IHDT56MW1WCDMA/GSM TRANSCEIVER WITH BT & WLAN

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MW1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 1 Congratulations CongratulationsVENUS2 by Motorola You work. You have a life. VENUS2 by Motorola helps you handle it all, hassle free.• Stay on top of your work and personal email. • Manage your hectic calendar, then sync with your computer and favorite websites for anytime access to important meetings and appointments. • Sync your work and personal contacts. • View and edit documents from anywhere. • Use your device as a mobile hotspot to connect up to 8 laptops or other WiFi™ devices. • Browse the web at lightening speeds and view full Flash content. • Take and share great images and video with a high performing 5MP camera. Caution: Before assembling, charging or using your phone for the first time, please read the important legal and safety information packaged with your phone. More•Answers: To u ch > Help Center . You can also flick your home screen left or right to see the Tips & Tricks widgets. •Updates: Phone updates, PC software, online help and more at motorola.com/myvenus2 . • Accessories: Find accessories for your phone at www.motorola.com/products . Notes:• All screen shots in this guide are simulated. Actual displays may vary. • Instructions to perform tasks in this guide may change depending on the software version on your phone. • Unless specified otherwise, all instructions to perform tasks in this guide assume that you are starting from the home screen. 2 Congratulations Your phonethe important keys & connectors Text Messa.. BrowserB Market Voicemail 11:35 Power Key Press=Sleep. Hold=Turn off. 3.5mm Headset Jack Home Key Back Key Microphone Menu Key Micro USB Connector Charge or connect to PC. Notification LED On=Charged. Flashing=New notification. Volume Keys Search Key Programmable Key Touchscreen Note: Your phone might look a little different. Text Messa.. BrowserBro wse r Market Voicemail 11:35 http://www.motorola.com http://www.motorola.com DeleteEnter Sh i ft S pac e Sym b ols Altern a te W hen you turn your phone, the screen adjusts for you. Vo ic e 3 Contents ContentsLet’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . 5Home screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16Tips & tricks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19Digital living . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . 22Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26YouTube™ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . 34Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35Personalize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37Maps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39Latitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41Apps for all . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42Bluetooth® wireless . . . . . . . . . . . . . . . . . . . . . . . . 44Wi-Fi®. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45Memory card & file management. . . . . . . . . . . . . . 47Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . 52Safety, Regulatory & Legal . . . . . . . . . . . . . . . . . . . 53 Let’s golet’s get you up and runningAssemble & charge 1 Cover off 2 SIM in 3 microSD in (may already be inserted) 4 Battery in 5 Cover on 6 Charge up 3H 4 Let’s go Caution: Please read the battery use and safety text in the important legal and safety information packaged with your phone.Tip: To save battery life, see “Battery tips” on page 19. Set up & goThe first time you turn on your phone, a setup wizard guides you through signing in to your Gmail™ account. If you don’t have one, don’t worry, the wizard will help you create one. After you log into Gmail, you can set up social networking, or you can do it later. Note: This phone supports data-intensive apps and services. It is strongly recommended that you purchase a data plan that meets your needs. Contact your service provider for details. 1 Press and hold Power on top of your phone to turn it on. 2 Select a language. 3 Follow the setup wizard to create or log in to your Gmail account. Note: If you have an existing Gmail account, your contacts from that account are synced to your phone. Whenever you choose to select all contacts for the one Power Key you want, your phone shows every contact, in every groups. Wi-Fi® connectIf you want to use a Wi-Fi computer network for even faster Internet access, touch Menu > Settings > Wireless & networks > Wi-Fi settings . Touch Wi-Fi to search for and connect to wireless networks. There’s more in “Wi-Fi®” on page 44. Cool content & moreBrowse and download thousands of the coolest apps on the planet from Android Market™. Look in “Apps for all” on page 41.Your phone comes with a microSD memory card installed—you can load it up with photos, videos, and music from your computer using “Memory card” on page 46. 5 Touchscreen & keys Touchscreen & keysa few essentialsTouch tipsHere are some tips on how to navigate around your phone.TouchTo choose an icon or option, t…

Text truncated - open the document above for the full version.

