IHDT56MG1i475 Portable iDEN Handset with Bluetooth

FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3) The attached User’s Manual is the final production-intended version of the generic Motorola International English User Manual. This guide will be adapted to carrier-specific versions, but the key information herein will be retained. Translations into other languages will also be done to support the needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to, placing this product onto the market. Selected portions of the User Guide can be found as indicated below: 8.1 Safety Section: Page 40 8.2 Part 15B Declaration of Conformity: Page 50 8.3 Specific Absorption Rate (SAR) Data: Page 48 8.4 Guidance for use with Hearing Aids: Page 36, 58 MOTOROLA i475 1Congratulations Congratulations MOTOROLA i475 Get the convenience of push-to-talk calls together with a sleek design in an affordable package. •Private Calls. Stay in touch with your family, friends, and colleagues with the simple touch of a button. •FM Radio. Listen to your favorite stations wherever you go. • My Phone, My Way. It’s your phone—make it that way. Customize your home screen with personal pictures, and change wallpapers and ringtones. More information On your computer—Go to www.motorola.com/support/ . Caution: Before assembling, charging or using your phone for the first time, please read the important legal and safety information packaged with your product. 2Your phone Your phone the important keys & connectors Note: Your phone might look a little different. 10:05pm 04/23 ContactsMessages Ready Volume Key PTT Button Send Key - ALT Key : Soft Key . End/Power Key Micro USB Connector Return Key 2.5 mm Headphone Jack Delete Key Shift Key Space Key Symbol Key ) Speaker Key Menu Key / Soft Key : r OK Key Navigation Key 3Contents Contents Menu map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Push-to-Talk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 SDG calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Media center. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 FM radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Bluetooth™ wireless . . . . . . . . . . . . . . . . . . . . . . . 30 Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 37 4Menu map Menu map main menu Call Alert Bluetooth® • Hands Free • Link to Devices • Device History • Setup •Find Me Settings •(see settings menu) Ring Tones • Vibrate All: On/Off • Ringtones •Vibrate • Silent Java Apps • Java System •FM Radio GPS • Position • Privacy • Interface Media Center Camera Net Datebook My Info •My name • Line 1 • Line 2 • Private ID • Group ID • Carrier IP •IP1 Address •IP2 Address VoiceRecord • [New VoiceRec] Memo Recent Calls Shortcuts • [Help] • 1)Shortcuts • 2)Cntcs[New Contact] • 3)Recent Calls • 4)Contacts • 5)Datebook • 6)Messages • 7)VoiceRecord •8)Net • 9)Call Forward 5Menu map main menu (con’t.) Contacts • [New Contact] • [New SDG List] • [New Msg Group] Note: Your carrier may not offer the Message Group feature. Call Forward Quick PTT Profiles • [New Profile] • Standard •Car • Meeting •Office • Outdoors • Headset •PRVT Only • CNTCS Only • Surveillance Call Timers • Last Call • Phone Reset • Phone Lifetime • Prvt/Grp Reset •Prvt/Grp Life • Kbytes Reset PT Manager •Quick PTT • Send Message • Send Picture • Send Event • Send My Info • Send Contact • Configure Messages • [Create Message] •Voice Mail •Inbox •Drafts •Outbox •Fax Mail • Net alert • Sent Items FM Radio Note: Your carrier may not offer the FM Radio feature. This is the standard main menu layout. Your phone’s menu may be different. 6Menu map settings menu Display/Info • Wallpaper •Text Size •Theme • Home Icons • Backlight •Clock • Menu View • Large Dialing • Language Phone Calls • Set Line • Any Key Ans • Auto Redial • Call Waiting •Auto Ans • Minute Beep • Call Duration •TTY •Hearing Aid • Notifications • DTMF Dialing • Prepend 2-Way Radio •Tkgrp Silent •Tkgrp Area • One Touch PTT •Alert Type • PTT Quick Notes • On/Off PTT • Store Rcvd Info • PTT Backlight Personalize • Menu Options •Up Key • Down Key •Left Key •Right Key • Center Key •Left Softkey •Right Softkey •Power Up App Volu m e • Line 1 • Line 2 • Messages • Earpiece • Speaker •Keypad • Java Earpiece • Java Spkr • Data 7Menu map settings menu (con’t.) Security • Phone Lock • Keypad Lock • SIM PIN •GPS PIN • Change Passwds Advanced •Alert Timeout • Headset/Spkr • Connectivity • Reset Defaults • Return to Home • Transmitters • Phone Only •Baud Rate 8Let’s go Let’s go let’s get you up and running Assemble & charge Caution: Please read “Battery Use & Safety” on page 37. 1Remove cover2SIM in 3Batter y in4Cover on 5Charge up 3H 9Let’s go Turn it on & off To turn on your phone, press and hold End/Power for a few seconds or until the display turns on. If prompted, enter your four-digit unlock cod…

