IHDT56MH1i1Q/i1X iDEN/MOTOTALK MOBILE WITH WI-FI AND BT

FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3) The attached User’s Manual is the final production-intended version of the generic Motorola International English User Manual. This guide will be adapted to carrier-specific versions, but the key information herein will be retained. Translations into other languages will also be done to support the needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to, placing this product onto the market. Selected portions of the User Guide can be found as indicated below: 8.1 Safety and Regulatory Section: Page 61 8.2 Part 15B Declaration of Conformity (Pursuant to 47 CFR 2.1077): Page 16 8.3 Specific Absorption Rate (SAR) Data: Page 65 8.4 Guidance for use with Hearing Aids (Pursuant to 47 CFR 20.19(f)(1): Page 57, 70 MOTOROLA i1x 68000201711.book Page -1 Friday, October 31, 2008 12:40 PM 1 Congratulations CongratulationsMOTOROLA i1x Get the convenience of push-to-talk calls together with a premium browsing and messaging experience, all in a QWERTY touchscreen phone.•Private Calls. Stay in touch with your family, friends, and colleagues with the simple touch of a button. • Organization. Check your email, calendar, and contacts wherever you are. • Browsing. Get more from the web with a huge screen. Search, browse, everything you want to do, all made easier. • Maps, entertainment, and more. The latest technology and apps. Google Maps™ to find your way. YouTube™ to stay entertained. Easy access to Google™ and thousands of Android applications to expand your world. Caution: Before assembling, charging or using your phone for the first time, please read the important legal and safety information packaged with your phone. More•Answers: To u ch > Help Center . You can also flick your home screen left or right to see the Getting Started and Tips & Tricks widgets. • Support: Phone updates, PC software, user guides, online help and more at www.motorola.com/myi1x . • Accessories: Find accessories for your phone at www.motorola.com/products . 2 Your phone Your phonethe important keys & connectors End/Power Key Send Key Menu Key B ac k Key Home Key M ic ro USB Conne c tor PTT Button Volume Keys C a mer a Key Not i f ica t i on LED 3.5 mm He a dset S c reen Lo c k Key S p e a ker Key To u c hs c reen Note: Your phone might look a little different. DeleteKey Altern a te Key Sh i ft Key S pac e Key Return KeySe a r c h Key Sym b ol Key For so m e features, when you turn your phone, the screen adjusts for you. 3 Let’s go ContentsLet’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11Push-to-Talk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14MOTOtalk™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19Messaging & email . . . . . . . . . . . . . . . . . . . . . . . . . 21Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 29Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44Wireless manager. . . . . . . . . . . . . . . . . . . . . . . . . . 46USB & memory card. . . . . . . . . . . . . . . . . . . . . . . . 49Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55Update my phone . . . . . . . . . . . . . . . . . . . . . . . . . . 57Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 57Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 58 Let’s golet’s get you up and runningAssemble & charge Caution: Please read “Battery Use & Safety” on page 58. 1 Cover off 2 SIM in 3 microSD in 4 Battery in 5 Cover on 6 Charge up 3 H 4 Let’s go Tip: To save battery life, see “Battery tips” on page 28. Set up & goThe first time you turn on your phone, a setup wizard guides you through:• Setting up your Wi-Fi™ connection. • Signing in to your existing Google™ account. Note: If you don’t have a Google account, you can create one using the wizard.Tip: Remember to write down your user name and password, and keep them in a safe place. • Setting up additional email accounts, such as POP3, IMAP , or Microsoft™ Exchange. • Loading contacts from your SIM card. • Loading apps from your microSD card. • Selecting your keypad type. Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details. Tu r n i t o n & o ffTo turn on your phone, press and hold End/Power . To turn off your phone, press and hold End/Power , then touch Power off . Wi-Fi™ connectIf you want to use a Wi-Fi computer network for even faster Internet access, touch > Settings > Wireless & networks > Wi-Fi settings . See “Wi-Fi™” on page 48. Cool content & moreBrowse and download thousands of the coolest apps on the planet from Android Market™. See “Apps for all” on page 44.Your phone comes with a microSD memory card…

Text truncated - open the document above for the full version.

FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3) The attached User’s Manual is the final production-intended version of the generic Motorola International English User Manual. This guide will be adapted to carrier-specific versions, but the key information herein will be retained. Translations into other languages will also be done to support the needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to, placing this product onto the market. Selected portions of the User Guide can be found as indicated below: 8.1 Safety and Regulatory Section: Page 61 8.2 Part 15B Declaration of Conformity (Pursuant to 47 CFR 2.1077): Page 16 8.3 Specific Absorption Rate (SAR) Data: Page 65 8.4 Guidance for use with Hearing Aids (Pursuant to 47 CFR 20.19(f)(1): Page 57, 70 27 Text entry Text entry settingsFind it: > Settings > Language & keyboard • To change your Swype settings, touch Swype . Enter alternate characters in the corners of keys Press Alternate Enter several alternate characters, until you press Alternate again Press Alternate twice Enter one capital letter Press Shift Enter only capital letters, until you press Shift again Press Shift twice Delete a character (hold to delete more) Press Delete Start a new line (email or text messaging) Press Return Select text , Cut , Copy , or Paste Touch and hold a blank spot in a text entry area. To . . . • To change the language and the style for your touchscreen keypad, touch Select locale . • To edit your word suggestion dictionary for the Android keyboard, touch User dictionary . • To change your Android keypad settings, touch Android keyboard . • To show the touchscreen keypad when holding your phone vertically, touch Show soft keypad in portrait . • To change the device keypad settings touch, Device Keyboard . 28 Tips & tricks Tips & tricksa few handy hintsShortcuts To ...Return to the home screen Press Home . See recently dialed numbers Press Talk . Sleep/wake your phone Press Screen Lock . Set screen timeout Touch > Settings > Sound & display > Screen timeout . Tu r n sound on/off Press and hold End/Power > Silent mode . Search Press Search . Show last few apps used Press and hold Home . Battery tipsYour phone is like a small computer, giving you a lot of information and apps, with a touch display! Depending on what you use, that can take a lot of power.To save even more battery life between charges, you could reduce:• Recording or watching videos, listening to music, or taking pictures. • Widgets that stream information to your home screen, like news or weather (“Home screen” on page 8). • Email updates: Touch > Email > Menu > Account Settings > Email check frequency > Every hour or Never to check for email manually. • Turn off Bluetooth power: touch > Settings > Wireless & networks > Bluetooth . • Turn off Wi-Fi: touch > Settings > Wireless & networks > Wi-Fi . • Google™ app updates: Touch > Settings > Accounts & sync > Background data . Tu r n airplane mode on/off Press and hold End/Power > Airplane mode . To ... 29 Photos & videos • Display brightness: Touch > Settings > Sound & display > Brightness > (dimmer setting) . • Display timeout delay: Touch > Settings > Sound & display > Screen timeout > (shorter setting) . Photos & videossee it, capture it, share it!PhotosTake & share photosTake that family photo, and post it online for everyone to see.Find it: Press Camera Note: Photos are stored on your microSD memory card. Picture Resolution is 5MP , unless you change it. 536 Location unkownLocation unko Sett i n g s P ic ture Counter Touchto openca m era options. Zoom Out Zoom In C ap ture Touch to open Media Center. 30 Photos & videos To focus the picture, press Camera half way until the auto focus box turns green. To take the photo, press Camera down all the way. To see the picture you’ve just taken, touch the thumbnail on the lower left-hand corner of the screen to open the Media Gallery. Then, touch the picture’s thumbnail to view it.• To set the photo as a wallpaper or contact photo, press Menu > Set as . • To send the photo in a message or post it online, press Menu > Share . For more info on sharing your photos, see “Share your photo gallery”. • To delete the photo, press Menu > Delete . • For more options, press Menu > More . Photo optionsIn the viewfinder, press Menu > Settings to open the camera menu: optionsPicture Resolution Set the photo resolution. Video Resolution Set the camcorder video resolution. View your photosFind it: > Media Gallery > All Pictures Play a slideshowTouch > Media Gallery > All Pictures , Menu > Play slideshow to start a slideshow. To stop the slideshow, touch the display. To return to the gallery, press Back . Quick Send Address Store email addresses for sending pictures and videos. Review Time Choose the amount of time a recently taken picture is displayed on the view screen. Share optimization When checked, you’ll be prompted to optimize photo or video for sharing. options All Video 2011-02-12-Filename 12:00 Media Gallery 31 Photos & videos Share your photo galleryFind it: > Media Gallery > All Pictures To send your photo in a message, private call, or post it online: 1 Touch and hold a photo, then touch Share . 2 Choose how you want to share—like PTT , Email , or Messaging . Manage your photosFind it: > Media Gallery > All Pictures Touch and hold a photo, then:• To delete the photo, touch Delete . • To set the photo as a contact picture or wallpaper, touch Set as . Tip: To copy photos to/from a computer, go to “USB drag & drop” on page 49.Edit your photosFind it: > Media Gallery > All Pictures Touch & hold a picture, then touch Edit > One-click optimize , Rotate , Crop , Effects , Brightness & contrast , Color & saturation , Flip , or Resize . VideosRecord & shar…