FCC ID: IHDT56MW1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 25 March 2011 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56KD1. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. Exhibit 4 (Block Diagrams) Schematic Diagrams. Exhibit 4 5 (Schematic Diagrams) Parts List and Tune Up Procedures. Exhibit 10 (Parts List/Tune Up Information) Transmitter Characteristics. Exhibit 12 (TX Characteristics) Motorola Mobility, Inc. requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility, Inc. understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56MW1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com SHORT TERM ONFIDENTIALITY REQUEST – 180 DAYS Pursuant to the Commission’s public notice DA 04-1705 (June 15, 2004), Motorola Mobility, Inc. is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility, Inc. temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. Exhibit 3 (External_Photos) Test set-up photographs. Exhibit 7 and 7A (Test Set-up Details) User’s Manual. Exhibit 8 (User Guide) Internal product photographs. Exhibit 9 (Internal Photos) Please contact me if you require any additional information. Regards, FCC Liaison Motorola Mobility, Inc. 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 E-mail: [email protected] Page 13b - 2

APPLICANT: MOTOROLA MOBILITY, I NC. FCC ID: IHDT56MW1 EXHIBIT 3 1 of 2 FRONT OF PHONE BACK OF PHONE BACK OF PHONE WITH BATTERY COVER REMOVED FCC ID Label Location APPLICANT: MOTOROLA MOBILITY, I NC. FCC ID: IHDT56MW1 EXHIBIT 3 2 of 2 SIDE OF PHONE TOP OF PHONE BOTTOM OF PHONE

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MW1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3, and is readily visible at the time of purchase. Other information may also be included on this label. FCC ID: IHDT56MW1

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MW1 EXHIBIT 9 1 of 6 Main Board Top With shields Main Board Top Without shields Main Board Bottom With Shields Main Board Bottom Without Shields APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MW1 EXHIBIT 9 2 of 6 Daughter Board Top Daughter Board Bottom With metal plate Daughter Board Bottom APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MW1 EXHIBIT 9 3 of 6 Headset Jack Flex Top Headset Jack Flex Bottom Rear Touch Flex Top Rear Touch Flex Bottom Jumper Flex Top Jumper Flex Bottom, APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MW1 EXHIBIT 9 4 of 6 Keypad Keypad PCB TOP Keypad PCB Bottom Keypad Bottom APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MW1 EXHIBIT 9 5 of 6 Inside Battery Cover Inside Rear Housing Ass’y Display Cover Ass’y LCD Ass’y Camera Bottom Front End Ass’y Speaker Bottom Main Lens Ass’y APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56MW1 EXHIBIT 9 6 of 6 Battery Cover Rear Housing Ass’y Inside Front End Ass’y Display Cover Ass’y LCD Ass’y Back Inside Main Lens Ass’y Speaker Top Camera Top

MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24383-1F FCC ID: IHDT56MW1 Exhibit 11 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobility, Inc. 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 24383-1F Date of Report: Sep-03-2010, revised on Mar-04-2011 Date of Test: Aug-17-2010 to Aug-26-2010, Feb-16- 2011, Mar-01-2011 to Mar-04-2011 FCC ID #: IHDT56MW1 Generic Name: MURQ7-3334411A11 Test Laboratory: Motorola Mobility, Inc. - Product Safety & Compliance Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Steven Hauswirth Distinguished Member of the Technical Staff Accreditation: 2404 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2011 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24383-1F FCC ID: IHDT56MW1 Exhibit 11 Page 2 of 25 Table of Contents 1. Introduction 3 2. Description of the Device Under Test 3 2.1 Antenna description 3 2.2 Device description 4 2.3 Evaluation of WCDMA modes 5 2.4 Evaluation of Wi-Fi 802.11 modes 6 2.5 Evaluation of Bluetooth 7 3. Test Equipment Used 8 3.1 Dosimetric System 8 3.2 Additional Equipment 9 4. Electrical parameters of the tissue simulating liquid 10 5. System Accuracy Verification 11 6. Test Results 12 6.1 Head Adjacent Test Results 12 6.2 Body Worn Test Results 17 6.3 Mobile Hotspot Test Results 21 References 25 Appendix 1: SAR distribution comparison for the system accuracy verification Appendix 2: SAR distribution plots for Phantom Head Adjacent Use Appendix 3: SAR distribution plots for Body Worn Configuration Appendix 4: Probe Calibration Certificate Appendix 5: Measurement Uncertainty Budget Appendix 6: Dipole Characterization Certificate MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24383-1F FCC ID: IHDT56MW1 Exhibit 11 Page 3 of 25 1. Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of the portable cellular phone covered by this test report. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with [1], [4] and [5]. The SAR values measured for the portable cellular phone are below the maximum recommended levels of 1.6 W/kg in a 1 g average set in [3] and 2.0 W/kg in a 10 g average set in [2]. For ANSI / IEEE C95.1 (1 g), the final SAR reading for this phone is 0.86 W/kg for head-adjacent use and 0.86 W/kg for body-worn use, and 0.92 W/kg in mobile hotspot mode. These measurements were performed using a Dasy4™ v4.7 system manufactured by Schmid & Partner Engineering AG (SPEAG), of Zurich Switzerland. 2. Description of the Device Under Test 2.1 Antenna description Main Antenna Type Internal Location Bottom of Transceiver Dimensions Width 10.55 mm Length 52.50 mm Bluetooth/Wi-Fi Antenna Type Internal Location Left-Side Rear of Transceiver Dimensions Width 3.56 mm Length 21.85 mm MOTOROLA, INC. Portable Cellular Phone SAR Test Report Number: 24383-1F FCC ID: IHDT56MW1 Exhibit 11 Page 4 of 25 2.2 Device description Serial Number(s) KVT00L0154 (Head and Body Worn SAR testing) 355498040001957 (WiFi Hotpost Mode Testing) Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled Mode(s) of Operation GSM 850 GSM 900 GSM 1800 GSM 1900 WCDMA 850 WCDMA 1900 WCDMA 2100 Wi-Fi 802.11b/g/n Bluetooth Modulation Mode(s) GMSK GMSK GMSK GMSK QPSK QPSK QPSK BPSK GFSK Maximum Output Power Setting 33.5 dBm 33.5 dBm 30.5 dBm 30.5 dBm 24.0 dBm 24.0 dBm 24.0 dBm 20.0 dBm 10 dBm Duty Cycle 1:8 1:8 1:8 1:8 1:1 1:1 1:1 1:1 1:1 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz 826.4 - 846.6 MHz 1852.4 - 1907.6 MHz 1922.4 - 1977.6 MHz 2412.0 - 2462.5 MHz 2402.0 - 2483.5 MHz Mode(s) of Operation GPRS 850 GPRS 900 GPRS 1800 GPRS 1900 Modulation GMSK GMSK GMSK GMSK Maximum Output Power Setting (dBm) 33.5 31.5 29.5 27.5 33.5 31.5 29.5 27.5 30.5 28.5 26.5 24.5 30.5 28.5 26.5 24.5 Duty Cycle 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 1:8 2:8 3:8 4:8 Transmitting Frequency Range(s) 824.2 - 848.8 MHz 880.2 - 914.8 MHz 1710.2 - 1784.8 MHz 1850.2 - 1909.8 MHz Mode(s) of Operation EDGE 850 EDGE 900 EDGE 1800 EDGE 1900 Modulation 8PSK 8PSK 8PSK 8PSK Maximum Output Power Setting (dBm) 27.5 26.5 24.5 22.5 27…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report Number: 24388-1 WLAN Page 1 of 22 EXHIBIT 6A3 PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT - Addendum Test Report Number –24388-1 WLAN Report Date –2011-02-12 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. Signature: Name: Lei Yang Title: EMC Project Manager Test: 2010-09-09 to 2010-09-10 As the responsible test lab manager, I hereby declare that the model tested as specified in this report conforms to the requirements indicated . Signature: Name: Yilin Zhao Title: Test Lab Manager Date: 2011-02-16 This report must not be reproduced, except in full, without written approval from this laboratory. FCC Registration Number: 177885 IC Registration Number: 109AW-1 ADR Testing Service location ADR BJ ISO/IEC-17025:2005 accredited by UKAS 2404 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report Number: 24388-1 WLAN Page 2 of 22 EXHIBIT 6A3 Table of Contents Test Report Details .............................................................................................................3 Applicable Standards .......................................................................................................... 4 Summary of Testing............................................................................................................ 5 General and Special Conditions.......................................................................................... 5 Equipment and Cable Configurations ................................................................................. 6 Measuring Equipment and Calibration Information ........................................................... 6 Measurement Procedures and Data..................................................................................... 8 FIELD STRENGTH OF SPURIOUS EMISSIONS....................................................... 8 Measurement Procedure.............................................................................................. 8 Measurement Results .................................................................................................. 9 WLAN Band (b) ......................................................................................................... 9 WLAN Band (g) ....................................................................................................... 12 BAND-EDGE COMPLIANCE OF RF RADIATED EMISSIONS............................. 15 Measurement Procedure............................................................................................ 15 Measurement Results ................................................................................................ 15 WLAN Band (b) ....................................................................................................... 16 WLAN Band (g) ....................................................................................................... 