Text truncated - open the document above for the full version.

FCC Filing Package for Motorola i475-Series Transceiver FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907 2.1. Specification Compliance Transceiver type described herein has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Amit Verma SIGNATURE: /s/ Amit Verma DATE: 31-Jan-11 TITLE: Principle Staff Engineer 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56MG1) is in compliance with all applicable parts of the FCC Rules. NAME: John Lewczak SIGNATURE: DATE: 31-Jan-11 TITLE: Engineering Manager, Product Safety and Compliance Page 2 - 1 FCC Filing Package for Motorola i475-Series Transceiver FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Page 2 - 2 2.3. Attestation Statement (Bluetooth) This device contains an embedded Bluetooth device that Motorola confirms are compliant with the applicable Part 15 regulations. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Amit Verma SIGNATURE: /s/ Amit Verma DATE: 31-Jan-11 TITLE: Principle Staff Engineer 2.4. Attestation Statement (Hearing Aid Compatibility) Motorola hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance. NAME: Amit Verma SIGNATURE: /s/ Amit Verma DATE: 31-Jan-11 TITLE: Principle Staff Engineer FCC Filing Package for Motorola i475-Series Transceiver FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN 2.5. Part 15B Declaration of Conformity Attestation We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the Class B computer peripheral portion of this composite filing. NAME: John Lewczak SIGNATURE: DATE: 31-Jan-11 TITLE: Engineering Manager, Product Safety and Compliance Page 2 - 3

FCC Filing Package for Motorola i475-Series Transceiver FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Page 1 Date: 7 February 2011 Mr. Jeff Woods Advanced Compliance Solutions, Inc. 5015 B U Bowman Drive Buford, GA 30518 USA Re: Job Number: CB-11-0014 Filing, with FCC ID: IHDT56MG1. Dear Mr. Woods, Motorola Mobility, Inc., 8000 W. Sunrise Blvd; Suite A; Plantation, FL, herein submits its response to your 4 February 2011 request for further information on FCC ID: IHDT56MG1, in relation to Job Number CB-11-0014. Q 1. In the iDEN RF Test Report (Parts 90 and 24 - 1of 2), a frequency of 900.98125 MHz was used to show compliance with the 901-902 (NBPCS) band (Figures 6a.5-3 and 6). This frequency does not fall in the band. Please explain. Response: This was a typographical error. The actual test frequency was 901.88125 MHz. The test report was amended, and is uploaded with this response. Q 2. Per 90.210, the sub-band 806-809 MHz (part of the 800 SMR) is required to show compliance to Mask H. There is no plot in iDEN RF Test Report (Parts 90 and 24 - 1of 2) showing compliance to this requirement. Please explain. Response: The band plan for the spectrum between 806 and 809 MHz has been established for 12.5 kHz channels (47 CFR 209(b)(5)). Mask H is intended for that application. The subject transmitter’s emission is suited to 25 kHz channels (aggregated), and thus the G-Mask is applicable. Q 3. Per 90.210, the sub-band 896-901 MHz (900 SMR) is required to show compliance to Mask J. The iDEN RF Test Report (Parts 90 and 24 - 1of 2) contains plots showing compliance to Mask G for this frequency band (see Figures 6a2.2-1, 2, 5, 6, 9, and 10). Please explain. Response: Like in the above situation, operation of this transmitter in the 900 MHz SMR band is on aggregated 12.5 kHz channels to form a 25-kHz channel. Thus the G-Mask is applicable.

FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN 31 January 2011 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of transmitter with FCC ID: IHDT56MG1, i475-Series Handsets, with Bluetooth. Gentlemen; Motorola Mobility, Inc.; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT56MG1. This is a variable output power (0.22 to 691 milliwatts) transmitter that is part of a handheld transceiver used in SMR and EA SMR trunking systems operating within the United States 806-821/851-866 MHz and 896-901/935-940 MHz frequency bands. Operation is also extended for use in a Narrowband PCS system operating in the United States in the spectrum between 901-902/940-941 MHz, on channels which the licensee has aggregated together to form twenty-one 25 kHz operating channels. To facilitate global roaming it is kindly requested that a note be provided in the Grant for Equipment Authorization, which states that this ‘receive first’ type of equipment is compliant for transmitter operation over the broader range 806-825 MHz when used with a compatible Authorized Base Station. This will aid equipment authorization in foreign countries, which accept a United States FCC Grant for Equipment Authorization, yet not jeopardize United States public safety or cellular systems licensed to operate in the 821-825 MHz frequency band since no compatible base station may be authorized on those frequencies in the United States. This radio product is equipped with a Bluetooth (BT) transceiver. BT supports both voice and data for short range wireless communications. The Bluetooth Band of Operation is 2.4 - 2.4835 GHz (1 MHz channel bandwidth). It is a Class 1 type device, with power rated +4 to +10 dBm (typically +8 dBm). The physical location of the Bluetooth antenna is shown in Exhibit 7b. The BT device complies with the requirements of FCC Rule Parts 15.247 (c), 15.205 and 15.209 (b). All transmitters contained in this radio product have been subjected to routine environmental evaluation (as applicable) according to 47 CFR Part 2.1093 (c) for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). This radio product features integrated GPS and FM broadcast receivers, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR Part 15.3(r). For these reasons a Declaration of Conformity has been prepared and provided as part of the User Guide (Exhibit 8), as shown on the exhibit cover page. Page 13a - 1 FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Enclosed is a complete Certification Application. Contact me at (847) 523-6167 if you require any additional information. Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected] Page 13a - 2

FCC ID: IHDT56MG1 Motorola Mobility, Inc; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Page 13b - 1 CONFIDENTIALITY REQUEST 31 January 2011 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56MG1. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. T56MG1_Ex_04 (Block Diagrams).pdf Schematic Diagrams. T56MG1_Ex_05 (Schematic Diagrams).pdf Parts List and Tune Up Procedures. T56MG1_Ex_10 (Active Components).pdf Transmitter Characteristics. T56MG1_Ex_12 (TX Characteristics).pdf Motorola Mobility, Inc. requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility, Inc. understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56MG1 Motorola Mobility, Inc; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN SHORT TERM ONFIDENTIALITY REQUEST – 60 DAYS (to 3/31/2011) Pursuant to the Commission’s public notice DA 04-1705 (June 15, 2004), Motorola Mobility, Inc. is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility, Inc. temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. T56MG1_Ex_03 (External_Photos).pdf Test set-up photographs. T56MG1_Ex_07b (SAR Test Set- up_Details).pdf T56MG1_Ex_07c (Part 15 Test Set- up_Details).pdf T56MG1_Ex_07d (HAC Test Set- up_Details).pdf User’s Manual. T56MG1_Ex_08 (User Guide).pdf Internal product photographs. T56MG1_Ex_09 (Internal Photos).pdf Please contact me if you require any additional information. Regards, FCC Liaison Motorola Mobility, Inc. 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 E-mail: [email protected] Page 13b - 2