Text truncated - open the document above for the full version.

FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907 2.1. Specification Compliance Transceiver type described herein has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Martha Lora SIGNATURE: /s/ Martha Lora DATE 28-Feb-2011 TITLE: Electrical Engineering Manager 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56MH1) is in compliance with all applicable parts of the FCC Rules. NAME: John Lewczak SIGNATURE: DATE 28-Feb-2011 TITLE: Engineering Manager, Product Safety and Compliance Page 2 - 1 FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Page 2 - 2 2.3. Attestation Statement (Bluetooth/Wi-Fi/MOTOtalk) This device contains an embedded Bluetooth device, and MOTOtalk capabilities, that Motorola confirms are compliant with the applicable Part 15 regulations. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Martha Lora SIGNATURE: /s/ Martha Lora DATE 28-Feb-2011 TITLE: Electrical Engineering Manager 2.4. Attestation Statement (Hearing Aid Compatibility) Motorola hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance. NAME: Martha Lora SIGNATURE: /s/ Martha Lora DATE 28-Feb-2011 TITLE: Electrical Engineering Manager FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN 2.5. Part 15B Declaration of Conformity Attestation We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the Class B computer peripheral portion of this composite filing. NAME: John Lewczak SIGNATURE: DATE 28-Feb-2011 TITLE: Engineering Manager, Product Safety and Compliance Page 2 - 3

FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907 2.1. SAR Testing Attestation The transceiver type described herein has been tested in accordance with the requirements contained in the appropriate Commission regulations. Specifically, with respect to RF Exposure (SAR) testing, there was no power reduction implemented in either the cellular or Wi-Fi bands during compliance testing with respect to simultaneous operation. All transmitters where evaluated at within 0.2 dB of their maximum rated power, as shown in the SAR test report. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with those standards.. NAME: John Lewczak SIGNATURE: DATE 8-Mar-11 TITLE: Engineering Manager, Product Safety and Compliance Page 2 - 1 FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 2 2.2. Attestation Statement (Bluetooth/MOTOtalk) This device contains an embedded Bluetooth device, and MOTOtalk capabilities, that Motorola confirms are compliant with the applicable Part 15 regulations. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Steven Tan SIGNATURE: /s/ Steven Tan DATE: 21-Nov-2008 TITLE: Engineering Section Manager 2.3. Attestation Statement (Hearing Aid Compatibility) Motorola hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance. NAME: Steven Tan SIGNATURE: /s/ Steven Tan DATE: 21-Nov-2008 TITLE: Engineering Section Manager FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com 2.4. Part 15B Declaration of Conformity Attestation We, the undersigned, hereby attest to the fact that we will apply the Declaration of Conformity procedure to the Class B computer peripheral portion of this composite filing. NAME: John Lewczak SIGNATURE: DATE 8-Mar-11 TITLE: Engineering Manager, Product Safety and Compliance Page 2 - 3

FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM 21 February 2011 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of transmitter with FCC ID: IHDT56MG1, i1Q/i1X-Series iDEN Handsets, with MOTOtalk, Wi-Fi, and Bluetooth. Gentlemen; Motorola Mobility, Inc.; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT56MH1. This is a variable output power (0.22 to 640 milliwatts) transmitter that is part of a handheld transceiver used in SMR and EA SMR trunking systems operating within the United States 806-821/851-866 MHz and 896-901/935-940 MHz frequency bands. Operation is also extended for use in a Narrowband PCS system operating in the United States in the spectrum between 901-902/940-941 MHz, on channels which the licensee has aggregated together to form twenty-one 25 kHz operating channels. To facilitate global roaming it is kindly requested that the grant for Part 90 800 MHz SMR operation reflects an extended frequency range (806 – 825 MHz) beyond that permitted under that part. Pursuant the guidance provide in KDB 634817 D01 (Freq Range Listing for Grants, v02r01), this application qualifies under the requirements of paragraph (d)(iii): use in other countries. This product will be distributed to operators in ITU Region 1 (Middle East), Region 2 (South America), and Region 3 (Asia) in countries that accept a United States FCC Grant for Equipment Authorization. This product is of the ‘receive first’ type of equipment, which can only transmit on frequencies assigned to it by a compatible Authorized Base Station. Therefore, no unauthorized transmission can occur within the United States or its territories, thus the product will not jeopardize United States public safety or other services licensed to operate in the 821-825 MHz frequency band, as no compatible base station may be authorized for those frequencies in the United States. This device also possesses a transmitter that operates in the ISM band (902 – 928 MHz). The two transmitters are configured so that they operate exclusive of each other (i.e. only one mode can operate at a time). While in this mode there is no connectivity to any cellular networks, and the transceiver uses only the FHSS protocol, as permitted in the ISM band. The operational mode is selected by the user via a menu selection. Certification is also sought for this transceiver, and performance data is provided for that purpose (Exhibit 6c). Page 13a - 1 FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM This radio product is also equipped with a Wi-Fi (802.11b/g) transceiver. Wi-Fi supports both voice and data for short range wireless communications. The Wi-Fi Band of Operation is 2.412 - 2.462 GHz, with channels up to 17 MHz in bandwidth for 802.11g operation and 80 mW of output power. The Wi-Fi device complies 15.247 (c), 15.205 and 15.209 (b). This radio product is equipped with a Bluetooth (BT) transceiver. BT supports both voice and data for short range wireless communications. The Bluetooth Band of Operation is 2.4 - 2.4835 GHz (1 MHz channel bandwidth). It is a Class 1 type device, with power rated +4 to +10 dBm (typically +8 dBm). The physical location of the Bluetooth antenna is shown in Exhibit 7b. The BT device complies with the requirements of FCC Rule Parts 15.247 (c), 15.205 and 15.209 (b). All transmitters contained in this radio product have been subjected to routine environmental evaluation (as applicable) according to 47 CFR Part 2.1093 (c) for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). This radio product features integrated GPS and FM broadcast receivers, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR Part 15.3(r). For these reasons a Declaration of Conformity has been prepared and provided as part of the User Guide (Exhibit 8), as shown on the exhibit cover page. Enclosed is a complete Certification Application. Contact me at (847) 523-6167 if you require any additional information. Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected] Page 13a - 2

