IHDT56LB1CDMA 800/1900 TRANSCEIVER W/BT CLASS 1.5 & WLAN

APPLICANT MOTOROLA INC. FCC ID: IHDT56LB1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 1 Congratulations CongratulationsMOTOROLA TM SHADOW with MOTOBLUR TM MOTOROLA SHADOW with MOTOBLUR is a premium multimedia device that gives you a high quality imaging, video, and multimedia sharing experience. With its high resolution display and ultrathin design, Shadow stands out from the crowd.• Take great photos & videos, then share them with friends or move them to your PC or even your HDTV. No memory cards to swap in and out, and no cables to tie you down. • With MOTOBLUR, sync your favorite social networking sites—all your contacts, all your messages, all the latest updates—straight to your MOTOROLA SHADOW . Oh, and MOTOBLUR backs it all up too. • Choose from thousands of cool apps to download from Android Market™. Caution: Before assembling, charging or using your phone for the first time, please read “Safety, Regulatory & Legal” on page 59. Once your phone is up and running, touch Menu > Settings > About phone > Safety & regulatory to read the full information. More informationOn your phone —Touch > Help Center . You can also flick your home screen right to see Getting Started and Tips & Tricks widgets. Touch them for helpful advice.On your computer —Go to http://www.motorola.com/myshadow . After you create a MOTOBLUR account, you can also log in and find help with MOTOBLUR: http://www.motorola.com/mymotoblur So, whether you want to read, watch, or play, we can help. Notes:• All screen shots in this guide are simulated. Actual displays may vary. • Instructions to perform tasks in this guide may change depending on the software version on your phone. • Unless specified otherwise, all instructions to perform tasks in this guide assume that you are starting from the home screen. 2 Your phone Your phoneTip: To activate/deactivate the Notification LED, touch Menu > Settings > Display & security > Notification LED . Note: Your phone might look a little different. Press to put the display to sleep, or hold to turn off. 3.5mm He a dset J ac k B ac k Key Menu Key M ic ro p hone Home Key To u c hs c reen C a mer a Key Power Key Volume Keys Press to open m enu options. Press to go back. Press to close any m enu or app & return to the ho m e screen. Se a r c h Key Press for textsearch or holdfor voice search. ContentsLet’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . . 6Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8App menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10Social networking. . . . . . . . . . . . . . . . . . . . . . . . . . . 10Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26V CAST Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31V CAST Music with Rhapsody® . . . . . . . . . . . . . . . 34Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40Latitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42VZ Navigator® . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45Bluetooth® wireless . . . . . . . . . . . . . . . . . . . . . . . . 46Wi-Fi. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47Memory card & file management . . . . . . . . . . . . . . 48Synchronize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 3 Let’s go Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 57Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 58 Let’s golet’s get you up and runningAssemble & charge 1 remove cover 2 insert microSD (may already be done) 3 insert battery 4 replace cover 5 charge up 3H 4 Let’s go Caution: Please read the battery use and safety text in the important legal and safety information packaged with your phone.Tip: To save battery life, see “Battery tips” on page 23. Set up & goCreate or log into a MOTOBLUR account. Use an existing email account and a memorable password—these will become your MOTOBLUR account ID and password. There’s more in “Your MOTOBLUR account” on page 10. Registration is secure, and should only take a few minutes.Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details. 1 Press and hold Power to turn on. 2 Select a language. 3 Register or log in.Note: If prompted, touch Activate to activate your phone.To create a MOTOBLUR account, enter your name, a current email address (where MOTOBLUR can send account information), and a MOTOBLUR account password. Tip: Open your phone to type. Tip: For more, or to add accounts anytime, go to “Add accounts” on page 11. MOTOBLUR ID: Enter email address Your name: e.g. John Smith Password: Password Next Back Creating your MOTOBLUR account... 5 Let’s go Wi-Fi connectIf y…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LB1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDT56LB1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Pat Mulhern TITLE: Engineering Manager Motorola Mobile Devices Business Date: March 12, 2010 Page 1 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDT56LB1 Page 2 of 3 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56LB1) is in compliance with all applicable parts of the FCC Rules. NAME: Pat Mulhern TITLE: Engineering Manager Motorola Mobile Devices Business Date: March 12, 2010 APPLICANT: MOTOROLA INC. FCC ID: IHDT56LB1 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Pat Mulhern TITLE: Engineering Manager Motorola Mobile Devices Business Date: March 12, 2010 Page 3 of 3 EXHIBIT 2

