IHDT56ML3Mobile Phone

Motorola Mobility LLC

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Jul 13, 2011
Application Purpose: Original Equipment
Date of Application: Jul 13, 2011
Equipment Note: Mobile Phone
Frequency Range: 2412.00000000 - 2462.00000000
Company: Motorola Mobility LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

MOTOROLA FIRE XT311/XT316 ™ 1Congratulations Congratulations MOTOROLA FIRE™ Yo u r M O TO R O L A FIRE phone is loaded with features, including videos, music, Web access, a powerful set of business tools, and more—all in a stylish phone design. • Mobile video: Record and watch videos, download or stream videos to watch on your phone. • Photos: Take and share great photos with a high performance camera. •Web: Get more from the Web, with support for Adobe® Flash® Player. Search, browse, everything you want to do, all made easier. Note: Certain apps and features may not be available in all countries. Caution: Before assembling, charging, or using your phone for the first time, please read the important legal and safety information at the back of this guide. 2Congratulations want More? • Support: Phone updates, PC software, online help and more at www.motorola.com/support. • Accessories: Find accessories for your phone at www.motorola.com/products . 3Your phone Your phone the important keys & connectors Note: Your phone might look a little different. Press = sleep. Hold = turn off. 3.5mm Headset Jack Back Key Menu Key Home Key Touchscreen Power/ Lock Key Volume Keys Touch to open menu options. Camera Key Touch for text search or hold for voice search. Search Key Micro USB Port Widgets Note: Your phone can only use an OMTP headset. 4Contents Contents Let’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Touchscreen & keys. . . . . . . . . . . . . . . . . . . . . . 8 Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24 Te entry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . 30 Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Photos & videos. . . . . . . . . . . . . . . . . . . . . . . . 38 Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40 personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 54 Safety, Regulatory & Legal . . . . . . . . . . . . . . . 55 5Let’s go Let’s go let’s get you up and running Assemble & charge 1Cover off2SIM in 3microSD in (may already be inserted) 4Battery in 5Cover on6Charge up 4H 6Let’s go Caution: Please read “Battery Use & Safety” on page 55. Tip: To save battery life, see “Battery tips” on page 31. Turn it on & off To turn on your phone, press Power (on the top left). To turn off your phone, press and hold Power, then touchPower off. Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details. Unlock To unlock your phone, touch the unlock icon and drag it to the right. Sounds off & on To turn phone sounds off, touch the sound icon and drag it to the left. 7Let’s go Wi-Fi™ connect You can use a Wi-Fi™ connection for even faster Internet access. Touch Menu >Settings >Wireless & networks >Wi-Fi settings. Touch Wi-Fi to turn it on and search for nearby wireless networks. Touch a network to connect. There’s more in “Wi-Fi Networks” on page 49. 8Touchscreen & keys Touchscreen & keys Touchscreen on/off a few essentials Your touchscreen is on when you need it and off when you don’t. •To make your touchscreen sleep or wake up, just press Power. •When you hold the phone to your ear during calls, your touchscreen sleeps to prevent accidental touches. •To let the touchscreen adjust brightness automatically, touch Menu >Settings >Display >Brightness and check Automatic brightness. Touch tips Here are some tips on how to navigate around your phone. To u ch To choose an icon or option, touch it. 9Touchscreen & keys Touch & hold To open special options, touch and hold an icon or other item. Try it: In the home screen, touch > Contacts, then touch and hold a contact to open options. Drag To scroll through a list or move slowly, drag across the touchscreen. Try it: In the home screen, touch > Contacts, then drag your Contacts list up or down. Tip: When you drag or flick a list, a scroll bar appears on the right. Drag the scroll bar to move the list to a letter A - Z. Flick To scroll through a list or move quickly, flick across the touchscreen (drag quickly and release). Contacts: A-Z Arthur Bando Barry Smyth Cheyenne Medina Christine Fanning All contacts Arthur Bando View contact Add to favorites Displaying 2 contacts A B C Arthur Baudo Barry Smyth Cheyenne Medina Christine Fanning Christopher Somers 10Touchscreen & keys Tip: When you flick a long list, touch the screen to stop it from scrolling. Pinch-to-zoom Get a closer look at maps, web pages, or photos. To zoom in, touch the screen with two fingers and then slide them apart. To zoom out, drag your fingers together. MessagingMarket N Clark St Wacker Dr M E Ohio St N Rush St N Park St N New St N Wabash Ave N Dearborn St E Grand Ave E Randolph St N Micigan Ave N Micigan Ave rD submuloC N W Lake StW Lake St E Wacker Pl State/Lake Grand Red Lake Randolph St Metra Randolph/ Wabash Washington-Blue E S WaterSt M M M M E Randolph St Ontario St E Ontario St pphh rra do ee do k E MM EEEERRRaanndddooolllphhhpphSSttt phh Messaging acker Dr M a rborn St N Micigan Ave W Lake StW Lake E Wacker Pl State/Lake Lake Randolph/ Wabash Washington-Blue E S M M M Randolph St Pinch to zoom out. 11Touchscreen & keys Key tips Menu, home, back & search Touch Home to close any menu or app and return to the home screen. In the home screen, touch and hold Home to show the…

