IHDT56EG1Portable Cellular / PCS GSM Transceiver

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EG1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: START HERE > V170 GSM 1 D R A F T Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola C170 wireless phone. . Note: Your phone may not appear exactly like the phone shown above. However, all key locations, sequences, and functions remain the same. Power/End Key Press & hold to turn phone on & off. Press & release to end phone calls, exit menu system. Left Soft Key Perform functions identified by left display prompt. Antenna Navigation Key Scroll through lists, set volume. Send/Answer Key Make & answer calls. Press in idle screen to see recently dialed calls. Menu Key Open a menu when you see in the display. Power Connector Port Insert charger. Right Soft Key Perform functions identified by right display prompt. Ear Piece Lanyard Attachment 2 D R A F T Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada) www.motorola.com (United States) www.motorola.ca (Canada) MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © Motorola, Inc. 2004 Caution: Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment. The information contained in Motorola’s user’s guides is believed to be correct at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice. The contents of Motorola’s user’s guides are provided “as is.” Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability, or contents of this guide. Manual number:6809491A02-O 3 D R A F T Contents Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Changing Your SIM Card and Battery. . . . . . . . . . . . . . . 10 Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Charging Your Phone’s Battery. . . . . . . . . . . . . . . . . . . . 11 Turning Your Phone On and Off . . . . . . . . . . . . . . . . . . . 12 Learning to Use Your Phone. . . . . . . . . . . . . . . . . . . . . . 13 Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Making and Answering Calls . . . . . . . . . . . . . . . . . . . . . 13 Symbols on the Screen. . . . . . . . . . . . . . . . . . . . . . . . . . 14 Using the Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Folding Back the Phone . . . . . . . . . . . . . . . . . . . . . . . . . 19 Setting Up Your Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Setting the Time and Date. . . . . . . . . . . . . . . . . . . . . . . . . . 20 Changing Personal Greetings . . . . . . . . . . . . . . . . . . . . . . . 20 Choosing Alert and Ring Tones . . . . . . . . . . . . . . . . . . . 20 Setting Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Setting Contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Setting Display Scrolling . . . . . . . . . . . . . . . . . . . . . . . . . 21 Setting Main Menu Animation. . . . . . . . . . . . . . . . . . . . . 22 Setting Battery Save . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Resetting all Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Clearing All Information . . . . . . . . . . . . . . . . . . . . . . . . . 22 Setting Up Your Phone for Optional Handsfree Use . . . . 23 Calling Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Displaying Your Phone Number . . . . . . . . . . . . . . . . . . . 24 Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 4 D R A F T Using My Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Terminating an Incoming Call . . . . . . . . . . . . . . . . . . . . 26 Dialing an Emergency Number . . . . . . . . . . . . . . . . . . . 26 Dialing International Numbers. . . . . . . . . . . . . . . . . . . . 27 Inserting Special Characters into Dialing Sequences . . 27 Viewing the Received Calls, Dialed Calls, or Missed Calls List . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Returning a Missed Call . . . . . . . . . . . . . . . . . . . . . . . . 29 Entering Numbers in the Notepad. . . . . . . . . . . . . . . . . 30 Using Voicemail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 1-Touch Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Quick Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Forwarding a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Conference Calls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Barring a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Putting a Call on Hold . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Lock/ Unlock the Keypad. . . . . . . . . . . . . . . . . . . . . . . . 37 Messages and Chat . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39 Setting Up the Text Message Inbox. . . . . . . . . . . . . . . . 39 Sending Messages, Pictures, and Sounds . . . . . . . . . . 40 Viewing Message Status . . . . . . . . . . . . . . . . . . . . . . . . 42 Receiving an…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EG1 ATTESTATION STATEMENTS Transceiver type FCC ID: IHDT56EG1 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, located at 600 North U.S. Highway 45, Libertyville, IL. NAME: Chris Wronski TITLE: Senior Product Engineer MOTOROLA PERSONAL COMMUNICATIONS SECTOR Date: October 22, 2004 Page 1 of 2 EXHIBIT 2 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EG1 I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (FCC ID: IHDT56EG1) is in compliance with all applicable parts of the FCC Rules. NAME: Chris Wronski TITLE: Senior Product Engineer MOTOROLA PERSONAL COMMUNICATIONS SECTOR Date: October 22, 2004 Page 2 of 2 EXHIBIT 2

