IHDT56JJ1Portable Cellular/ PCS CDMA Transceiver with BT

V750 CMY CMMYCY CMY K v525689.eps 1/31/2008 3:22:33 PMv525689.eps 1/31/2008 3:22:33 PM 1 HELLOMOTOIntroducing your new Motorola 750 wireless phone! It’s rugged and full of high performance features:Quick Communication – With Verizon Wireless® Push to Talk, you can connect instantly with one or more people with the push of a button. Anywhere Entertainment – Download and play V CAST music and videos. Use the music player to set your playlist for your morning commute. Optimize your music listening experience with Bluetooth® stereo headphones (sold separately). Connect on Many Levels – Whether it’s with work or friends, connect in a variety of ways—voice, messaging, downloads, or swapping an optional memory card—you’ll be on top of all the latest news and views to share! My Phone, My Way – It’s your phone—make it that way. Customize your home screen with personal pictures, change wallpapers, and use your favorite song as your ringtone. 2Here’s a quick anatomy lesson. C a mer a / C a m c order Key Send Key Make & answer calls. Cle a r Key R ig ht Soft Key Perfor m function in lower right display.Power/End KeyTurn phone on/off,end calls, exitm enus. M ic ro p hone Left Soft Key Perfor m function in lower left display. 4-W a y N a v iga t i on Key w i th Center Sele c t Press center key to openm ain m enu. C a mer a Lens Mus ic Pl a yer Controls: Play/Pause Skip Back/RewindSkip Forward/Fast Forward Extern a l D i s p l a y See inco m ing call infor m ation, use as ca m era viewfinder when flip is closed. 3 Raise & lower volu m e. Connect headphones. Sm a rt/- S p e a ker p hone Key Turn handsfree speaker on/off. Vo ic e Comm a nd Key Create voice records, activate speech dialing & voice co mm ands. M ic ro-USB Port Insert charger & phone accessories. Push to T a lk Key 4 N N b CONTACTS c 1. New Contact2. Contact List3. Groups4. Speed Dials5. In Case of E m ergency B G H A J Message Contacts Tue, Oct 23 12:45pm MENU OK 1 ❙❙❙ ò 1X EVEV 1 ❙❙❙ ò 1X EVEV M ai n S c reen Cont ac ts Menu Press & hold Power/End Key ( P ) until display lights up to turn on your phone. 1 Press Center Sele c t Key ( s ) to select it. 4 Press N a v iga t i on Key ( S ) up/down/ left/right to highlight a m enu option. 3 Press Center Sele c t Key ( s ) to openCont ac ts Menu . 2 5 Motorola, Inc.Consumer Advocacy Office1307 East Algonquin RoadSchaumburg, IL 60196www.hellomoto.com1-800-331-6456 (United States)1-888-390-6456 (TTY/TDD United States for hearing impaired)1-800-461-4575 (Canada)Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider’s network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user’s guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. Microsoft and Windows are registered trademarks of Microsoft Corporation; and Windows XP is a trademark of Microsoft Corporation. Verizon Wireless® is a registered trademark of Verizon Trademark Services, LLC.BREW is a trademark of QUALCOMM Incorporated.© Motorola, Inc., 2008. Caution: Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment. Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.Manual Number: -A 6 c ontents c ontents menu map . . . . . . . . . . . . . . . . 8Use and Care . . . . . . . . . . . . . 10essentials . . . . . . . . . . . . . . . . 11 about this guide . . . . . . . . . 11battery. . . . . . . . . . . . . . . . . 11charge the battery. . . . . . . . 14turn it on & off. . . . . . . . . . . 15make a call . . . . . . . . . . . . . 16answer a call . . . . . . . . . . . . 16end a call . . . . . . . . . . . . . . . 16store a phone number . . . . 17call a stored phone number . . . . . . . . . . . . . . . . 17 basics . . . . . . . . . . . . . . . . . . . 18 main screen . . . . . . . . . . . . 18adjust volume . . . . . . . . . . . 21change sound settings . . . . 22 handsfree . . . . . . . . . . . . . . 22standalone mode . . . . . . . . 23change lock code. . . . . . . . . 24lock & unlock phone . . . . . . 25manage memory. . . . . . . . . 26TTY operation . . . . . . . . . . . 29voice privacy . . . . . . . . . . . . 31 tips & tricks . . . . . . . . . . . . . . 32personalize …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDT56JJ1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDT56JJ1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical bas is. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: JongHwa Lee TITLE: Engineering Manager Motorola Mobile Devices Business Date: February 28, 2008 Page 1 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDT56JJ1 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this applic ation was taken under my supervision and is hereby duly certified. I also certify that this transmi t equipment (IHDT56JJ1) is in compliance with all applicable parts of the FCC Rules. NAME: JongHwa Lee TITLE: Engineering Manager Motorola Mobile Devices Business Date: February 28, 2008 Page 2 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDT56JJ1 Page 3 of 3 EXHIBIT 2 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: JongHwa Lee TITLE: Engineering Manager Motorola Mobile Devices Business DATE: February 28 2008