FCC ID: IHDT56MH1 Motorola Mobility, Inc; 600 North US Hwy 45, Libertyville, IL 60048, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 21 February 2011 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56MH1. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. T56MH1_Ex_04 (Block Diagrams).pdf Schematic Diagrams. T56MH1_Ex_05 (Schematic Diagrams).pdf Parts List and Tune Up Procedures. T56MH1_Ex_10 (Active Components).pdf Transmitter Characteristics. T56MH1_Ex_12 (TX Characteristics).pdf Manufacturer PBA Correspondence Record T56MH1_Ex_12 (Manufacturer PBA FCC).pdf Motorola Mobility, Inc. requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility, Inc. understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56MH1 Motorola Mobility, Inc; 600 North US Hwy 45, Libertyville, IL 60048, USA www.motorola.com SHORT TERM ONFIDENTIALITY REQUEST – 75 DAYS (to 05/16/2011) Pursuant to the Commission’s public notice DA 04-1705 (June 15, 2004), Motorola Mobility, Inc. is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility, Inc. temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. T56MH1_Ex_03 (External_Photos).pdf Test set-up photographs. T56MH1_Ex_07b (SAR Test Set- up_Details).pdf T56MH1_Ex_07c (Part 15 Test Set- up_Details).pdf T56MH1_Ex_07d (HAC Test Set- up_Details).pdf User’s Manual. T56MH1_Ex_08 (User Guide).pdf Internal product photographs. T56MH1_Ex_09 (Internal Photos).pdf Please contact me if you require any additional information. Regards, FCC Liaison Motorola Mobility, Inc. 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 E-mail: [email protected] Page 13b - 2

FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 3. External Photographs -- Pursuant to 47 CFR 2.1033(c)(12) The radio product shapes, colors and housings/bezels may vary. Figure 3-1. Front of radio Page 3 - 1 FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Figure 3-2. Back of radio Page 3 - 2 FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Figure 3-3. PTT/Volume Button Side of radio Figure 3-4. Opposite Side of radio Page 3 - 3 FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Figure 3-5. Top of radio Figure 3-6. Bottom of radio Page 3 - 4 FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Temporary Confidentiality Requested Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Figure 3-7. Interior Compartment of radio FCC Label Location. See Exhibit 1 for details. Page 3 - 5

FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11) 1.1 Location On the rear (back) side of the radio product chassis, beneath the battery (see also Exhibit 3). 1.2 Type The label is of a white polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with minimum peel strength of 5 lbs/in. 1.3 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. Figure 1.3.1. Representations of FCC Label information. FCC ID: IHDT56MH1 IC: 109O-T56MH1 Model No. H78XAN9JR9BN FCC ID: IHDT56MH1 IC: 109O-T56MH1 Model No. H78XAN9JR9AN Page 1 - 1 FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Page 1 - 2 Figure 1.3.2. Representation of FCC Label information. This label will be placed on the equipment (within the Battery Compartment) as shown below. Other information may also be included on this label, and other labels may also be present. Figure 1.3.2. Location of FCC Label (position, orientation, and other information shown may vary). Please note that this label and its placement complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. Further, at the time of purchase, batteries are shipped in a separate section or compartment of the radio packaging, and are not attached to the radio. In some instances they may be shipped in separate boxes. So, the customer needs to physically install the battery by removing the battery cover, if any, or attach the battery before using the radio. Further, the placement of the label in the battery compartment is done because space is limited on the exterior of the device. The battery compartment also helps to protect the label from getting obliterated or made unreadable through regular handling and use. The product’s Market or Trade Name is indelibly printed on the face of the product, as shown in Exhibit 3. FCC ID: IHDT56MH1 IC: 109O-T56MH1 Model No. H78XAN9JR9CN Interior Battery Compartment FCC Label Back Side of Phone FCC Filing Package for Motorola i1Q/i1X Transceiver-Series FCC ID: IHDT56MH1 Motorola Mobility, Inc.; 600 North US Hwy 45, Libertyville, IL 60048, USA WWW.MOT.COM/iDEN Page 1 - 3 Exhibit 1A: General Information 1A.1 Production Plans Quantity production is planned. 1A.2 Data Submittal Procedure Performance data located in Exhibit 6 are supplied in accordance with the Commission’s rules: 47 CFR Part 2, Subpart…

Text truncated - open the document above for the full version.
