IHDT56GK1Dual-Band GSM Portable Transceiver

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GK1 INSTRUCTION MANUAL • A preliminary draft copy of the User’s Manual follows this cover page. • The User’s Manual will have the following text added to it: "NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: . Reorient or relocate the receiving antenna. . Increase the separation between the equipment and receiver. . Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. . Consult the dealer or an experienced radio/TV technician for help." EXHIBIT 8 motorola.com W220 GSM 900/1800 1 HELLOMOTOIntroducing your new Motorola W220 GSM wireless phone. Here’s a quick anatomy lesson. Headset Jack Power Connector Insert charger. Navigation KeyPress S to scroll through menus and lists. Menu Key Opens a sub-menu when M appears on the display, or selects a highlighted feature. Right Soft KeyPerforms functions in lower right display. Left Soft Key Performs functions in lower left display. Send/Answer Key Make and answer calls. Press when idle to see the list of recently dialed calls. Power/End KeyTurns phone on/off, ends calls, exits menus. Volume Key Note: Your phone may not appear exactly as the phone image above. 2Motorola, Inc.Consumer Advocacy Office1307 East Algonquin RoadSchaumburg, IL 60196www.hellomoto.comCertain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider's network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user's guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation. MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. 2006 All other product or service names are the property of their respective owners. © Motorola, Inc. 2006.Manual Number: 68XXXXX149-O contents 3 contentsmenu map. . . . . . . . . . . . 5Use and Care . . . . . . . . . 7essentials . . . . . . . . . . . . 8 about this guide . . . . . . 8SIM card . . . . . . . . . . . . 9battery . . . . . . . . . . . . . 9battery tips . . . . . . . . . 10turn it on & off . . . . . . . 11make a call . . . . . . . . . 12answer a call. . . . . . . . 12adjust the volume. . . . 12view your phone number . . . . . . . . . . . . 12 main attractions . . . . . . 13 use the FM radio . . . . 13send a multimedia message. . . . . . . . . . . 16 receive a multimedia message. . . . . . . . . . . 16 basics. . . . . . . . . . . . . . . 18 display . . . . . . . . . . . . 18menus . . . . . . . . . . . . 23text entry . . . . . . . . . . 25navigation key. . . . . . . 31codes & passwords . . 32lock & unlock your phone . . . . . . . . . . . . . 32 customize . . . . . . . . . . . 34 ring style. . . . . . . . . . . 34time & date. . . . . . . . . 34wallpaper . . . . . . . . . . 35display appearance . . . 35answer options . . . . . . 36 calls . . . . . . . . . . . . . . . . 37 turn off a call alert . . . . 37recent calls . . . . . . . . . 37redial . . . . . . . . . . . . . . 38return a call . . . . . . . . . 38notepad . . . . . . . . . . . 38hold a call . . . . . . . . . . 39call waiting . . . . . . . . . 39caller ID . . . . . . . . . . . 39emergency calls . . . . . 40international calls . . . . 401-touch dial . . . . . . . . . 40voicemail. . . . . . . . . . . 41 other features . . . . . . . . 43 advanced calling . . . . . 43phonebook . . . . . . . . . . 45chat . . . . . . . . . . . . . . . 47 4 contents personalizing . . . . . . . . 47phone alerts . . . . . . . . 50miscellaneous . . . . . . . 51call times and costs . . 52handsfree . . . . . . . . . . 52network . . . . . . . . . . . 53security . . . . . . . . . . . . 55games . . . . . . . . . . . . . 56 service and repairs . . . . 58Specific Absorption Rate Data . . . . . . . . . . . . . . . . 59European Union Directives Conformance Statement . . . . . . . . . . . 61index. . . . . . . . . . . . . . . . 