IHDT56LG1GSM 850/1900 TRANSCEIVER W/EDGE, BT & WLAN

APPLICANT MOTOROLA INC. FCC ID: IHDT56LG1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 User’s Guide MOTO MT810 TM Please note:This draft documents features as they were available and functioning at the time of production (software version BHTD_N_02.03.34I). 1 Congratulations CongratulationsMOTOROLA MT810 The MOTOROLA MT810 lets you multi-task with premium business features and provides a rich multimedia and browsing experience.• Dual touch experience—finger touch on outer flip screen, stylus touch on inner screen. • Don’t miss your favorite program, watch TV when and where you want (“Mobile TV” on page 29). • Surf the Internet to your heart’s content (“Web” on page 29). • Enjoy yourself with powerful features, such as, Mobile Market , Fetion , 139Mail , Monternet , DCD , Navigation and Mobile Stock (“Apps for all” on page 32). • Business features— Mobile Reader , Notes , Dictionary , and Business Card Reader . Caution: Before assembling, charging or using your phone for the first time, please read the important legal and safety information at the back of this guide. Once your phone is up and running, Home > Settings > About phone > Legal information to read the open source notice and platform information. More•Answers:• Accessories: Find accessories for your phone at www.motorola.c om/products . 2 Congratulations Your phonethe important keys & connectors M ic ro USB Conne c tor Charge or connect to headset or PC. Fl ip To u c hs c reen Power KeyPress to put the display to sleep, or hold to turn off. Stylus C a mer a (on bac k of p hone) Note: Your phone might look a little different. Volume Keys C a mer a Key T a sk M a n ag er Key Menu Key Home Key B ac k Key Front C a mer a Phone Tou c hs c reen Antenn a M ic ro p hone 3 Let’s go ContentsYour phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 21Business tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25Mobile TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 32Wi-Fi™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34USB & memory card. . . . . . . . . . . . . . . . . . . . . . . . 35Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 41Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 42 Let’s golet’s get you up and runningAssemble & charge Caution: See “Battery Use & Safety” on page 42“ . 1 cover off 2 SIM in 3 battery in 4 microSD in 5 cover on 6 charge up 3H 4 Let’s go Turn it on & offTo turn on your phone, press Power (on the top right).To turn off your phone, press and hold Power , then touch Power off in the menu that opens.Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details.Wi-Fi connectIf you want to use a Wi-Fi network for even faster Internet access, press Home > Settings > Wireless Lan Settings . Touch WLAN to turn on, search for and connect to wireless networks. There’s more in “Wi-Fi™” on page 34.Cool content & moreBrowse and download thousands of the coolest apps on the planet from the Internet. On top of that, you get a full HTML browser, so you can surf in style.Download new apps from the “Web” on page 29. Your phone comes with 122 MB of internal memory, and an optional microSD memory card (upto 16 GB) can be installed—you can load it up with photos, videos, and music from your computer using “USB drag & drop” on page 35.SecurityThere are plenty of ways to protect your phone and your information, in “Security” on page 39. 5 Touchscreen & keys Touchscreen & keysa few essentialsTouch tipsHere are some tips on how to navigate around your phone. With the flip closed, you can use your finger to touch the flip touchscreen. With the flip open, use the stylus to touch the phone touchscreen.To u chTo choose an icon or option, touch it. Try it: In the home screen, touch Contacts . Touch & holdTo open special options, touch and hold an icon or other item. Try it: In the home screen, touch Contacts , then touch and hold a contact to open options. Phone Mobile TV Mobile Stocks Contacts Messaging My PIM Phone book CMCC STK Apps Mobile Read. SIM Phone book CMCC Andrew CarmodyAllen SmithAnu ShahAndrea Shunney Alex Pico Angelique BukvicAshok HemdevSIM - 1112223333SIM - 3334445555SIM - 2552552525SIM - 2223334444 SIM - 8887773333 Please input name All A Frequent Groups SIM - 3223223232SIM - 4554554545 Voice callVideo callIP callSend msgSend contactDelete Alex Pico Phone book CMCC DragTo scroll through a list or move slowly, drag across the touchscreen. Try it: In the home screen, touch Contacts , then dra…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LG1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDT56LG1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Chu Wang TITLE: Engineering Manager Motorola Mobile Devices Business Date: 2010-05-06 Page 1 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDT56LG1 Page 2 of 3 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56LG1) is in compliance with all applicable parts of the FCC Rules. NAME: Chu Wang TITLE: Engineering Manager Motorola Mobile Devices Business Date: 2010-05-06 APPLICANT: MOTOROLA INC. FCC ID: IHDT56LG1 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Chu Wang TITLE: Engineering Manager Motorola Mobile Devices Business Date: 2010-05-06 Page 3 of 3 EXHIBIT 2

