IHDT56MJ1CDMA 800/1900 TRANSCEIVER WITH BT & WLAN

APPLICANT MOTOROLA INC. FCC ID: IHDT56MJ1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 USER GUIDE [TITLE FPO...DAYTONA] 1 Congratulations Congratulations[Daytona_Product_Name] by Motorola[Daytona] by Motorola gives you a high quality imaging, video, and multimedia sharing experience.• Enjoy multitasking while you surf the web with a blistering fast 1 GHz dual core processor. • View Flash videos on your 4.3” qHD touchscreen or use Mirror Mode to view your smartphone on your TV screen: gaming, videos, web browsing, and more. • Capture life’s moments in HD video or use the connected media gallery to gather all your friends’ photos in one place. • Stream and store multimedia on any DLNA™ Certified device in your home network. No memory cards to swap, no cables to attach. • Choose from thousands of cool apps—including apps for downloading your favorite movies and TV shows to watch on your smartphone. Caution: Before assembling, charging or using your smartphone for the first time, please read “Safety, Regulatory & Legal” on page 59. More•Answers: Touch Launcher icon > Help Center . •Updates: Smartphone updates, PC software, online help and more at www.motorola.com/mydroidx2 . • Accessories: Find accessories for your smartphone at www.motorola.com/products . Notes:• All screens in this guide are simulated. Actual displays may vary. • Your smartphone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details. • Instructions to perform tasks in this guide may change depending on the software version on your smartphone. • Unless specified otherwise, all instructions to perform tasks in this guide assume that you are starting from the home screen. 2 Your smartphone Your smartphoneNote: Your smartphone might look a little different. P ress to put the displa y to sleep, press and hold to t urn of f . 3.5mm He a dset J ac k B ac k K e y Menu Key M ic ro p hone Home Key 4.3” qHD To u c hs c r een P o w er/ Lo c k K e y V olume Zoom K e ys Se a r c h Key P ress f or te xt searc h or press and hold f or v oice searc h. M ic ro U S B Po r t Charge or connect to PC. HDMI P or t / Co nten ts L e t ’ s g o . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 T o u c h scr e e n & k e y s . . . . . . . . . . . . . . . . . . . . . . . . . . 4 H o me s c r e e n . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 A p p s & u p d a t e s . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 0 C a l l s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1 C o n t ac t s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 4 T e xt e n t r y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 6 T i ps & t r i c k s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 9 D i g i t a l l i v i n g . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 0 Ph o t o s & vi d e os . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 2 M u si c . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 6 Y o u T ub e ™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 0 M e ssag in g . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1 So ci al n e t w o r k i n g . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 4 W e b . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 5 P e r s o n a l i z e . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 6 G o og l e M a p s ™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 8 G o og l e L a t i t u de ™ . . . . . . . . . . . . . . . . . . . . . . . . . . 4 0 A p p s f o r al l . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 1 B l u e t oo t h ® w i r e l e ss . . . . . . . . . . . . . . . . . . . . . . . . 4 3 W i -F i ™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 4 M e mo r y car d & f i l e m a na ge m e n t . . . . . . . . . . . . . . 4 6 T o o l s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 8 M a n a g e m e nt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 9 Se cu r i t y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 9 T r o u b l e sh o o t i n g . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 1 Saf e t y , R e gu l a t o r y & Leg al . . . . . . . . . . . . . . . . . . . . 5 2 3 Let’s go Let’s golet’s get you up and runningAssemble & charge 1 remove cover 2 insert microSD (may already be installed) 3 insert battery 4 replace cover 5 charge up Goldcont acts B at ter y re m ova l t ab (do not cut) 3H C a ut ion: Please read the battery use and safety text in the important legal and safety information packaged with your smartphone.Tip: To save battery life, see “Battery tips” on page 19. Set up & goThe first time you turn on your smartphone, a setup wizard guides you through signing in to your Gmail™ account. If you don’t have one, don’t worry, the wizard will help you create one. After you log in to Gmail, you can set up social networking, or you can do it later. Note: Your smartphone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details. 1 Press and hold Power/Lock on top of your smartphone to turn it on. 2 Select a language. 3 Follow the setup wizard to create or log in to your Gmail account. Note: If you have an existing Gmail account, your contacts from that account are synced to your smartphone. Whenever you choose to select all 4 Touchscreen & keys contacts for the one you want, your smartphone shows every contact, in every groups. Wi-Fi™ connectIf you want to use a Wi-Fi network for even faster Internet access, press Menu > Settings > Wireless & networks > Wi-Fi settings . Touch…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDT56MJ1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type (IHDT56MJ1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, 600 N. U.S. Highway 45, Libertyville, IL 60048. NAME: Patrick Mulhern TITLE: Engineering Manager Motorola Mobility Date: February 2, 2011 Page 1 of 3 EXHIBIT 2 APPLICANT: MOTOROLA INC. FCC ID: IHDT56MJ1 Page 2 of 3 EXHIBIT 2 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDP56KC1) is in compliance with all applicable parts of the FCC Rules. NAME: Dan Weiche TITLE: Engineering Manager Motorola Mobile Devices Business Date: February 2, 2011 APPLICANT: MOTOROLA INC. FCC ID: IHDT56MJ1 ATTESTATION STATEMENT This device contains an embedded Bluetooth device that Motorola confirms compliance with the following Part 15 regulations. 15.247(a)(1) • the hopping sequence must be pseudorandom • all Channels are used equally on average • the receiver input bandwidth is approximately equal to the transmit bandwidth • the receiver hops in sequence with the transmitted signal 15.247(g) the system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information) 15.247(h) the system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters NAME: Dan Weiche TITLE: Engineering Manager Motorola Mobile Devices Business Date: February 2, 2011 Page 3 of 3 EXHIBIT 2

