APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 1 Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907 2.1. Specification Compliance Transceiver type described herein (IHDT56NS4) has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Frank.Hyochang Kim SIGNATURE: /s/ Frank.Hyochang Kim DATE: 30 Aug 2012 TITLE: Engineering Manager 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56NS4) is in compliance with all applicable parts of the FCC Rules. NAME: John Lewczak SIGNATURE: DATE 30 Aug 2012 TITLE: Engineering Manager, Product Safety and Compliance APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 2 2.3. Attestation Statement (Equipment Class DTS and DSS - Bluetooth/Wi-Fi) This device contains an embedded Bluetooth device, Wi-Fi device capabilities that Motorola Mobility confirms are compliant with the applicable Part 15C regulations. Personal Hotspot operation is supported in the 2.4 GHz and 5.8GHz ISM bands. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Frank.Hyochang Kim SIGNATURE: /s/ Frank.Hyochang Kim DATE: 30 Aug 2012 TITLE: Engineering Manager APPLICANT: MOTOROLA MOBILITY, INC. FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 3 2.4. Attestation Statement (Equipment Class NII - U-NII Wi-Fi) This device contains an embedded U-NII Wi-Fi device that Motorola Mobility confirms to be compliant with the applicable Part 15E regulations. Note that Personal Hotspot operation is not supported within the equipment class. 15.407(c) The device will automatically discontinue transmission in case of either the absence of information to transmit or operational failure. 15.407(h)(1) This device does not operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, and as such Transmit Power Control (TPC) is not required. 15.407(h)(2) This device does not operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, and as such Radar Detection Function of Dynamic Frequency Selection (DFS) is not required. NAME: Frank.Hyochang Kim SIGNATURE: /s/ Frank.Hyochang Kim DATE: 30 Aug 2012 TITLE: Engineering Manager

APPLICANT: MOTOROLA MOBILITY, LLC. FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 1 30 August 2012 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of transmitter with FCC ID: IHDT56NS4, PCS Handsets, with Wi-Fi and Bluetooth. Gentlemen; Motorola Mobility, Inc.; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT56NS4. The primary transceiver in this composite device operates in the 850 MHz and 1900 MHz bands as a WCDMA/GSM portable transceiver and employs HSPA/EDGE&GPRS data transmission capabilities. Note: This device also contains functions, and operates within frequency bands, that are not authorized within the United States or its territories. This filing is only applicable to supported US operations. This radio product is also equipped with a Wi-Fi (802.11a/b/g/n) transceiver. Wi-Fi supports both voice and data for short range wireless communications. The Wi-Fi Bands of Operation is 2.412 - 2.462 GHz, 5.180 – 5.240 GHz, and 5.745 – 5.850 MHz for 802.11a/b/g/n operation. The Wi-Fi device complies 15.247 (c), 15.407, 15.205 and 15.209 (b). This radio product is equipped with a Bluetooth (BT) transceiver. BT supports both voice and data for short range wireless communications. The Bluetooth Band of Operation is 2.402 - 2.480 GHz (1 MHz channel bandwidth). The BT device complies with the requirements of FCC Rule Parts 15.247 (c), 15.205 and 15.209 (b). This product also supports NFC operation as a low-power itinerant transmitter. All transmitters contained in this radio product have been subjected to routine environmental evaluation (as applicable) according to 47 CFR Part 2.1093 (c) for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). APPLICANT: MOTOROLA MOBILITY, LLC. FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 2 This radio product features an integrated GPS receiver, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR Part 15.3(r). A Part 15B test report is included for certification. Enclosed is a complete Certification Application. Contact me at (954) 723-6272 if you require any additional information. Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 30 August 2012 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56NS4. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. IHDT56NS4_Ex_04 (Block Diagrams).pdf Schematic Diagrams. IHDT56NS4 _Ex_05 (Schematic Diagrams).pdf Parts List and Tune Up Procedures. IHDT56NS4 _Ex_10 (Active Components).pdf Transmitter Characteristics. IHDT56NS4 _Ex_12 (TX Characteristics).pdf Motorola Mobility, Inc. requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility, Inc. understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 2 SHORT TERM ONFIDENTIALITY REQUEST – 180 DAYS Pursuant to the Commission’s public notice DA 04-1705 (June 15, 2004), Motorola Mobility, Inc. is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility, Inc. temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. IHDT56NS4 _Ex_03 (External_Photos).pdf Test set-up photographs. IHDT56NS4 _Ex_07D (RF Exposure Test Set- up_Details).pdf IHDT56NS4_Ex_07 (EMC Test Set-up Photographs).pdf User’s Manual. IHDT56NS4 _Ex_08 (User Guide).pdf Internal product photographs. IHDT56NS4 _Ex_09 (Internal Photos).pdf Please contact me if you require any additional information. Regards, FCC Liaison Motorola Mobility, Inc. 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 1 Exhibit 3. External Photographs -- Pursuant to 47 CFR 2.1033(c)(12) The radio product colors, housings/bezels may vary, but only consistent with the requirements of FCC Class I Permissive Change rules and guidance (47 CFR 2.1043 and KDB 178919 D01). Figure 3-1. Front of device Figure 3-2. Back of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 2 Figure 3-3. Left Side of device Figure 3-4. Right Side of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 3 Figure 3-5. Top of radio Figure 3-6. Bottom of radio APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 4 Figure 3-7. Interior Compartment of radio FCC Label Location