18 WLAN Band (n) @ 6.5 Mbps................................................................................... 20 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report Number: 24388-1 WLAN Page 3 of 22 EXHIBIT 6A3 Test Report Details Tests Performed By: Motorola (Beijing) Mobility Technologies Co., Ltd. Asia Global Compliance Labs No.1 Wang Jing East Road Chao Yang District Beijing, 100102, P. R. China Phone: +86 10 8473 2610 FCC Registration Number: 177885 IC Registration Number: 109AW-1 Tests Requested By: Motorola Mobility, Inc. 600 North US Hwy 45 Libertyville, IL 60048 United States Product Type: Cell Phone embedded WLAN Signaling Capability: WCDMA 850/1900, GSM 850/1900, EDGE 850/1900, Bluetooth, 802.11b & g & n IMEI: 353635040003044 FCC ID: IHDT56MW1 Project number: 24388-1 Testing Complete Date: 2010-09-10 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report Number: 24388-1 WLAN Page 4 of 22 EXHIBIT 6A3 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart C – Intentional Radiators Part 22 Subpart H - Public Mobile Services Part 24 - Personal Communications Services Part 27 - Wireless Communications Service Part 90 - Private Land Mobile Radio Service Applicable Standards: ANSI C63.4-2003, RSS-Gen Issue 2, RSS-210 Issue 7. The following tests were performed according to the regulations: • The spurious radiated emission requirements of § 15.247 and § 15.249 of CFR47 Part 15 2007, specifically” radiated emissions which fall in the restricted bands, as defined in Section 15.205(a), must also comply with the radiated emission limits specified in Section 15.209(a) (see Section 15.205(c)). • Under this project only 30 to 1000 MHz, 1 to 26.5 GHz radiated and radiated band-edge measurements were performed. • For frequencies below 1 GHz a 100 kHz RBW (6 dB) is used and above 1 GHz a 1 MHz RBW (6 dB) is used. APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report Number: 24388-1 WLAN Page 5 of 22 EXHIBIT 6A3 Summary of Testing Test Test Name Pass/Fail _____________________________________________________________________ 1 Field Strength of Spurious Emissions Pass 2 Band-edge Compliance of RF Radiated Emissions Pass Test Test Name Results ______________________________________________________________________ 1 Field Strength of Spurious Emissions See plots 2 Band-edge Compliance of RF Radiated Emissions See plots The margin with respect to the limit is the minimum margin for all modes and bands. General and Special Conditions The 24388-1 test sample was tested using a fully charged Model SNN5843A 1420mAH battery when applicable. Where a battery could not be used due to the need for a controlled variation of input volt…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report 24388-1 WLAN 1 of 55 EXHIBIT 6A5 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 24388-1 WLAN Report Date – February 15, 2011 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated. Signature: Name: Albert J. Patapack Title: EMC Engineer Date: February 15, 2011 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 2518-02 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report 24388-1 WLAN 2 of 55 EXHIBIT 6A5 Table of Contents Test Report Details .............................................................................................................3 Applicable Standards .......................................................................................................... 3 Summary of Testing............................................................................................................ 4 General and Special Conditions.......................................................................................... 4 Equipment and Cable Configurations ................................................................................. 5 Measuring Equipment and Calibration Information ........................................................... 5 Description of WLAN Transmitter ..................................................................................... 5 Measurement Procedures and Data..................................................................................... 6 Spectrum Bandwidth....................................................................................................... 6 Measurement Procedure.............................................................................................. 6 Measurement Results .................................................................................................. 6 Peak Output Power ....................................................................................................... 16 Measurement Procedure............................................................................................ 16 Measurement Results ................................................................................................ 16 Power Spectral Density................................................................................................. 22 Measurement Procedure............................................................................................ 22 Measurement Results ................................................................................................ 22 Spurious RF Conducted Emissions............................................................................... 23 Measurement Procedure............................................................................................ 23 Measurement Results ................................................................................................ 23 AC Line Conducted Emissions ..................................................................................... 45 Measurement Procedure............................................................................................ 45 Measurement Results ................................................................................................ 45 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report 24388-1 WLAN 3 of 55 EXHIBIT 6A5 Test Report Details Tests Performed By: Motorola Mobility Mobile Devices business (MDb) Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 FCC Registration Number: 316588 Industry Canada Number: 109O-1 Tests Requested By: Motorola Mobility, Inc. Mobile Devices Business 600 North US Hwy 45 Libertyville, IL 60048 Product Type : Cellular Phone Signaling Capability: WCDMA 850/1900, GSM 850/1900, HSUPA, HSDPA, EDGE, GPRS, Bluetooth, 802.11b/802.11g/802.11n FCC ID: IHDT56MW1 Serial Numbers: 35365040003069 Testing Complete Date: August 25, 2010 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart C – Intentional Radiators Applicable Standards: ANSI 63.4 2003, RSS-210 Issue 7 APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report 24388-1 WLAN 4 of 55 EXHIBIT 6A5 Summary of Testing Test Test Name Pass/Fail ___________________________________________________________ 1 Spectrum Bandwidth Pass 2 Peak Power Pass 3 Power Spectral Density Pass 4 Spurious RF Conducted Emissions Pass 5 AC Line Conducted Emissions Pass Test Test Name Results ____________________________________________________________ 1 Spectrum Bandwidth See plots 2 Peak Power See plots 3 Power Spectral Density See tables 4 Spurious RF Conducted Emissions See plots 5 AC Line Conducted Emissions See Plots General and Special Conditions All testing for this report was performed with a fully charged Model SNN5843A 1390mAH Battery. All testing was done in an indoor controlled environment. The temperature and the relative humidity were maintained within the ANSI C63.4 2003 Standard requirements during the entire duration of testing. APPLICANT: MOTOROLA MOBILITY, INC FCC ID: IHDT56MW1 Test Report 24388-1 WLAN 5 of 55 EXHIBIT 6A5 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical us…