62 menu map 5 menu map main menun Phonebook s Recent Calls • Received Calls• Dialed Calls• Notepad• Erase All• Call Time*• Call Cost*• GPRS Data Counter*• GPRS Connection Time* e Messages • Create Message• Message Inbox• Outbox•Drafts•Voicemail*• Browser Msgs*•Quick Notes• MMS Templates É Tools • Calculator• Calendar• Shortcuts•Chat*• SIM Toolkit *• Lantern Q Game á WebAccess •Browser• Web Shortcuts•Go to URL•History• Web Sessions• Web Settings h Multimedia •Pictures• Sounds•FM Radio A Alarm Clock w Settings • (see next page) * network or subscription dependent features This is the standard main menu layout. Your phone’s menu may be a little different. 6 settings menul Personalize • Home Screen• Color Style• Wallpaper •Quick Dial t Ring Styles •Style•(Style) Detail H Call Forward* • When Busy• No Reply• Not Reachable• Not Available• All Calls• Cancel All U In-Call Setup • Dialing Prefix*• In-Call Timer• Call Cost Setup• Show Number• Call Waiting*• Anykey Answer• …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GK1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDT56GK1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Diane Steel TITLE: Lead Electrical Engineer Motorola Mobile Devices Business DATE: August 4, 2006 Page 1 of 2 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GK1 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56GK1) is in compliance with all applicable parts of the FCC Rules. NAME: Diane Steel TITLE: Lead Electrical Engineer Motorola Mobile Devices Business DATE: August 4, 2006 Page 2 of 2

APPLICANT: MOTOROLA FCC ID: IHDT56GK1 August 4, 2006 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification (Revised, as seen below) Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56GK1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in the 850 and 1900 MHz PCS bands. The unit may be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Omit this part of the original request for letter dated July 27, 2006. Note: This device contains 900 MHz and 1800 MHz GSM, functions that are not operational in U.S. territories. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048 Exhibit 13A

Date: August 11, 2006 Subject: Request for additional information regarding FCC ID: IHDT56GK1 (Portable PCS GSM transceiver) Reference: Correspondence Reference Number: IHD0449 Confirmation Number: 1607280449 Date of Original Email: August 11, 2006 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois Questions and responses follow: 1. Please verify that the EUT cannot connect to a pc. If it can, then the FCC Rules require that it also be classified as a Class B pc peripheral, subject to either DoC or Certification. Response: Confirmed; this device is not classified as a pc peripheral (feature is not supported). 2. Please specify the detector function used to perform radiated and RF conducted spurious emission measurements. Response: A peak detected is used for radiated and conducted spurious emission measurements (same as radiated power). 1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GK1 FRONT OF PHONE FLIP OPEN BACK OF PHONE FLIP OPEN EXHIBIT 3 1 of 2 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GK1 FRONT OF PHONE BACK OF PHONE BACK OF PHONE WITH BATTERY COVER REMOVED EXHIBIT 3 2 of 2

APPLICANT: MOTOROLA INC. FCC ID: IHDT56GK1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT56GK1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GK1 Main Board Bottom Without Shields Main Board Bottom With Shields EXHIBIT 9 1 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GK1 Main Board Top Without Popples Main Board Top With Popples EXHIBIT 9 2 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GK1 Flip Board Flip LCD EXHIBIT 9 3 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56GK1 EXHIBIT 9 4 of 4 Inside Back Housing Inside Front Housing

