IHDT56KS1Portable Cellular/ PCS/ AWS CDMA Transceiver with Bluetooth

APPLICANT: MOTOROLA INC. FCC ID: IHDT56KS1 Page 1 of 5 EXHIBIT 2 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDT56KS1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. NAME: C.K.Kim TITLE: Engineering Manager Motorola Mobile Devices Business Date: July 28, 2009 APPLICANT: MOTOROLA INC. FCC ID: IHDT56KS1 Page 2 of 5 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56KS1) is in compliance with all applicable parts of the FCC Rules. NAME: C.K.Kim TITLE: Engineering Manager Motorola Mobile Devices Business Date: July 28, 2009 APPLICANT: MOTOROLA INC. FCC ID: IHDT56KS1 Page 3 of 5 EXHIBIT 2 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: C.K.Kim TITLE: Engineering Manager Motorola Mobile Devices Business Date: July 28, 2009

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56KS1 July 26, 2009 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56K S1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the Digital CDMA standard in the 800 and 1900 MHz PCS band, as well as 1700 and 2100 MHz band. The unit also employs EVDO and contains a 2.4 GHz Bluetooth transmitter (Part 15.247). The unit may be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56KS1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDT56K S1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Date: Aug 12, 2009 Subject: Request for additional information regarding FCC ID: IHDT56KS1 Reference: Correspondence Reference Number: IHD90923 Confirmation Number: 907280923-5 Date of Original Email: Aug 4, 2009 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois 60048 Questions and responses follow: 1. Please resubmit the BT Block Diagram, including more detail (the entire TX is shown as a single box). Response: Please refer to the revised Exhibit 4 submitted online. 2. What is the peak gain of the BT antenna? Response: Please refer to the revised Exhibit 6A1 submitted online. The BT antenna gain is addressed on page 5 of the report. 3. The licensed transmitter Block Diagram does not show the clocks/oscillators- please revise. Response: Please refer to the revised Exhibit 4 submitted online. 4. The licensed transmitter Operational Description only lists cellular and PCS band capability (not AWS). Please revise. Response: Please refer to the revised Exhibit 12 submitted online. 5. Several items in the 22/24/27 EMC report are listed as being past cal due at the time of testing, with no replacement equipment in the list (p.5/31). Please address. Response: Please refer to the revised Exhibit 6 submitted online. 1 6. A PCS band PAR plot was provided. Please provide the PAR plot for the AWS band emission. Response: Please refer to the revised Exhibit 6 submitted online. 7. The EMC Analyzer is listed in the BT report as being past cal due at the time of testing, with no replacement equipment in the list. Please address. Response: Please refer to the revised Exhibit 6A1 submitted online. 8. Page 3/51 of the SAR report lists the BT power as 4 dBm, but measured data shows the BT power as being more than 5 dB higher than this. Please revise. Response: Please refer to the revised Exhibit 11 submitted online. 9. Page 15/51 of the SAR report- when we scale the SAR level to compensate for high tissue permittivity, we obtain a result of 1.59 (not 1.58). Please provide your calculations. Response: Please refer to the revised SAR report submitted online. Also note that the highest SAR value for the "head" configuration has been updated, so the SAR date in the user’s manual is updated accordingly. Please refer to the revised user’s manual submitted online as well. 10. The maximum body SAR listed in the user’s manual should not be the summed SAR (licensed + BT), but the highest measured stand-alone SAR level. In this case, the manual lists 1.59, but this value may end up remaining valid, depending on your response to question 9 (above). Response: Please refer to the revised Exhibit 8 submitted online. 11. Appendix 6 of the SAR report- the Dipole Characterization Certificate is missing. Please submit. Response: Please refer to the revised Exhibit 11 submitted online. 12. FYI: Page 18 of the 22/24/27 EMC report, the top plot- the marker is set a t a point outside of the viewable range, but compliance can still be ascertained from the plot. Response: Noted. 13. Exhibit 6B1 and Exhibit 11 indicates two Battery types tested; however Exhibit 6B2 indicates 4 battery types available. Please include evaluation for the other two batteries or please clarify. 2 3 Response: Please refer to the revised Exhibit 6B1, Exhibit 6B2 and SAR report submitted online to include 4 battery types. Request: Due to product security "leaks' on the internet, we would like confidentiality on the HAC statement. And per agreement with the TCB, we now put the HAC statement under exhibit 8 for a STC and revised Exhibit 2 submitted online to exclude that information.

