IHDT56LE2Portable Cellular/ PCS WCDMA/ GSM/ EDGE Transceiver with WLAN and Bluetooth

APPLICANT MOTOROLA INC. FCC ID: IHDT56LE2 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 Your Phone 1 DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION Your PhoneMost of what you need is in the touchscreen and three simple keys: “Menu, home, search, & back” on page 6. M ic ro p hone Menu Home M ic ro USB Connect charger or PC Charged or new m essage Volume3.5mm He a dset C a mer a B ac k Power / Lo c k Press= sleep Hold= power Se a r c h To u c h P a d When you open your phone, the screen rotates:Note: Your phone might look a little different. Tip: Your phone can automatically switch to vibrate mode whenever you place it face-down. To change this, touch Menu > Settings > Sound & display > Smart Profile: Face Down to Vibrate . DeleteNew L i ne S c roll/ Sele c t Sh i ft Altern a te Menu B ac k Se a r c h Press=textHold=voiceS pac e Sym b ols DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION Device Setup 2Device SetupAssemble & Charge 1. Cover off 2. SIM in 3. Battery in 4. Cover on 5. Charge up 6. Power up & log in Caution: Before assembling, charging or using your phone for the first time, please read the Safety, Regulatory, & Legal Information provided with your phone. Start MOTOBLURWhen you first turn on your phone, you need to create or log into your MOTOBLUR account . MOTOBLUR brings together your contacts, email, messages, and status information from your other accounts. It then updates all of your accounts when you make changes. Registration is secure and should only take a few minutes: 1. Press and hold Power on top of your phone to turn it on. 2. Select a language. 3. Log in or register: Enter your name, your current email address (where MOTOBLUR can send account information), and a new MOTOBLUR account password. 4. To add an account to MOTOBLUR, touch the account type, then enter the account’s user name (or email) and password. 5. After you sign in, touch Contacts , then touch Menu > Settings > Manage SIM card > Import SIM card . Touch OK to import your SIM contacts. Tip: To see the accounts you added, touch Menu > Settings > Accounts . Device Setup 3 DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION Your MOTOBLUR AccountYou can log into your MOTOBLUR account from a computer to upload contacts, reset your password, get help, or even locate your phone: www.motorola.com/mymotoblurWhat is MOTOBLUR?Only MOTOBLUR syncs contacts, posts, feeds, messages, e-mails, photos and much more—from sources like Facebook, Twitter, MySpace, your work e-mail, Picasa, Photobucket—and automatically serves it up just the way you want it. No opening and closing apps and menus, it’s all front and center on your home screen and integrated throughout the entire phone so you can communicate anyway you like.Cool Content & MoreBrowse and download thousands of the coolest apps on the planet from Android. On top of that, you get a full HTML browser, so you can surf in style.Your phone comes with a microSD memory card installed—you can load it up with photos, videos, and music from your computer using “USB Drag & Drop” on page 37.Note: Do not remove your memory card while your phone is using it or writing files on it. SecurityYour contacts are backed-up on MOTOBLUR, so don’t worry. Even if you lose your phone, MOTOBLUR can help you find it or wipe it. When you get your next MOTOBLUR product, your stored info makes it a snap to set up with just a username and password.Of course it doesn't stop there. There are plenty of ways to protect your phone and your information, in “Security” on page 40. DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION Ringtones & Settings 4Ringtones & SettingsQuick Start: Ringtones & SettingsYou can customize sound and display settings:• To set your ringtone and notifications, touch Menu > Settings > Sound & display . To use a song as a ringtone, touch > AT&T Music > Music Player , touch and hold the song name, then touch Use as phone ringtone . • To switch to silent mode when you have Screen lock turned on, you can slide the silence switch on the unlock screen., You can also try Menu > Settings > Sound & display > Double-Tap to Silence or Smart Profile: Face Down to Vibrate . • To set different notifications for message types, touch > Messaging > Menu > Messaging Settings > Text Messaging , Email , or Social Messaging . • To set your display brightness, orientation, wallpaper, and more, touch Menu > Settings > Sound & display . SoundsDisplayYou can set your display brightness, orientation, wallpaper, and more.Find it: Menu > Settings > Sound & display Quick Launch ShortcutsTo use a quick launch shortcut, press Search and the assigned key, like Search and B to launch the browser. To...set volume for media and videos Menu > Settings > Sound & display > Media volume hear tones when you dial numbers Menu > Settings > Sound & display > Audible touch tones hear sounds when you select screen items Menu > Settings > Sound & display > Audible selection Touchscreen & Keys 5 DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION DRAFT - MOTOROLA CONFIDENTIAL & PROPRIETARY INFORMATION Date & TimeSet date, time, time zone, and formats:Find it: Menu > Settings > Date & time Language & RegionSet your menu language and region:Find it: Menu > Settings > Language & keyboard > Select locale Touchscreen & KeysTouchscreen TipsIf your screen goes to sleep, press Power to wake it up.TouchpadYou can use the touchpad to select small items in the display (like a small link on a web page), or control a game without blocking Kristine KelleyNot even ready to go back to school 10 minutes ago No meetings this week THU 08 JUL Browser Messaging g o b ac k t o sc h oo l bkt h l 10 minutes a go Kristine Kelle y y Not even read y t t hi s w …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LE2 Page 1 of 3 EXHIBIT 2 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDT56LE2) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Tom Kim TITLE: Engineering Manager Motorola Mobile Devices Business Date: June 23, 20010 APPLICANT: MOTOROLA INC. FCC ID: IHDT56LE2 Page 2 of 3 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56LE2) is in compliance with all applicable parts of the FCC Rules. NAME: Tom Kim TITLE: Engineering Manager Motorola Mobile Devices Business Date: June 23, 2010 APPLICANT: MOTOROLA INC. FCC ID: IHDT56LE2 Page 3 of 3 EXHIBIT 2 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Tom Kim TITLE: Engineering Manager Motorola Mobile Devices Business Date: June 23, 2010

