IHDT56NA1WCDMA/GSM TRANSCEIVER WITH BT & WLAN

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NA1 INSTRUCTION MANUAL A representative version of the user's manual follows: Exhibit 8 MOTOROLA XT605 EN January 10, 2012 January 10, 2012 1 Congratulations CongratulationsMOTOROLA XT605Stay connected, organize your life, and absolutely own the web with MOTOROLA XT605.• Direct Connect calls. Keep in touch with your family, friends, and colleagues with the simple touch of a button. • Organization. Check your email, calendar, and contacts wherever you are. •Browsing. Get more from the web with a huge screen. Search, browse, everything you want to do, all made easier. • Maps, entertainment, and more. The latest technology and apps. Google Maps™ to find your way. YouTube™ to stay entertained. Easy access to Google™ and thousands of Android™ apps to expand your world. Note: Certain apps and features may not be available in all countries. Caution: Before assembling, charging, or using your phone for the first time, please read the important legal and safety information packaged with your product. This product meets the applicable SAR limits of 1.6 W/kg (FCC & IC) and 2.0 W/kg (ICNIRP). The limits and guidelines include a substantial safety margin designed to assure the safety of all persons, regardless of age and health. The highest SAR values measured for this device are listed in the regulatory information packaged with your product.Note: When using the product while worn on your body, either use an approved accessory such as a holster or maintain a distance of 2.5 cm (1 inch) from the body to ensure compliance with SAR requirements. Note that the product may be transmitting even if you are not making a phone call. More•Answers: Touch > Help Center . • Updates: Smartphone updates, computer software, user guides, online help, and more at www.motorola.com/myXT605 . • Accessories: Find accessories for your smartphone at www.motorola.com/products . January 10, 2012 2 Your phone Your phonethe important keys & connectorsNote: Your phone might look a little different. 11:58 Add a social network Add a social network HAPPENINGS UNIVERSALINBOX No recent unseen messages 64 ̊ WOODSTOCK 64 ̊ WOODSTOCK Press=Sleep/Wake up. Hold=Turn on/off. Speaker Key Home Key Back Key Menu Key Micro USB Connector Charge or connect to PC. Volume Keys Search Key DC Button ProgrammableKey Touchscreen Power/ScreenLock Key 3.5mm Headset Jack ContentsLet’s go . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3Touchscreen & keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4Home screen & apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10Direct Connect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16Messaging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20Text entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23Tips & tricks. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25Photos & videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31Social networking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38Personalize. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42Apps for all. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44Bluetooth™ wireless. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47Memory card & file management . . . . . . . . . . . . . . . . . . . . . . . . 49Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61Safety, Regulatory & Legal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 January 10, 2012 3 Contents Let’s golet’s get you up and runningAssemble & chargeCaution: Please read “ Battery Use & Safety ” on page 62. Tip: To save battery life, see “ Battery tips ” on page 26. 1 Cover off 2 m icroSD in 3 SIM in 5 Cover on 6 Charge Battery inB 4 3H SIM m icroSIM m icroSIM + Adapter Set up & goNote: This phone supports apps and services that use a lot of data, so make sure your data plan meets your needs. Contact your service provider for details.Note: If you have an existing Gmail™ account, your contacts from that account are synced to your phone. 11:58 Add a social network Add a social network HAPPENINGS UNIVERSALINBOX No recent unseen messages 64 ̊ WOODSTOCK 64 ̊ WOODSTOCK d d a soci HA 6 6464 AAd eeen nn ̊ ̊ 6 66 44 ̊ ̊ 64 ̊ 1 Turn on. A P 1 1 58 al nnnen 2 Select a language. 64 6464 3 Create account,or log in. Kim Vonesh Welcome Touch the android to begin. Emergency dial Change language Set up your Google Account 4 Add accounts. Don’t have a Google Account?Already have a Google Account? Want to set up an account later? Create Sign in Skip If you use any of the services below, tap the icon to set …

Text truncated - open the document above for the full version.