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 March 6, 2008 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56JJ1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the Digital CDMA standard in both the 800 and 1900 MHz PCS band. The unit also employs EVDO and contains a 2.4 GHz Bluetooth transmitter (Part 15.247). The unit may be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 SHORT TERM CONFIDENTIALITY REQUEST 45 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiv er FCC ID IHDT56JJ1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 45 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Date: March 19, 2008 Subject: Request for additional information regarding FCC ID: IHDT56JJ1 Reference: Correspondence Reference Number: IHD80164 Confirmation Number: 803060164-6 Date of Original Email: March 17, 2008 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois 60048 Questions and responses follow: 1. The application must comply with the FCC’s new Handset SAR requirements, released during the recent TCBC Workshop. It is not clear whether, in this application, simultaneous SAR measurements (BT and CDMA) are required, if stand-alone BT SAR measurements are required, or if the BT is exempt from SAR measurements altogether. Please submit an internal photo of the EUT, showing the location of the BT and CDMA antennas and the distance between them (both open and closed positions). Please compare the BT conducted output power to Pref (from the new requirements), and, in conjunction with the antenna separation distance, determine the level of SAR testing required for the BT transmitter. Please submit this information. Response: This device does allow simultaneous transmission between BT and CDMA. Because of the close proximity of the intentional and other unintentional radiating structures, stand-alone BT SAR measurements were performed in the configuration that resulted in the highest SAR during the stand-alone evaluation of the dominant transmitter. The SAR results from the BT and the CDMA measurements were summed together and shown to be less than the 1.6 W/kg (1g) SAR limit. Please refer to the revised SAR report attached. 2. If so required by the results to question #1 above (i.e., if simultaneous SAR is not required, based on antenna separation distance and output power), please remove all references to the BT from the SAR report and resubmit it. If stand-alone BT SAR testing is required, please include that data and the supporting information by which it has been obtained. Response: Please see updated SAR test report for additional BT SAR data. 1 2 3. Please resubmit the user’s manual, including the correct maximum SAR levels, based on the revised SAR report. Response: Please see updated SAR test report for revised summation SAR results. Please note, because of the extremely low BT SAR results, the highest SAR value, reported in the user manual, has not changed. 4. Please resubmit the block diagram, showing all clock/oscillator values, as required Response: Please refer to the revised Block Diagram attached showing clocks/oscillator values. 5. Page 5 of the Bluetooth report specifies that EDR mode is available to the EUT, but the test report data does not reflect this. Please submit 20 dBc BW plots and bandedge plots in EDR mode, and confirm that the maximum Bluetooth output power listed in the report is correct. Response: The Bluetooth transmitter in this device does not support Bluetooth Version 2.0+EDR, therefore the maximum output power listed in the report is for Bluetooth 2.0 only. 6. Please submit an Operational Description (technical description) of the Bluetooth transmitter. Response: Please refer to page 10 of the Operational Description attached for the Bluetooth transmitter and a supplement file showing function controls. 7. Please include updated HAC test procedure on Page 8, Exhibit 6B-1 per the test photographs. Response: Please refer to the updated HAC report attached.

