IHDT56LC1Portable Cellular/ PCS/ AWS CDMA Transceiver with Bluetooth

APPLICANT MOTOROLA INC. FCC ID: IHDT56LC1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 1 congratulations! Congratulations on your new MOTO TM WX404 CDMA wireless phone! Its rugged, sporty design fits your energetic lifestyle. Take pictures and video in a snap with the 1.3 megapixel camera with 4x digital zoom. Listen to your favorite music with the digital music player, and watch your music come to life with stunning visual effects. We’ve crammed all of the main features of your phone into this handy guide, and in a matter of minutes we’ll show you just how easy your phone is to use. So go on, check it out, and put your phone to work. more information To learn even more about your phone and accessories, go to www.motorola.com/support. Caution: Before using your phone for the first time, please read the important Safety, Regulatory & Legal information at the back of this guide (page 49). 2 this guide symbols in this guide This means a feature is network, SIM card, or subscription dependent and may not be available in all areas. Contact your service provider for more information. This means a feature requires an optional accessory. 3 contents your phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 settings menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 text entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Bluetooth® wireless. . . . . . . . . . . . . . . . . . . . . . . . . 36 cable connections. . . . . . . . . . . . . . . . . . . . . . . . . . . 39 memory card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42 tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 service & repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 49 your phone 4 your phone the important keys & connectors Power/ End Key Turn on/off, hang up, exit menus. Center Key Open menu & select. Right Soft Key Voice Key Clear/ Back Key Volume Keys Send Key Make & answer calls. Left Soft Key Smart Key Micro USB Connector Charge & connect to PC. 2.5 mm Headset Jack main menu 5 ma in me nu LPhonebook •New • Contact List • Groups • Speed Dial jMultimedia • Music & Sounds •Camera • Pictures •StorageDevice uSettings • (see next page) mTools • Voice Commands • Datebook •AlarmClock •WorldClock •Calculators • Notepad • Stopwatch ôBrowser gMessaging • Create Message • Conversations •Voicemail •Email* •IM* •Drafts —Music Player ÛPhone Info • My Number •SW/HWVersion • Icon Glossary GDatebook qRecent Calls • Received Calls • Missed Calls • Dialed Calls • All Calls •Timers JBrew àRingtones This is the standard main menu layout. Your phone’s menu may be different. * Optional and/or network dependent feature. Not available in all areas. settings menu 6 settings menu • Sounds • Easy Setup • Call Ringtone • Message Ringtone • Voicemail Ringtone • Ring and Vibrate • Alert Reminders • Service Alerts •PowerOn/Off • Voice Readout • Keypad Volume • Volume Sidekeys •Display • Easy Setup • Banner • Backlight • Brightness • Wallpaper •Skins •ClockFormat • Menu Font Size • Idle Shortcuts • Phone • Airplane Mode • Keypad Lock Settings • Language • Location • Security • Network Selection • ActiveLine* •TextLearning • Quick Contact Search • Contact List Search •Call • Answer Options • Auto Retry • TTY Setup • One Touch Dial • Int’l Dialing • DTMF Tones • Hearing Aid • Predefined Response • Bluetooth •AddNewDevice •USB •MassStorage • Modem/COM • Storage Device • Save Options * • Phone Memory •MemoryCard* • Phone Info • My Number •SW/HWVersion • Icon Glossary •SetupWizard * Optional and/or network dependent feature. Not available in all areas. let’s go 7 let’s go let’s get you up & running Caution: See Battery Use & Safety (page 49). 1cover off:2microSD: 3battery:4cover on: 5charge: 4H basics 8 basics here’s a few essentials turn it on & off Press and hold for a few seconds or until the screen lights up. make & answer calls To make a call, enter a phone number and press. To answer a call when your phone rings and/or vibrates, just press. During a call, you can press Mute, Spkr On, or pressOptions to select other in-call options (page 13). end a call To hang up, press. basics 9 menu navigation PressMenu to open the main menu (this may be the center key or a soft key, depending on your phone). Scroll the navigation key up, down, left, or right to scroll to a menu option. Press to select the highlighted option. If necessary, press to return to the home screen. basics 10 store contacts 1Enter a phone number in the home screen. 2PressSave. 3Set the number type (Mobile 1, Mobile 2, Home, Work, or Fax), and press. 4Enter contact details, and pressSave. (To enter text, see page 20.) call or text contacts Find it: Menu >LPhonebook >Contact List 1Scroll to the contact. Shortcut: To jump to a contact, enter the first few letters of the name. If a contact has more than one number,…

Text truncated - open the document above for the full version.

