IHDT56EQ1Portable Cellular / PCS GSM Transceiver

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EQ1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: 1 Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola C650 GSM wireless phone. 032338a Headset Jack Left Soft Key Perform function in lower left display. Power & End Key Turn phone on/off, end calls, exit menu system. Menu Key Right Soft Key Perform function in lower right display. Send Key Make & answer calls. 5-Way Navigation Key Scroll through menus & lists. Power Connector Accessory Connector 2 Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada) www.motorola.com (United States) www.motorola.ca (Canada) MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. All other product or service names are the property of their respective owners. © Motorola, Inc., 2003. Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse- engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non- exclusive, royalty-free license to use that arises by operation of law in the sale of a product. Manual Number: UGXXXX Cover Number: UGCGXXXX 3 Contents Safety and General Information. . . . . . . . . . . . . . . . . . . . 6 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Installing the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . 13 Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Installing a Lanyard . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . 17 Adjusting Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . 18 Highlight Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Taking and Sending a Photo . . . . . . . . . . . . . . . . . . . . . 20 Sending a Multimedia Message . . . . . . . . . . . . . . . . . . 22 Receiving a Multimedia Message . . . . . . . . . . . . . . . . . 24 Playing Video Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Using Event Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Using Ring Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Learning to Use Your Phone . . . . . . . . . . . . . . . . . . . . . 28 Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Using the 5-Way Navigation Key . . . . . . . . . . . . . . . . . . 33 Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36 Changing a Code, PIN, or Password. . . . . . . . . . . . . . . 46 Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 46 If You Forget a Code, PIN, or Password . . . . . . . . . . . . 48 4 Locking and Unlocking the Keypad . . . . . . . . . . . . . . . . . 48 Using the Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . 49 Setting Up Your Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Storing Your Name and Phone Number . . . . . . . . . . . . . 52 Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . . 52 Setting a Ring Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . . 53 Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . . 54 Setting Display Color . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Setting Display Timeout . . . . . . . . . . . . . . . . . . . . . . . . . 56 Calling Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . . 57 Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57 Using Automatic Redial. . . . . . . . . . . . . . . . . . . . . . . . . . 57 Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . . 59 Calling an Emergency Number . . . . . . . . . . . . . . . . . . . . 59 Dialing International Numbers . . . . . . . . . . . . . . . . . . . . 60 Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . 60 Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . . 62 Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 At…

Text truncated - open the document above for the full version.

APPLICANT MOTOROLA INC. FCC ID: IHDT56EQ1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type FCC ID: IHDT56EQ1 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at: Motorola Electronics Pte. Ltd., Ang Mo Kio Street 64, Ang Mo Kio Industrial Park 3, Singapore 569088. Motorola Personal Communications Sector Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 NAME: CHNG KAH JOO TITLE: ENGINEERING MANAGER, PERSONAL COMMUNICATIONS SECTOR Exhibit 2A APPLICANT MOTOROLA INC. FCC ID: IHDT56EQ1 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (FCC ID: IHDT56EQ1) is in compliance with all applicable parts of the FCC Rules. NAME: THAY CHOON TECK TITLE: PRINCIPAL STAFF ENGINEER Personal Communications Sector Date: 8 March 2004 Exhibit 2B

Date: March 25, 2004 Subject: Request for additional information regarding FCC ID: IHDT56EQ1 (Portable Cellular/PCS GSM transceiver) Reference: Application Received: 3/9/2004 Correspondence Reference Number: 240325A.IHD Confirmation Number: TC4080 Date of Original Email: 3/25/2004 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois Questions and responses follow: 1. What instrument settings (i.e., RBW, VBW, detector function) were used to make both spurious radiated and conducted emission measurements? Response: Please refer to the following table. Test Technology Band FCC Part RBW (MHz) VBW (MHz) Detector Trace Sweep Time Spurious Conducted Emissions GSM 850 22 0.1 Auto, ≥ RBW Peak Max Hold Auto - Cal Spurious Conducted Emissions GSM 1900 24 1 Auto, ≥ RBW Peak Max Hold Auto - Cal Spurious Radiated Emissions GSM 850 24 0.1 Auto, ≥ RBW Peak Max Hold Auto - Cal Spurious Radiated Emissions GSM 1900 24 1 Auto, ≥ RBW Peak Max Hold Auto - Cal Spurious Radiated Emissions GSM 850 15.109 0.12, 1 * Auto, ≥ RBW Peak, QP, Ave ** Max Hold Auto - Cal Spurious Radiated Emissions GSM 1900 15.109 0.12, 1 * Auto, ≥ RBW Peak, QP, Ave ** Max Hold Auto - Cal * Resolution BW adjusted based on emission frequency: -120 kHz RBW used for emissions from 30 MHz - 1 GHz -1 MHz RBW used for emission greater than 1GHz. ** The detector used was adjusted based on emission frequency (Prelim sweeps made with peak detector): -QP used for emissions from 30 MHz - 1 GHz -Average used for emission greater than 1GHz. 2. Please submit the SAR data plots. Response: Please refer to the supplemental SAR report submitted on 3/25/04. 1 3. There is a typo on p.6 of the SAR report: the 900 MHz validation test results taken 2/14/04 should be 11.32, per the data plot. Response: Please refer to the supplemental SAR report submitted on 3/25/04 2