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDT56 LB1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 February 22, 2010 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56LB1. Motorola is also the manufacturer of this equipment. Confidentiality : Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the Digital CDMA standard in the 800 and 1900 MHz PCS band. The unit also employs EVDO and contains a Bluetooth transmitter (Part 15.247). The unit may be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 EXHIBIT_3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 EXHIBIT_3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 EXHIBIT_3

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LB1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDT56LB1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 EXHIBIT 9 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 EXHIBIT 9 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 EXHIBIT 9

MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23649-1F FCC ID: IHDT56LB1 Exhibit 11 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobile Devices 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 23649-1F Date of Report: Mar-11-2010 Date of Test: Feb-24-2010 to Mar-07-2010 FCC ID #: IHDT56LB1 Generic Name: N/A Test Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Thomas Knipple Senior RF Engineer Accreditation: TESTING CERT #2518-02 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2010 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23649-1F FCC ID: IHDT56LB1 Exhibit 11 Page 2 of 15 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 4 2.1 Antenna description 4 2.2 Device description 4 3. Test Equipment Used 5 3.1 Dosimetric System 5 3.2 Additional Equipment 5 4. Electrical parameters of the tissue simulating liquid 6 5. System Accuracy Verification 7 6. Test Results 8 6.1 Head Adjacent Test Results 10 6.2 Body Worn Test Results 13 References 15 Appendix 1: SAR distribution comparison for the system accuracy verification Appendix 2: SAR distribution plots for Phantom Head-Adjacent Use Appendix 3: SAR distribution plots for Body-Worn Configuration Appendix 4: Probe Calibration Certificate Appendix 5: Measurement Uncertainty Budget Appendix 6: Dipole Characterization Certificate MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23649-1F FCC ID: IHDT56LB1 Exhibit 11 Page 3 of 15 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1 g average set in [3] and 2.0 W/kg in a 10 g average set in [2]. For ICNIRP (10 g), the final SAR reading for this phone is 0.93 W/kg for head-adjacent use and 0.84 W/kg for body-worn use. For ANSI / IEEE C95.1 (1 g), the final SAR reading for this phone is 1.18 W/kg for head-adjacent use and 1.38 W/kg for body-worn use. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23649-1F FCC ID: IHDT56LB1 Exhibit 11 Page 4 of 15 2. Description of the Device Under Test 2.1 Antenna description Type Internal Location Bottom Rear of Transceiver Length 51.6 cm Dimensions Width 6.2 cm Configuration Cadillac 2.2 Device description Serial Number(s) LSOV290109, LSOV290159 Mode(s) of Operation CDMA 800 CDMA 1900 EV-DO Rev. A 800 EV-DO Rev. A 1900 Wi-Fi 802.11b/g/n Bluetooth Modulation Mode(s) QPSK QPSK QPSK QPSK BPSK GFSK Maximum Output Power Setting 25.0 dBm 25.0 dBm 25.0 dBm 25.0 dBm 20.5 dBm 10 dBm Duty Cycle 1:1 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.70 - 848.31 MHz 1851.20 - 1908.75 MHz 824.70 - 848.31 MHz 1851.20 - 1908.75 MHz 2412.0 - 2462.5 MHz 2402.0 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23649-1F FCC ID: IHDT56LB1 Exhibit 11 Page 5 of 15 3. Test Equipment Used 3.1 Dosimetric System The Motorola Mobile Devices Business Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy4™ v4.7) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. All the SAR measurements are taken within a shielded enclosure. The overall 10 g RSS uncertainty of the measurement system is ±10.8% (K=1) with an expanded uncertainty of ±21.6% (K=2). The overall 1 g RSS uncertainty of the measurement system is ±11.1% (K=1) with an expanded uncertainty of ±22.2% (K=2). The measurement uncertainty budget is given in Appendix 5. Per IEEE 1528, this uncertainty budget is applicable to the SAR range of 0.4 W/kg to 10 W/kg. The list of calibrated equipment used for the measurements is shown in the following table. Description Serial Number Cal Due Dat…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 23649-1 Exhibit 6B - 1 Page 1 of 11 HAC Test Report for Near Field Emissions IHDT56LB1 Tests Requested By: Motorola Mobile Devices 600 N. US Highway 45 Libertyville, IL 60048 Date of Tests: Date of Report: Feb-24-2010 - Feb-25-2010 Mar-11-2010 Test Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, Illinois 60048 Report Author: Thomas Knipple Senior RF Engineer Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT56LB1 to which this declaration relates, complies with recommendations and guidelines per FCC 47 CFR §20.19. The measurements were performed to ensure compliance to ANSI C63.19- 2007. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) Results Summary: M Category = M4 ©Motorola, Inc. 2010 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 23649-1 Exhibit 6B - 1 Page 2 of 11 Table of Contents 1. INTRODUCTION ...................................................................................................................................................3 2. DESCRIPTION OF THE DEVICE UNDER TEST.............................................................................................3 3. TEST EQUIPMENT USED....................................................................................................................................4 4. VALIDATION .........................................................................................................................................................5 5. PROBE MODULATION FACTOR ......................................................................................................................6 6. TEST RESULTS......................................................................................................................................................8 7. MEASUREMENTS FOR CERTIFICATION OF 3G DEVICES.....................................................................11 Appendix 1: Details justifying the conversion to peak A1.1 Procedure for PMF measurements A1.2 0-span spectrum plots for PMF measurements Appendix 2: HAC Distribution Plots for Validation Appendix 3: HAC Distribution Plots for E-Field and H-Field Appendix 4: Motorola Uncertainty Budget A4.1 Motorola Uncertainty Budget for RF HAC testing A4.2 Probe Rotation Contributions to Isotropy Error Appendix 5: Pictures of Test Setup Appendix 6: Probe Calibration Certificates Appendix 7: Dipole Characterization Certificates APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 23649-1 Exhibit 6B - 1 Page 3 of 11 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed Hearing Aid Compatibility (HAC) measurements for the portable cellular phone (FCC ID IHDT56LB1). The portable cellular phone was tested in accordance with the ANSI C63.19-2007 standard. The test results presented herein clearly demonstrate compliance per FCC 47 CFR § 20.19. This report demonstrates compliance for near-field emissions only and not for Telecoil HAC performance compliance. 2. Description of the Device Under Test Table 1: Information for the Device Under Test Serial Number(s) LSOV290121, LSOV290109 Mode(s) of Operation CDMA 800 CDMA 1900 EV-DO Rev. A 800 EV-DO Rev. A 1900 Wi-Fi 802.11b/g/n Bluetooth Modulation Mode(s) QPSK QPSK QPSK QPSK BPSK GFSK Maximum Output Power Setting 25.0 dBm 25.0 dBm 25.0 dBm 25.0 dBm 20.5 dBm 10 dBm Duty Cycle 1:1 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.70 - 848.31 MHz 1851.20 - 1908.75 MHz 824.70 - 848.31 MHz 1851.20 - 1908.75 MHz 2412.0 - 2462.5 MHz 2402.0 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled Note: No Bluetooth profile exists in this phone that will allow a Bluetooth link while in a cellular call that passes audio to the earpiece. If the user had Bluetooth enabled and a link established, they could not be listening to the phone through the earpiece. Note: Wi-Fi capability is included in this phone without measurements for hearing aid compatibility based on the interim ruling by the FCC according to paragraph 37 of the Federal Register, Volume 3, Number 89, as of May 7, 2008. Users shall be informed of this via the product user guide per the same FCC ruling. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 23649-1 Exhibit 6B - 1 Page 4 of 11 3. Test Equipment Used The Motorola Mobile Devices Business Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (DASY4™ v4.7) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. All the HAC measurements are taken within a shielded enclosure. The measurement uncertainty budget is given in Appendix 4. The list of calibrated equipment used for the measurements is shown below. Table 2: Dosimetric System Equipment Description Serial Number Cal Due Date E-Field Probe ER3DV6R 2248 Jul-16-2010 DAE4 376 Mar-11-2010 H-Field Probe H3DV6 6074 Jul-16-2010 DAE4 699 Apr-27-2010 835 MHz Dipole CD835V3 1042 May-14-2010 1880 MHz Dipole CD1880V3 1059 Jul-16-2010 Table 3: Additional Test Equipment Description Serial Number Cal Due Date Power Supply 6623A US37360826 Aug-22-2010 Signal Generator E4438C MY45090104 Aug-22-2011 Amplifier ZHL-42-SMA 1040 3 dB Attenuator 8491A 50581 Sep-04-2010 Directional Coup…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 23649-1 Page 1 Exhibit 6B - 2 HAC Test Report for Telecoil IHDT56LB1 Date of test: Date of Report: Mar-10-2010 Mar-11-2010 Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, Illinois 60048 Test Responsible: Thomas Knipple Senior RF Engineer Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC IHDT56LB1 to which this declaration relates, complies with recommendations and guidelines FCC 47 CFR §20.19. The measurements were performed to ensure compliance to the ANSI C63.19-2007. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) Results Summary: T Category = T3 ©Motorola, Inc. 2010 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 23649-1 Page 2 Exhibit 6B - 2 Table of Contents 1. INTRODUCTION ...................................................................................................................................................3 2. DESCRIPTION OF THE DEVICE UNDER TEST.............................................................................................3 3. TEST EQUIPMENT USED....................................................................................................................................4 4. SIGNAL VERIFICATION .....................................................................................................................................7 5. TEST RESULTS......................................................................................................................................................8 5.1 Telecoil SNR Results ...............................................................................................................................8 5.2 Telecoil Environment Results...............................................................................................................11 6. MEASUREMENTS FOR CERTIFICATION OF 3G DEVICES.....................................................................13 APPENDIX 1: CONTOUR PLOTS........................................................................................................................14 APPENDIX 2: AMBIENT NOISE SPECTRUM PLOTS ....................................................................................19 APPENDIX 3: DETAILS ON THE MEASUREMENT SYSTEMS....................................................................22 APPENDIX 4: PICTURES OF TEST SETUP ......................................................................................................29 APPENDIX 5: MOTOROLA UNCETAINTY BUDGET ....................................................................................30 APPENDIX 6: AUDIO MAGNETIC PROBE CERTIFICATE ..........................................................................32 APPENDIX 7: AMCC CERTIFICATE (HELMHOLZ COIL)...........................................................................33 APPENDIX 8: HAC DISTRIBUTION PLOTS FOR E-FIELD AND H-FIELD ...............................................34 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LB1 23649-1 Page 3 Exhibit 6B - 2 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed Hearing Aid Compatibility (HAC) measurements for the portable cellular phone (FCC ID IHDT56LB1). The portable cellular phone was tested in accordance with ANSI/IEEE standard C63.19-2007. The test results presented herein clearly demonstrate compliance FCC 47 CFR § 20.19. This report demonstrates compliance for Telecoil performance only and not for RF near-field emissions. 2. Description of the Device Under Test Table 1: Information for the Device Under Test Serial Number(s) LSOV290121, LSOV290109 Mode(s) of Operation CDMA 800 CDMA 1900 EV-DO Rev. A 800 EV-DO Rev. A 1900 Wi-Fi 802.11b/g/n Bluetooth Modulation Mode(s) QPSK QPSK QPSK QPSK BPSK GFSK Maximum Output Power Setting 25.0 dBm 25.0 dBm 25.0 dBm 25.0 dBm 20.5 dBm 10 dBm Duty Cycle 1:1 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.70 - 848.31 MHz 1851.20 - 1908.75 MHz 824.70 - 848.31 MHz 1851.20 - 1908.75 MHz 2412.0 - 2462.5 MHz 2402.0 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled Note: No Bluetooth profile exists in this phone that will allow a Bluetooth link while in a cellular call that passes audio to the earpiece. If the user had Bluetooth enabled and a link established, they could not be listening to the phone through the earpiece. Note: Wi-Fi capability is included in this phone without measurements for hearing aid compatibility based on the interim ruling by the FCC according to paragraph 37 of the Federal Register, Volume 3, Number 89, as of May 7, 20…
