IHDT56LQ1CDMA 1900 TRANSCEIVER WITH BLUETOOTH

APPLICANT MOTOROLA INC. FCC ID: IHDT56LQ1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 MOTOROLA RAMBLER TM User’s Guide 1 Congratulations CongratulationsThanks for purchasing the MOTOROLA RAMBLER TM wireless phone! It’s an affordable phone with a sleek design that’s sure to get attention.Impressive Inside and Out. Sleek styling with all the right features, including rich imaging and multimedia. Take pictures and videos in a snap with the 1.3 megapixel camera with 4x digital zoom (see page 27).Messaging is Easy. Your phone’s full QWERTY keypad makes text entry quick and easy (see page 19). Your text message conversations look like IM exchanges (see page 24).My Phone, My Way. It’s your phone—make it that way. Customize your home screen with personal pictures (see page 12). Set different ringtones to identify calls from different contacts (see page 22). Caution: Before assembling, charging or using your phone for the first time, please read “Safety, Regulatory & Legal” on page 35. ContentsYour phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2Menu map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Get started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4Basics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33Bluetooth® connections . . . . . . . . . . . . . . . . . . . . . 33Service & repairs . . . . . . . . . . . . . . . . . . . . . . . . . . . 34Safety, Regulatory & Legal. . . . . . . . . . . . . . . . . . . . 35 2 Contents Your phone Center Sele c t Key Open m enu & select options. N a v iga t i on Key R ig ht Soft Key Left Soft Key Power/End Key Power up, end calls, exit m enus. C a ll Key Call & answer. Cle a r/B ac k Key C a mer a Key Extern a l D i s p l a y See inco m ing calls & status infor m ation. 2.5mm He a dset J ac k Vo ic e Key C a mer a Lens Volume Keys S p e a ker Key M i n i USB Conne c tor Charge & connect to PC. Vo ic e Key S pac e Key Sym b ol/ CAPS Key S p e a ker Key Delete Key L i ne Bre a k Key Fun c t i on Key Browser Key Mess agi n g Key 3 Menu map Menu map Main menu Contacts •New• Contact List• Groups• Speed Dial Messaging •Voicemail• Create Message• Conversations• Outbox•Drafts•Email•IM My StuffRe-BoostHistory • Received Calls• Missed Calls• Dialed Calls• All Calls•Timers Get Stuff Multimedia • Ringtones & Sounds • Camera•Pictures• Camcorder• Videos• Storage Device WebSettings •(see Settings menu ) Bluetooth®NavigationTo o l s • Voice Commands• Datebook•Alarm Clock•World Clock• Calculator•Notepad This is the standard main menu layout. Your phone’s menu may be different. Settings menu• Sounds • Call Ringtone• Message Ringtone• Voicemail Ringtone• Ring & Vibrate• Alert Reminders• Service Alerts• Power On/Off• Voice Readout• Keypad Volume• Volume Sidekeys •Display • Banner• Backlight• Brightness• Wallpaper•Skins•Clock Format • Phone • Airplane Mode• Shortcuts• Language• Location•Security• Active Line• Text Learning •Call • Answer Options•Auto Retry•TTY Setup• One Touch Dial• Int’l Dialing• DTMF Tones•Hearing Aid •Bluetooth • Add New Device •USB • Connect to PC• Mass Storage •StorageDevice • Phone Memory • Update Phone • Update Firmware• Update PRL• Update Profile • Phone Info • My Number• SW/HW Version• Icon Glossary • Java Settings 4 Get started Get startedAssemble & charge Caution: Please read “Battery Use & Safety” on page 35.1 Cover off 2 Battery in 3 Cover on 4 Charge up 3 H BasicsAbout this guideThis guide shows how to find a menu feature as follows:Find it: > History > Dialed Calls This means that, from the home screen: 1 Press the center key to open the menu. 2 Press the navigation key to scroll to History , and press to select it. 3 Press to scroll to Dialed Calls , and press to select it. Turn it on & offPress and hold until the display turns on or off. 5 Basics Home screenYour phone shows the home screen when you are not on a call or using the menu.Note: Your home screen may be a little different. Soft key labels in the home screen show the current soft key functions.Indicators at the top of your phone’s display provide important status information, such as incoming calls, missed messages, and other conditions. For a description of the status indicators that can appear on your phone, press > Settings > Phone Info > Icon Glossary > Status Bar . Tue 10/04/11 12:42 pmTue 10/04/11 12:42 pmTue 10/04/11 12:42 pm Mess ag e Cont a cts Left Soft Key L ab el Signal Strength R ig ht Soft Key L ab el Battery LevelLocation On 1xRTT Coverage Press up, down, left, or right to open shortcuts. External displayWhen you close the phone flip, the external display shows the time and date, status indicators, and notifications for incoming calls and events. For a list of status indicators, press > Settings > Phone Info > Icon Glossary > Status Bar . Make & answer callsTo make a call , enter a phone number and press . To answer a call when your phone rings and/or vibrates, just open the phone flip or press . To hang up , close the phone flip or press . Adjust volumeWith the phone flip open, press the volume keys up or down to:• turn off an incoming call alert • adjust earpiece or spe…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LQ1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDT56LQ1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Nitin S Sisodia TITLE: Engineering Lead Motorola Mobile Devices Business Date: 5/19/2010 Page 1 of 4 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDT56LQ1 Page 2 of 4 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56LQ1) is in compliance with all applicable parts of the FCC Rules. NAME: Nitin S Sisodia TITLE: Engineering Lead Motorola Mobile Devices Business Date: 5/19/2010 APPLICANT: MOTOROLA INC. FCC ID: IHDT56LQ1 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Nitin S Sisodia TITLE: Engineering Lead Motorola Mobile Devices Business Date: 5/19/2010 Page 3 of 4 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDT56LQ1 Page 4 of 4 EXHIBIT 2 ATTESTATION STATEMENT Motorola hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance for FCC ID: IHDT56LQ1. NAME: Nitin S Sisodia TITLE: Engineering Lead Motorola Mobile Devices Business Date: 5/19/2010