SPECIFICATION COMPLIANCE STATEMENT Transceiver type FCC ID: IHDT56LC1 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at: Motorola Mobile Devices Business Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 NAME: John Tuck TITLE: Engineering Manager CDMA Low Tier Engineering Date: December 3, 2009 APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LC1 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (FCC ID: IHDT56LC1) is in compliance with all applicable parts of the FCC Rules. NAME: Saqib Malik TITLE: Electrical Lead Engineer CDMA Low Tier Engineering Date: December 3, 2009 APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LC1 EXHIBIT 2 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Saqib Malik TITLE: Electrical Lead Engineer CDMA Low Tier Engineering Date: December 3, 2009 APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LC1 EXHIBIT 2

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LC1 December 16, 2009 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHD T56LC1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the Digital CDMA standard in the 800, 1700 and 1900 MHz PCS band. The unit also employs EVDO Release 0 and contains a 2.4 GHz Bluetooth functions (Part 15.247). The unit may be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LC1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHD T56LC1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Date: January 19, 2010 Subject: Request for additional information regarding FCC ID: IHDT56LC1 Reference: Correspondence Reference Number: IHD91457 Confirmation Number: 912021457 Date of Original Email: Dec. 17, 2009 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois 60048 Questions and responses follow: 1. Please provide RF conducted bandedge plots for the cellular band starting at points removed from both bandedges by 1 MHz with RBW = 100 kHz. Response: Please refer to the cellular Bandedge measurements submitted online. 2. The BT RE plots on pp. 9-13 show multiple emissions exceeding the limit line (at more than one frequency). Please provide tabular (peak and average) field strength data for these emissions. Response: Please refer to EX6A2-addendum submitted online. 3. The bandedge plots on pp.17-18 of the BT RE report appear to show peak emissions exceeding the average limit in the 2310-2390 MHz restricted band. Please provide average field strength data demonstrating compliance of these emissions. Response: Please refer to the average detector results in EX6A2-addendum submitted online. 4. Based on the measured tissue parameters listed on p.5 of the SAR report, the cellular band body tissue fluid parameters do not meet the tighter limits, however, p.11 contains corrected SAR values for cellular brain tissue permittivity compensation. Please provide the corrected levels for the cellular body SAR measurements. Response: Please refer to the updated SAR report submitted online. 1 2 5. The power data tables on p.7 of the SAR report show the need to test cellular body SAR (mid channel) in EvDO Rev.0 RTAP mode. Please provide this data. Response: Please refer to the updated SAR report submitted online. 6. The FCC ID in the HAC RF emissions and T-coil exhibits are incorrect. Please amend. Response: Please refer to the revised EX6B-1 and EX6B-2 submitted online.

Front view Back view Back view w/o Batt. door APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LC1 EXHIBIT 3 Left side view Right side view Top view Bottom view APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LC1 EXHIBIT 3

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LC1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDT56LC1

Front view PCB with Display Back view w/ shield-cover Front view PCB w/o Display Back view w/o shield-cover APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LC1 EXHIBIT 9 Front view Back Housing Back view Back Housing Back view Battery Door Front view Battery Door APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LC1 EXHIBIT 9 Front view Front Housing Back view Front Housing Front view Front Housing w/ Keypad Front view Front Housing w/o Keypad APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LC1 EXHIBIT 9 OJ Front view OJ Back view LCM Front view LCM back view Shield-cover Front view Shield-cover Back view Front view Keypad Back view Keypad APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LC1 EXHIBIT 9 OJ Holder Front view OJ Holder Front view SPK Rubber Front view SPK Rubber back view Vibrator Front and back view Headset Jack Rubber Front & back view Headset Jack Front & back view APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LC1 EXHIBIT 9