0 0 Portable Cellular Phone SAR Test Report Test Report #: 18690-2F Date of Report: 25-Jul-06 Date of Test: 03-Jul-06 through 05-Jul-06 FCC ID #: IHDT56GK1 Generic Name: N/A Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 11th Floor, Hibrand Living Hall, 215, Yangae-Dong, Seocho-Gu, Seoul, South Korea, 137-130 Report Author: Jon Park Senior Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI / IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE 1528, IEC 62209-1 FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-02 Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with CENELEC en50361:2001, IEEE 1528, as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2006 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 18690-2F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Table of Contents 1. Introduction 2 2. Description of the Device Under Test 2 2.1 Antenna description 2 2.2 Device description 2 3. Test Equipment Used 3 3.1 Dosimetric System 3 3.2 Additional Equipment 3 4. Electrical parameters of the tissue simulating liquid 4 5. System Accuracy Verification 5 6. Test Results 6 6.1 Head Adjacent Test Results 6 6.2 Body Worn Test Results 9 References 11 Appendix 1: SAR distribution comparison for system accuracy verification 12 Appendix 2: SAR distribution plots for Phantom Head Adjacent Use 13 Appendix 3: SAR distribution plots for Body Worn Configuration 14 Appendix 4: Probe Calibration Certificate 15 Appendix 5: Measurement Uncertainty Budget 16 Appendix 6: Photographs of the device under test 18 Appendix 6: Photographs of the device under test 19 Appendix 7: Dipole Characterization Certificate 22 MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 18690-2F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1g average set in [3] and 2.0W/kg in a 10g average set in [2]. 2. Description of the Device Under Test 2.1 Antenna description Type Internal Antenna Location Bottom of Transceiver Length 37.5 mm Dimensions Width 5 mm Configuration FJA 2.2 Device description Serial number 010971000000240 Mode(s) of Operation GSM 850 GSM 1900 Modulation Mode(s) GMSK GMSK Maximum Output Power Setting 32.8 dBm 30.2 dBm Duty Cycle 1:8 1:8 Transmitting Frequency Rang(s) 824.2-848.8 MHz 1850.2-1909.8 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 18690-2F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 3. Test Equipment Used 3.1 Dosimetric System The Motorola Mobile Devices Business Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy4™ v4.6) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. All the SAR measurements are taken within a shielded enclosure. The overall 10g RSS uncertainty of the measurement system is ±10.8% (K=1) with an expanded uncertainty of ±21.6% (K=2). The overall 1g RSS uncertainty of the measurement system is ±11.1% (K=1) with an expanded uncertainty of ±22.2% (K=2). The measurement uncertainty budget is given in Appendix 6. Per IEEE 1528, this uncertainty budget is applicable to the SAR range of 0.4W/kg to 10W/kg. The list of calibrated equipment used for the measurements is shown in the following table. Description Serial Number Cal Due Date DASY4™ DAE V1 398 16-Feb-2007 E-Field Probe ETDV6 1515 30-Aug-2006 Dipole Validation Kit, DV900V2 094 22-May-2007 S.A.M. Phantom used for 800/900MHz TP-1168 Dipole Validation Kit, DV1800V2 276tr S.A.M. Phantom used for 1800/1900MHz TP-1138 3.2 Additional Equipment Description Serial Number Cal Due Date Signal Generator HP8648C 3847A04840 02-Dec-2007 Power Meter E4419B GB39511085 01-Dec-2006 Power Sensor #1 - 8481A MY41095452 06-Mar-2007 Power Sensor #2 - 8481A 2702A82671 05-Dec-2006 Network Analyzer HP8753ES US39172714 07-Mar-2007 Dielectric Probe Kit HP85070CUS99360207 MOTOROLA, INC. Portable Cellular Phone SAR Test Rep…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT56GK1 Test Report Number: 18730-1 EXHIBIT 6 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 18730-1 Report Date – July 17, 2006 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated. Signature: Name: Thanigaiselvan Palaniswami Title: EMC Engineer Date: July 17, 2006 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1651-01 APPLICANT: MOTOROLA INC FCC ID: IHDT56GK1 Test Report Number: 18730-1 EXHIBIT 6 2 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 RF Power Output 6 Measurement results 6 Radiated Power 7 Measurement results 7 