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LQ1 May 20, 2010 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Devices, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT56LQ1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the Digital CDMA standard in the 1900 MHz PCS band. The unit also employs EVDO and contains a Bluetooth transmitter (Part 15.247). The unit may be connected to a computer via a USB connection (Part 15, Class B, Computing Device Peripheral). Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LQ1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDT56 LQ1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LQ1 Exibit 3 Page 1 of 3 FRONT OF PHONE FLIP OPEN BACK OF PHONE FLIP OPEN APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LQ1 FRONT OF PHONE BACK OF PHONE BACK OF PHONE WITH BATTERY COVER REMOVED Exibit 3 Page 2 of 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LQ1 Exibit 3 Page 3 of 3 SIDE OF PHONE

APPLICANT: MOTOROLA INC. FCC ID: IHDT56LQ1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDT56LQ1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LQ1 REPLACE WITH YOUR PHOTO Main Board Bottom With Shields Main Board Bottom Without Shields EXHIBIT 9 1 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LQ1 Main Board Top Without Popples Main Board Top With Popples EXHIBIT 9 2 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LQ1 Flip CLI Flip LCD EXHIBIT 9 3 of 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56LQ1 EXHIBIT 9 4 of 4 Inside Back Housing Inside Front Housing

APPLICANT: MOTOROLA INC FCC ID: IHDT56LQ1 Test Report Number: 23794-1 Supplement 1 of 9 EXHIBIT 6A4 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 23794-1 Supplement Report Date – 2010-05-21 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Signature: Name: Lei Yang Title: EMC Project Manager Test: 2010-05-01 to 2010-05-21 As the responsible test lab manager, I hereby declare that the model tested as specified in this report conforms to the requirements indicated. Signature: Name: Yilin Zhao Title: Test Lab Manager Date: 2010-05-21 This report must not be reproduced, except in full, without written approval from this laboratory. FCC Registration Number: 177885 IC Registration Number: 109AW-1 ADR Testing Service location ADR BJ ISO/IEC-17025:2005 accredited by UKAS 2404 APPLICANT: MOTOROLA INC FCC ID: IHDT56LQ1 Test Report Number: 23794-1 Supplement 2 of 9 EXHIBIT 6A4 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 APPLICANT: MOTOROLA INC FCC ID: IHDT56LQ1 Test Report Number: 23794-1 Supplement 3 of 9 EXHIBIT 6A4 Test Report Details Tests Performed By: Motorola (China) Technologies Ltd. Asia Global Compliance Labs No. 1 Wang Jing East Road, Chao Yang District Beijing, 100102, P. R. China Phone: +86 10 8473 2610 FCC Registration Number: 177885 IC Registration Number: 109AW-1 Tests Requested By: Motorola Inc. Mobile Devices business 600 North US Hwy 45 Libertyville, IL 60048 United States Product Type: Cellular Phone Signaling Capability: CDMA 1900, CDMA 1X, Bluetooth FCC ID: IHDT56LQ1 MEID: A0000015CE7E93F Testing Complete Date: 05-21-2010 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47: X Part 15 Subpart B – Unintentional Radiators Applicable Standards: ANSI C63.4-2003, RSS-Gen Issue 2 APPLICANT: MOTOROLA INC FCC ID: IHDT56LQ1 Test Report Number: 23794-1 Supplement 4 of 9 EXHIBIT 6A4 Summary of Testing Test Test Name # Pass/Fail _________ 1 Field Strength of Spurious Emissions Pass from Unintentional Radiators 2 AC Line Conducted Emissions Pass Test Test Name Margin with respect # to the Limit_________ 1 Field Strength of Spurious Emissions see results from Unintentional Radiators 2 AC Line Conducted Emissions see results The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The EUT was tested using a fully charged battery. All testing was done in an indoor controlled environment. The temperature and the relative humidity were maintained within the ANSI C63.4-2003 Standard requirements during the entire duration of testing. APPLICANT: MOTOROLA INC