APPLICANT: MOTOROLA FCC ID: IHDT56LE2 Exhibit 13 January 24, 2010 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiv er, FCC ID: IHDT56LE2. Motorola is also the manufacturer of this equipment. Confidentiality : Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in the 850, 900, 1800 and 1900 MHz PCS band. It also operates in WCDMA 850 and 1900 MHz and contains EDGE/GPRS Class 12, and 2.4 GHz Bluetooth & 802.11b/g functions (Part 15.247). The unit may also be connected to a computer via a USB connection (Part 15 Class B Computing Device Peripheral). Note: This device also contains functions that are not operational in U.S. territories. This filing is only applicable for US operations. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDT56LE 2 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Date: July 28, 2010 Subject: Request for additional information regarding FCC ID: IHDT56LE2 Reference: Correspondence Reference Number: IHD91457 Confirmation Number: Y1007160852-5 Date of Original Email: July 22, 2010 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois 60048 Questions and responses follow: 1. Please submit block diagrams for the DTS and DSS (WLAN and BT) transmitters that provide some detail of their RF sections. Response: Please refer to the revised block diagrams submitted online. 2. In the Confidentiality Request letter, the Description of the EUT does not include its DTS (WLAN) transmitter- please revise. Response: Please refer to the revised cover letter submitted online. 3. The HAC Key Feature list does not include WiFi capability- please revise. Response: Please refer to the revised HAC feature list submitted online. 4. Please revise the tune- up procedure to include the maximum power levels set at the factory, including the acceptable tolerance, for each licensed emission type and band. Response: Please refer to the revised tune-up procedure submitted online. 5. Please provide PCS WCDMA bandedge plots, starting 1 MHz removed from both bandedges and using RBW = 1 MHz. Response: Please refer to the cellular Bandedge measurements submitted online. 1 2 6. The DTS EMC test report only presents data for the various tests at certain specific data rates. Please confirm that all data rates were investigated, and that the data submitted represent the worst-case results. Response: Please refer to the revised DTS EMC report submitted online. 7. Please provide DTS (WLAN) bandedge plots (peak detector, RBW = 100 kHz) demonstrating compliance, in both b and g modes, with the 20 dBc limit. Response: Please refer to the revised DTS EMC report submitted online. 8. Please identify the data rates used to produce the DTS radiated emission data. Please confirm that all data rates were investigated, and that the data submitted represent the worst-case results. Response: Confirmed and please refer to the revised DTS radiated report submitted online. 9. Page 7 of T-coil Exhibit 6B-2 has a typo. Table 3 should indicate "GSM/WCDMA". Response: Please refer to the revised Exhibit 6B-2 submitted online.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 3 FRONT OF PHONE BACK OF PHONE Slider Close APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 3 FRONT OF PHONE BACK OF PHONE Slider Open APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 3 Bottom View APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 3 SIDE OF PHONE