From: LI LILLIAN-WNCK38 Sent: Thursday, August 13, 2009 4:17 PM To: PCTEST TCB/CB; PCTEST - Gregory Czumak Subject: RE: Follow-Up Questions Regarding FCC ID: IHDT56KS1 Hi Greg, Please find our response to your questions below and supporting document submitted online and let us know if you have any further questions. Thanks! Lillian Li From: PCTEST TCB/CB Sent: Wednesday, August 12, 2009 3:37 PM To: Bachler Andrew-WLAB00 Cc: LI LILLIAN-WNCK38; PCTEST - Gregory Czumak; PCTEST - Randy Ortanez; PCTEST - Steve Liu; PCTEST - Courtenay Geraghty Subject: Follow-Up Questions Regarding FCC ID: IHDT56KS1 To: Mr. Andrew Bachler / Motorola Inc. From: Mr. Gregory Czumak / PCTEST TCB/CB RE: FCC ID: IHDT56KS1 Applicant: Motorola Inc. Correspondence Reference Number: IHD90923-A Confirmation Number: 907280923-5 Date of Original Email: August 12, 2009 Subject: Request for additional information In regards to your recent TCB application referenced above, we kindly request that you provide the following additional information. 1. Thank you for your email. Regarding your response to question #6, the revised test report contains the required AWS PAR plot, but the PCS PAR plot is now missing. Please revise to include both required plots. Response: The PCS band EIRP was measured using a Peak Detector. 2. The FCC has stated that SAR values are to be rounded to 2 significant digits (see attached). When doing so in this case, the summation of (corrected) cellular band body SAR and BT SAR is 1.6 W/kg. In accordance with FCC requirements for SAR evaluation of cell phones with multiple transmitters, simultaneous SAR testing is required when the summation is not less than 1.6 W/kg. Please apply the SAR-to- peak-location-separation ratio test to determine if simultaneous SAR testing is, indeed, required for the EUT. Response: Please refer to the revised Exhibit 11 submitted online. The difference between this report and the previous one was: We did not round each value used in the calculation of the simultaneous SAR to two significant figures, instead only the final result was appropriately rounded. The item indicated above must be submitted before processing can continue on the above referenced application. Sincerely, Gregory Czumak Senior Certification Engineer Quality Manager PCTEST Engineering Laboratory, Inc. 6660-B Dobbin Road Columbia, MD 21045 410-290-6652 410-290-6654 (Fax) [email protected] This communication and its attachments contain information from PCTEST Engineering Laboratory, Inc., and is intended for the exclusive use of the recipient (s) named above. It may contain information that is confidential and/or legally privileged. Any unauthorized use that may compromise that confidentiality via distribution or disclosure is prohibited. Please notify the sender immediately if you receive this communication in error, and delete it from your computer system. Usage of PCTEST email addresses for non-business related activities is strictly prohibited. No warranty is made that the e-mail or attachment(s) are free from computer virus or other defect. Thank you.

APPLICANT: MOTOROLA INC. FCC ID: IHDT56KS1 EXHIBIT 3 FRONT OF PHONE FLIP OPEN BACK OF PHONE FLIP OPEN APPLICANT: MOTOROLA INC. FCC ID: IHDT56KS1 EXHIBIT 3 FRONT OF PHONE FLIP CLOSE BACK OF PHONE FLIP CLOSE APPLICANT: MOTOROLA INC. FCC ID: IHDT56KS1 EXHIBIT 3 BACK OF PHONE WITH BATTERY COVER REMOVED APPLICANT: MOTOROLA INC. FCC ID: IHDT56KS1 EXHIBIT 3 SIDE OF PHONE