APPLICANT: MOTOROLA FCC ID: IHDT56EQ1 March 10, 2004 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56EQ1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in both the 850 MHz and 1900 MHz PCS bands. Note: This device contains 900 MHz and 1800 MHz GSM functions that are not operational in U.S. territories. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Cellular Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EQ1 EXHIBIT 3A Rear View Front View APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EQ1 EXHIBIT 3B Rear View Rear View with Battery & Cover Removed To Show ID Label Location

APPLICANT: MOTOROLA INC. FCC ID: IHDT56EQ1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT56EQ1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC FCC ID: IHDT56EQ1 Rear View Rear View with Shields Removed Exhibit 9 APPLICANT: MOTOROLA, INC FCC ID: IHDT56EQ1 Front View (Keypad Mylar) Front View Exhibit 9 APPLICANT: MOTOROLA, INC FCC ID: IHDT56EQ1 Front Housing E NDO Level Rear Housing Exhibit 9 APPLICANT: MOTOROLA, INC FCC ID: IHDT56EQ1 ENDO Disassembled Exhibit 9 APPLICANT: MOTOROLA, INC FCC ID: IHDT56EQ1 Keypad LCD Display Metal Bezel Exhibit 9

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EQ1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report IHDT56EQ1 Date of test: Date of Report: 02/12/2004 to 02/24/2004 02/25/2004 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Albert Patapack Senior Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE P1528 (DRAFT) FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT56EQ1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2003 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EQ1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION......................................................................................................................................3 2. DESCRIPTION OF THE DEVICE UNDER TEST....................................................................................3 2.1 Antenna description................................................................................................................................................ 3 2.2 Device description ................................................................................................................................................. 3 3. TEST EQUIPMENT USED........................................................................................................................4 3.1 Dosimetric System................................................................................................................................................. 4 3.2 Additional Equipment .......................................................................................................................................... 4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID.............................................4 5. SYSTEM ACCURACY VERIFICATION..................................................................................................5 6. TEST RESULTS........................................................................................................................................6 6.1 Head Adjacent Test Results ................................................................................................................................. 7 6.2 Body Worn Test Results ....................................................................................................................................... 9 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION....11 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR PHANTOM HEAD ADJACENT USE........................12 APPENDIX 3: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION...........................17 APPENDIX 4: PROBE CALIBRATION CERTIFICATE...........................................................................20 APPENDIX 5: DIPOLE CHARACTERIZATION CERTIFICATE............................................................21 APPENDIX 6: MEASUREMENT UNCERTAINTY BUDGET...................................................................22 APPENDIX 7: PHOTOGRAPHS OF DEVICE UNDER TEST ....................................................................25 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56EQ1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1. Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT56EQ1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2. Description of the Device Under Test a. Antenna description Type Internal Antenna Location Back of Phone Length 25mm Dimensions Width 35mm b. Device description FCC ID Number IHDT56EQ1 Serial number S50U31224X, S50U31224Z, S50U31224F & S50U3124QF Mode(s) of Operation GSM 850 GSM 900 GSM 1800 GSM 1900 GPRS 850 GPRS 900 GPRS 1800 GPRS 1900 Modulation Mode(s) GSM GSM GSM GSM GSM GSM GSM GSM Maximum Output Power Setting 33.00 dBm 32.50 dBm 30.00 dBm 30.00 dBm 33.00 dBm 32.50 dBm 30.00 dBm 30.00 dBm Duty Cycle 1:08 1:08 1:08 1:08 2:08 2:08 2:08 2:08 Transmitting Frequency Rang(s) 824.2- 848.8 MHz 880.2- 914.8 MHz 1710.2- 1784.8 MHz 1850.2 – 1909.8 Mhz 824.2- 848.8 MHz 880.2- 914.8 MHz 1710.2- 1784.8 MHz 1850.2 – 1909.8 MHz Production Unit or Identical Prototype (47 CF…

Text truncated - open the document above for the full version.

