above and as indicated in the measurement report number: T110916301-D Sb Lu / Sr. Engineer Date: October 17, 2011

Cover Letter(s)

FCC ID: IHDP6MC1 Motorola Mobility, Inc., 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33022, USA Pag e 13A - 1 15 September 2011 Power of Attorney RE: Power of Attorney. We, the undersigned Motorola Mobility, Inc. hereby authorize Cheng Uei Precision Industry Co., Ltd. (Foxlink) to act on our behalf in all matters relating to any and all processes required in obtaining FCC Part 15 approval for FCC ID: IHDP6MC1, and any communication required with the national authority. Any and all acts carried out by Cheng Uei Precision Industry Co., Ltd. Foxlink) on our behalf shall have the same effects as acts of our own, subject to this Power of Attorney. This Power of Attorney will be effective between 15 September 2011 and 31 December 2011, and will expire thereafter. If you have any questions regarding this authorization, please don’t hesitate to contact us. Sincerely yours, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd, Suite A Plantation, FL 33022 Phone: (954) 723-6272 FAX: (954) 337-2377 Mail: [email protected]

Cover Letter(s)

FCC ID: IHDP6MC1 Motorola Mobility, Inc., 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33022, USA Pag e 13B - 1 15 September 2011 Authorization of Agent Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 RE: Grantee Code IHD . Authorization: I, John Lewczak, the FCC contact for Grantee Code “IHD,” hereby authorize the following company (agent) to act on behalf of Motorola Mobility, Inc. for the application specified below. This includes: • Form 731, Attestation Statement Exhibit, and Confidentiality Request Signatures. • Technical Contact. • Non-Technical Contact. • Test Firm Contact Information. The grant should still be mailed to the applicant of record for Grantee Code “IHD,” and any audit requests should also be directed to the applicant of record. Authorized Agent: Mr.Eddy Wang Cheng Uei Precision Industry Co., Ltd.(Foxlink) No.18,Chung Shan Rd., Tu-Cheng City, Taipei Hsien, Taiwan 114 E-Mail: [email protected] Specific Application: FCC ID: IHDP6MC1 Contact Information: Please contact me by telephone at (954) 723-6272, or by e-mail ([email protected] ), if there are questions or additional information needed concerning this authorization Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd, Suite A Plantation, FL 33022

Cover Letter(s)

CHENG UEI PRECISION INDUSTRY CO.,LTD No.8 R&D Rd.,1, Science-Based Industrial Park, Hsinchu 300,Taiwan,R.O.C Federal Communications Commission 7435 Oakland Mills Road Columbia MD 21046 Date: Sep 22, 2011 Subject: Request for Confidentiality FCC ID: IHDP6MC1 To Whom It May Concern: Pursuant to the provisions of Sections 0.457 and 0.459 of the Commission’s rules (47 CFR §§ 0.457, 0.459), we are requesting the Commission to withhold the following attachments as confidential document from public disclosure indefinitely. Schematic Diagram Block Diagram Theory of Operation ANT specification Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In additional to above mentioned documents, pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices. We are requesting 180 days commission to grant short-term confidentiality request on the following attachments until 2012/03/18 External Photos Internal Photos User Manual Test setup photo It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Best Regards Sincerely yours, ___________________________ Name/Title: Eddy Wang / Quality Manager Company Name: CHENG UEI PRECISION INDUSTRY CO.,LTD(Foxlink) Address: No.18, Chung Shan Rd., Tu-Cheng City, Taipei Hsien, Taiwan TEL: 886-2-22699888 ext.27051 FAX: 886-2-22699816 Email: [email protected]

Cover Letter(s)

External Photos

Report No.：T110916301 Page 1 of 14 External Photo Report No.：T110916301 Page 2 of 14 Report No.：T110916301 Page 3 of 14 Report No.：T110916301 Page 4 of 14 USB Cable Photo Report No.：T110916301 Page 5 of 14

ID Label/Location Info

Report No.ΚT110916301 Page 3 of 14 !!

Internal Photos

Report No.ΚT110916301 Page 6 of 14 !! Internal Photo Report No.ΚT110916301 Page 7 of 14 !! Report No.ΚT110916301 Page 8 of 14 !! Report No.ΚT110916301 Page 9 of 14 !! Report No.ΚT110916301 Page 10 of 14 !! Report No.ΚT110916301 Page 11 of 14 !! Report No.ΚT110916301 Page 12 of 14 !! Report No.ΚT110916301 Page 13 of 14 !! Report No.ΚT110916301 Page 14 of 14 !!