APPLICANT: MOTOROLA MOBILITY, LLC. FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 1 Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11) 1.1 Location On the rear (back) side of the radio product chassis, etched into the housing, near the bottom edge of the device (see Figure 1.3.2, and also Exhibit 3). 1.2 Type The label will be laser etched into the rear housing of the device. 1.3 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. Figure 1.3.1. Representation of FCC Label information. This information will be permanently etched onto the equipment rear cover as shown below, and in Exhibit 3. Other information may also be present. FCC ID: IHDT56NS4 Model No. XT905 APPLICANT: MOTOROLA MOBILITY, LLC. FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 2 Figure 1.3.2. Location of FCC Label (position, orientation, and other information shown may vary). Please note that this label and its placement complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. The product’s Market or Trade Name is also indelibly printed on the back cover of the product, as shown in Exhibit 3. FCC Label Back of Device APPLICANT: MOTOROLA MOBILITY, LLC. FCC ID: IHDT56NS4 Motorola Mobility, Inc.; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 3 Exhibit 1A: General Information 1A.1 Production Plans Quantity production is planned. 1A.2 Data Submittal Procedure The information in this application is provided in accordance with requirements for certification as outlined in the FCC Rules and Regulations: 47 CFR Part 2; Subpart J; Part 15, Subparts B, C, and and E; Part 22 Subpart H; Part 24 Subparts B and E. 1A.3 Similar, currently Certified Transceiver FCC ID: IHDP56ME1 1A.4 Additional Considerations This device includes NFC (Near Field Communications) capabilities, functioning as both a tag and a reader, supporting simplified pairing with a NFC-tagged Bluetooth device, In addition to the radio receivers associated with the services authorized within this application, this device integrates a receiver designed to process signals from Global Positioning System satellites. Compliance with FCC requirements was done via the Verification process (47 CFR 2.902). This device may be considered to be a digital device, per 47 CFR 15.3(k), and can function as a computer peripheral device when functioning as an RF modem, as described in 47 CFR 15.3(r). For this reason, a Part 15B test report is included with this application.

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 1 Exhibit 9: Internal Photographs -- Pursuant to 47 CFR 2.1033(c)(12) Photograph 9-1: Front side view of the device’s PC Board, Shields in place. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 2 Photograph 9-2: Back side view of the device’s PC Board, Shields in place. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 3 Photograph 9-3: Front side view of the device’s PC Board, Shields Removed. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 4 Photograph 9-4: Back side view of the device’s PC Board, Shields Removed. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 5 Photograph 9-5: Interior Housing View.(Front & Rear housing, Battery, Camera module, Headset jack flex) APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56NS4 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 6 Photograph 9-6: Antenna Locations and Spacings.

MOTOROLA MOBILITY, INC. Portable Cellular Phone SAR Test Report Number: 25140-1F Rev 1 FCC ID: IHDT56NS4 Exhibit 11 Portable Cellular Phone SAR Test Report Tests Requested By: Motorola Mobility, Inc. 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 25140-1F Rev 1 Date of Report: Sept 12, 2012 Date of Test: Aug 2, 2012 – Aug 14, 2012 FCC ID #: IHDT56NS4 IC ID #: N/A Generic Name: M0D5D Test Laboratory: Motorola Mobility, Inc. - ADR Test Services Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Katerina Bruggemann Engineer Accreditation: 2404 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate IEC 62209-1 RSS-102 IEEE 1528 - 2003 FCC OET Bulletin 65 (including Supplement C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 2003 CENELEC EN 50360 ARIB Std. T-56 (2002) On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers Statement of Compliance: Motorola declares under its sole responsibility that the portable cellular telephone model to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093) as well as with CENELEC en50360:2001 and ANSI / IEEE C95.1. It also declares that the product was tested in accordance with IEEE 1528 / CENELEC EN62209-1 (2006), as well as other appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola Mobility, Inc. 2012 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. MOTOROLA MOBILITY, INC. Portable Cellular Phone SAR Test Report Number: 25140-1F Rev 1 FCC ID: IHDT56NS4 {Rev. 0} Exhibit 11 Page 2 of 32 Table of Contents 1. Introduction ............................................................................................................................................................. 3 2. Description of the Device Under Test .................................................................................................................... 4 2.1 Antenna description ............................................................................................................................................. 4 2.2 Device Signaling .................................................................................................................................................. 5 2.2.2 Transmitter power reduction conditions and modes .....................................................................................7 2.3 Device Conducted Power Measurements ............................................................................................................ 8 2.3.3 GSM modes ..................................................................................................................................................8 2.3.4 WCDMA modes ...........................................................................................................................................9 2.3.5 Wi-Fi 802.11 modes ...................................................................................................................................10 2.3.6 Bluetooth modes and test exclusion ...........................................................................................................12 3. Test Equipment Used ............................................................................................................................................ 13 3.1 Dosimetric System ............................................................................................................................................. 13 3.2 Additional Equipment ........................................................................................................................................ 13 4. Electrical parameters of the tissue simulating liquid ......................................................................................... 14 5. System Accuracy Verifications ............................................................................................................................. 16 6. Test Results ............................................................................................................................................................ 18 6.1 Head Adjacent Test Results ............................................................................................................................... 18 6.2 Body Worn Test Results ..................................................................................................................................... 22 6.4 Mobile Hotspot Test Results .............................................................................................................................. 25 6.5 Description and Evaluation of Simultaneous Transmitters ............................................................................... 30 References .................................................................................................................................................................. 32 Appendix 1: SAR distribution comparisons for System Accuracy Verifications Appendix 2: SAR distribution plots for Head Adjacent Test Results Appendix 3: SAR distribution plots for Body Worn Test Results Appendix 4: SAR dis…

