IHDT56MC1GSM TRANSCEIVER WITH BT & WLAN

APPLICANT MOTOROLA INC. FCC ID: IHDT56MC1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 MOTOROLA MT620 1 Congratulations CongratulationsMOTOROLA MT620 Your comfortable, pocket-size, smartphone with full touchscreen and QWERTY kepad—all part of the design of your MOTOROLA MT620 . • Stay on top of your work and personal email. • Take and share great images and video with a high performance 5MP camera. • Listen to the FM radio in stereo with a Bluetooth™ headset. • Don’t miss your favorite program, watch TV when and where you want. • Browse the web at lightening speeds. • Sleek comfortable design, that you can personalization with changeable covers—fits great in your pocket. Note: Certain apps and features may not be available in all countries. Caution: Before assembling, charging, or using your phone for the first time, please read the important legal and safety information packaged with your product. More•Answers: To u ch > Help Center . You can also flick your home screen left or right to see the Getting Started and Tips & Tricks widgets. • Support: Phone updates, PC software, user guides, online help and more at www.motorola.com/motorolaMT620 . • Accessories: Find accessories for your phone at www.motorola.c om/products . 2 Your phone Your phonethe important keys & connectors 3.5mm He a dset Home Key B ac k Key M ic ro p hone Menu Key M ic ro USB Conne c tor Charge or connect to PC. C a mer a (Front) Volume Keys Se a r c h Key C a mer a Key Press=Sleep/ W ake up. Hold=Turn on/off. Cover Rele a se Power Key Not i f ica t i onLED On=Charged. Flashing=New notification. Note: Your phone might look a little different. http://www.motorola.com http://www.motorola.com DeleteEnter Sh i ft S pac e Sym b ols Altern a te For so m e features, when you turn your phone, the screen adjusts for you. 3 Let’s go ContentsLet’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 22Business tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26TV & radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 35Wi-Fi™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36USB & memory card. . . . . . . . . . . . . . . . . . . . . . . . 38Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 44Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 45 Let’s golet’s get you up and runningAssemble & charge 1 cover off 2 SIM in 3 microSD in 4 battery in 5 cover on 6 charge up 3H 4 Let’s go Caution: Please read “Battery Use & Safety” on page 45.Tip: To save battery life, see “Battery tips” on page 20. Turn it on & offTo turn on your phone, press Power (on the top right). To turn off your phone, press and hold Power , then touch Power off in the menu that opens. Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details.Wi-Fi™ connectIf you want to use a Wi-Fi network for even faster Internet access, touch Menu > Settings > Wireless & networks . Touch WLAN to turn on, search for and connect to wireless networks. There’s more in “Wi-Fi™” on page 36.Cool content & moreBrowse and download the coolest apps on the planet from the Internet. On top of that, you get a full HTML browser, so you can surf in style. Power Key Download new apps from the “Web” on page 32. Your phone comes with 206.5 MB of internal memory, and an optional microSD memory card (upto 32 GB) can be installed—you can load it up with photos, videos, and music from your computer using “USB drag & drop” on page 38.SecurityThere are plenty of ways to protect your phone and your information, in “Security” on page 42. 5 Touchscreen & keys Touchscreen & keysa few essentialsTouch tipsHere are some tips on how to navigate around your phone.To u chTo choose an icon or option, touch it. Try it: In the home screen, touch Contacts . Touch & holdTo open special options, touch and hold an icon or other item. Try it: In the home screen, touch Contacts , then touch and hold a contact to open options. Clock Settings Browser Contacts g 06:00 Abc Abc Alex Pico SIM - 8887773333 All Contacts A Andrew CarmodyAllen SmithAnu ShahAndrea ShunneyAngelique Bukvic SIM - 1112223333SIM - 3334445555SIM - 2552552525SIM - 2223334444SIM - 3223223232 Alex Pico View contactVoice CallVideo CallIP CallText CallAdd to favoritesShare A DragTo scroll through a list or move slowly, drag across the touchscreen. Try it: In the home screen, touch Contacts , then drag your contacts list up or down.Tip: When you drag or flick a list, a scroll bar appears on the right. Drag the scroll bar to move the list to a letter A-Z.FlickTo scroll through a list or move quickly, flick ac…

Text truncated - open the document above for the full version.