Text truncated - open the document above for the full version.

Users Manual

19Calls •Touch and hold an entry to call it, send a text message, view call details or add the number to your contacts. •Touch Menu >Clear call log to clear the list. Conference calls To start a conference call, call the first number. After they answer, touch Add call and call the next number. When the next number answers, touch Merge calls. Your phone number To show your phone number, touch Menu >Settings >About phone >Status > My phone number Your caller ID To hide your number from the people you call, touch Menu>Settings >Call settings >Additional settings >Caller ID. Call forwarding & waiting To forward calls, touch Menu >Settings >Call settings >Call forwarding. You can forward calls all the time, or only when your phone is busy, unanswered, or unreachable (not on the network) 20Calls To turn on call waiting, touch Menu>Settings >Call settings >Additional settings >Call waiting. Call waiting lets you answer new calls when you’re already on a call. If call waiting is off, new calls go straight to your voicemail. Restricted calls To restrict your phone so that it can only dial a few numbers, touch Menu>Settings >Call settings >Fixed Dialing Numbers. •To turn fixed dialing on, touchEnable FDN. •To add or delete the allowed numbers, touch FDN list. Cool down In very limited circumstances, such as where your phone has been exposed to extreme heat, you may see “Cool Down” messages. To avoid possible damage to your battery and phone, you should follow these instructions until the phone is within its recommended temperature range. When your phone is in “Cool Down” mode, only emergency calls can be made. 21Calls Emergency calls Note: Your service provider programs one or more emergency phone numbers (such as 911 or 112) that you can call under any circumstances, even when your phone is locked. Emergency numbers vary by country. Your pre-programmed emergency number(s) may not work in all locations, and sometimes an emergency call cannot be placed due to network, environmental, or interference issues. 1Open the phone, then touchPhone (if your phone is locked, touchEmergency Call). 2Enter the emergency number. 3To u chCall to call the emergency number. Note: Your mobile device can use AGPS satellite signals to help emergency services find you (“Location Services (GPS & AGPS)” on page 65). 22Contacts Contacts contacts like you’ve never had before Quick start: Contacts From the home screen, touch > Contacts. •To create a contact, touch > Contacts >Menu >New contact, choose where you want to store the contact, then enter details (to close the display keyboard, touch Back). •To open a contact’s details, touch > Contacts, then touch the contact. Cheyenne Medina Call log PhoneFavorites Contacts A B C Arthur Baudo Barry Smyth Search New contact Accounts Import/Export More Display options Touch to open. Touch & hold to open options. Drag or flick to scroll. Switch to the dialer, recent calls, or favorites. Touch to open a menu where you can search, create, and more. 23Contacts •To edit or text a contact, touch > Contacts, then touch and hold the contact. SIM and Memory Card Contacts When you create a new contact you can choose to store it in your Google™ account, phone memory, or your SIM card. If you need to import or export contacts on your SIM or memory card, touch > Contacts, then touch Menu > Import/Export. 24Messaging Messaging sometimes it’s best to text or email... Quick start: Text Messaging From the home screen, touch > Messaging. Tip: To see more messages, flick or drag up. •To create a text message, touch >Messaging > New message. For options, touch Menu. Messaging New message Compose new message 12254558787 14447772222 You had 1 missed call from 122545458787 ... 17 Aug Wanna catch something to eat tonight? How about ... 17 Aug 12223334545 Ha! Thanks. 16 Aug Settings Delete threads Search Compose Touch to open. Touch & hold to open options. Drag or flick to scroll. Touch to open a menu where you can change settings and more. 25Messaging •To open text messages, touch > Messaging, then touch the sender’s name. When you see in the status bar at the top of your screen, flick down the status bar and touch the new message to open it. •To respond to a text message, just open it and enter your response in the text box at the bottom. •To forward, copy, and more, touch > Messaging, touch the sender’s name, then touch and hold the message. attachments To send a file in a text message, touch >Messaging > New message, then touch Menu >Attach. When you open a message with an attachment, touch Download to download it. Touch the downloaded attachment to open it, then touch it again to save it, share it, and more. Tip: To send and receive large attachments faster, use “Wi-Fi Networks” on page 49. 26Messaging Email •To set up Gmail or Corporate Microsoft™ Exchange server accounts, touch Menu > Settings > Accounts & sync > Add account. For details, contact the account provider. To set up a standard email account, touch > Email and follow the wizard. To add more standard accounts, open Email and touch Menu > Accounts > Menu > Add account. For details, contact the account provider. •To open email, touch > Email or Gmail. Touch a message to open it. Tip: Touch Menu for options like Refresh or Search. •To create an email, touch > Email or Gmail, then touch Menu >Compose. Tip: Touch Menu for options like Attach or Add Cc/Bcc. Voicemail When you have a new voicemail, shows in the status bar at the top of your screen. To hear voicemails, touch then touch and hold 1. 27Messaging If you need to change your voicemail number, in the home screen touch Menu >Settings >Call settings >Voicemail settings. 28Text entry Text entry keys when you need them Typing tips To... Enter alternate charactersFrom the number keyboard, touch Alternate. Touch again to return to symbols/numbers. Enter one capital letterTouch Shift. Enter only capital letters, until you touch Shift again To u ch S h i ft twice. Touch again to revert to lowerc…