29 Photos & videos VideosRecord & share videosFind it: > Camcorder Note: To get the clearest videos, wipe the lens clean with a soft, dry cloth before you record a video.To r e c o r d a video, touch . Touch to stop the recording.Note: Photos are stored on your phone’s internal memory unless you switch it to a microSD memory card (sold separately). Video Resolution is High Definition (720p) unless you change it. ww 55 44 000 666 - 7 - 2222 0000000 88888 22 444 555 44 555 SCREEN NOT YET AVAILABLE Open your gallery and touch and hold a video to view options.HD videosYou can capture HD-quality videos to watch on an HDTV or monitor.To record an HD quality video, be sure to select the correct Video resolution . From the active camcorder viewfinder, touch Menu > Settings > Video resolution > High Definition (720p) . To enhance the video quality, touch Menu > Scenes or Effects . Options Play To play the video, touch . Upload To upload the video to an online album, touch . Share To send the video in a message or post it online, touch . For more info on sharing your video, see “ Share photos & videos ” on page 31. Delete To delete the video, touch Menu > Delete . January 10, 2012 30 Photos & videos Video SettingsYou can make adjustments to optimize your video. Touch Menu to see these options. Options Settings Set Video Resolution . Effects Change video look: Normal , Black and White , Negative , and more. Scenes Adjust for better audio capture in different environments: Auto and Night . Modes Choose from Normal video , Video Message , Fast motion , or Slow motion . BrightnessLight Turn a light on or off to adjust for the lighting where you are recording. Switch to Camera Flick the switch below to toggle between photo and camcorder. View photos & videosFind it: > Gallery SCREEN NOT YET AVAILABLE January 10, 2012 31 Music Share photos & videosFind it: > Gallery 1 Touch a photo or video, then touch . 2 Choose how you want to share—like Bluetooth , Email , Text Messaging , or an online album. Manage photos & videosFind it: > Gallery Touch a thumbnail image from your camera roll or library, then:• To delete the photo or video, touch Menu > Delete . • To set the photo as a contact picture, social network profile picture, or wallpaper, touch Menu > Set as . Tip: To copy photos to/from a computer, go to “ View & transfer files with Motorola phone portal ” on page 50. Edit photos & videosFind it: > Gallery > Camera roll , select a picture, and touch Menu > Edit You can choose advanced editing features to resize, crop, or change the color. Musicwhen music is what you need...Quick start: MusicFind it: > Music SCREEN NOT YET AVAILABLE January 10, 2012 32 Music Touch a category, then touch the song or playlist you want to play. Touch Menu > More > to randomly play all your songs, or touch Search to find a song. Tip: When a song is playing, you can add it to a playlist by touching Menu > Add to playlist . Tip: To listen to music during a flight, turn off all your network and wireless connections: Press and hold Power/Lock then touch Airplane mode . Set up musicWhat music transfer tools do I need?To put music on your computer and then load it on your phone, you need:• Microsoft™ Windows™ computer or Apple™ Macintosh™. • USB data cable (included with your phone). • Optional microSD memory card (sold separately).Your phone supports removable microSD memory cards up to 32GB capacity. To make sure your memory card is installed, go to “ Assemble & charge ” on page 3.Tip: To see the available memory on your memory card, touch > Settings > Storage . What audio file formats can I play?Your phone can play many types of files: AAC, AMR, MP3, WAV, WMA, AAC+, and MIDI.What headphones can I use?Your phone has a 3.5mm headset jack for wired stereo listening (required for FM radio). You can also go wireless with Bluetooth™ stereo headphones or speakers (see “ Bluetooth™ wireless ” on page 46). Get musicTransfer music from your computer to your phone using a USB cable connection. Music files can be transferred to your phone by syncing with Windows Media® Player or using Motorola Media Link.Note: Copyright—do you have the right? Always follow the rules. See “ Content Copyright ” on page 69. Sync with Windows Media Player 1 Using a USB cable, connect your phone to an available USB port on your computer. 2 Flick the status bar down and touch USB Connection > Windows Media Sync . 3 Open Windows Media Player and drag and drop your music into the sync list. 4 Click on Start Sync. January 10, 2012 33 Music Transfer music with Motorola Media LinkMotorola Media Link lets you transfer music files from Windows Media Player or iTunes®. Before you can transfer music, you’ll need to create playlists with the music you wish to transfer.The first time you use the music player, you’ll be prompted to install Media Link from your phone. You can also download Media link from www.motorola.com/medialink . To transfer music: 1 Use a USB cable to connect your device to an available USB port on your computer. Once the Photos Last Sync 06/14/2011 Music Last Sync 06/14/2011 Device Tools Help Sync toDevice All Playlists Windows Media Player Selectted Playlists: XT605(3) 3 Songs Refresh Sync Capacity: 1 GB Free 8.5 GB Other 454.7 MB Podcasts 0.0B Videos Photos XT605 - Internal Storage Music 0.0B 0.0B 12.4 MB Sync fromDevice Sync Music from: Videos Last Sync Never Podcasts Last Sync Never Contacts Last Sync Never Sync to or fro m your device. Select Music. Start the sync. Choose m usic player to sync with. correct Motorola Drivers have been installed on your computer, Media Link will start. 2 Make sure the Sync to Device tab is selected, and Music has a check mark next to it. 3 In the Sync to Device tab, make sure Sync Music from is selected, and select either Windows Media Player or iTunes from the drop down box to the right. 4 You can select to sync all playlists, or selected playlists. If you choose to sync selected playlists, choose the playlists from …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NA1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 1 Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907 2.1. Specification Compliance Transceiver type described herein (IHDT56NA1) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Samar Ayoub SIGNATURE: /s/ Samar Ayoub DATE: Dec 28, 2011 TITLE: Senior Resource Manager 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56NA1) is in compliance with all applicable parts of the FCC Rules. NAME: John Lewczak SIGNATURE: DATEDate TITLE: Engineering Manager, Product Safety and Compliance APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NA1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 2 2.3. Attestation Statement (Equipment Class DTS and DSS - Bluetooth/Wi-Fi) This device contains an embedded Bluetooth device, Wi-Fi device, and MOTOtalk capabilities that Motorola Mobility confirms are compliant with the applicable Part 15C regulations. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Samar Ayoub SIGNATURE: /s/ Samar Ayoub DATE: Dec 28, 2011 TITLE: Senior Resource Manager