Date: November 4, 2004 Subject: Request for additional information regarding FCC ID: IHDT56EG1 (Portable Cellular/PCS GSM transceiver) Reference: Application Received: 10/04/2004 Correspondence Reference Number: 241103A.IHD Confirmation Number: TC4337 Date of Original Email: 11/03/2004 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois Questions and responses follow: 1. Does the EUT contain an embedded Bluetooth transmitter? It is referenced on p.3 of the EMC report, but nowhere else. If it does, please submit the application for that device, as well as SAR data for the phone taken while the Bluetooth is active. Response: Page 3 of the EMC report is in error. The phone does not contain Bluetooth. 2. Page 6 of the EMC report lists the output power level for cellular operation on channel 251 as 32.03 dBm, while the SAR data lists the output power level for channel 251 as 32.75 dBm (p.7 of the SAR report). These values are more than 0.5 dB apart, which is not permitted for RF conducted measurements. It appears that the level listed in the EMC report may be a typo (it is much lower than the levels for the other 2 channels listed). Please address. Response: The conducted power level on page 6 of the EMC report is error. Please correct 32.03 dBm to 33.03 dBm. 3. The PCS right touch SAR data was taken on 9/1/04, however, there is no validation data for that date, nor do the tissue parameters match those values listed in the Table on p.4 of the SAR report. Please address. Response: Please refer to the supplemental SAR report submitted on November 4, 2004. 4. The User’s Manual does not contain a statement regarding the requirements for RFx compliance with respect to body-worn configurations. Please verify that this statement will be included prior to marketing. Response: Yes. The required compliance statements will be included in the separate booklet: IMPORTANT SAFETY AND LEGAL INFORMATION. 1

APPLICANT: MOTOROLA FCC ID: IHDT56EG1 October 4, 2004 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56EG1. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a dual band GSM portable transceiver, which operates in the 850 MHz and 1900 MHz PCS bands. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Personal Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EG1 EXHIBIT 3 Rear View with Battery Cover Removed Showing ID Label Rear View Front View Flip Open View

APPLICANT: MOTOROLA INC. FCC ID: IHDT56EG1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT56EG1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EG1 EXHIBIT 9A Main Board Front View Main Board Rear View Main Board Shield Removed APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EG1 EXHIBIT 9B Sub Board Rear View Sub Board Front View Sub Board Display Removed

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EG1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report IHDT56EG1 Date of test: Date of Report: 08/30/2004 to 08/31/2004 09/23/2004 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Albert Patapack Senior Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests: Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE P1528 (DRAFT) FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT56EG1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2004 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EG1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION........................................................................................................................................................................3 2. DESCRIPTION OF THE DEVICE UNDER TEST..................................................................................................................3 2.1 Antenna description.................................................................................................................................................................3 2.2 Device description.....................................................................................................................................................................3 3. TEST EQUIPMENT USED.........................................................................................................................................................3 3.1 Dosimetric System...................................................................................................................................................................3 3.2 Additional Equipment...............................................................................................................................................................4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID........................................................................4 5. SYSTEM ACCURACY VERIFICATION.................................................................................................................................5 6. TEST RESULTS..........................................................................................................................................................................5 6.1 Head Adjacent Test Results....................................................................................................................................................6 6.2 Body Worn Test Results.........................................................................................................................................................8 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION.........................9 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR PHANTOM HEAD ADJACENT USE............................................10 APPENDIX 3: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION...............................................13 APPENDIX 4: PROBE CALIBRATION CERTIFICATE......................................................................................................15 APPENDIX 5: DIPOLE CHARACTERIZATION CERTIFICATE.......................................................................................16 APPENDIX 6: MEASUREMENT UNCERTAINTY BUDGET................................................................................................17 APPENDIX 7: PHOTOGRAPHS OF DEVICE UNDER TEST...............................................................................................20 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EG1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1 Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT56EG1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2 Description of the Device Under Test 2.1 Antenna description Type External Location Upper Right Corner Length 25mm Dimensions Width 9mm Configuration Helix 2.2 Device description FCC ID Number IHDT56EG1 Serial number Phone1 and Phone2 Mode(s) of Operation GSM 850 GSM 1900 Modulation Mode(s) GSM GSM Target Value fo…

Text truncated - open the document above for the full version.