Text truncated - open the document above for the full version.

EMC TEST SETUP PHOTOS Radiated Emissions APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MW1 EXHIBIT 7 AC Line Conducted Emissions APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MW1 EXHIBIT 7 Antenna - Substitution APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MW1 EXHIBIT 7 Part 15, PC Peripheral Radiated Emissions APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MW1 EXHIBIT 7 EMC TEST SETUP PHOTOS Radiated Emissions APPLICANT: MOTOROLA MOBILITY, INC.FCC ID: IHDT56MW1 EXHIBIT 7

Applicant: Motorola, Inc. FCC ID: IHDT56MW1 24383-1P Exhibit 7D Page 0 0 Portable Cellular Phone SAR Test Report Photographs of the Device Under Test Applicant: Motorola, Inc. FCC ID: IHDT56MW1 24383-1P Exhibit 7D Page 1 1 Figure 1: Phone Front and Back Figure 2: Antenna Separation Applicant: Motorola, Inc. FCC ID: IHDT56MW1 24383-1P Exhibit 7D Page 2 2 Figure 3: Cheek Position, Front of Head of Phantom Figure 4: Cheek Position, Top of Head of Phantom Applicant: Motorola, Inc. FCC ID: IHDT56MW1 24383-1P Exhibit 7D Page 3 3 Figure 5: Tilt Position, Front of Head of Phantom Figure 6: Tilt Position, Top of Head of Phantom Applicant: Motorola, Inc. FCC ID: IHDT56MW1 24383-1P Exhibit 7D Page 4 4 Figure 7: Body Position
