IHDT56LD1Portable Cellular/ PCS WCDMA/ GSM/ EDGE Transceiver with WLAN and Bluetooth

APPLICANT MOTOROLA INC. FCC ID: IHDT56LD1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 MOTOROLA FLIPOUT TM with MOTOBLUR TM 1 Congratulations CongratulationsMOTOROLA FLIPOUT with MOTOBLUR Introducing the MOTOROLA FLIPOUT with MOTOBLUR - an innovative phone that's as unique as you are. Most intriguing is how its touch screen rotates on a hinge to expose a QWERTY keypad with a separate number row for easy.MOTOBLUR is the only service that can sync all your friends, emails, messages, Facebook™, MySpace, Twitter and happenings with continuous updates and back-ups, along with the ability to remotely locate and wipe your phone if its lost or stolen. Caution: Before assembling, charging or using your phone for the first time, please read the important legal and safety information packaged with your phone. Once your phone is up and running, touch Menu > Settings > About phone > Legal information to read the full information. More informationOn your phone —Touch Home > Help Center . On your computer —Go to www.mo torola .com/ . After you create a MOTOBLUR account, you can also log in and find help with MOTOBLUR: www.motorola.com /mymotoblur So, whether you want to read, watch, or play, we can help. 2 Congratulations Your phonethe important keys & connectors Home Key B ac k Key Menu Key To u c hs c reen Power Key Volume Keys Open m enu options. M ic ro USB Conne c tor Charge or connect to PC. Return to ho m e screen. 3.5mm He a dset J ac k Note: Your phone might look a little different. W hen you open or turn your phone, the screen adjusts for you. S c roll & Sele c t EnterOK S pac e Altern a te Sh i ft Delete Se a r c h Sym b ols 3 Let’s go Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 6Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . 11Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23Google Maps™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 30Wi-Fi™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 36Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39USB & memory card. . . . . . . . . . . . . . . . . . . . . . . . 42Synchronize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 50Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 51 Let’s golet’s get you up and runningAssemble & charge 1 Cover off 2 SIM in 3 MicroSD in (may already be inserted) 4 Battery in 5 Cover on 6 Charge up 3H 4 Let’s go Caution: Please read “Battery Use & Safety” on page 51.Set up & goCreate or log into a MOTOBLUR account to get your contacts, email, messages, and status information, for all your accounts, all in one place, all the time. There’s more in “Your MOTOBLUR account” on page 11. Registration is secure, and should only take a few minutes: 1 Tu r n o n . 2 Select a language. 3 Register or log in.Tip: Open your phone to type. If you have not created a MOTOBLUR account, you’ll need to register: Enter your name, your current email address (where MOTOBLUR can send account information), and a new MOTOBLUR account password. Pl eaea ssese c h oose a l angua ge Start E mer ge nc y ca ll Password Checking for data connectivity 5 Let’s go Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details.Turn it on & offTo turn on your phone, press and hold Power (on the right side of the phone).To turn off your phone, press and hold Power , then touch Power off . 4 Add your accounts to MOTOBLUR. To add an account, touch it. Then, enter the user name or email and password that you set up on that account.Tip: For more, or to add accounts anytime, go to “Add account” on page 11. 5 Import your SIM contacts. After you sign in, your phone will automatically start to import your SIM contacts. Facebook MySpaceMOTOBLUR Accounts Set up existing accounts Last FM Twitter Email Finished adding accounts If you use any of the services below, tap the icon to set it up or press and hold the icon for more details. 8:52 Wi-Fi connectIf you want to use a Wi-Fi computer network for even faster Internet access, touch Menu > Settings > Wireless & networks > Wi-Fi settings . Cool content & moreBrowse and download thousands of the coolest apps on the planet from Android Market™ (see “Apps for all” on page 29).Your phone comes with a microSD memory card installed—you can load it up with photos, videos, and music from your computer using “USB drag & drop” on page 42.SecurityYour contacts are backed-up on MOTOBLUR, so don’t worry. Even if you lose your phone, MOTOBLUR can help you find it or wipe it. And when you get your next MOTOBLUR product, your stored in…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA FCC ID: IHDT56LD1 Exhibit 13 January 24, 2010 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiv er, FCC ID: IHDT56LD1. Motorola is also the manufacturer of this equipment. Confidentiality : Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in the 850, 900,1800 and 1900 MHz PCS band. It also operates in WCDMA 850 and 1900 MHz and contains EDGE/GPRS Class 12, and 2.4 GHz Bluetooth & WLAN transmitters (Part 15.247). The unit may also be connected to a computer via a USB connection (Part 15 Class B Computing Device Peripheral). Note: This device also contains functions that are not operational in U.S. territories. This filing is only applicable for US operations. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LD1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHD T56LD1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Date: June 10, 2010 Subject: Request for additional information regarding FCC ID: IHDT56LD1 Reference: Correspondence Reference Number: IHD100475 Confirmation Number: 1Y1004190475 Date of Original Email: June 8, 2010 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois 60048 Questions and responses follow: 1. Please resubmit the user’s manual, including the required HAC language. RESPONSE: Please refer to the revised user’s manual submitted online. 2. Please submit a block diagram for the DTS transmitter listing all clock/oscillator values (p.3/4 of the Block Diagram document is a schematic, and does not appear to show the clock/oscillator values). RESPONSE: Please refer to the revised block diagrams submitted online. 3. The BT block diagram (p.2/4 of the Block Diagram document) does not list the clock/oscillator values. Please revise and resubmit. RESPONSE: Please refer to the revised block diagrams submitted online. 4. Please revise the tune- up procedure to include the max output power target levels set at the factory, along with the acceptable deviation from the target levels, for GSM and WCDMA operation (both bands). RESPONSE: Please see below: TRANSCEIVER ADJUSTMENTS / TUNE-UP PROCEDURE 1 There are no user accessible adjustments or tuning in this portable cellular transceiver. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service or repair are done as part of that process, as special equipment is required to perform such adjustments. Note: The conducted power levels in the SAR, EMC, and HAC reports (when applicable), are within +/- 0.2 dB of the maximum allowed factory value. The amplitudes of factory “target” levels are always lower. 5. The PCE EMC report, p.8/50, states that an “RMC” detector was used for the PCS GSM EIRP measurements. Should this be “RMS”? If so, please revise. If not, please explain what an RMC detector is. RESPONSE: Please refer to the revised PCE EMC report submitted online. 6. In the DTS conducted EMC report, p.19/45 states that these are “peak” output power measurements, however, the plots show “RM” on the left side, where “PK” is normally displayed. In addition, these are the same levels as those listed in the SAR report, where average measurement data is used. Are these actually RMS average measurements? I note that, in typical 802.11b/g configurations, the b mode avg levels exceed the g mode avg levels, as is the case here, but g mode peak levels typically exceed b mode peak levels. Please clarify. RESPONSE: Please refer to the revised Exhibit 6A5 submitted online. 7. In the DTS conducted EMC report, 802.11b conducted output power measurements were only performed at the lowest available data rate. Please confirm that the other data rates were also investigated, and that the data provided represents the highest levels. RESPONSE: Please refer to the revised Exhibit 6A5 submitted online. 8. DTS radiated emissions (RE) were measured in 802.11b mode at 11 Mbps, and 802.11g mode at 54 Mbps (p.5/40). Please justify these choices. Output power data was not provided at these data rates- were other data rates also investigated for RE? Please address. RESPONSE: The WLAN conducted power level is measured for all the data rates supported across all modes. The data rate with the higher conducted power level for each mode is evaluated for Conducted and Radiated requirements. Please refer to the revised DTS reports. 9. Please provide RF conducted bandedge plots for the DTS transmitter in the appropriate modes of operation, demonstrating compliance with the 20 dBc limit if output power was measured in peak mode, or with the 30 dBc limit if output 2 3 power was measured in avg mode (see question 6, above). RESPONSE: Please refer to the revised Exhibit 6A5 submitted online. 10. Page 4/84 of the SAR report lists a max output power level for 802.11 operation that exceeds the actual levels measured in the DTS EMC report by nearly 3 dB. Please address. RESPONSE: Please refer to the revised SAR report submitted online. 11. The SAR report shows multiple batteries available to the EUT. Please confirm that EMC measurements (ERP/EIRP/conducted output power) were investigated with all available batteries, and that the data submitted represents the worst case. Please revise the PCE, DTS and DSS test reports to indicate the specific battery used for testing. RESPONSE: All EMC testing was performed with Model SNN5819B - 1130 mAH Battery. This battery will be shipped with the EUT. All EMC test reports are updated to include the battery used. 12. Table 4 on page 5 of the HAC RFE report incorrectly lists "E-field Results" in the header of the second portion of the table. This portion of the table is providing "H-field" data, please revise. RESPONSE: Please refer to the revised HAC report submitted online. 