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LG1 May 6, 2010 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56LG1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM transceiver operating in the 850 and 1900 MHz PCS band, it also has the capability to operate in the TD-SCDMA standard in both the 2010 and 2025 MHz band. The unit contains a 2.4 GHz Bluetooth and 802.11b&g functions(Part 15.247). The unit may also be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LG1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDT56 LG1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LG1 EXHIBIT 3 FRONT OF PHONE BACK OF PHONE BACK OF PHONE WITH BATTERY COVER REMOVED APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LG1 EXHIBIT 3 SIDE OF PHONE APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LG1 EXHIBIT 3

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LG1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDT56LG1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LG1 Main Board Bottom Without Shields Main Board Bottom With Shields EXHIBIT 9 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LG1 Main Board Top Without Shields Main Board Top With Shields EXHIBIT 9 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LG1 Daughter Board Bottom Daughter Board Top EXHIBIT 9 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LG1 EXHIBIT 9 Inside Front Housing Inside Back Housing

APPLICANT: MOTOROLA LTD FCC ID: IHDT56LG1 Test Report Number: 23633-1 Supplement 1 of 9 EXHIBIT 6A4 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 23633-1 Supplement Report Date – 2010-03-08 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Signature: Name: Lei Yang Title: EMC Project Manager Test: 2010-02-22 to 2010-03-08 As the responsible test lab manager, I hereby declare that the model tested as specified in this report conforms to the requirements indicated. Signature: Name: Yilin Zhao Title: Test Lab Manager Date: 2010-05-14 This report must not be reproduced, except in full, without written approval from this laboratory. FCC Registration Number: 177885 IC Registration Number: 109AW-1 ADR Testing Service location ADR BJ ISO/IEC-17025:2005 accredited by UKAS 2404 APPLICANT: MOTOROLA LTD FCC ID: IHDT56LG1 Test Report Number: 23633-1 Supplement 2 of 9 EXHIBIT 6A4 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 APPLICANT: MOTOROLA LTD FCC ID: IHDT56LG1 Test Report Number: 23633-1 Supplement 3 of 9 EXHIBIT 6A4 Test Report Details Tests Performed By: Motorola (China) Technologies Ltd. Asia Global Compliance Labs No. 1 Wang Jing East Road Chao Yang District Beijing, 100102, P. R. China Phone: +86 10 8473 2610 FCC Registration Number: 177885 IC Registration Number: 109AW-1 Tests Requested By: Motorola (China) Technologies Ltd. Mobile Devices business No.1 Wangjing East Road Chao Yang District Beijing, 100102, P. R. China Product Type: Cellular Phone Signaling Capability: GSM 850/900/1800/1900, TD-SCDMA 2010/2025, HSDPA 2.8 Mbps (Category 15), EDGE Class 10, GPRS Class 10, Standalone GPS/aGPS, Bluetooth, 802.11b/802.11g FCC ID: IHDT56LG1 IMEI: 35155304000001, 351553040000013 Testing Complete Date: 03-08-2010 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47: X Part 15 Subpart B – Unintentional Radiators Applicable Standards: ANSI C63.4-2003, RSS-Gen Issue 2 APPLICANT: MOTOROLA LTD FCC ID: IHDT56LG1 Test Report Number: 23633-1 Supplement 4 of 9 EXHIBIT 6A4 Summary of Testing Test Test Name # Pass/Fail _________ 1 Field Strength of Spurious Emissions Pass from Unintentional Radiators 2 AC Line Conducted Emissions Pass Test Test Name Margin