Test Report

FCC IDIHDP6MC1 Report No.T110916301-RP1 Page 1 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. FCC 47 CFR PART 15 SUBPART C AND ANSI C63.4:2003 TEST REPORT For SF500 Model : SF500 Trade Name : MOTOROLA Issued for Motorola Mobility Inc. 8000W.Sunrise Blvd,Suite A. Plantation,FL 33322 U.S.A. Issued by Compliance Certification Services Inc. Hsinchu Lab. NO. 989-1 Wen Shan Rd., Shang Shan Village, Qionglin Shiang Hsinchu County 30741, Taiwan, R.O.C TEL: +886-3-5921698 FAX: +886-3-5921108 http://www.ccsrf.com E-Mail : [email protected] Issued Date: October 07, 2011 Note: This report shall not be reproduced except in full, without the written approval of Compliance Certification Services Inc. This document may be altered or revised by Compliance Certification Services Inc. personnel only, and shall be noted in the revision section of the document. The client should not use it to claim product endorsement by TAF or any government agencies. The test results of this report relate only to the tested sample identified in this report. FCC IDIHDP6MC1 Report No.T110916301-RP1 Page 2 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. Revision History Rev. Issue Date Revisions Effect Page Revised By 00 10/07/2011 Initial Issue All Page 27 Winnie Chen FCC IDIHDP6MC1 Report No.T110916301-RP1 Page 3 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. TABLE OF CONTENTS TITLE PAGE NO. 1. TEST REPORT CERTIFICATION ................................................................................ 4 2. EUT DESCRIPTION ..................................................................................................... 5 3. DESCRIPTION OF TEST MODES ............................................................................... 6 4. TEST METHODOLOGY ............................................................................................... 7 5. FACILITIES AND ACCREDITATION ........................................................................... 7 5.1 FACILITIES ............................................................................................................ 7 5.2 ACCREDITATIONS................................................................................................ 7 5.3 MEASUREMENT UNCERTAINTY ......................................................................... 8 6. SETUP OF EQUIPMENT UNDER TEST...................................................................... 9 7. FCC PART 15.249 REQUIREMENTS.......................................................................... 10 7.1 RADIATED EMISSION........................................................................................... 10-22 7.2 CONDUCTED EMISSION ...................................................................................... 23-25 APPENDIX SETUP PHOTOS .......................................................................................... 26-27 FCC IDIHDP6MC1 Report No.T110916301-RP1 Page 4 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 1. TEST REPORT CERTIFICATION Applicant Motorola Mobility Inc. Address 8000W.Sunrise Blvd,Suite A. Plantation,FL 33322 U.S.A. Equipment Under Test SF500 Model SF500 Trade Name MOTOROLA Tested Date September 16 ~ October 07, 2011 APPLICABLE STANDARD Standard Test Result FCC Part 15 Subpart C AND ANSI C63.4:2003 PASS WE HEREBY CERTIFY THAT: The above equipment has been tested by Compliance Certification Services Inc., and found compliance with the requirements set forth in the technical standards mentioned above. The results of testing in this report apply only to the product/system, which was tested. Other similar equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties. Approved by: Reviewed by: Rex Liao Jacky Chen Deputy Section Manager Deputy Section Manager FCC IDIHDP6MC1 Report No.T110916301-RP1 Page 5 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 2. EUT DESCRIPTION Product Name SF500 Model Number SF500 Identify Number T110916301 Received Date September 16, 2011 Frequency Range 2402MHz～2480MHz Transmit Power 93.33 dBμV/m Channel Spacing 2MHz Channel Number 40 Channels Transmit Data Rate GFSK (1Mbps) Type of Modulation Frequency Hopping Spread Spectrum Frequency Selection by software / firmware Transmitter Classification portable device Antenna Type IFA Antenna, Antenna Gain -0.54 dBi Power Source 3.7Vdc (Battery Powered) 5.0Vdc (From Notebook PC, Powered From Host Device) Signal Cable Shielded Micro USB Cable 0.15m × 1 I/O Port Micro USB port × 1 Remark : 1. The sample selected for test was engineering sample that approximated to production product and was provided by manufacturer. 2. For more details, please refer to the User’s manual of the EUT. 3. This submittal(s) (test report) is intended for FCC ID: IHDP6MC1 filing to comply with Section 15.207, 15.209 and 15.249 of the FCC Part 15, Subpart C Rules. FCC IDIHDP6MC1 Report No.T110916301-RP1 Page 6 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. 3. DESCRIPTION OF TEST MODES The EUT (SF500) had been tested under operating condition. Radiated Emission (Below 1 GHz) and Conducted Emission Test: 1. The following test modes were scanned during the preliminary test: No. Pre-Test Mode 1 TX Mode 2. After the preliminary scan, the following test mode was found to produce the highest emission level. Final Test Mode Radiated Emission TX Mode Emission Conducted Emission N/A Remark : Then, the above highest emission mode of the configuration of the EUT and cable was chosen for all final test items. Radia…

Text truncated - open the document above for the full version.

Test Setup Photos

FCC IDIHDP6MC1 Report No.T110916301-RP1 Page 26 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc. APPENDIX SETUP PHOTOS RADIATED EMISSION SETUP FCC IDIHDP6MC1 Report No.T110916301-RP1 Page 27 / 27 This report shall not be reproduced, except in full, without the written approval of Compliance Certification Services Inc.