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MJ1 January 29, 2011 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Dear Sir/Madame: Motorola Mobility, Inc., 600 N. U.S. Highway 45, Libertyville, Illinois 60048 herein submits Application for Equipment Authorization for Certification of a Cellular/PCS Transceiver, FCC ID: IHDT56MJ1. Motorola Mobility is also the manufa cturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission’s rules (CFR 47), Motorola Mobility requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola’s trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a Digital CDMA portable transceiver, which operates in the Cellular 850 and PCS 1900 MHz band. It employs EVDO data transission in the network and contains 2.4 GHz Bluetooth and WiFi functions (part 15.247). The unit is also connected to a computer via a USB connection(Part 15B). Note: This devi ce also contains functions that are not operational in the U.S. territories. This filing is only applicable for US operations. Contact Information: If there are any further questions or additional information needed concerning this filing, please contact me, John Lewczak, by telephone at (954) 723-6272 or via E-mail at: [email protected] . Regards, FCC Liaison Motorola Mobility, Inc. 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 E-mail: [email protected] Exhibit 13 1

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MJ1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDT56MJ1

Exterior – Rear with Battery and Battery Door Removed Battery and Battery Door APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MJ1 EXHIBIT 9 Interior - Front Interior - Rear APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MJ1 EXHIBIT 9 Interior – Front with PCB Removed APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MJ1 EXHIBIT 9

PCB - Rear PCB - Front APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MJ1 EXHIBIT 9 PCB – Rear with Shields Removed PCB – Front with Shields Removed APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MJ1 EXHIBIT 9

MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24341-1F E E x x h h i i b b i i t t 1 1 1 1 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobile Devices 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 24341-1F Date of Report: Feb 14, 2011 Date of Test: Feb 5 – Feb 10, 2011 FCC ID #: IHDT56MJ1 Generic Name: N/A Test Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Katerina Bruggemann Engineer Accreditation: Testing Laboratory No. 2404 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola Mobility, Inc. 2011 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24341-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 o o f f 2 2 1 1 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 4 2.1 Antenna description 4 2.2 Device description 4 3. Test Equipment Used 5 3.1 Dosimetric System 5 3.2 Additional Equipment 5 4. Electrical parameters of the tissue simulating liquid 6 5. System Accuracy Verification 7 6. Test Results 8 6.1 Head Adjacent Test Results 11 6.2 Body Worn Test Results 14 6.3 Mobile Hotspot Test Results 17 References 21 Appendix 1: SAR distribution comparison for the system accuracy verification Appendix 2: SAR distribution plots for Phantom Head Adjacent Use Appendix 3: SAR distribution plots for Body Worn Configuration Appendix 4: SAR distribution plots for Mobile Hotspot Configuration Appendix 5: Probe Calibration Certificate Appendix 6: Measurement Uncertainty Budget Appendix 7: Dipole Characterization Certificate MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24341-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 o o f f 2 2 1 1 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1g average set in [3] and 2.0W/kg in a 10g average set in [2]. For ANSI / IEEE C95.1 (1g), the final stand-alone SAR reading for this phone is 0.74 W/kg for head adjacent use, 1.40 W/kg for body worn use, and 1.50 W/kg in mobile hotspot mode. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24341-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 4 4 o o f f 2 2 1 1 2. Description of the Device Under Test 2.1 Antenna description Type Internal Location Bottom of Transceiver Length 51.6 mm Dimensions Width 6.2 mm 2.2 Device description 1 Serial Number(s) A0000022B36C41 (CDMA conducted power measurements, CDMA/800/1900/WIFI SAR testing, CDMA 800 Mobile Hotspot SAR testing), A0000022B3746E (CDMA 1900 Mobile Hotspot SAR testing) A0000022B36975 (Wi-Fi / Bluetooth conducted power measurements) Mode(s) of Operation CDMA 800 CDMA 1900 EV-DO Rev. A 800 EV-DO Rev. A 1900 Wi-Fi 802.11b/g /n Bluetooth Modulation Mode(s) QPSK QPSK QPSK QPSK BPSK GFSK Maximum Output Power Setting 25.0 dBm 25.0 dBm 25.0 dBm 25.0 dBm 18.6 dBm 8.39 dBm Duty Cycle 1:1 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.70 - 848.31 MHz 1851.20 - 1908.75 MHz 824.70 - 848.31 MHz 1851.20 - 1908.75 MHz 2412.0 - 2462.5 MHz 2402.0 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled 1 The DUT utilizes a reduced limit for the maximum transmit power when the mobile hotspot functionality is enabled. A description of this functionality is provided in the “Operational Description” contained within Exhibit 12. This description was also discussed within FCC KDB 631391. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24341-1F E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 5 5 o o f f 2 2 1 1 3. Test Equipment Used 3.1 Dosimetric System The Motorola Mobile Devices Business Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (D…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MJ1 Test Report Number: 24345-1 EXHIBIT 6 1 of 25 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 24345-1 Report Date – February 11, 2011 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated. Signature: Name: Albert J. Patapack Title: EMC Engineer Date: February 11, 2011 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY UKAS OR ANY AGENCY OF THE U.S. GOVERNMENT. UKAS Certificate Number: 2404 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MJ1 Test Report Number: 24345-1 EXHIBIT 6 2 of 25 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configuration 5 Measurement Procedures and Data 6 RF Power Output 6 Measurement results 6 Radiated Power 8 Measurement results 8 Occupied Bandwidth 10 Measurement results 11 Spurious Emissions at Antenna Terminals 15 Measurement results 16 Field Strength of Spurious Emissions 20 Measurement results 21 Frequency Stability 22 Measurement results 23 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MJ1 Test Report Number: 24345-1 EXHIBIT 6 3 of 25 Test Report Details Tests Performed By: Motorola Mobility Mobile Devices business (MDb) Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 