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56KS1 EX HIBIT 9 1 of 5 Main Board Bottom With Shields Main Board Bottom Without Shields APPLICANT: MOTOROLA, INC. FCC ID: IHDT56KS1 EX HIBIT 9 2 of 5 Main Board Top With Popples Main Board Top Without Popples APPLICANT: MOTOROLA, INC. FCC ID: IHDT56KS1 EX HIBIT 9 3 of 5 LCD Module & FLIP Rigid PCB & CLi & Hinge Flex PCB & Ear Piece APPLICANT: MOTOROLA, INC. FCC ID: IHDT56KS1 EX HIBIT 9 4 of 5 INSIDE FLIP HOUSING APPLICANT: MOTOROLA, INC. FCC ID: IHDT56KS1 EX HIBIT 9 5 of 5 INSIDE MAIN HOUSING

MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23126-1F E E x x h h i i b b i i t t 1 1 1 1 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobile Devices 18th Floor, Hibrand Living Hall, 215, Yanjae-Dong, Seocho-Gu, Seoul, 137-130, South Korea Test Report #: 23126-1F Date of Report: Aug-10-2009 updated on 13 Aug 2009 (change to scaled SAR tables) Date of Test: Jun-15-2009 t hrough Jun-19-2009 FCC ID #: IHDT56KS1 Generic Name: W845 Test Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 11th Floor, Hibrand Living Hall, 215, Yanjae-Dong, Seocho-Gu, Seoul, 137-130, South Korea Report Author: Jon Park Senior Staff Engineer Accreditation: TESTING CERT #2518-02 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2009 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23126-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 o o f f 1 1 9 9 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 3 2.1 Antenna description 3 2.2 Device description 3 3. Test Equipment Used 4 3.1 Dosimetric System 4 3.2 Additional Equipment 4 4. Electrical parameters of the tissue simulating liquid 5 5. System Accuracy Verification 6 6. Test Results 7 6.1 Head Adjacent Test Results 8 6.2 Body Worn Test Results 14 References 19 Appendix 1: SAR distribution comparison for the system accuracy verification Appendix 2: SAR distribution plots for Phantom Head Adjacent Use Appendix 3: SAR distribution plots for Body Worn Configuration Appendix 4: Probe Calibration Certificate Appendix 5: Measurement Uncertainty Budget Appendix 6: Dipole Characterization Certificate MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23126-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 o o f f 1 1 9 9 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1g average set in [3] and 2.0W/kg in a 10g average set in [2]. For ICNIRP (10g), the final SAR reading for this phone is 0.74 W/kg for head adjacent use and 1.11 W/kg for body worn use. For ANSI / IEEE C95.1 (1g), the final SAR reading for this phone is 1.12 W/kg for head adjacent use and 1.59 W/kg for body worn use. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. 2. Description of the Device Under Test 2.1 Antenna description Type Internal Location Bottom of the transceiver Length 34.18 mm Dimensions Width 7.8 mm Configuration FJA 2.2 Device description Serial number 80C9004E Mode(s) of Operation 800 CDMA 1700 CDMA 1900 CDMA 800 1xEVDO Rel. O 1700 1xEVDO Rel. O 1900 1xEVDO Rel. O Bluetooth Modulation Mode(s) QPSK QPSK QPSK QPSK QPSK QPSK GMSK Maximum Output Power Setting 25.00 dBm 25.00 dBm25.00 dBm25.00 dBm25.00 dBm25.00 dBm 10.00 dBm Duty Cycle 1:1 1:1 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.70 – 848.31 MHz 1711.2 - 1753.75 MHz 1851.25 – 1908.75 MHz 824.70 – 848.31 MHz 1711.2 - 1753.75 MHz 1851.25 – 1908.75 MHz 2400.0 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23126-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 4 4 o o f f 1 1 9 9 3. Test Equipment Used 3.1 Dosimetric System The Motorola Mobile Devices Business Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy4™ v4.7) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. All the SAR measurements are taken within a shielded enclosure. The overall 10g RSS uncertainty of the measurement system is ±10.8% (K=1) with an expanded uncertainty of ±21.6% (K=2). The overall 1g RSS uncertainty of the measurement system is ±11.1% (K=1) with an expanded uncertainty of ±22.2% (K=2). The measurement uncertainty budget is given in Appendix 5. Per IEEE 1528, …