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NA1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 1 December 28, 2011 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of transmitter with FCC ID: IHDT56NA1, PCS Handsets, with Wi-Fi and Bluetooth. Gentlemen; Motorola Mobility, Inc.; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT56NA1. The primary transceiver in this composite device operates in the WCDMA1700/1900 MHz bands and GSM850/1900 MHz bands as a portable transceiver and employs HSPA/EDGE/GPRS data transmission capabilities. Note: This device also contains functions, and operates within frequency bands, that are not authorized within the United States or its territories. This filing is only applicable to supported US operations. This radio product is also equipped with a Wi-Fi (802.11b/g/n) transceiver. The Wi-Fi Band of operation is 2.412 - 2.462 GHz, with channels up to 17 MHz in bandwidth for 802.11g operation. The Wi-Fi device complies 15.247 (c), 15.205, 15.209 (b). This radio product is equipped with a Bluetooth (BT) transceiver. BT supports both voice and data for short range wireless communications. The Bluetooth Band of Operation is 2.4 - 2.4835 GHz (1 MHz channel bandwidth). The BT device also complies with the requirements of FCC Rule Parts 15.247 (c), 15.205 and 15.209 (b). All transmitters contained in this radio product have been subjected to routine environmental evaluation (as applicable) according to 47 CFR Part 2.1093 (c) for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). This radio product features an integrated GPS receiver, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR Part 15.3(r). A Part 15B test report is included for certification. Enclosed is a complete Certification Application. Contact me at (954) 723-6272 if you require any additional information. APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NA1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 2 Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