FCC Registration Number: 316588 Industry Canada Number: 109O Tests Requested By: Motorola Mobility, Inc. Mobile Devices Business 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: CDMA 800/1900, CDMA 1X/EV-DO Release A, Bluetooth, 802.11b/802.11g/802.11n FCC ID: IHDT56MJ1 Serial Numbers: A0000022B360AE, A0000022B35E82 Testing Complete Date: February 11, 2011 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 2 X Part 22 Subpart H - Public Mobile Services X Part 24 Subpart E – Personal Communications Services Applicable Standards: ANSI 63.4 2003, ANSI/TIA-603-C-2004, RSS-Gen Issue 3, RSS-129 Issue 2, RSS-132 Issue 2, RSS-133 Issue 5 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MJ1 Test Report Number: 24345-1 EXHIBIT 6 4 of 25 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) Pass 3 EIRP (Effective Isotropic Radiated Power) Pass 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) See results 3 EIRP (Effective Isotropic Radiated Power) See results 4 Occupied Bandwidth See Plots 5 Spurious Emissions at Antenna Terminal See results 6 Field Strength of Spurious Emissions See results 7 Frequency Stability See results The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions When applicable, EMC testing was performed with a fully charged Model SNN5865A 1500mAH Battery. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment. The temperature and the relative humidity were maintained within the ANSI C63.4 2003 Standard requirements during the entire duration of testing. APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MJ1 Test Report Number: 24345-1 EXHIBIT 6 5 of 25 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Manufacturer Equipment Type Model No. Serial Number Calibration Due Date Rohde & Schwarz Receiver ESIB40 100226 4/08/2011 Hewlett Packard EMC Analyzer E7405 US40240219 10/19/2011 Agilent MXA Signal Analyzer N9020A US46470586 12/18/2011 Hewlett Packard Signal Generator 83623B 3844A00935 4/24/2011 A. H. Systems Horn Antenna SAS 200/571 365 4/07/2011 A. H. Systems Horn Antenna SAS 200/571 265 9/09/2011 ETS Log-Periodic Antenna 3148 1188 2/02/2011 ETS Log-Periodic Antenna 3148 1189 1/19/2012 ETS Biconical Antenna 3110B 3369 2/02/2011 ETS Biconical Antenna 3110B 3370 1/19/2012 Attenuator Weinschel AS-6 6675 NCR Attenuator Weinschel AS-6 6677 NCR Thermotron Environmental Chamber S-4 31580 1/13/2012 Agilent Power Meter E4416A GB41293263 9/11/2011 Agilent Power Sensor E9323A US40412066 8/30/2011 Agilent Microwave Preamplifier 8449B 3008A00535 10/05/2011 Note that the Agilent power meter and microwave preamplifier are on a two-year calibration cycle. All other equipment is on a one-year calibration cycle. All testing was performed using equipment that was within calibration at the time that the test was performed. No equipment listed in the table above was used after the specified calibration due date. If, during the course of product testing, a piece of equipment went out of calibration and that piece of equipment was needed to complete product testing, a similar piece of calibrated equipment was substituted. If a substitution was made, that new piece of equipment would be listed in the above table along with the piece that was removed from service. APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MJ1 Test Report Number: 24345-1 EXHIBIT 6 6 of 25 Measurement Procedures and Data RF POWER OUTPUT Measurement Procedure The RF output port of the equipment under test (EUT) is di…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56MJ1 P P a a g g e e 1 1 E E x x h h i i b b i i t t 6 6 B B - - 2 2 HAC Test Report for T-coil IHDT56MJ1 Date of test: Date of Report: Feb 10, 2011 Feb 14, 2011 Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Katerina Bruggemann Engineer Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC IHDT56MJ1 to which this declaration relates, complies with recommendations and guidelines FCC 47 CFR §20.19. The measurements were performed to ensure compliance to the ANSI C63.19-2007. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) Results Summary: T Category = T3 ©Motorola Mobility, Inc. 2011 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56MJ1 P P a a g g e e 2 2 E E x x h h i i b b i i t t 6 6 B B - - 2 2 Table of Contents 1. INTRODUCTION ...................................................................................................................................................3 2. DESCRIPTION OF THE DEVICE UNDER TEST.............................................................................................3 3. TEST EQUIPMENT USED....................................................................................................................................4 4. SIGNAL VERIFICATION .....................................................................................................................................7 5. TEST RESULTS......................................................................................................................................................8 5.1 T-coil SNR Results ..................................................................................................................................8 5.2 T-coil Environment Results..................................................................................................................11 6. MEASUREMENTS FOR CERTIFICATION OF 3G DEVICES.....................................................................13 APPENDIX 1: CONTOUR PLOTS........................................................................................................................14 APPENDIX 2: AMBIENT NOISE SPECTRUM PLOTS ....................................................................................15 APPENDIX 3: DETAILS ON THE MEASUREMENT SYSTEMS....................................................................18 APPENDIX 4: PICTURES OF TEST SETUP ......................................................................................................25 APPENDIX 5: MOTOROLA UNCETAINTY BUDGET ....................................................................................26 APPENDIX 6: AUDIO MAGNETIC PROBE CERTIFICATE ..........................................................................28 APPENDIX 7: AMCC CERTIFICATE (HELMHOLZ COIL)...........................................................................29 APPENDIX 8: HAC DISTRIBUTION PLOTS FOR E-FIELD AND H-FIELD ...............................................30 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56MJ1 P P a a g g e e 3 3 E E x x h h i i b b i i t t 6 6 B B - - 2 2 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed Hearing Aid Compatibility (HAC) measurements for the portable cellular phone (FCC ID IHDT56MJ1). The portable cellular phone was tested in accordance with ANSI PC63.19-2007 standard. The test results presented herein clearly demonstrate compliance FCC 47 CFR § 20.19. This report demonstrates compliance for T-coil performance only and not for near field emissions. 2. Description of the Device Under Test Table 1: Information for the Device Under Test Serial Number(s) A0000022B367B1 Mode(s) of Operation CDMA 800 CDMA 1900 EV-DO Rev. A 800 EV-DO Rev. A 1900 Wi-Fi 802.11 b/g/n Bluetooth Modulation Mode(s) QPSK QPSK QPSK QPSK BPSK GFSK Maximum Output Power Setting 25.0 dBm 25.0 dBm 25.0 dBm 25.0 dBm 18.6 dBm 8.39 dBm Duty Cycle 1:1 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.70- 848.31 MHz 1851.20- 1908.75 MHz 824.70- 848.31 MHz 1851.20- 1908.75 MHz 2412.0- 2462.5 MHz 2402.0- 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable Note: No Bluetooth profile exists in this phone that will allow a Bluetooth link while in a cellular call that passes audio to the earpiece. If the user had Bluetooth enabled and a link established, they could not be listening to the phone through the earpiece. Note: Wi-Fi capability is included in this phone without measurements for hearing aid compatibility based on the interim ruling by the FCC according to paragraph 37 of the Federal Register, Volume 3, Number 89, as of May 7, 2008. Users shall be informed of this via the product user guide per the same FCC ruling. APPLICANT: MOTOROLA, INC. FCC ID: IHDT56MJ1 P P a a g g e e 4 4 E E x x h h i i b b i i t t 6 6 B B - - 2 2 3. Test Equipment Used The Motorola Mobile Devices Business Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy4™ v4.7) manufactured by Schmid & Partner Engineering AG (SPEAG™) of Zurich, Switzerland. All T-coil measurements are taken within a shielded enclosure. The measurement uncertainty budget is given in Appendix 5. The list of calibrated equipment used fo…

Text truncated - open the document above for the full version.

EMC TEST SETUP PHOTOS Radiated Emissions APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MJ1 EXHIBIT 7 AC Line Conducted Emissions APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MJ1 EXHIBIT 7 Antenna - Substitution APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MJ1 EXHIBIT 7 PC Peripheral APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MJ1 EXHIBIT 7 EMC TEST SETUP PHOTOS Radiated Emissions – BT & WLAN APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MJ1 EXHIBIT 7

APPLICANT: MOTOROLA, INC. FCC ID: IHDT56MJ1 P P a a g g e e 1 1 E E x x h h i i b b i i t t 7 7 B B Pictur…
