IHDT56EA1Portable Cellular / PCS GSM / EDGE Transceiver

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EA1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: 1 Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola V551 GSM wireless phone. 040488a Left Soft Key Perform function in lower left display. Volume Keys Camera Key Voice Key Headphone Connector Smart Key Power & End Key Turn phone on/off, end calls, exit menu system. Menu Key Send Key Make & answer calls. Browser Key Right Soft Key Perform function in lower right display. 5-Way Navigation Key Scroll to items. Accessory Connector 2 Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 www.motorola.com 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States for hearing impaired) 1-800-461-4575 (Canada) MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © Motorola, Inc., 2004. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The information contained in Motorola's user's guides is believed to be correct at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice. The contents of Motorola’s user's guides are provided “as is.” Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability, or contents of this guide. Caution: Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment. Manual Number: 6809486A96-0 3 Contents Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Installing the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Battery Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Charging the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Turning Your Phone On. . . . . . . . . . . . . . . . . . . . . . . . . . 11 Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . . 13 Highlight Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Taking and Sending a Photo. . . . . . . . . . . . . . . . . . . . . . 14 Recording Video Clips . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Sending a Multimedia Message . . . . . . . . . . . . . . . . . . . 18 Receiving a Multimedia Message . . . . . . . . . . . . . . . . . . 20 Using the Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Learning to Use Your Phone. . . . . . . . . . . . . . . . . . . . . . 24 Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Using the 5-Way Navigation Key. . . . . . . . . . . . . . . . . . . 28 Using Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Using the Smart Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 Using the External Display . . . . . . . . . . . . . . . . . . . . . . . 42 Using the Handsfree Speaker. . . . . . . . . . . . . . . . . . . . . 43 Changing a Code, PIN, or Password . . . . . . . . . . . . . . . 43 Locking and Unlocking Your Phone . . . . . . . . . . . . . . . . 44 If You Forget a Code, PIN, or Password . . . . . . . . . . . . . 45 4 Setting Up Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . 47 Storing Your Name and Phone Number . . . . . . . . . . . . 47 Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . 47 Setting a Ring Style. . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Setting Answer Options. . . . . . . . . . . . . . . . . . . . . . . . . 48 Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . 49 Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . 50 Setting Display Skin . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Setting Display Brightness . . . . . . . . . . . . . . . . . . . . . . 51 Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . 51 Setting Display Timeout . . . . . . . . . . . . . . . . . . . . . . . . 51 Conserving Battery Power . . . . . . . . . . . . . . . . . . . . . . 51 Calling Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . 53 Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Using Automatic Redial . . . . . . . . . . . . . . . . . . . . . . . . . 54 Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . 55 Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . 55 Calling an Emergency Number . . . . . . . . . . . . . . . . . . . 55 Dialing International Numbers. . . . . . . . . . . . . . . . . . . . 56 Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . 58 Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Attaching a Number . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

APPLICANT MOTOROLA INC. FCC ID: IHDT56EA1 SPECIFICATION COMPLIANCE STATEMENT The transceiver type IHDT56EA1 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were at Motorola Inc. Libertyville, Illinois NAME: Jack Gleeson TITLE: Section Manager San2rini Development Signed: (Signed) Date: Aug 16, 2004 EXHIBIT 2A APPLICANT MOTOROLA INC. FCC ID: IHDT56EA1 STATEMENT OF CERTIFICATION The technical data supplied with this application, was taken under my supervision is hereby duly certified. I also certify that this transmit equipment (FCC ID: IHDT56EA1) compliance with all applicable parts of the FCC Rules. The following is a statement of my qualifications: NAME: Gene Santana TITLE: Senior Engineer San2rini Development Signed: (Signed) Date: August 14, 2004 I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. NAME: Rob Siomkos TITLE: Lead Engineer San2rini Development Signed: (Signed) Date: August 14, 2004 EXHIBIT 2B