FCC ID: IHDT56NA1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 4 January 2012 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56NA1. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. IHDT56NA1_Ex_04 (Block Diagrams).pdf Schematic Diagrams. IHDT56NA1 _Ex_05 (Schematic Diagrams).pdf Parts List and Tune Up Procedures. IHDT56NA1 _Ex_10 (Active Components).pdf Transmitter Characteristics. IHDT56NA1 _Ex_12 (TX Characteristics).pdf Motorola Mobility, Inc. requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility, Inc. understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56NA1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com SHORT TERM ONFIDENTIALITY REQUEST – 180 DAYS Pursuant to the Commission’s public notice DA 04-1705 (June 15, 2004), Motorola Mobility, Inc. is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility, Inc. temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. IHDT56NA1 _Ex_03 (External_Photos).pdf Test set-up photographs. IHDT56NA1 _Ex_07d (SAR Test Set- up_Details).pdf IHDT56NA1 _Ex_07 (Part 15 Test Set- up_Details).pdf User’s Manual. IHDT56NA1 _Ex_08 (User Guide).pdf Internal product photographs. IHDT56NA1 _Ex_09 (Internal Photos).pdf Please contact me if you require any additional information. Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected] Page 13b - 2

APPLICANT: MOTOROLA MOBILITY , INC. F CC ID : IHDT56NA1 BACK OF PHONE FRONT OF PHONE BACK OF PHONE FOR NO BATTERY COVER 1 EXHIBIT 3 APPLICANT: MOTOROLA MOBILITY , INC. F CC ID : IHDT56NA1 To p View Right Side View 2 EXHIBIT 3 APPLICANT: MOTOROLA MOBILITY , INC. F CC ID : IHDT56NA1 3 EXHIBIT 3 Left Side ViewBottom View

APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NA1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11) 1.1 Location On the rear (back) side of the radio product chassis, beneath the battery (see also Exhibit 3). 1.2 Type The label is of a white polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with minimum peel strength of 5 lbs/in. 1.3 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. Figure 1.3.1. Representation of FCC Label information. This label will be placed on the equipment (within the Battery Compartment) as shown below. Other information may also be included on this label, and other labels may also be present. FCC ID: IHDT56NA1 Page 1 - 1 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NA1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Figure 1.3.2. Location of FCC Label (position, orientation, and other information shown may vary). Interior Battery Compartment FCC Label Back of Device Please note that this label and its placement complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. Further, at the time of purchase, batteries are shipped in a separate section or compartment of the radio packaging, and are not attached to the radio. In some instances they may be shipped in separate boxes. So, the end user needs to physically install the battery by removing the battery cover, if any, or attach the battery before using the radio. Further, the placement of the label in the battery compartment is done because space is limited on the exterior of the device. The battery compartment also helps to protect the label from getting obliterated or made unreadable through regular handling and use. The product’s Market or Trade Name is indelibly printed on the face of the product, as shown in Exhibit 3. Exhibit 1A: General Information 1A.1 Production Plans Quantity production is planned. 1A.2 Data Submittal Procedure Performance data located in Exhibit 6 are supplied in accordance with the Commission’s rules: 47 CFR Part 2, Subpart J. The intended use of this transceiver includes applications covered in the Code of Federal Regulations Title 47, Part 15, Subparts A, B, and C; Part 22 Subpart H; and Part 24 Subpart E. Page 1 - 2 APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDP56MN1 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 3 1A.3 Additional Considerations In addition to the radio receivers associated with the services authorized within this application, this device integrates a receiver designed to process signals from Global Positioning System satellites. Compliance with FCC requirements was done via the Verification process (47 CFR 2.902). Similar handling of the FM broadcast receiver. This device may be considered to be a digital device, per 47 CFR 15.3(k), and can function as a computer peripheral device when functioning as an RF modem, as described in 47 CFR 15.3(r). For this reason, a Part 15B test report is included with this application.