IHDT56EG1 Exhibit 11 Supplement Response Page 1 of 3 November 04, 2004 Supplement to SAR Test Report for Motorola portable cellular phone (FCC ID IHDT56EG1) Prepared by: Albert Patapack Motorola Personal Communications Sector Product Safety Laboratory Libertyville, Illinois IHDT56EG1 Exhibit 11 Supplement Response Page 2 of 3 Summary of FCC request for additional information There was a request for additional information regarding Motorola’s SAR Test Report for Motorola portable cellular phone (FCC ID IHDT56EG1) . The requested information is addressed below in the same numbering sequence received. 3. The PCS right touch SAR data was taken on 9/1/04, however, there is no validation data for that date, nor do the tissue parameters match those values listed in the Table on p.4 of the SAR report. Please address. Response : The tissue parameter data and the validation data were not entered into the appropriate tables. Attached here are the corrected tables. The validation scans are attached below in the Supplement to Appendix 1. 4 Electrical parameters of the tissue simulating liquid Dielectric Parameters f (MHz) Tissue type Limits / Measured ε r σ (S/m) Temp (°C) Measured, 08/30/2004 41.6 0.91 20.3 Head Recommended Limits 41.5 ±5% 0.90 ±5% 18-25 Measured, 08/30/2004 55.1 0.97 20.3 835 Body Recommended Limits 55.2 ±5% 0.97 ±5% 18-25 Measured, 08/31/2004 39.8 1.47 20.3 Measured, 09/01/2004 39.5 1.47 20.5 Head Recommended Limits 40.0 ±5% 1.40 ±5% 18-25 Measured, 08/31/2004 53.0 1.58 20.2 1880 Body Recommended Limits 53.3 ±5% 1.52 ±5% 18-25 5 System Accuracy Verification f Dielectric Parameters (MHz) Description SAR (W/kg), 1gram ε r σ (S/m) Ambient Temp (°C) Tissue Temp (°C) Measured, 08/30/2004 11.5 40.8 0.97 19.0 20.6 900 Recommended Limits 11.4 41.5 ±5% 0.97 ±5% 18-25 18-25 Measured, 08/31/2004 39.4 40.1 1.38 21.0 20.4 Measured, 09/01/2004 38.96 39.9 1.38 21.0 20.4 1800 Recommended Limits 40.7 40.0 ±5% 1.4 ±5% 18-25 18-25 IHDT56EG1 Exhibit 11 Supplement Response Page 3 of 3 Supplement to Appendix 1 of the Original Report SAR distribution comparison for the system accuracy verification Dipole 1800 MHz1800 MHz System Performance Check / Dipole Sn# 276trPM1 Power = 201mW Sim.Temp@meas=20.66°C Sim.Temp@SPC = 20.4°C Room Temp @ SPC = 21°CR8 Glycol TP-1138 SAM Expanded (Rev. 2)-9Jan03 Phantom; Flat Section; Pos ition: (90°,90°); Frequency: 1800 MHz Probe: ET3DV6R - SN1501 - Validation4; ConvF(4.79,4.79,4.79); Crest factor: 1.0; 1800 MHz VALIDATION: σ = 1.38 mho/m ε r = 39.9 ρ = 1.00 g/cm 3 Cubes (2): SAR (1g): 7.83 mW/g ± 0.04 dB, SAR (10g): 4.14 mW/g ± 0.04 dB, (Worst-case extrapolation)Coarse: Dx = 15.0, Dy = 15.0, Dz = 10.0Penetration depth: 8.4 (8.1, 9.1) [mm]Powerdrift: 0.06 dB SAR Tot [mW/g] 4.77E-19.54E-11.43E+01.91E+02.39E+02.86E+03.34E+03.82E+04.29E+04.77E+05.25E+05.72E+06.20E+06.68E+0 09/01/04Motorola, Inc. Dipole 1800 MHz1800 MHz System Performance Check / Dipole Sn# 276trPM1 Power = 201mW Sim.Temp@meas=20.66°C Sim.Temp@SPC = 20.4°C Room Temp @ SPC = 21°CR8 Glycol TP-1138 SAM Expanded (R ev. 2)-9Jan03 Phantom; Section; Position: ; Frequency: 1800 MHz Probe: ET3DV6R - SN1501 - Validation4; ConvF(4.79,4.79,4.79); Crest factor: 1.0; 1800 MHz VALIDATION: σ = 1.38 mho/m ε r = 39.9 ρ = 1.00 g/cm 3 : , ()Z-Axis: Dx = 0.0, Dy = 0.0, Dz = 5.0Penetration depth: 8.3 (8.0, 9.1) [mm]09/01/04Motorola, Inc. -2 02468 10121416 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150 SAR tot [mW/g] [mm]