Text truncated - open the document above for the full version.

Users Manual

39Photos & videos View & Share Photos & videos From the home screen, touch >My Gallery. Flick left and right to show folders. Touch a folder to show its photos or videos, then touch a thumbnail image to open, share, or delete it. Tip: From the viewfinder, you can touch the thumbnail in the top right to open your last photo or video. •To zoom in, touch the screen with two fingers and then drag them apart. To zoom out, drag your fingers together. •To send or post the photo or video, touchMenu > Share. •To delete the photo or video, touchMenu > Delete. •To set a photo as your wallpaper or a contact photo, touchMore > Set as. •To crop or rotate a photo, touch More. •To play a video, touch . Tip: Turn the phone sideways for a widescreen view. 40Music Music when music is what you need... Quick start: Music From the home screen, touch > Music, then choose a song to play it: •To adjust volume, use the phone’s volume keys. 11:04 Music Artist Album Title Song Title 0:263:27 Open Playlist Shuffle On/Off Repeat Off/All/Current Music Controls Total Song Time Progress Bar 41Music •When a song is playing, you touch Menu to add it to a playlist or use it as a Use it as a ringtone. To edit, delete, or rename playlists, touch >Music touch the Playlists tab, then touch and hold the playlist name. •To hide the player and use other apps, touch Home. Your music keeps playing. To return to the player, flick down the status bar and touch. Tip: For quick music player controls, touch and hold an empty spot in your home screen, then choose Widget > Music. •To stop the player, touch. •Before a flight, turn off network and wireless connections so that you can keep listening to music: Press and hold Power > Flight Mode. Note: When you select flight Mode, all wireless services are disabled. You can then turn Wi-Fi and/or Bluetooth back on, if permitted by your airline. Other wireless voice and data services (such as calls and text messages) remain off in flight Mode. Emergency calls to your region's emergency number (e.g., 911) can still be made. You can use your phone’s 3.5mm OMTP headset jack to connect wired headphones, or go wireless with “Bluetooth™ Devices” on page 47. 42Music To listen to FM radio stations, plug in a 3.5mm OMTP headset and touch >FM Radio. Your phone uses the headset wire as the radio antenna. Music Files Note: Copyright—do you have the right? Always follow the rules. See “Content Copyright” in your legal and safety information. To get songs for your music player, you can download them from online services or copy them from your computer. Your music player can play these file formats: MP3, M4A, AAC, ACC+, MIDI, WAV, or OGG Vorbis. Note: Your phone does not support any DRM protected files. To copy files from your computer to your phone, you can use “Cable Connection” on page 50 or “Bluetooth™ Devices” on page 47. To save a CD as files on your computer (“rip” the CD), you can use a program like Microsoft™ Windows™ Media Player. First, make sure you change the format to MP3 (under Rip > Format in Windows Media Player). 