with respect # to the Limit_________ 1 Field Strength of Spurious Emissions see results from Unintentional Radiators 2 AC Line Conducted Emissions see results The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The EUT was tested using a fully charged battery. All testing was done in an indoor controlled environment. The temperature and the relative humidity were maintained within the ANSI C63.4-2003 Standard requirements during the entire duration of testing. APPLICANT: MOTOROLA LTD FCC ID: IHDT56LG1 Test Report Number: 23633-1 Supplement 5 of 9 EXHIBIT 6A4 Equipment List Through the test, the EUT was installed in an evaluation board. Equipment Model/type Serial number Operational range Date of calibration EMI analyzers ESU 40 100036 20 Hz – 40 GHz 05.15.2009 PA-02-0001: 2007343 (10 kHz – 3 GHz) 06.26.2009 PA-02-218 2007344 3 GHz – 18 GHz 06.26.2009 Pre Amplifiers PA-02-5 2007345 18 GHz – 40 GHz 06.26.2009 Radio com. Tester CMU 200 112790 GSM 850/900/1800/1900 UMTS, CDMA, Bluetooth N/A WRCD N/A GSM 850/900/1800/1900 UMTS, CDMA N/A Band Reject Filter 4N45-24241/3/6 N/A WLAN N/A EMI analyzers R&S ESCI 100650 9 kHz – 3 GHz 03.07.2010 LISN ENV216 100055 9 kHz – 30 MHz 12.19.2008 The antennas used in the various tests are listed in the below table. Antenna Type Serial number Operational range Date of calibration Hybrid-log periodic TDK HLP 3003C 130361 30 MHz – 3 GHz 11.07.08 Double ridged Horn TDK HRN0118130303 1 GHz – 18 GHz 03.26.09 Double ridged Horn ETS HRN3116 0007193818 GHz – 40 GHz 10.17.08 All test equipment was within their calibration date during the time of testing. When equipment went out of calibration during testing it was replaced using a similar piece of calibrated equipment. All these equipments are listed in the equipment list. The LISN is on a two-year calibration cycle. The antennas are on a three-year calibration cycle. All other equipments are on a one-year calibration cycle. The Dell D620 Laptop Computer, D-Link DI-624+A Router and the Sony D-600 L Camera are labeled as DoC. APPLICANT: MOTOROLA LTD FCC ID: IHDT56LG1 Test Report Number: 23633-1 Supplement 6 of 9 EXHIBIT 6A4 Measurement Procedures and Data FIELD STRENGTH OF EMISSIONS FROM UNINTENTIONAL RADIATORS Measurement Procedure The equipment under test is placed inside the semi-anechoic chamber on a Styrofoam table on the turntable center. For each radiated emission, the antenna mast is raised and lowered from 1 to 4 meters and the turntable is rotated 360 degrees to obtain a maximum peak reading on the spectrum analyzer. The final radiated emissions are then measured using an EMI receiver employing a CISPR quasi-peak detector function below 1000 MHz and an average detector function above 1000 MHz. This is repeated for both horizontal and vertical polarizations of the receive antenna. The field strength of each radiated emission is calculated by correcting the EMI receiver level for cable loss, amplifier gain, and antenna correction factors. Field Strength (dBuV/m) = EMI Receiver Level (dBuV) + Cable Loss (dB) - Amplifier Gain (dB) + Antenna Correction Factor (3/m) Test Setup The EUT and the host equipment were setup according to the procedures in ANSI C63.4- 2003. The EUT was connected to a laptop computer using a USB …

Text truncated - open the document above for the full version.

EMC TEST SETUP PHOTOS Radiated Emissions Radiated Emissions – Computer Peripheral APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LG1 EXHIBIT 7 AC Line Conducted Emissions AC Line Conducted Emissions – Computer Peripheral APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LG1 EXHIBIT 7