APPLICANT: MOTOROLA INC FCC ID: IHDT56LC1 Test Report Number: 23449-1 Supplement 1 of 11 EXHIBIT 6A4 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 23449-1 Supplement Report Date – November 12, 2009 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated. Signature: Name: Albert J. Patapack Title: EMC Engineer Date: November 12, 2009 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 2518-02 APPLICANT: MOTOROLA INC FCC ID: IHDT56LC1 Test Report Number: 23449-1 Supplement 2 of 11 EXHIBIT 6A4 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 APPLICANT: MOTOROLA INC FCC ID: IHDT56LC1 Test Report Number: 23449-1 Supplement 3 of 11 EXHIBIT 6A4 Test Report Details Tests Performed By: Motorola Mobile Devices business (MDb) Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 Motorola MDb FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: 109O-1 Tests Requested By: Motorola Inc. Mobile Devices business 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: CDMA 1700/2100/800/1900, CDMA 1X/EV-DO Release 0, Bluetooth Class 1.5, Version 2.1+EDR FCC ID: IHDT56LC1 Serial Numbers: A0000002CB02ABA Testing Complete Date: October 27, 2009 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 : X Part 15 Subpart B – Unintentional Radiators Applicable Standards: ANSI 63.4 2003, RSS-Gen Issue 2, RSS-210 Issue 7 APPLICANT: MOTOROLA INC FCC ID: IHDT56LC1 Test Report Number: 23449-1 Supplement 4 of 11 EXHIBIT 6A4 Summary of Testing Test Test Name # Pass/Fail _________ 1 Field Strength of Spurious Emissions Pass from Unintentional Radiators 2 AC Line Conducted Emissions Pass Test Test Name Margin with respect # to the Limit_________ 1 Field Strength of Spurious Emissions see results from Unintentional Radiators 2 AC Line Conducted Emissions see results The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The Cellular Phone hereinafter referred to as the Equipment under Test or EUT was tested using a fully charged battery. The temperature and the relative humidity were maintained within the ANSI C63.4 2003 Standard requirements during the entire duration of testing. APPLICANT: MOTOROLA INC FCC ID: IHDT56LC1 Test Report Number: 23449-1 Supplement 5 of 11 EXHIBIT 6A4 Equipment List Manufacturer Equipment Type Model No. Serial Number Calibration Due Date Rohde & Schwarz Receiver ESIB40 100226 1/30/2010 Rohde Schwarz Receiver ESI26 838786/010 5/01/2010 ETS DRG Horn Antenna SAS 200/571 265 4/29/2010 ETS Log-Periodic Antenna 3148 1189 6/12/2010 ETS Biconical Antenna 3110B 3370 10/02/2010 Attenuator Weinschel AS-6 6675 NCR Attenuator Weinschel AS-6 6677 NCR ETS LISN 3810/2NM 00062907 12/10/2009 ETS LISN 3810/2NM 00062912 12/10/2009 Dell Laptop Computer M20 NA NA Iomega Zip Drive Z250S P9HM1992CK NA Olympus Camera D-600L 4020727 NA All testing was performed using equipment that was within calibration at the time that the test was performed. No equipment listed in the table above was used after the specified calibration due date. If, during the course of product testing, a piece of equipment went out of calibration and that piece of equipment was needed to complete product testing, a similar piece of calibrated equipment was substituted. If a substitution was made, that new piece of equipment would be listed in the above table along with the piece that was removed from service. All equipment is on a one-year calibration cycle. The Dell M20 Laptop Computer, the Iomega Z250S Zip Drive and the Olympus D-600L Camera are labeled as DoC. APPLICANT: MOTOROLA INC FCC ID: IHDT56LC1 Test Report Number: 23449-1 Supplement 6 of 11 EXHIBIT 6A4 Measurement Procedures and Data FIELD STRENGTH OF EMISSIONS FROM UNINTENTIONAL RADIATORS Measurement Procedure The equipment under test is placed inside the semi-anechoic chamber on a wooden table on the turntable center. For each radiated emission, the antenna mast is raised and lowered from 1 to 4 meters and the turntable is rotated 360 degrees to obtain a maximum peak reading on the spectrum analyzer. The final radiated emissions are then measured using an EMI receiver employing a CISPR quasi-peak detector function below 1000 MHz and an average detector function above 1000 MHz. This is repeated for both horizontal and vertical polarizations of the receive antenna. The field strength of each radiated emission is calculated by correcting the EMI receiver level for cable loss, amplifier gain, and antenna correction factors. Field Strength (dBuV/m) = EMI Receiver Level (dBuV) + Cable Loss (dB) - Amplifier Gain (dB) + Antenna Correction Factor (1/m) Test Setup The EUT and the host equipment were setup according to the procedures in ANSI C63.4- 2003. The EUT was connected to a laptop computer using a USB data cable. The USB data cable is 1 m in length. The parallel and the serial ports of the computer were populated. The EUT was communicating with the laptop computer continuously. APPLICANT: MOTOROLA INC FCC ID: IHDT56LC1 Test Report Number: 23449-1 Supplement 7 of 11 EXHIBIT 6A4 Measurement Results Operating Mod…

Text truncated - open the document above for the full version.

EMC TEST SETUP PHOTOS EMC Report #23449 AC Line - Part 15 APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LC1 EXHIBIT 7 EMC Report #23449 Part 15, PC Peripheral APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LC1 EXHIBIT 7 EMC Report #23449Antenna - Substitution APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LC1 EXHIBIT 7 EMC Report #23449 Tx Radiated APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LC1 EXHIBIT 7