43personalize personalize add your personal touch Quick Start: personalize From the home screen, touch Menu >Settings >Sound or Display. Display settings Brightness Screen timeout All window animations are shown Animation Auto-rotate screen Adjust the delay before the screen automatically turns off Sound settings General Incoming calls Only in Silent mode Vibrate Volume Silent mode Silence all sounds except media & alarms Phone ringtone Notifications Notification ringtone Choose separate volume settings for incoming calls, media, alarms, and notifications. Call & Message Notifications Turn on or off menu animations. 44personalize •To choose a ring tone or vibration for incoming calls and messages, touch Menu >Settings >Sound, then choose Phone ringtone, Notification ringtone, or Vibrate. •To set the volume for your ringtone, media, and alarm, touch Menu >Settings >Sound >Volume. Tip: Press the volume keys to change the ringer volume (in the home screen), or the earpiece volume (during a call). •To hear dialpad sounds, touch Menu >Settings >Sound > Audible touch tones. •To hear menu selection sounds, touch Menu >Settings >Sound >Audible selection •To set a new wallpaper, touch and hold an empty spot on the home screen, then touch Wallpapers. •To set display brightness, touch Menu >Settings >Display >Brightness •Many apps can rotate the screen when you rotate your phone. To turn this on or off, touch Menu >Settings >Display > Auto-rotate screen. •Screen animations make your menus look smoother. To turn animations on or off, touch Menu >Settings >Display >Animation Volume Keys 45personalize wallpaper To set a new wallpaper, touch and hold an empty spot on the home screen, then touch Wallpapers. Language & region Set your menu language and region: Find it: Menu >Settings >Language & keyboard >Select language Date & time Set date, time, time zone, and formats: Find it: Menu >Settings >Date & time 46Connections Connections home, office, or hotspot Quick Start: Connections From the home screen, touch Menu >Settings >Wireless & networks, then Bluetooth settings or Wi-Fi settings. Wi-Fi networks Wi-Fi settings Notify me when an open network is available Network notification (Your network) Add Wi-Fi network Wi-Fi Bluetooth devices Bluetooth settings (Your Phone) Device name Scan for devices Make device discoverable Discoverable Bluetooth Pair with this device (Nearby Bluetooth Device) Turn Bluetooth power on & scan, or turn off. Change your phone’s Bluetooth device name. Turn Wi-Fi power on & scan, or turn off. Re-scan. Connect a device found by the scan. Connect a device found by the scan. 47Connections •To connect Bluetooth devices, touch Menu >Settings >Wireless & networks >Bluetooth settings > Scan for devices (or Bluetooth, if it is off). Touch a device that your phone found, to connect it. •To connect Wi-Fi networks, touch Menu >Settings >Wireless & networks >Wi-Fi settings (then touch …

Text truncated - open the document above for the full version.