March 25, 2004 Supplement to SAR Test Report for Motorola portable cellular phone (FCC ID IHDT56EQ1) Prepared by: Steven Hauswirth Motorola Personal Communications Sector Product Safety Laboratory Libertyville, Illinois Summary of FCC request for additional information There was a request for additional information regarding Motorola’s SAR Test Report for Motorola portable cellular phone (FCC ID IHDT56EQ1). The requested information is addressed below in the same numbering sequence received. 2. Please submit the SAR data plots. Response : Please see Appendix 1 for the SAR plots 3. There is a typo on p.6 of the SAR report: the 900 MHz validation test results taken 2/14/04 should be 11.32, per the data plot. Response : Please look at the below updated table. Dielectric Parameters f (MHz) Description SAR (W/kg), 1gram ε r σ (S/m) Ambient Temp (°C) Tissue Temp (°C) Measured, 02/12/04 11.31 42.0 0.99 20.0 19.7 Measured, 02/13/04 11.62 41.6 0.98 20.0 19.6 Measured, 02/14/04 11.32 41.6 0.98 20.0 19.5 Measured, 02/24/04 11.00 41.4 0.96 20.0 20.2 900 Recommended Limits 11.6 41.5 ±5% 0.97 ±5% 18-25 18-25 Measured, 02/14/04 40.45 38.9 1.36 20.0 19.2 Measured, 02/15/04 40.00 38.8 1.37 20.0 18.9 Measured, 02/24/04 40.80 39.7 1.36 20.0 19.5 1800 Recommended Limits 39.7 40.0 ±5% 1.4 ±5% 18-25 18-25 Appendix 1 Requested SAR plots S50U31224ZCh# 190 / Pwr Step: 5 Antenna Position: Internal Type of Modulation: GSM Battery Model #: AANN4285A DEVICE POSITION (cheek or rotated): Cheek Accessory Model #: R# 2 TP-1106 SUGAR SAM Expanded (Rev. 2)-9Jan03 Phantom; Left Hand Section; Position: ( 90°,180°); Frequency: 836 MHz Probe: ET3DV6 - SN1522 - IEEE Head; ConvF(4.70,4.70,4. 70); Crest factor: 8.0; 835 MHz Head & Body: σ = 0.93 mho/m ε r = 42.9 ρ = 1.00 g/cm 3 Cube 7x7x7: SAR (1g): 1.11 mW/g, SAR (10g): 0.754 mW/g, (Worst-case extrapolation)Coarse: Dx = 15.0, Dy = 15.0, Dz = 15.0Penetration depth: 14.9 (14.2, 15.7) [mm]Powerdrift: -0.04 dB SAR Tot [mW/g] 5.62E-21.69E-12.81E-13.93E-15.06E-16.18E-17.31E-18.43E-19.55E-11.07E+0 02/12/04Motorola, Inc. S50U31224ZCh# 190 / Pwr Step: 5 Antenna Position: Internal Type of Modulation: GSM Battery Model #: AANN4285A DEVICE POSITION (cheek or rotated): CHEEK Accessory Model #: R# 2 TP-1106 SUGAR SAM Expanded (Rev. 2 )-9Jan03 Phantom; Right Hand Section; Po sition: (90°,180°); Frequency: 836 MHz Probe: ET3DV6 - SN1522 - IEEE Head; ConvF(4.70,4.70,4. 70); Crest factor: 8.0; 835 MHz Head & Body: σ = 0.93 mho/m ε r = 42.9 ρ = 1.00 g/cm 3 Cube 7x7x7: SAR (1g): 1.15 mW/g, SAR (10g): 0.770 mW/g, (Worst-case extrapolation)Coarse: Dx = 15.0, Dy = 15.0, Dz = 15.0Penetration depth: 14.2 (13.3, 15.1) [mm]Powerdrift: -0.20 dB SAR Tot [mW/g] 3.28E-29.83E-21.64E-12.29E-12.95E-13.60E-14.26E-14.91E-15.57E-16.23E-16.88E-17.54E-18.19E-18.85E-19.50E-11.02E+01.08E+0 02/12/04Motorola, Inc. S50U31224ZCh# 190 / Pwr Step: 5 Antenna Position: Internal Type of Modulation: GSM Battery Model #: AANN4285A DEVICE POSITION (cheek or rotated): ROTATED Accessory Model #: R# 2 TP-1106 SUGAR SAM Expanded (Rev. 2)-9Jan03 Phantom; Left Hand Section; Position: ( 90°,180°); Frequency: 848 MHz Probe: ET3DV6 - SN1522 - IEEE Head; ConvF(4.70,4.70,4. 