13. FYI: as requested previously, in the future please provide data, such as output power and radiated emissions, for the DTS and DSS test reports, in tabular form, instead of submitting scores of plots (only the plots for the worst-case values need be submitted). This will greatly aid in reducing the amount of time required for review. RESPONSE: Noted.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LD1 EXHIBIT 3 FRONT OF PHONE BLADE OPEN BACK OF PHONE BLADE OPEN APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LD1 x FRONT OF PHONE BACK OF PHONE BACK OF PHONE WITH BATTERY COVER REMOVED EXHIBIT 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LD1 EXHIBIT 3 SIDE OF PHONE APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LD1 EXHIBIT 3

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LD1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDT56LD1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LD1 Main Board Bottom Without Shields Main Board Bottom With Shields EXHIBIT 9 1 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LD1 Main Board Top Without Popples Main Board Top With Popples EXHIBIT 9 2 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LD1 Blade Flex Blade LCD EXHIBIT 9 3 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LD1 EXHIBIT 9 4 of 4 Inside Back Housing Inside Front Housing

MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23612-1 Rev. B FCC ID: IHDT56LD1 Exhibit 11 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobile Devices 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 23612-1 Rev. B Date of Report: May-12-2010 Date of Test: Feb-11-2010 to Apr-13-2010 FCC ID #: IHDT56LD1 Generic Name: MRQ8-334411A11 Test Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Thomas Knipple Senior RF Engineer Accreditation: TESTING CERT #2518-02 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2010 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23612-1 Rev. B FCC ID: IHDT56LD1 Exhibit 11 Page 2 of 21 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 4 2.1 Antenna description 4 2.2 Device description 4 3. Test Equipment Used 5 3.1 Dosimetric System 5 3.2 Additional Equipment 5 4. Electrical parameters of the tissue simulating liquid 6 5. System Accuracy Verification 7 6. Test Results 8 6.1 Head Adjacent Test Results 10 6.2 Body Worn Test Results 16 References 21 Appendix 1: SAR distribution comparison for the system accuracy verification Appendix 2: SAR distribution plots for Phantom Head Adjacent Use Appendix 3: SAR distribution plots for Body Worn Configuration Appendix 4: Probe Calibration Certificate Appendix 5: Measurement Uncertainty Budget Appendix 6: Dipole Characterization Certificate MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23612-1 Rev. B FCC ID: IHDT56LD1 Exhibit 11 Page 3 of 21 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1 g average set in [3] and 2.0 W/kg in a 10 g average set in [2]. For ICNIRP (10 g), the final SAR reading for this phone is 0.36 W/kg for head-adjacent use and 0.62 W/kg for body-worn use. For ANSI / IEEE C95.1 (1 g), the final SAR reading for this phone is 0.61 W/kg for head-adjacent use and 1.06 W/kg for body-worn use. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 23612-1 Rev. B FCC ID: IHDT56LD1 Exhibit 11 Page 4 of 21 2. Description of the Device Under Test 2.1 Antenna description Type Internal Location Bottom of Transceiver Width 5 mm Dimensions Length 63 mm Configuration Cadillac 2.2 Device description Serial Number(s) LRTA390014, LRTA390069, LRTAA20089 Mode(s) of Operation GSM 850 GSM 900 GSM 1800 GSM 1900 WCDMA 850 WCDMA 1900 Wi-Fi 802.11b/g/n Bluetooth Modulation Mode(s) GSMK GSMK GSMK GSMK QPSK QPSK BPSK GFSK Maximum Output Power Setting 33.0 dBm 33.0 dBm 31.0 dBm 31.0 dBm 24.0 dBm 24.0 dBm 17.5 dBm 10 dBm Duty Cycle 1:8 1:8 1:8 1:8 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz 826.4 - 846.6 MHz 1852.4 - 1907.6 MHz 2412.0 - 2462.5 MHz 2402.0 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled Mode(s) of Operation GPRS 850 GPRS 900 GPRS 1800 GPRS 1900 Modulation GMSK GMSK GMSK GMSK Maximum Output Power Setting 33.0 31.0 29.0 27.0 33.0 31.0 29.0 27.0 31.0 29.0 27.0 25.0 31.0 29.0 27.0 25.0 Duty Cycle 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz Mode(s) of Operation EDGE 850 EDGE 900 EDGE 1800 EDGE 1900 Modulation 8PSK 8PSK 8PSK 8PSK Maximum Output Power Setting 27.5 25.5 23.5 21.5 27.5 25.5 23.5 21.5 26.5 24.5 22.5 20.5 26.5 24.5 22.5 20.5 Duty Cycle 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz Note: Bolded entries indicate data mode configurations of highest time-average pow…
