IHDT56FJ1Portable Dual Band GSM Transceiver with Bluetooth

MOTOMANUALMOTOMANUAL 1 HELLOMOTO Introducing your new Motorola V6 GSM wireless phone. Here’s a quick anatomy lesson. Left Soft Key Navigate menus.Open menus. Select menu items. Volume Keys Open browser Smart Key Voice Key Voice dial phone numbers, open applications, create voice records. Right Soft Key Turn on & off, hang up, exit menus. Make & answer calls. Send a message. 2 check it out! check it out! features voice dial phonebook entry Press and release voice key, wait for phone prompt, say “Name Dial” wait for prompt, speak the phonebook entry’s name. voice dial phone number Press and release voice key, wait for phone prompt, say “Digit Dial” wait for prompt, speak phone number digits. record video clip Press M>Multimedia >Videos >[New Video], point lens at subject, press the CAPTURE key to begin recording, press the STOP key to stop recording. play video clipPress M>Multimedia >Videos >video clip Battery Charge & Bluetooth® Indicator Light Accessory Connector Port Insert charger & phone accessories. Handsfree Speaker (on back of phone) Camera Lens External Display See incoming call information. 3 check it out! take photoPress M>Multimedia >Camera, point lens at subject, press the CAPTUREkey to take a photo. send photoSend a photo to a phone number or email address: Take photo, press the STOREkey, select Send In Message. set photo as picture ID Assign a photo to a phonebook entry to allow picture caller ID: Take photo, press the STOREkey, select Apply as Phonebook Entry. send multimedia message Send a multimedia message with pictures, animations, sounds, and video clips: R >Create Message >New Multimedia Msg receive multimedia message When your display shows New Message, press the READkey to read the message you received. Bluetooth® wireless Pair your phone with a Bluetooth headset, car kit, or computer: M>Bluetooth Link >Setup >Power >On, press the BACKkey, >Handsfree >[Look For Devices] features 4 Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 www.hellomoto.com 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States for hearing impaired) 1-800-461-4575 (Canada) Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider’s network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user’s guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation. MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. All other product or service names are the property of their respective owners. © Motorola, Inc., 2005. Caution: Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment. Manual Number: 68XXXXXX92-O 5 Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. 6 feature locator feature locator main menu nPhonebook sRecent Calls • Received Calls • Dialed Calls • Notepad •Call Times • Call Cost * •Data Times •Data Volumes eMessages • Create Message •Email Msgs • Message Inbox •Voicemail • Browser Msgs • Info Services * •Quick Notes • Outbox •Drafts •MMS Templates ÉTools • SIM Apps * • Calculator • Datebook • Shortcuts • Voice Records •Alarm Clock • Dialing Services • Fixed Dial • Service Dial * •Quick Dial •IM * • Log In •Offline Convs. • IM Account • Offline Settings •Help QGames & Apps áWeb Access •Browser • Web Shortcuts • Stored Pages •History •Go To URL •Browser Setup • Web Sessions hMultimedia • Themes • Camera. •Pictures • Sounds •Videos EBluetooth Link w Settings • (see next page) This is the standard main menu layout. Your phone’s menu may be a little different. * optional features 7 feature locator settings menu lPersonalize • Home Screen • Main Menu • Voice Dial Setup •Skin • Greeting • Wallpaper • Screen Saver •Quick Dial tRing Styles •Style •style Detail LConnection • Bluetooth Link •Sync H Call Forward •Voice Calls • Fax Calls • Data Calls • Cancel All • Forward Status UIn-Call Setup • Dialing Prefix * • In-Call Timer • Call Cost Setup * •My Caller ID • Talk and Fax • Answer Options • Call Waiting ZInitial Setup • Time and Date • 1-Touch Dial • Display Timeout • Backlight • TTY Setup * •Scroll • Language •Battery Save • Brightness • External Display •DTMF • Master Reset •Master Clear mPhone Status •My Tel. Numbers • Credit Info/Available * • Active Line * •Battery Meter • Software Update *…

Text truncated - open the document above for the full version.