APPLICANT: MOTOROLA FCC ID: IHDT56EA1 August 12, 2004 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56EA1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in 850 and 1900 MHz bands. The unit also contains a 2.4 GHz Bluetooth transmitter (Part 15.247). Note: This device contains 900 MHz and 1800 MHz GSM, functions which are not operational in U.S. territories. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Personal Communications Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EA1 EXHIBIT 3 Front View Rear View with Battery Cover Removed Showing ID Label

APPLICANT: MOTOROLA INC. FCC ID: IHDT56EA1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT56EA1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6EA1 EXHIBIT 9 Main Board (shields on) Main Board (shields off) Main Board Front View

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EA1 E E x x h h i i b b i i t t 1 1 1 1 Exhibit 11: SAR Test Report IHDT56EA1 Date of test: Date of Report: 6 & 10 August, 2004 25 August, 2004 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Steven Hauswirth Principal Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE P1528 (DRAFT) FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT56EA1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2004 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EA1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION...................................................................................................................................... 3 2. DESCRIPTION OF THE DEVICE UNDER TEST.................................................................................... 3 2.1 Antenna description ..............................................................................................................................................3 2.2 Device description..................................................................................................................................................3 3. TEST EQUIPMENT USED........................................................................................................................ 3 3.1 Dosimetric System .................................................................................................................................................3 3.2 Additional Equipment...........................................................................................................................................4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID............................................. 4 5. SYSTEM ACCURACY VERIFICATION.................................................................................................. 5 6. TEST RESULTS........................................................................................................................................ 5 6.1 Head Adjacent Test Results..................................................................................................................................6 6.2 Body Worn Test Results .......................................................................................................................................7 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION.... 10 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR PHANTOM HEAD ADJACENT USE....................... 11 APPENDIX 3: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION........................... 14 APPENDIX 4: PROBE CALIBRATION CERTIFICATE.......................................................................... 16 APPENDIX 5: DIPOLE CHARACTERIZATION CERTIFICATE............................................................ 17 APPENDIX 6: MEASUREMENT UNCERTAINTY BUDGET................................................................... 18 APPENDIX 7: PHOTOGRAPHS OF DEVICE UNDER TEST ................................................................... 21 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EA1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1 Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT56EA1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2 Description of the Device Under Test 2.1 Antenna description Type External Location Upper Right Corner Length 22mm Dimensions Width 10mm Configuration Helix 2.2 Device description FCC ID Number IHDT56EA1 Serial number 4400007583659 Mode(s) of Operation GSM 850 GSM 900 GSM 1800 GSM 1900 GPRS 850 GPRS 900 GPRS 1800 GPRS 1900 EDGE 850 EDGE 900 EDGE 1800 EDGE 1900 Blue Tooth Modulation Mode(s) GSM GSM GSM GSM GSM GSM GSM GSM EDGE EDGE EDGE EDGE Blue Tooth Maximum Output Power Setting 32.50 dBm 32.50 dBm 29.70 dBm 29.70 dBm 32.50 dBm 32.50 dBm 29.70 dBm 29.70 dBm 28.00 dBm 28.00 dBm 27.00 dBm 27.00 dBm 4.00 dBm Duty Cycle 1:8 1:8 1:8 1:8 2:8 2:8 2:8 2:8 1:8 1:8 1:8 1:8 1:1 Transmitting Frequency Rang(s) 824.2- 848.8 MHz 880.2- 914.8 MHz 1710.2- 1784.8 MHz 1850.20 – 1909.80 MHz 824.