70); Crest factor: 8.0; 835 MHz Head & Body: σ = 0.93 mho/m ε r = 42.9 ρ = 1.00 g/cm 3 Cube 7x7x7: SAR (1g): 0.650 mW/g, SAR (10g): 0.447 mW/g, (Worst-case extrapolation)Coarse: Dx = 15.0, Dy = 15.0, Dz = 15.0Penetration depth: 15.0 (14.2, 15.8) [mm]Powerdrift: -0.01 dB SAR Tot [mW/g] 3.22E-29.66E-21.61E-12.25E-12.90E-13.54E-14.19E-14.83E-15.47E-16.12E-1 02/12/04Motorola, Inc. S50U31224ZCh# 190 / Pwr Step: 5 Antenna Position: Internal Type of Modulation: GSM Battery Model #: AANN4285A DEVICE POSITION (cheek or rotated): ROTATED Accessory Model #: R# 2 TP-1106 SUGAR SAM Expanded (Rev. 2 )-9Jan03 Phantom; Right Hand Section; Po sition: (90°,180°); Frequency: 848 MHz Probe: ET3DV6 - SN1522 - IEEE Head; ConvF(4.70,4.70,4. 70); Crest factor: 8.0; 835 MHz Head & Body: σ = 0.93 mho/m ε r = 42.9 ρ = 1.00 g/cm 3 Cube 7x7x7: SAR (1g): 0.756 mW/g, SAR (10g): 0.491 mW/g, (Worst-case extrapolation)Coarse: Dx = 15.0, Dy = 15.0, Dz = 15.0Penetration depth: 11.5 (10.8, 12.5) [mm]Powerdrift: -0.03 dB SAR Tot [mW/g] 3.82E-21.14E-11.91E-12.67E-13.43E-14.20E-14.96E-15.72E-16.49E-17.25E-1 02/12/04Motorola, Inc. S50U31224XCh# 661 / Pwr Step: 0 OTA Antenna Position: INTERNAL Type of Modulation: 1900 GSM Battery Model #: AAANN4285A DEVICE POSITION (cheek or rotated): CHEEK Accessory Model #: NONER# 2 TP-1235 GLYCOL SAM Expanded (Rev. 2)-9Jan03 Phantom; Le ft Hand Section; Position: ( 90°,180°); Frequency: 1880 MHz Probe: ET3DV6 - SN1522 - IEEE Head; ConvF(3.40,3.40,3. 40); Crest factor: 8.0; 1880 MHz Head & Body: σ = 1.45 mho/m ε r = 38.6 ρ = 1.00 g/cm 3 Cube 7x7x7: SAR (1g): 0.396 mW/g, SAR (10g): 0.210 mW/g, (Worst-case extrapolation)Coarse: Dx = 15.0, Dy = 15.0, Dz = 15.0Penetration depth: 7.8 (7.4, 8.6) [mm]Powerdrift: 0.13 dB SAR Tot [mW/g] 1.91E-25.71E-29.53E-21.33E-11.71E-12.10E-12.48E-12.86E-13.24E-13.62E-1 02/14/04Motorola, Inc. S50U31224XCh# 661 / Pwr Step: 0 OTA Antenna Position: INTERNAL Type of Modulation: 1900 GSM Battery Model #: AAANN4285A DEVICE POSITION (cheek or rotated): CHEEK Accessory Model #: NONER# 2 TP-1235 GLYCOL SAM Expanded (Rev. 2)-9Jan03 Phantom; Ri ght Hand Section; Position: ( 90°,180°); Frequency: 1880 MHz Probe: ET3DV6 - SN1522 - IEEE Head; ConvF(3.40,3.40,3. 40); Crest factor: 8.0; 1880 MHz Head & Body: σ = 1.45 mho/m ε r = 38.6 ρ = 1.00 g/cm 3 Cube 7x7x7: SAR (1g): 0.559 mW/g, SAR (10g): 0.279 mW/g, (Worst-case extrapolation)Coarse: Dx = 15.0, Dy = 15.0, Dz = 15.0Penetration depth: 8.3 (8.0, 8.9) [mm]Powerdrift: -0.10 dB SAR Tot [mW/g] 2.47E-27.41E-21.23E-11.73E-12.22E-12.72E-13.21E-13.71E-14.20E-14.69E-1 02/14/04Motorola, Inc. S50U31224XCh# 661 / Pwr Step: 0 OTA Antenna Position: INTERNAL Type of Modulation: 1900 GSM Battery Model #: AAANN4285A DEVICE POSITION (cheek or rotated): TILTED Accessory Model #: NONER# 2 TP-1235 GLYCOL SAM Expanded (Rev. 2)-9Jan03 …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT56EQ1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 13371-1 Report Date – March 3, 2004 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature Name: _Michael E. Hill Title: Senior Electrical Engineer Date : 2004-03-03____ This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1846-01 EXHIBIT 6 APPLICANT: MOTOROLA INC FCC ID: IHDT56EQ1 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configurations 5 Measuring Equipment and Calibration Information 5 Measurement Procedures and Data RF Power Output 6 Radiated Power (ERP) 7 Occupied Bandwidth 8 GSM 850 Reference Level Plot 9 GSM 850 Occupied Bandwidth Plot 