From: LI LILLIAN-WNCK38 Sent: Thursday, March 20, 2008 3:48 PM Subject: RE: Follow-Up Questions Regarding FCC ID: IHDT56JJ1 Hi Greg again, Thanks for your quick Follow-up RT on this product FCC ID: IHDT56JJ1. Please find our new response to Q1 below and attached is a revised exhibit in response to Q2. The FCC grants for this product are also very criticalto us right now, your speedy review and approval are highly appreciated! Thanks a lot! From: PCTEST TCB [mailto:[email protected]] Sent: Thursday, March 20, 2008 11:17 AM Subject: Follow-Up Questions Regarding FCC ID: IHDT56JJ1 DearAndy, Thank you for your response to the referenced application. Please see below follow- up question pertaining to your submittal. Follow-Up RT: 1. Thank you for your response. Please submit an internal photo of the EUT, as requested, identifying the BT and CDMA antennas and showing their locations and the distance(s) between them. In the future, please refer to this distance and the measured Bluetooth output power level, as compared to Pref, in order to arrive at the level of SAR testing required for the BT transmitter. Response: Per the March 20, 2008 discussion with the examining engineer; Motorola chooses to use the summation method for evaluation of simultaneous transmitters. Photographs, measured distances, and power output levels to determine the "antenna pair SAR to antenna separation ration" are therefore not required. 2. The user’s manual lists an incorrect maximum body SAR level. Please revise, and resubmit the manual. Response: Please refer to the revised user manual attached. The items indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Gregory Czumak Senior Certification Engineer Quality Manager PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 FRONT OF PHONE FLIP OPEN BACK OF PHONE FLIP OPEN Motorola Confidential Proprietary EXHIBIT 3 1 of 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 FRONT OF PHONE FLIP CLOSE BACK OF PHONE FLIP CLOSE Motorola Confidential Proprietary EXHIBIT 3 2 of 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 BACK OF PHONE WITH BATTERY COVER REMOVED Motorola Confidential Proprietary EXHIBIT 3 3 of 3

APPLICANT: MOTOROLA INC. FCC ID: IHDT56JJ1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT56JJ1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 Main Board Top With Shields Main Board Top Without Shields Motorola Confidential Proprietary EXHIBIT 9 1 of 5 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 Main Board Bottom With Shields Main Board Bottom Without Shields Motorola Confidential Proprietary EXHIBIT 9 2 of 5 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 LCD Module & CLi Module & FLIP RFPC & Hinge FPC & Vibrator & Came ra Module & Music Key FPC Motorola Confidential Proprietary EXHIBIT 9 3 of 5 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 INSIDE FLIP HOUSING Motorola Confidential Proprietary EXHIBIT 9 4 of 5 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 INSIDE MAIN HOUSING Motorola Confidential Proprietary EXHIBIT 9 5 of 5

0 0 Portable Cellular Phone SAR Test Report Test Report #: 21686-1F Date of Report: 03/18/208 Date of Test: 02/29/2008 through 3/18/2008 FCC ID #: IHDT56JJ1 Generic Name: V750 Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 11th Floor, Hibrand Living Hall, 215, Yangjae-Dong, Seocho-Gu, Seoul, South Korea, 137-130 Report Author: DH Moon RF Engineer Accreditation: TESTING CERT #2518-03 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 (2001) CENELEC EN 50361 (2001) ARIB Std. T-56 (2002) On the following products or types of products: On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2007 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Table of Contents 1. Introduction 2 2. Description of the Device Under Test 2 2.1 Antenna description 2 2.2 Device description 2 3. Test Equipment Used 3 3.1 Dosimetric System 3 3.2 Additional Equipment 3 4. Electrical parameters of the tissue simulating liquid 4 5. System Accuracy Verification 5 6. Test Results 6 6.1 Head Adjacent Test Results 6 6.2 Push-to-Talk Position Test Results 10 6.3 Body Worn Test Results 13 References 16 Appendix 1: SAR distribution comparison for system accuracy verification 17 Appendix 2: SAR distribution plots for Phantom Head Adjacent Use 18 Appendix 3: SAR distribution plots for Push-to-Talk Configuration 19 Appendix 4: SAR distribution plots for Body Worn Configuration 20 Appendix 5: Probe Calibration Certificate 21 Appendix 6: Measurement Uncertainty Budget 22 Appendix 7: Photographs of the device under test 24 Appendix 8: Dipole Characterization Certificate 25 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1g average set in [3] and 2.0W/kg in a 10g average set in [2]. For ANSI / IEEE C95.1 (1g), the final SAR reading for this phone is 1.45 W/kg for head adjacent use and 0.69 W/kg for body worn use. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. 2. Description of the Device Under Test 2.1 Antenna description Type Internal Location Bottom of the transceiver Length 37.78 mm Dimensions Width 7.48 mm Configuration FJA 2.2 Device description Serial number 8008FD8B Mode(s) of Operation CDMA 800 CDMA 1900 CDMA 800 1xEV-DO Rev.A CDMA 1900 1xEV-DO Rev.A Bluetooth Modulation Mode(s) QPSK QPSK QPSK QPSK GFSK Maximum Output Power Setting 25.00 dBm 25.00 dBm 25.00 dBm 25.00 dBm 4.00 dBm Duty Cycle 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Rang(s) 824.7 – 848.31 MHz 1851.25 – 1908.75MHz 824.7 – 848.31 MHz 1851.25 – 1908.75MHz 2400.0 – 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled APPLICANT: MOTOROLA, INC. FCC ID: IHDT56JJ1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 3. Test Equipment Used 3.1 Dosimetric System The Motorola Mobile Devices Business Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy4™ v4.7) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. All the SAR measurements are taken within a shielded enclosure. The overall 10g RSS uncertainty of the measurement system is ±10.8% (K=1) with an expanded uncertainty of ±21.6% (K=2). The overall 1g RSS uncertainty of the measurement system is ±11.1% (K=1) with an expanded uncertainty of ±22.2% (K=2). The measurement uncertainty budget is given in Appendix 6. Per IEEE 1528, this uncertainty budget is applicable to the SAR range of 0.4W/kg to 10W/kg. The list of calibrated equipment used for the measurements is shown in the following table. Description Serial Number Cal Due Date DASY4™ DAE3 383 08/24/2008 E-Field Probe ETDV6 1515 08/28/2008 S.A.M. Phantom used for 800/900 MHz TP-1129 S.A.M. Phantom used for 1900/2450 MHz TP-1134 Dipole Validation Kit, DV900V2 097 05/01/2008 Dipole Validation Kit, DV1800V2 277tr 05/01/2008 Dip…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT56JJ1 Test Report Number: 21620-1 EXHIBIT 6 1 of 32 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 21620-1 Report Date – March 10, 2008 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated. Signature: Name: Albert J. Patapack Title: EMC Engineer Date: March 10, 2008 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 2518-02 APPLICANT: MOTOROLA INC FCC ID: IHDT56JJ1 Test Report Number: 21620-1 EXHIBIT 6 2 of 32 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 RF Power Output 6 Measurement results 6 Radiated Power 8 Measurement results 8 Occupied Bandwidth 9 Measurement results 9 Spurious Emissions at Antenna Terminals 14 Measurement results 15 Field Strength of Spurious Emissions 17 Measurement results 18 Frequency Stability 20 Measurement results 21 Field Strength of Spurious Emissions -Unintentional Radiators 23 Measurement results 24 AC Line Conducted Emissions 25 Measurement results 26 APPLICANT: MOTOROLA INC FCC ID: IHDT56JJ1 Test Report Number: 21620-1 EXHIBIT 6 3 of 32 Test Report Details Tests Performed By: Motorola Mobile Devices business (MDb) Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 Motorola MDb FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908-1 Tests Requested By: Motorola Inc. Mobile Devices Business 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: CDMA 800, CDMA 1900, EV-DO Rev0, EV-DO RevA, Bluetooth FCC ID : IHDT56JJ1 Serial Numbers: 80D36724, 80E1DB33, 8015F830, 80443F01, 80D1F0E8 Testing Complete Date: March 5, 2008 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators X Part 22 Subpart H - Public Mobile Services X Part 24 Subpart E – Personal Communications Services Applicable Standards: TIA EIA 137-A, TIA EIA 98-C, ANSI 63.4 2001, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-133 (PCS) APPLICANT: MOTOROLA INC FCC ID: IHDT56JJ1 Test Report Number: 21620-1 EXHIBIT 6 4 of 32 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) Pass 3 EIRP (Effective Isotropic Radiated Power) Pass 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass 8 Field Strength of Spurious Emissions Pass from Unintentional Radiators 9 AC Line Conducted Emissions Pass Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) See results 3 EIRP (Effective Isotropic Radiated Power) See results 3 Occupied Bandwidth See Plots 4 Spurious Emissions at Antenna Terminal See results 5 Field Strength of Spurious Emissions See results 6 Frequency Stability See results 7 Field Strength of Spurious Emissions Below noise floor from Unintentional Radiators 8 AC Line Conducted Emissions See Plots The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. APPLICANT: MOTOROLA INC FCC ID: IHDT56JJ1 Test Report Number: 21620-1 EXHIBIT 6 5 of 32 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Manufacturer Equipment Type Model No. Serial Number Calibration …

Text truncated - open the document above for the full version.