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LE2 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDT56LE2

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 9 1 of 9 Bottom View APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 9 2 of 9 Take off Case D
 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 9 3 of 9 Flip + Keypad PCB + Main PCB

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 9 4 of 9 Main PCB Main Board Bottom With Shields Main Board Bottom Without Shields Main Board Top With Shields Main Board Top Without Shields APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 9 5 of 9 Keypad PCB Keypad Board Top Keypad Board Bottom APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 9 6 of 9 Keypad PCB without FPC/camera/conducted cloth/popples (keypad metal dome) Keypad Board Top Keypad Board Bottom APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 9 7 of 9 Case C + Flip

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 9 8 of 9 Case B with Slide FPC + Case A with Slide PCB ,LCDM Case B with Slide FPC Case A with Slide PCB and LCM



         APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LE2 EXHIBIT 9 9 of 9 Slide PCB Case A Top of Slide PCB Bottom of Slide PCB

APPLICANT: MOTOROLA INC FCC ID: IHDT56LE2 Test Report Number: 23805-1 Supplement 1 of 9 EXHIBIT 6A4 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 23805-1 Supplement Report Date – 2010-03-25 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Signature: Name: Lei Yang Title: EMC Project Manager Test: 2010-03-01 to 2010-03-25 As the responsible test lab manager, I hereby declare that the model tested as specified in this report conforms to the requirements indicated. Signature: Name: Yilin Zhao Title: Test Lab Manager Date: 2010-05-21 This report must not be reproduced, except in full, without written approval from this laboratory. FCC Registration Number: 177885 IC Registration Number: 109AW-1 ADR Testing Service location ADR BJ ISO/IEC-17025:2005 accredited by UKAS 2404 APPLICANT: MOTOROLA INC FCC ID: IHDT56LE2 Test Report Number: 23805-1 Supplement 2 of 9 EXHIBIT 6A4 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 APPLICANT: MOTOROLA INC FCC ID: IHDT56LE2 Test Report Number: 23805-1 Supplement 3 of 9 EXHIBIT 6A4 Test Report Details Tests Performed By: Motorola (China) Technologies Ltd. Asia Global Compliance Labs No. 1 Wang Jing East Road, Chao Yang District Beijing, 100102, P. R. China Phone: +86 10 8473 2610 FCC Registration Number: 177885 IC Registration Number: 109AW-1 Tests Requested By: Motorola Inc. Mobile Devices business 600 North US Hwy 45 Libertyville, IL 60048 United States Product Type: Cellular Phone Signaling Capability: WCDMA 850/1900, GSM 850/900/1800/1900, HSDPA 7.2 Mbps (Category 7/8), EDGE Class12, GPRS Class 12, HSUPA 2.0 Mbps, eCompass/aGPS, Bluetooth, 802.11b/802.11g FCC ID: IHDT56LE2 IMEI: 351553040000039 Testing Complete Date: 03-25-2010 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47: X Part 15 Subpart B – Unintentional Radiators Applicable Standards: ANSI C63.4-2003, RSS-Gen Issue 2 APPLICANT: MOTOROLA INC FCC ID: IHDT56LE2 Test Report Number: 23805-1 Supplement 4 of 9 EXHIBIT 6A4 Summary of Testing Test Test Name # Pass/Fail _________ 1 Field Strength of Spurious Emissions Pass from Unintentional Radiators 2 AC Line Conducted Emissions Pass Test Test Name Margin with respect # to the Limit_________ 1 Field Strength of Spurious Emissions see results from Unintentional Radiators 2 AC Line Conducted