APPLICANT MOTOROLA INC. FCC ID: IHDT56FJ1 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Tadd Scarpelli TITLE: ENGINEERING MANAGER Mobile Device Business Motorola, Inc. 8/26/05 EXHIBIT 2A

APPLICANT: MOTOROLA FCC ID: IHDT56FJ1 August 15, 2005 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Device Business, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56FJ1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in 850 and 1900 MHz bands. The unit also contains a 2.4 GHz Bluetooth transmitter (Part 15.247). Note: This device contains 900 MHz and 1800 MHz GSM, functions which are not operational in U.S. territories. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Device Business 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56FJ1 EXHIBIT 3A Front View Flip Opened Rear View Flip Opened APPLICANT: MOTOROLA, INC. FCC ID: IHDT56FJ1 EXHIBIT 3B Rear View with Battery Cover Removed Showing ID Label Rear View Front View

APPLICANT: MOTOROLA INC. FCC ID: IHDT56FJ1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT56FJ1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT:MOTOROLA,INC.FCCID:IHDT6FJ1 EXHIBIT9 FrontView RearView RearViewwithoutshields MAIN BOARD W/O SHIELDS MAIN BOARD APPLICANT: MOTOROLA FCC ID: IHDT56FJ1 EXHIBIT 9 PHONE DISASSEMBLED FLIP DISASSEMBLED FLIP BOARD

APPLICANT: MOTOROLA INC FCC ID: IHD56FJ1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT - Addendum Test Report Number – 16757-1BT Report Date – August 18, 2005 Revision 2 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature: Name: Mark Sidlow Title: Senior Electrical Engineer Date : 2005-26-08 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1651.01 EXHIBIT 6A APPLICANT: MOTOROLA INC FCC ID: IHDT56FJ1 Table of Contents Test Report Details............................................................................................................. 5 Applicable Standards.......................................................................................................... 6 Summary of Testing............................................................................................................ 7 General and Special Conditions.......................................................................................... 7 Equipment and Cable Configurations................................................................................. 8 Measuring Equipment and Calibration Information........................................................... 8 Description of Bluetooth Transmitter................................................................................. 9 Measurement Procedures and Data................................................................................... 10 CARRIER FREQUENCY SEPARATION.................................................................. 10 Measurement Procedure............................................................................................ 10 Measurement Results................................................................................................ 10 Carrier Frequency Separation............................................................................... 11 NUMBER OF HOPPING FREQUENCIES................................................................. 12 Measurement Procedure............................................................................................ 12 Measurement Results................................................................................................ 12 Number of Hopping Frequencies (Channels 0 – 39)............................................ 13 Number of Hopping Frequencies (Channels 39 – 78).......................................... 13 TIME OF OCCUPANCY (DWELL TIME)................................................................. 14 Measurement Procedure............................................................................................ 14 Measurement Results................................................................................................ 14 Dwell Time........................................................................................................... 15 20dB Bandwidth........................................................................................................... 16 Measurement Procedure............................................................................................ 16 Measurement Results................................................................................................ 16 FIELD STRENGTH OF SPURIOUS EMISSIONS..................................................... 18 Measurement Procedure............................................................................................ 18 Measurement Results................................................................................................ 18 30-1000MHz Low Channel Dual Polarization X................................................. 19 30-1000MHz Low Channel Dual Polarization Y................................................. 20 30-1000MHz Low Channel Dual Polarization Z.................................................. 21 30-1000MHz Mid Channel Dual Polarization X.................................................. 22 30 -1000MHz Mid Channel Dual Polarization Y................................................. 23 30 -1000MHz Mid Channel Dual Polarization Z................................................. 24 30 -1000MHz High Channel Dual Polarization X................................................ 25 30 -1000MHz High Channel Dual Polarization Y................................................ 26 30 -1000MHz High Channel Dual Polarization Z................................................ 27 1-25 GHz Low Channel Dual Polarization X....................................................... 28 1-25 GHz Low Channel Dual Polarization Y....................................................... 29 1-25 GHz Low Channel Dual Polarization Z....................................................... 30 1-25 GHz Mid Channel Dual Polarization X........................................................ 31 1-25 GHz Mid Channel Dual Polarization Y........................................................ 32 1-25 GHz Mid Channel Dual Polarization Z........................................................ 33 1-25 GHz High Channel Dual Polarization X...................................................... 34 1-25 GHz High Channel Dual Polarization Y...................................................... 35 1-25 GHz High Channel Dual Polarization Z....................................................... 36 Test Report Number: 16757-1 EXHIBIT 6A 2 APPLICANT: MOTOROLA INC FCC ID: IHDT56FJ1 Authorized Band Emissions Low Channel Dual Polarization X.................…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT56FJ1 Appendix A – Radiated Emissions Test Setup Photos A.1 Radiated Emissions Measurement A.2 Substitution Measurement End of Test Report Test Report Number: 16757-1 EXHIBIT 6 26