Occupied Bandwidth 8 Measurement results 9 Spurious Emissions at Antenna Terminals 13 Measurement results 14 Field Strength of Spurious Emissions 16 Measurement results 17 Frequency Stability 19 Measurement results 20 Field Strength of Spurious Emissions -Unintentional Radiators 22 Measurement results 23 AC Line Conducted Emissions 24 Measurement results 25 Appendix A - Radiated Emissions Test Setup Photos 31 Figure A.1 – Substitution Measurement 31 APPLICANT: MOTOROLA INC FCC ID: IHDT56GK1 Test Report Number: 18730-1 EXHIBIT 6 3 Test Report Details Tests Performed By: Motorola Mobile Devices business (MDb) Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 Motorola MDb FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908-1 Tests Requested By: Motorola Inc. Mobile Devices Business 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: GSM 850, 1900 FCC ID : IHDT56GK1 Serial Numbers: 010971000000034, 010971000000042, 010971000000069 Testing Complete Date: July 10, 2006 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators X Part 22 Subpart H - Public Mobile Services X Part 24 Subpart E- Personal Communications Services Applicable Standards: ANSI 63.4 2003, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-132, RSS-133 (PCS) APPLICANT: MOTOROLA INC FCC ID: IHDT56GK1 Test Report Number: 18730-1 EXHIBIT 6 4 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) Pass 3 Occupied Bandwidth Pass 4 Spurious Emissions at Antenna Terminal Pass 5 Field Strength of Spurious Emissions Pass 6 Frequency Stability Pass 7 Field Strength of Spurious Emissions Pass from Unintentional Radiators 8 AC Line Conducted Emissions Pass Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) See results 3 Occupied Bandwidth See Plots 4 Spurious Emissions at Antenna Terminal 16.6 dB 5 Field Strength of Spurious Emissions See Table 6 Frequency Stability 55 Hz 7 Field Strength of Spurious Emissions Below noise floor from Unintentional Radiators 8 AC Line Conducted Emissions See Plots The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. APPLICANT: MOTOROLA INC FCC ID: IHDT56GK1 Test Report Number: 18730-1 EXHIBIT 6 5 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Manufacturer Equipment Type Model No. Serial Number Calibration Due Date Rohde Schwarz Receiver ESI26 100001 3/08/07 Rohde Schwarz Receiver ESI40 100226 6/05/07 Hewlett Packard EMC Analyzer E7405 US39440191 1/05/07 Hewlett Packard Signal Generator 83712A 3429A00286 6/6/07 A.H. Systems DRG Horn Antenna SAS 200/571 365 5/12/07 ETS. Horn Antenna 3115 6222 3/03/07 ETS Log-Periodic Antenna 3148 1189 8/22/06 ETS Biconical Antenna 3110B 3369 8/15/06 Attenuator Weinschel 2 AS-6 6675 6/6/07 Attenuator Weinschel 2 AS-6 6677 11/10/06 Attenuator Weinschel 2 AS-6 7075 1/31/07 Attenuator Weinschel 2 AS-6 6675 6/06/07 Thermotron Environmental Chamber S-4 31580 1/31/07 Agilent Power Meter E4416A GB41293246 02/03/07 Agilent Power Sensor E4412B US38486321 02/03/07 ETS LISN 3810/2NM 00062907 5/10/07 ETS LISN 3810/2NM 00062912 5/10/07 All equipment is on a one-year calibration cycle. APPLICANT: MOTOROLA INC FCC ID: IHDT56GK1 Test Report Number: 18730-1 EXHIBIT 6 6 Measurement Procedures and Data RF POWER OUTPUT Measurement Procedure The RF output port of the equipment under test is directly coupled to the input of a Agilent power meter through a 20dB passive attenuator, adaptor (if needed), and specialized RF connector. The peak power output is measured for all channels. CFR47 Part 2.1046 Measurement Results GSM 850 Frequency (MHz) Power (dBm) 824.2 32.79 836.6 32.78 848.8 32.87 GSM 1900 Frequency (MHz) Power (dBm) 1850.20 30.19 1880.00 30.20 1909.80 30.21 APPLICANT: MOTOROLA INC FCC ID: IHDT56GK1 Test Report Number: 18730-1 EXHIBIT 6 7 RADIATED POWER (EIRP AND ERP) Measurement Procedure The phone was tested in a 16’ anechoic chamber wi…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT56GK1 Radiated Emissions Test Setup Photos Radiated Emissions Measurement Substitution Measurement EXHIBIT 7