FCC ID: IHDT56LQ1 Test Report Number: 23794-1 Supplement 5 of 9 EXHIBIT 6A4 Equipment List Through the test, the EUT was installed in an evaluation board. Equipment Model/type Serial numberOperational range Date of calibration EMI analyzers ESU 40 100036 20 Hz – 40 GHz 05.16.2010 PA-02-0001: 2007343 (10 kHz – 3 GHz) 06.26.2009 PA-02-218 2007344 3 GHz – 18 GHz 06.26.2009 Pre Amplifiers PA-02-5 2007345 18 GHz – 40 GHz 06.26.2009 Radio com. Tester CMU 200 112790 GSM 850/900/1800/1900 UMTS, CDMA, Bluetooth N/A WRCD N/A GSM 850/900/1800/1900 UMTS, CDMA N/A Band Reject Filter 4N45-24241/3/6 N/A WLAN N/A EMI analyzers R&S ESCI 100650 9 kHz – 3 GHz 03.08.2010 LISN ENV216 100057 9 kHz – 30 MHz 12.20.2008 The antennas used in the various tests are listed in the below table. Antenna Type Serial number Operational range Date of calibration Hybrid-log periodic TDK HLP 3003C 130361 30 MHz – 3 GHz 11.07.08 Double ridged Horn TDK HRN0118130303 1 GHz – 18 GHz 03.26.09 Double ridged Horn ETS HRN3116 0007193818 GHz – 40 GHz 10.17.08 All test equipment was within their calibration date during the time of testing. When equipment went out of calibration during testing it was replaced using a similar piece of calibrated equipment. All these equipments are listed in the equipment list. The LISN is on a two-year calibration cycle. The antennas are on a three-year calibration cycle. All other equipments are on a one-year calibration cycle. The Dell D620 Laptop Computer, D-Link DI-624+A Router and the Sony D-600 L Camera are labeled as DoC. APPLICANT: MOTOROLA INC FCC ID: IHDT56LQ1 Test Report Number: 23794-1 Supplement 6 of 9 EXHIBIT 6A4 Measurement Procedures and Data FIELD STRENGTH OF EMISSIONS FROM UNINTENTIONAL RADIATORS Measurement Procedure The equipment under test is placed inside the semi-anechoic chamber on a Styrofoam table on the turntable center. For each radiated emission, the antenna mast is raised and lowered from 1 to 4 meters and the turntable is rotated 360 degrees to obtain a maximum peak reading on the spectrum analyzer. The final radiated emissions are then measured using an EMI receiver employing a CISPR quasi-peak detector function below 1000 MHz and an average detector function above 1000 MHz. This is repeated for both horizontal and vertical polarizations of the receive antenna. The field strength of each radiated emission is calculated by correcting the EMI receiver level for cable loss, amplifier gain, and antenna correction factors. Field Strength (dBuV/m) = EMI Receiver Level (dBuV) + Cable Loss (dB) - Amplifier Gain (dB) + Antenna Correction Factor (1/m) Test Setup The EUT and the host equipment were setup according to the procedures in ANSI C63.4- 2003. The EUT was connected to a laptop computer using a USB data cable. The USB data cable is 1 m in length. The parallel and the serial ports of the computer were populated. The EUT was communicating with the laptop computer continu…

Text truncated - open the document above for the full version.

EMC SETUP PHOTOS AC Line Conduct Emission AC Line Conduct Emission-Computer Peripheral APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LQ1 EXHIBIT 7 Radiated Emission Radiated Emission-Computer Peripheral APPLICANT: MOTOROLA, INC.FCC ID: IHDT56LQ1 EXHIBIT 7

Applicant: Motorola, Inc. FCC ID: IHDT56LQ1 23795-1P Exhibit 7D Page 0 0 Portable Cellular Phone SAR Test Report Photographs of the Device Under Test Applicant: Motorola, Inc. FCC ID: IHDT56LQ1 23795-1P Exhibit 7D Page 1 1 Figure 1: Phone Open Front and Back Applicant: Motorola, Inc. FCC ID: IHDT56LQ1 23795-1P Exhibit 7D Page 2 2 Figure 2: Phone Closed Front and Back Applicant: Motorola, Inc. FCC ID: IHDT56LQ1 23795-1P Exhibit 7D Page 3 3 Figure 3: Cheek Position, Front of Head of Phantom Figure 4: Cheek Position, Top of Head of Phantom Applicant: Motorola, Inc. FCC ID: IHDT56LQ1 23795-1P Exhibit 7D Page 4 4 Figure 5: Tilt Position, Front of Head of Phantom Figure 6: Tilt Position, Top of Head of Phantom Applicant: Motorola, Inc. FCC ID: IHDT56LQ1 23795-1P Exhibit 7D Page 5 5 Figure 7: Body Position