9 GSM 850 Ch128 Lower Band Edge 10 GSM 850 Ch251 Upper Band Edge 10 GSM 1900 Occupied Band Plot 11 GSM 1900 Reference Plot 11 GSM 1900 Ch512 Lower Band Edge 12 GSM 1900 Ch810 Upper Band Edge 12 Spurious Emissions at Antenna Terminals 13 GSM 850 Tabular and Graphical Data 14 GSM 1900 Tabular and Graphical Data 15 Field Strength of Spurious Emissions 16 GSM 850 Tabular and Graphical Data 17 GSM 1900 Tabular and Graphical Data 18 Frequency Stability 19 GSM 850 Tabular and Graphical Data 20 GSM 1900 Tabular and Graphical Data 21 Field Strength of Spurious Emissions from Unintentional Radiators 22 GSM 850 Tabular and Graphical Data 23 GSM 1900 Tabular and Graphical Data 24 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 25 Figure A.2 – Substitution Measurement 25 Test Report Number: 13371-1 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT56EQ1 Test Report Details Tests Performed By: Motorola Personal Communications Sector Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (561) 739-2179 Fax (561) 739-2131 Motorola PCS FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908 Tests Requested By: Motorola Inc. Personal Communications Sector 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: GSM 850, GSM 1900 Model Number: C650 Version: AALG1021AA Serial Numbers: S50U31224Q, S50U31224H, S50U31224M Testing Complete Date: March 3, 2004 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators X Part 22 Subpart H - Public Mobile Services X Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 137-A, TIA EIA 98-C, ANSI 63.4 2001, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-133 (PCS) Test Report Number: 13371-1 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT56EQ1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Modulation Characteristics Pass 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass 8 Field Strength of Spurious Emissions Pass from Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Modulation Characteristics NA 4 Occupied Bandwidth See Plots 5 Spurious Emissions at Antenna Terminal 15.8dB 6 Field Strength of Spurious Emissions 3.6dB 7 Frequency Stability 62.18Hz 8 Field Strength of Spurious Emissions Below noise floor from Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Test Report Number: 13371-1 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT56EQ1 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Measuring Equipment and Calibration Information ETSDRG Horn Antenna31156222 A.H. Systems Inc.DRG Horn AntennaSAS-200/5712654/29/2004 ETSLog-Periodic Antenna314811894/29/2004 ETSBiconical Antenna3110B33694/29/2004 ETSBiconical Antenna3110B337011/14/2004 AttenuatorWeinschel AS-6667510/14/2004 AttenuatorWeinschel AS-6667711/4/2004 Rohde & SchwarzMobile Test SetCMD 80DE29008N/A Hewlett Packard Signal Generator 83623B 3844A01195 5/20/2004 ThermotronEnvironmental ChamberS-4315801/5/2005 Hewlett PackardPre-Amplifier8347A11/4/2004 Hewlett PackardPre-Amplifier8447F2805A034195/19/2004 AgilentPower MeterEE4418B12/5/2004 AgilentSensorE4412B11/23/2004 All equipment is on a one-year calibration cycle. Test Report Number: 13371-1 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT56EQ1 Measurement Procedures and Data RF POWER OUTPUT Measurement Procedure The RF output port of th…

Text truncated - open the document above for the full version.