APPLICANT: Motorola Mobility, INC. FCC ID: IHDT56NA1 Keypad Board EXHIBIT 9 1 APPLICANT: Motorola Mobility, INC. FCC ID: IHDT56NA1 Main Board-Top Main Board-Top (Shielding removed) EXHIBIT 9 2 APPLICANT: Motorola Mobility, INC. FCC ID: IHDT56NA1 Main Board-Bottom Main Board-Bottom (Shielding removed) EXHIBIT 9 3 APPLICANT: Motorola Mobility, INC. FCC ID: IHDT56NA1 Front Cover (External view) Main LCM Front Cover (internal view) Keypad EXHIBIT 9 4 APPLICANT: Motorola Mobility, INC. FCC ID: IHDT56NA1 Back Housing (External View) Back Housing (Internal View) Battery Cover EXHIBIT 9 5 APPLICANT: Motorola Mobility, INC. FCC ID: IHDT56NA1 EXHIBIT 9 6 GPS Antenna Diversity Rx Antenna Backhousing external view WIFI/BT Antenna Main Antenna NOTE: GPS, Diversity and main antennas are covered by Black coverlay

MOTOROLA MOBILITY, INC. Portable Cellular Phone SAR Test Report Number: 24832-1F FCC ID: IHDT56NA1 Rev. A Exhibit 11 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobility, Inc. 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 24832-1F Date of Report: Jan-09-2012 Date of Test: Nov-23-2011 to Dec-22-2011 FCC ID #: IHDT56NA1 Generic Name: M0C12 Test Laboratory: Motorola Mobility, Inc. - ADR Test Services Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Thomas Knipple Senior RF Engineer Accreditation: 2404 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non- Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: Motorola’s ISO 17025 accreditation scope does not currently include SAR testing in the 5 GHz band. Therefore, SAR testing performed in this band was performed outside of our ISO 17025 accreditation. The general procedures and guidelines provided within; FCC KDB 248227 D01, FCC KDB 648474 D01, FCC KDB 865664 D01 and IEC 62209-2 were utilized for testing. Powers in the tables provided in section 2.3 represent output powers for the SAR test configurations applicable and may not represent the highest output powers for all capabilities. ©Motorola Mobility, Inc. 2012 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA MOBILITY, INC. Portable Cellular Phone SAR Test Report Number: 24832-1F FCC ID: IHDT56NA1 Rev. A Exhibit 11 Page 2 of 29 Table of Contents 1. Introduction .............................................................................................................................................................3 2. Description of the Device Under Test ....................................................................................................................4 2.1 Antenna description.............................................................................................................................................4 2.2 Device Signaling..................................................................................................................................................5 2.2.1 Power limit reduction for Mobile Hotspot functionality ..............................................................................6 2.3 Device Conducted Power Measurements ............................................................................................................7 2.3.1 GSM modes ..................................................................................................................................................7 2.3.2 WCDMA modes ...........................................................................................................................................8 2.3.3 Wi-Fi 802.11 modes .....................................................................................................................................9 3. Test Equipment Used ............................................................................................................................................10 3.1 Dosimetric System .............................................................................................................................................10 3.2 Additional Equipment ........................................................................................................................................10 4. Electrical parameters of the tissue simulating liquid .........................................................................................11 5. System Accuracy Verifications.............................................................................................................................12 6. Test Results ............................................................................................................................................................14 6.1 Head Adjacent Test Results ...............................................................................................................................15 6.2 Body Worn Test Results.....................................................................................................................................19 6.3 Mobile Hotspot Test Results ........................…