Emissions see results The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The EUT was tested using a fully charged battery. All testing was done in an indoor controlled environment. The temperature and the relative humidity were maintained within the ANSI C63.4-2003 Standard requirements during the entire duration of testing. APPLICANT: MOTOROLA INC FCC ID: IHDT56LE2 Test Report Number: 23805-1 Supplement 5 of 9 EXHIBIT 6A4 Equipment List Through the test, the EUT was installed in an evaluation board. Equipment Model/type Serial numberOperational range Date of calibration EMI analyzers ESU 40 100036 20 Hz – 40 GHz 05.16.2010 PA-02-0001: 2007343 (10 kHz – 3 GHz) 06.26.2009 PA-02-218 2007344 3 GHz – 18 GHz 06.26.2009 Pre Amplifiers PA-02-5 2007345 18 GHz – 40 GHz 06.26.2009 Radio com. Tester CMU 200 112790 GSM 850/900/1800/1900 UMTS, CDMA, Bluetooth N/A WRCD N/A GSM 850/900/1800/1900 UMTS, CDMA N/A Band Reject Filter 4N45-24241/3/6 N/A WLAN N/A EMI analyzers R&S ESCI 100650 9 kHz – 3 GHz 03.08.2010 LISN ENV216 100057 9 kHz – 30 MHz 12.20.2008 The antennas used in the various tests are listed in the below table. Antenna Type Serial number Operational range Date of calibration Hybrid-log periodic TDK HLP 3003C 130361 30 MHz – 3 GHz 11.07.08 Double ridged Horn TDK HRN0118130303 1 GHz – 18 GHz 03.26.09 Double ridged Horn ETS HRN3116 0007193818 GHz – 40 GHz 10.17.08 All test equipment was within their calibration date during the time of testing. When equipment went out of calibration during testing it was replaced using a similar piece of calibrated equipment. All these equipments are listed in the equipment list. The LISN is on a two-year calibration cycle. The antennas are on a three-year calibration cycle. All other equipments are on a one-year calibration cycle. The Dell D620 Laptop Computer, D-Link DI-624+A Router and the Sony D-600 L Camera are labeled as DoC. APPLICANT: MOTOROLA INC FCC ID: IHDT56LE2 Test Report Number: 23805-1 Supplement 6 of 9 EXHIBIT 6A4 Measurement Procedures and Data FIELD STRENGTH OF EMISSIONS FROM UNINTENTIONAL RADIATORS Measurement Procedure The equipment under test is placed inside the semi-anechoic chamber on a Styrofoam table on the turntable center. For each radiated emission, the antenna mast is raised and lowered from 1 to 4 meters and the turntable is rotated 360 degrees to obtain a maximum peak reading on the spectrum analyzer. The final radiated emissions are then measured using an EMI receiver employing a CISPR quasi-peak detector function below 1000 MHz and an average detector function above 1000 MHz. This is repeated for both horizontal and vertical polarizations of the receive antenna. The field strength of each radiated emission is calculated by correcting the EMI receiver level for cable loss, amplifier gain, and antenna correction factors. Field Strength (dBuV/m) = EMI Receiver Level (dBuV) + Cable Loss (dB) - Amplifier Gain (dB) + Antenna Correction Factor (1/m) Test Setup The EUT and the host equipment were setup according to the procedures in ANSI C63.4- 2003. The EUT was connected to a laptop computer using a USB data cable. The USB data cable is 1 m in lengt…

Text truncated - open the document above for the full version.

EMC TEST SETUP PHOTOS Radiated Emissions Radiated Emissions – Computer Peripheral APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LE2 EXHIBIT 7 AC Line Conducted Emissions AC Line Conducted Emissions – Computer Peripheral APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LE2 EXHIBIT 7