APPLICANT: Motorola Mobility Holdings, Inc FCC ID: IHDT56MC1 Page 1 of 3 EXHIBIT 2 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDT56M C1) has been tested in accordance with the requiremen ts contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola Mobility 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Chu_Wang TI TLE: Engineering Manager Motorola Mobilit y, Inc Date: Jan, 27, 2011 APPLICANT: Motorola Mobility Holdings, Inc FCC ID: IHDT56MC1 Page 2 of 3 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56M C1) is in compliance with all applicable parts of the FCC Rules. NAM E: Chu_Wang TI TLE: Engineering Manager Motorola Mobilit y, Inc Date: Jan, 27, 2011 APPLICANT: Motorola Mobility Holdings, Inc FCC ID: IHDT56MC1 Page 3 of 3 EXHIBIT 2 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Chu_Wang TI TLE: Engineering Manager Motorola Mobilit y, Inc Date: Jan, 27, 2011

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MC1 January 29, 2011 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Dear Sir/Madame: Pursuant to sections 0. 457 & 0.49 of the commission’s rules, Motorola Mobility, Inc., 600 N. U.S. Highway 45, Libertyville, Illinois 6004 8 herein submits Application for Equipment Authorization for Certification of a Cellular/PCS Transceiver, FCC ID: IHDT56MC1. Motorola Mobility is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission’s rules (CFR 47), Motorola Mobility requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola’s trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM transceiver, which operates in the PCS 1900 MHz band. It employs EDGE/GPRS data transission in the network and contains 2.4 GHz Bluetooth and WiFi functions (part 15.247). The unit also operates in the TD-SCDMA 1900/2100 bands for other reginal market. It is connected to a computer via a USB connection(Part 15B). Note: This device also contains functions that are not operational in the U.S. territories. This filing is only applicable for US operations. Contact Information: If there are any further questions or additional information needed concerning this filing, please contact me, John Lewczak, by telephone at (954) 723-6272 or via E-mail at: [email protected] . Regard s, FCC Liaison Motorola Mobility, Inc. 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 E-mail: [email protected] Exhibit 13 1

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MC1 SHORT TERM CONFIDENTIALITY REQUEST 180 DAYS Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Cellular/PCS Transceiver FCC ID IHDT56MC1 Gentlemen: Introduction: Pursuant to Section 0.459 of the Commission's rules (CFR 47) and Section 552(b)(4) of the Freedom of Information Act, Pursuant to sections 0. 457 & 0.49 of the commission’s rules, Motorola requests confidentiality for portions of the material contained in this application; and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Standard Confidentiality Request: Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List / Tune up Information • Exhibit 12 Operational Description Short Term Confidentiality Request: Furthermore, due to sensitive business information, Motorola requests the following exhibits be withheld from public viewing for 180 days: • Exhibit 3 External Photographs • Exhibit 7 and 7A Photographs of the device under test • Exhibit 8 User’s Manual • Exhibit 9 Internal Photographs Contact Information: Please contact me by telephone at (954) 723-6272, or by e-mail ([email protected]) , if there are questions or additional information needed concerning this filing. Regards, John Lewczak FCC Liaison Mobile Devices 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13A

Front of the phone Back of the phone Back of the phone with battery cover removed APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MC1 EXHIBIT 3 4 Sides of the phone APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MC1 EXHIBIT 3

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MC1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDT56MC1

Main PCB top with shielding Main PCB top without shielding APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MC1 EXHIBIT 9 Main PCB bottom with shielding Main PCB bottom without shielding APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MC1 EXHIBIT 9 Camera board top side Camera board bottom side APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MC1 EXHIBIT 9 Inside front housing Inside back housing APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MC1 EXHIBIT 9

APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MC1 Test Report Number: 24331-1 Supplement 1 of 9 EXHIBIT 6A4 PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 24331-1 Supplement Report Date – 2011-01-26 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Signature: Name: Lei Yang Title: EMC Project Manager Test: 2011-01-07 to 2011-01-28 As the responsible test lab manager, I hereby declare that the model tested as specified in this report conforms to the requirements indicated. Signature: Name: Yilin Zhao Title: Test Lab Manager Date: 2011-04-27 This report must not be reproduced, except in full, without written approval from this laboratory. FCC Registration Number: 177885 IC Registration Number: 109AW-1 ADR Testing Service location ADR BJ ISO/IEC-17025:2005 accredited by UKAS 2404 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MC1 Test Report Number: 24331-1 Supplement 2 of 9 EXHIBIT 6A4 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MC1 Test Report Number: 24331-1 Supplement 3 of 9 EXHIBIT 6A4 Test Report Details Tests Performed By: Motorola (Beijing) Mobility Technologies Co., Ltd. Asia Global Compliance Labs No. 1 Wang Jing East Road Chao Yang District Beijing, 100102, P. R. China Phone: +86 10 8473 2610 FCC Registration Number: 177885 IC Registration Number: 109AW-1 Tests Requested By: Motorola (Beijing) Mobility Technology Co., Ltd. No.1 Wang Jing East Road, Chao Yang District, Beijing 100102, P.R. China Product Type: Cellular Phone Signaling Capability: GSM1900, EDGE1900, Bluetooth, 802.11b/802.11g/802.11n FCC ID: IHDT56MC1 IMEI: 860403000051289 Testing Complete Date: 01-28-2011 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47: X Part 15 Subpart B – Unintentional Radiators Applicable Standards: ANSI C63.4-2003, RSS-Gen Issue 2 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MC1 Test Report Number: 24331-1 Supplement 4 of 9 EXHIBIT 6A4 Summary of Testing Test Test Name # Pass/Fail _________ 1 Field Strength of Spurious Emissions Pass from Unintentional Radiators 2 AC Line Conducted Emissions Pass Test Test Name Margin with respect # to the Limit_________ 1 Field Strength of Spurious Emissions see results from Unintentional Radiators 2 AC Line Conducted Emissions see results The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The EUT was tested using a fully charged Model SNN5879A 1930mAH battery. All testing was done in an indoor controlled environment. The temperature and the relative humidity were maintained within the ANSI C63.4-2003 Standard requirements during the entire duration of testing. APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MC1 Test Report Number: 24331-1 Supplement 5 of 9 EXHIBIT 6A4 Equipment List Through the test, the EUT was installed in an evaluation board. Equipment Model/type Serial number Operational range Date of calibration EMI analyzers ESU 40 100036 20 Hz – 40 GHz 11.05.2010 PA-02-0001: 2007343 (10 kHz – 3 GHz) 06.26.2010 PA-02-218 2007344 3 GHz – 18 GHz 06.26.2010 Pre Amplifiers PA-02-5 2007345 18 GHz – 40 GHz 06.26.2010 Radio com. Tester CMU 200 112790 GSM 850/900/1800/1900 UMTS, CDMA, Bluetooth N/A WRCD N/A GSM 850/900/1800/1900 UMTS, CDMA N/A Band Reject Filter 4N45-24241/3/6 N/A WLAN N/A EMI analyzers R&S ESCI 100650 9 kHz – 3 GHz 03.08.2010 LISN ENV216 100055 9 kHz – 30 MHz 12.20.2010 The antennas used in the various tests are listed in the below table. Antenna Type Serial number Operational range Date of calibration Hybrid-log periodic TDK HLP 3003C 130361 30 MHz – 3 GHz 11.07.08 Double ridged Horn TDK HRN0118130303 1 GHz – 18 GHz 03.26.09 Double ridged Horn ETS HRN3116 0007193818 GHz – 40 GHz 10.17.08 All test equipment was within their calibration date during the time of testing. When equipment went out of calibration during testing it was replaced using a similar piece of calibrated equipment. All these equipments are listed in the equipment list. The LISN is on a two-year calibration cycle. The antennas are on a three-year calibration cycle. All other equipments are on a one-year calibration cycle. The Dell D620 Laptop Computer, D-Link DI-624+A Router and the Sony D-600 L Camera are labeled as DoC. APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MC1 Test Report Number: 24331-1 Supplement 6 of 9 EXHIBIT 6A4 Measurement Procedures and Data FIELD STRENGTH OF EMISSIONS FROM UNINTENTIONAL RADIATORS Measurement Procedure The equipment under test is placed inside the semi-anechoic chamber on a Styrofoam table on the turntable center. For each radiated emission, the antenna mast is raised and lowered from 1 to 4 meters and the turntable is rotated 360 degrees to obtain a maximum peak reading on the spectrum analyzer. The final radiated emissions are then measured using an EMI receiver employing a CISPR quasi-peak detector function below 1000 MHz and an average detector function above 1000 MHz. This is repeated for both horizontal and vertical polarizations of the receive antenna. The field strength of each radiated emission is calculated by correcting the EMI receiver level for cable loss, amplifier gain, and antenna correction factors. Field Strength (dBuV/m) = EMI Receiver Level (dBuV) + Cable Loss (dB) - Amplifier Gain (dB) + Antenna Correction Factor (3/m) Test Setup The EUT and the host equipment were setup according to the procedures in ANSI C63.4- 2003. The EUT was connected to a laptop computer using a USB data cable. The USB data cable is 1 m in length…

Text truncated - open the document above for the full version.

EMC TEST SETUP PHOTOS Radiated Emissions Radiated Emissions – Computer Peripheral APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MC1 EXHIBIT 7 AC Line Conducted Emissions AC Line Conducted Emissions – Computer Peripheral APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MC1 EXHIBIT 7