FCC Filing Package for Motorola i475-Series Transceiver FCC ID: IHDT56MG1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 3. External Photographs -- Pursuant to 47 CFR 2.1033(c)(12) The radio product shapes, colors and housings/bezels may vary. Figure 3-1. Front of radio Page 3 - 1 FCC Filing Package for Motorola i475-Series Transceiver FCC ID: IHDT56MG1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Figure 3-2. Back of radio Page 3 - 2 FCC Filing Package for Motorola i475-Series Transceiver FCC ID: IHDT56MG1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Figure 3-3. Button Side of radio Figure 3-4. Opposite Side of radio Page 3 - 3 FCC Filing Package for Motorola i475-Series Transceiver FCC ID: IHDT56MG1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Figure 3-5. Top of radio Figure 3-6. Bottom of radio Page 3 - 4 FCC Filing Package for Motorola i475-Series Transceiver FCC ID: IHDT56MG1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Figure 3-7. Interior Compartment of radio FCC Label Location. See Exhibit 1 for details. Page 3 - 5

FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11) 1.1 Location On the rear (back) side of the radio product chassis, beneath the battery (see also Exhibit 3). 1.2 Type The label is of a white polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with minimum peel strength of 5 lbs/in. 1.3 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. FCC ID: IHDT56MG1 IC: 109O-T56MG1 Model No. H79XAN6QR2BN FCC ID: IHDT56MG1 IC: 109O-T56MG1 Model No. H79XAN6QR2AN Page 1 - 1 FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Page 1 - 2 Figure 1.3.1. Representation of FCC Label information. This label will be placed on the equipment (within the Battery Compartment) as shown below. Other information may also be included on this label, and other labels may also be present. Figure 1.3.2. Location of FCC Label (position, orientation, and other information shown may vary). Please note that this label and its placement complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. Further, at the time of purchase, batteries are shipped in a separate section or compartment of the radio packaging, and are not attached to the radio. In some instances they may be shipped in separate boxes. So, the customer needs to physically install the battery by removing the battery cover, if any, or attach the battery before using the radio. Further, the placement of the label in the battery compartment is done because space is limited on the exterior of the device. The battery compartment also helps to protect the label from getting obliterated or made unreadable through regular handling and use. The product’s Market or Trade Name is indelibly printed on the face of the product, as shown in Exhibit 3. FCC ID: IHDT56MG1 IC: 109O-T56MG1 Model No. H79XAN6QR2CN Interior Battery Compartment FCC Label Back Side of Phone FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Page 1 - 3 Exhibit 1A: General Information 1A.1 Production Plans Quantity production is planned. 1A.2 Data Submittal Procedure Performance data located in Exhibit 6 are supplied in accordance with the Commission’s rules: 47 CFR Part 2, Subpart J. The intended use of this transceiver includes applications covered in the Code of Federal Regulations Title 47, Part 15, Subparts A, B, and C; Part 24 Subparts B and D; and Part 90, Subparts I and S. 1A.3 Similar, currently Certified Transceiver FCC ID: IHDT56KB12 1A.4 Additional Considerations This radio product integrates a receiver designed to process signals from Global Positioning System satellites, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR 15.3(r). It also features the capability to receive FM broadcast signals. For these reasons a Declaration of Conformity has been prepared and provided as part of the User Guide (See Exhibit 8). Compliance with Part 15 requirements for the Direct-Conversion (zero IF superheterodyne) receiver has been determined by verification in accordance with 47 CFR 15.1.

FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 9: Internal Photographs -- Pursuant to 47 CFR 2.1033(c)(12) Photograph 9-1: Component side view of radio product PC Board. Page 9 - 1 FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Photograph 9-2: Component side view of radio product PC Board (Shields Removed). Page 9 - 2 FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Photograph 9-3: Keypad (Front) side view of radio product PC Board. Page 9 - 3

MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24311-1F E E x x h h i i b b i i t t 1 1 1 1 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobile Devices 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 24311-1F Date of Report: January 11, 2011 Date of Test: Dec 27 – Dec 31, 2010 FCC ID #: IHDT56MG1 Generic Name: N/A Test Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Katerina Bruggemann Engineer Accreditation: Testing Laboratory No. 2404 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola Mobility, Inc. 2011 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24311-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 o o f f 2 2 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 4 2.1 Antenna description 4 2.2 Device description 4 3. Test Equipment Used 5 3.1 Dosimetric System 5 3.2 Additional Equipment 5 4. Electrical parameters of the tissue simulating liquid 6 5. System Accuracy Verification 7 6. Test Results 8 6.1 Head Adjacent Test Results 10 6.2 Dispatch/Push-to-Talk Test Results 14 6.2 Body Worn Test Results 16 References 20 Appendix 1: SAR distribution comparison for the system accuracy verification Appendix 2: SAR distribution plots for Phantom Head Adjacent Use Appendix 3: SAR distribution plots for Body Worn Configuration Appendix 4: Probe Calibration Certificate Appendix 5: Measurement Uncertainty Budget Appendix 6: Dipole Characterization Certificate MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24311-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 o o f f 3 3 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1g average set in [3] and 2.0W/kg in a 10g average set in [2]. For ANSI / IEEE C95.1 (1g), the final SAR reading for this phone is 1.01 W/kg for head adjacent use and 1.02 W/kg for body worn use. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24311-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 4 4 o o f f 4 4 2. Description of the Device Under Test 2.1 Antenna description Type Internal Location Bottom of Transceiver Length 62.43 mm Dimensions Width 10.40 mm Configuration PIFA 2.2 Device description Serial number 364VLWGNSV Mode(s) of Operation 800 iDEN (Interconnect / Dispatch) 800 iDEN (Packet Data) 900 iDEN (Interconnect/ Dispatch) 900 iDEN (Packet Data) Bluetooth Modulation Mode(s) M16-QAM M64-QAM, M16-QAM, QPSK M16-QAM M64-QAM, M16-QAM, QPSK GFSK Maximum Output Power Setting 28.06 dBm 28.06 dBm 9.5 dBm Duty Cycle 2:6 / 1:6 81:120 2:6 / 1:6 81:120 1:1 Transmitting Frequency Range(s) 806.0125 – 824.9875 MHz 896.01875 – 901.98125 MHz 2400.0 – 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled The Device Under Test (DUT) is a digital multi-service data-capable device that employs time division multiplexing (TDMA) with duty cycles of 16.67% (Dispatch), 16.67% or 33.00% (Interconnect or Circuit Data), and up to 67.50% (Packet Data) operation. Possible modulation formats are QPSK, M16-QAM, or M64-QAM. All voice modes employ M16-QAM modulation and are interleaved as 1:6 (for Dispatch or Interconnect) or 1:3 (Interconnect only). Split 1:3 Interconnect is operated at 16.67% duty cycle, but because there will be two pulses in each 90 ms frame, the overall interleave is 2:6. Data transmissions employ QPSK, M16-QAM, or M64-QAM modulations and have a maximum duty cycle of 67.50% (Packet Data). Packet Data operation is possible with and without connection to an external data device (via data cable or Bluetooth link). All iDEN modes (Interconnect, Dispatch, and Data) are available in both the …

Text truncated - open the document above for the full version.

FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Mobile Devices business iDEN Mobile Devices Operations RF Test Report FCC Rule Parts: 90S and 24D Industry Canada: RSS-Gen, RSS-119, RSS-134 Product Name: i475-Series FCC ID: IHDT56MG1 IC ID: 109O- T56MG1 Date: February 2, 2011 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN FCC Filing Package for Motorola i475-Series Transceivers FCC ID: IHDT56MG1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Table of Contents Test Report Details 6a.0-1 Transmitter Output Power 6a.1-1 Modulation Characteristics 6a.2-1 Radiated Spurious Emissions ACS Report Power Line Conducted Spurious Voltage ACS Report Frequency St…