Text truncated - open the document above for the full version.

MOTOROLA MOBILITY, INC. Portable Cellular Phone SAR Test Report Number: 25140-1F FCC ID: IHDT56NS4 Exhibit 11 Appendix 7 Dipole Characterization Certificate A-101 A-102 A-103 A-104 A-105 A-106 A-107 A-108 A-109 A-110 MOTOROLA MOBILITY, EME Laboratories Extension of Dipole Calibration Interval FCD‐1954, Rev.1 Dipole SN: Date of last external calibration: External calibration performed by: 1st Extension Original Calibration Data: Internal Verification: <3/18/11><3/8/12> Return loss (dB): Verify < ‐20dB ‐31.1Verified Impedance, Real (Ω): Verify within +/‐5Ω of original 51.450.4 Impedance, Imaginary (Ω): Verify within +/‐5Ω of original ‐2.5‐1.3 Conclusion: First Extension Period: Approved extension period: 1 year Previous due date:3/18/2012 NEW DUE DATE: 3/18/2013 2 years from date of last external calibration 436tr 3/18/2011 SPEAG Based on the requirements of KDB 50824 D02 Dipole SAR Validation Veritification v01, it has been concluded that the dipole identified above has qualified for extension of its calibration interval for one additional year. This review shall be repeated annually, but not to exceed a maximum 3 years from the most recent manufacturer's calibration. Extension of Dipole Calibration Interval, FCD‐1954, Rev.1 A-111 A-112 A-113 A-114 A-115 A-116 A-117 A-118 A-119 A-120 A-121 A-122 A-123 A-124 A-125 A-126 A-127 A-128 A-129 A-130 A-131 A-132 A-133 A-134 A-135 A-136 MOTOROLA MOBILITY, EME Laboratories Extension of Dipole Calibration Interval Dipole SN: Date of last external calibration: External calibration performed by: 1st Extension Original Calibration Data: Internal Verification: <3/17/11><3/14/12> Return loss (dB): Verify < ‐20dB ‐27.7verified Impedance, Real (Ω): Verify within +/‐5Ω of original 53.151.3 Impedance, Imaginary (Ω): Verify within +/‐5Ω of original 2.9‐1.2 Conclusion: First Extension Period: Approved extension period: 1 year Previous due date:3/17/2012 NEW DUE DATE: 3/17/2013 863 3/17/2011 SPEAG Based on the requirements of KDB 50824 D02 Dipole SAR Validation Veritification v01, it has been concluded that the dipole identified above has qualified for extension of its calibration interval for one additional year. This review shall be repeated annually, but not to exceed a maximum 3 years from the most recent manufacturer's calibration. Extension of Dipole Calibration Interval, FCD‐1954, Rev.1 A-137 A-138 A-139 A-140 A-141 A-142 A-143 A-144 A-145 A-146 A-147 A-148 A-149 A-150

MOTOROLA MOBILITY, INC. Portable Cellular Phone SAR Test Report Number: 25140-1F Supplemental Rev 1 FCC ID: IHDT56NS4 Exhibit 11 Portable Cellular Phone Supplemental SAR Test Report Tests Requested By: Motorola Mobility, Inc. 600 N. US Highway 45 Libertyville, IL 60048 Test Report #: 25140-1F Supplemental REV 1 Date of Report: Sept 12, 2012 Date of Test: Aug 10, 2012 – Aug 24, 2012 FCC ID #: IHDT56NS4 Generic Name: M0D5D Test Laboratory: Motorola Mobility, Inc. - ADR Test Services Laboratory 600 N. US Highway 45 Libertyville, IL 60048 Report Author: Katerina Bruggemann Engineer Accreditation: 2404 This laboratory is accredited to ISO/IEC 17025-2005 to perform the following test…