APPLICANT: MOTOROLA INC FCC ID: IHDT56EG1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 14876-1 Report Date – October 6, 2004 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature Name: _Michael E. Hill Title: Senior Electrical Engineer Date: October 6, 2004_ This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1846-01 EXHIBIT 6 APPLICANT: MOTOROLA INC FCC ID: IHDT56EG1 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configurations 5 Measuring Equipment and Calibration Information 5 Measurement Procedures and Data RF Power Output 6 Radiated Power (ERP) 7 Occupied Bandwidth 8 GSM 850 Reference Level Plot 9 GSM 850 Occupied Bandwidth Plot 9 GSM 850 Ch128 Lower Band Edge 10 GSM 850 Ch251 Upper Band Edge 10 GSM 1900 Occupied Band Plot 11 GSM 1900 Reference Plot 11 GSM 1900 Ch512 Lower Band Edge 12 GSM 1900 Ch810 Upper Band Edge 12 Spurious Emissions at Antenna Terminals 13 GSM 850 Tabular and Graphical Data 14 GSM 1900 Tabular and Graphical Data 15 Field Strength of Spurious Emissions 16 GSM 850 Tabular and Graphical Data 17 GSM 1900 Tabular and Graphical Data 18 Frequency Stability 19 GSM 850 Tabular and Graphical Data 20 GSM 1900 Tabular and Graphical Data 21 Field Strength of Spurious Emissions from Unintentional Radiators 22 GSM 850 Tabular and Graphical Data 23 GSM 1900 Tabular and Graphical Data 24 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 25 Figure A.2 – Substitution Measurement 25 Test Report Number: 14876-1 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT56EG1 Test Report Details Tests Performed By: Motorola Personal Communications Sector Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (561) 739-2179 Fax (561) 739-2131 Motorola PCS FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908 Tests Requested By: Motorola Inc. Personal Communications Sector 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: GSM 850, GSM 1900, Bluetooth Model Number: V171 Version: SJUG0502AA Serial Numbers: 500134280122371, 001005000614261, 001005000613982 Testing Complete Date: September 28, 2004 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators X Part 22 Subpart H - Public Mobile Services X Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 137-A, TIA EIA 98-C, ANSI 63.4 2001, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-133 (PCS) Test Report Number: 14876-1 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT56EG1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Modulation Characteristics Pass 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass 8 Field Strength of Spurious Emissions Pass from Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Modulation Characteristics NA 4 Occupied Bandwidth See Plots 5 Spurious Emissions at Antenna Terminal 19.7 dB 6 Field Strength of Spurious Emissions 3.3dB 7 Frequency Stability 48.00 Hz 8 Field Strength of Spurious Emissions Below noise floor from Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Test Report Number: 14876-1 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT56EG1 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Measuring Equipment and Calibration Information ManufacturerEquipment TypeModel No.Serial NumberCal. Due Date Rohde & SchwarzReceiverESI26838786/0105/17/2005 Hewlett-PackardEMC Analyzer8593EM3536A0011810/2/2004 Hewlett-PackardEMC Analyzer7405US3944019111/13/2004 MiteqPreamplifier 0.1-26.5GHzNSP2650-NF-S9663501/8/2005 ETSDRG Horn Antenna31156222 9/29/2004 A.H. Systems Inc.DRG Horn AntennaSAS-2--/57136512/17/2004 ETSLog-Periodic Antenna314811883/5/2005 ETSBiconical Antenna3110B337011/14/2004 AttenuatorWeinschelAS-6667510/14/2004 AttenuatorWeinschelAS-6667711/4/2004 Rohde & SchwarzMobile Test SetCMD 80DE29008N/A Hewlett-PackardSignal Generator83623B3844A011956/20/2005 ThermotronEnvironmental ChamberS-4315801/5/2005 Hewlett-PackardPre-Amplifier8347A3307A0200111/4/2004 AgilentPower MeterEE4418BGB4020638812/5/2004 AgilentPower SensorE4412BUS3848632111/23/2004 Hewlett-PackardPre-Amplifier8447F2805A034195/19/2005 All equipment is on a one-year calibration cycle. Test Report Number: 14876-1 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT56EG1 Measurement Procedures and Data RF POWER OUT…