Cover Letter(s)

FCC ID: IHDT56ML3 Motorola Mobility, Inc., 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33022, USA Pag e 13a - 1 24 June 2011 Authorization of Agent Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 RE: Grantee Code IHD . Authorization: I, John Lewczak, the FCC contact for Grantee Code “IHD,” hereby authorize the following company (agent) to act on behalf of Motorola Mobility, Inc. for the application specified below. This includes: • Form 731, Attestation Statement Exhibit, and Confidentiality Request Signatures. • Technical Contact. • Non-Technical Contact. • Test Firm Contact Information. The grant should still be mailed to the applicant of record for Grantee Code “IHD,” and any audit requests should also be directed to the applicant of record. Authorized Agent: Jones Tsai SPORTON INTERNATIONAL INC.. No. 52, Hwa Ya 1st Rd. Hwa Ya Technology Park Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C Specific Application: FCC ID: IHDT56ML3 Contact Information: Please contact me by telephone at (954) 723-6272, or by e-mail ([email protected] ), if there are questions or additional information needed concerning this authorization Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd, Suite A Plantation, FL 33022

Cover Letter(s)

1/1 Sporton International Inc. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Tel: 886-3-327-3456 ; Fax: 886-3-328-4978 Date: July 7, 2011 Federal Communications Commission Authorization and Evaluation Division RE : Certification Application FCC ID : IHDT56ML3 To Whom It May Concern, Pursuant to sections 0.457 and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, the applicant requests the following documents contained in this certification application be temporarily withheld from public disclosure for an initial period of 180 days:  External Photos (file: XT311_ExtPho.pdf)  Internal Photos (file: XT311_IntPho.pdf)  Test Setup Photos (file: XT311_Tsup.pdf)  User Manual (file: XT311_UserMan.pdf) The application contains technical information, which Sporton International Inc. deems to be trade secrets and proprietary. If made public, the information might be used to the disadvantage of the applicant in the market place. Sincerely, Jones Tsai

Cover Letter(s)

Rev. 1/1/03 Sporton International Inc. No. 52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. Tel: 886-3-327-3456 ; Fax: 886-3-328-4978 Date: July 7, 2011 Federal Communications Commission Authorization and Evaluation Division Confidentiality Request regarding application for certification of FCC ID: IHDT56ML3 Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Schematics (file: XT311_Schem.pdf) Block Diagram (file: XT311_BlkDia.pdf) Parts List (file: XT311_PartsLst.pdf) Operation Description (file: XT311_OpDes.pdf) Tune up Procedure (file: XT311_TunPro.pdf) The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, ________________________ Jones Tsai

External Photos

Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 1 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 2 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 3 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 4 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 5 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 6 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 7 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 8 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 9 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 10 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 11 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 12 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 13 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 14 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 15 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 WWAN Antenna <Tx / Rx> Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 16 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 WLAN & Bluetooth Antenna <Tx / Rx> Photographs of EUT Report No.: EP130415-02 Brand Name: MOTOROLA / Model Name: XT311 SPORTON INTERNATIONAL INC. Page Number : 17 of 17 TEL : 886-3-327-3456 Report Issued Date : Jun. 08, 2011 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56ML3 720510 GPS Antenna <Rx Only>

ID Label/Location Info

1 XT311 Label 2 XT311 Label Location 116.5 58

ID Label/Location Info

2 XT311 Label Location 116.5 58

Internal Photos

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jeff Narducci(Director Product Compliance)

[email protected]847-687-6928Fax: 847-687-6928

Test Firm

Sporton International IncKathy Lin

[email protected]886-2-26962468Fax: 886-2-26962255

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	80.00 mW

Confidentiality

Long Term

Grant Notes

Output power is conducted. This device was tested with a 1.0 cm device-to-body spacing gap and was not tested with any body-worn accessories made by any other manufacturer. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and must provide at least 1.0 cm separation between the device and the user body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values for head, body worn accessory, and mobile hotspot device are : 0.29W/kg, 0.13W/kg, 0.13W/kg respectively