…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT56EA1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 14836-1 Report Date – September 19, 2004 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature Name: _Michael E. Hill Title: Senior Electrical Engineer Date: September 19, 2004_ This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. EXHIBIT 6 A2LA Certificate Number: 1846-01 APPLICANT: MOTOROLA INC FCC ID: IHDT56EA1 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configurations 5 Measuring Equipment and Calibration Information 5 Measurement Procedures and Data RF Power Output 6 Radiated Power (ERP) 7 Occupied Bandwidth 8 GSM 850 Reference Level Plot 9 GSM 850 Occupied Bandwidth Plot 9 GSM 850 Ch128 Lower Band Edge 10 GSM 850 Ch251 Upper Band Edge 10 GSM 1900 Occupied Band Plot 11 GSM 1900 Reference Plot 11 GSM 1900 Ch512 Lower Band Edge 12 GSM 1900 Ch810 Upper Band Edge 12 Spurious Emissions at Antenna Terminals 13 GSM 850 Tabular and Graphical Data 14 GSM 1900 Tabular and Graphical Data 15 Field Strength of Spurious Emissions 16 GSM 850 Tabular and Graphical Data 17 GSM 1900 Tabular and Graphical Data 18 Frequency Stability 19 GSM 850 Tabular and Graphical Data 20 GSM 1900 Tabular and Graphical Data 21 Field Strength of Spurious Emissions from Unintentional Radiators 22 GSM 850 Tabular and Graphical Data 23 GSM 1900 Tabular and Graphical Data 24 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 25 Figure A.2 – Substitution Measurement 25 Test Report Number: 14836-1 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT56EA1 Test Report Details Tests Performed By: Motorola Personal Communications Sector Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (561) 739-2179 Fax (561) 739-2131 Motorola PCS FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908 Tests Requested By: Motorola Inc. Personal Communications Sector 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: GSM 850, GSM 1900, Bluetooth Model Number: V551 Version: SUG3936AA Serial Numbers: 004400007590431, 004400007590282, 004400005533896, 004400005533847, 0044000005533813 Testing Complete Date: September 16, 2004 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators X Part 22 Subpart H - Public Mobile Services X Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 137-A, TIA EIA 98-C, ANSI 63.4 2001, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-133 (PCS) Test Report Number: 14836-1 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT56EA1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Modulation Characteristics Pass 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass 8 Field Strength of Spurious Emissions Pass from Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Modulation Characteristics NA 4 Occupied Bandwidth See Plots 5 Spurious Emissions at Antenna Terminal 17.6 dB 6 Field Strength of Spurious Emissions 1.4dB 7 Frequency Stability 44.36 Hz 8 Field Strength of Spurious Emissions Below noise floor from Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Test Report Number: 14836-1 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT56EA1 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Measuring Equipment and Calibration Information ManufacturerEquipment TypeModel No.Serial NumberCal. Due Date Rohde & SchwarzReceiverESI26838786/0105/17/2005 Hewlett-PackardEMC Analyzer8593EM3536A0011810/2/2004 Hewlett-PackardEMC Analyzer7405US3944019111/13/2004 MiteqPreamplifier 0.1-26.5GHzNSP2650-NF-S9663501/8/2005 ETSDRG Horn Antenna31156222 9/29/2004 A.H. Systems Inc.DRG Horn AntennaSAS-2--/57136512/17/2004 ETSLog-Periodic Antenna314811883/5/2005 ETSBiconical Antenna3110B337011/14/2004 AttenuatorWeinschelAS-6667510/14/2004 AttenuatorWeinschelAS-6667711/4/2004 Rohde & SchwarzMobile Test SetCMD 80DE29008N/A Hewlett-PackardSignal Generator83623B3844A011956/20/2005 ThermotronEnvironmental ChamberS-4315801/5/2005 Hewlett-PackardPre-Amplifier8347A3307A0200111/4/2004 AgilentPower MeterEE4418BGB4020638812/5/2004 AgilentPower SensorE4412BUS3848632111/23/2004 Hewlett-PackardPre-Amplifier8447F2805A034195/19/2005 All equipment is on a one-year calibration cycle. Test Report Number: 14836-1 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT56EA1 Meas…

Text truncated - open the document above for the full version.
