IHDT56QA1Multi-Band GSM/ EDGE/ WCDMA/ LTE Portable Handset with WLAN, Bluetooth and RFID

Motorola Mobility LLC

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Aug 27, 2014
Application Purpose: Original Equipment
Date of Application: Aug 06, 2014
Equipment Note: Multi-Band GSM/ EDGE/ WCDMA/ LTE Portable Handset with WLAN, Bluetooth and RFID
Frequency Range: 13.56000000 - 13.56000000
Company: Motorola Mobility LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 / IC ID: 109O-T56QA1 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 8 - 1 Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3) and RSP100, Section 5. The attached User’s Manual is the final production-intended version of the generic Motorola International English User Manual. This guide will be adapted to carrier-specific versions i , but the key information herein will be retained. Translations into other languages will also be done to support the needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to, placing this product onto the market. Selected portions of the User Guide can be found as indicated below: 8.1 Safety and Regulatory Section: Page 62 8.2 Specific Absorption Rate (SAR) Data: Page 64 8.3 Guidance for use with Hearing Aids (Pursuant to 47 CFR 20.19(f)(1): Page 25, 67 i Motorola Mobility attests that the User’s Guide provided with product shipping into Canada will provide any required Industry Canada notices and/or statements in both English and French, per the requirements of RSS-Gen. C alls C ontact s C ontrol & customize St ar t Home screen & app s At a glanc e Soc i a liz e B r o w se Ph o t os & vi deos T yp e M essages Locate & navigat e P ro t ec t Or g anize Connect & transfer Book s Hot to p ic s Search to p ics Want more ? Troubleshoot M usic G ames Safet y E mai l St t & Pt t Moto GMotorola XT1097 23 MAY 2014 FCC SUBMIT Back Next Menu More At a glancea quick look First lookYour new XT1097 has a big, bright, high-definition display that goes from one side all the way to the other. Its curved body fits in your hand. Note: Your phone may look a little different. 11:35 GoogleGo og le Play Store 11:35 WED, JULY 16 T HU 7:00 AM WALLPAPER TBDWALLPAPER TBD HeadphoneJack VolumeKeys Power Key Micro USB/ Charger Microphone FrontCamera BackHomeRecent Apps Microphone Nano SIM Card Tray Speaker Ti p s & t r i c k s •Start: Ready to start? See “ Start ”. •Top topics: Just want a quick list of what your phone can do? See “ Top topics ”. •Help: All your questions about your new phone answered right on your phone. Touch Apps > Help . Want even more? See “ Get help & more ”. Note: Certain apps and features may not be available in all countries.Note: Motorola Shells are sold separately and availability varies by country. This product meets the applicable national or international RF exposure guidance (SAR guideline) when used normally against your head or, when worn or carried, at a distance of 1.5 cm from the body. The SAR guideline includes a considerable safety margin designed to assure the safety of all persons, regardless of age and health. Caution: Before using your phone, please read the safety, regulatory and legal information provided with your product. At a glance First look Top topics 23 MAY 2014 FCC SUBMIT Back Next Menu More At a glance Top topicsCheck out what your phone can do. • Personalize your home screen: see “ Redecorate your home screen ”. • Make a quick change: see “ Quick settings ”. • Go online: see “ Browse ”. • Explore: see “ Google Play™ ”. • Find apps: see “ Download apps ”. • Be social: see “ Socialize ”. • Find it yourself: see “ Locate & navigate ”. • Take a photo: see “ Take photos ”. • Connect to Wi-Fi: see “ Wi-Fi Networks ”. • Watch a movie: see “ Play Movies & TV ”. • Protect your phone: see “ Screen lock ”. • Walk through interactive tutorials: see “ Help & more ”. • Get all the help you need: see “ Get help & more ”. Ti p s & t r i c k s •Interactive: To get started quickly, touch Apps > Help for interactive tutorials. • Google™ help: In most Google Mobile apps, you can touch Menu > Help . You can also view the Google Help Centers online at www.google.com/support . At a glance First look Top topics 23 MAY 2014 FCC SUBMIT Back Next Menu More Startlet’s get up & running Put in the SIMPut the SIM in, charge up, and power on. (Your SIM may already be in your phone. If it is, just charge up and power on.)Caution: Make sure you use the correct sized SIM card, and don’t use adapters with your SIM card. Use the tool to pop out the SIM tray. Put the nano SIM into the tray. Push the tray back into your phone. 1 3 Power on. Press & hold Power until the screen lights up. Put in the SIM card. 3 H Charge up, if you need to.CC 2 SIM TOOL TBDTOOL TBD Ti p s & t r i c k s • SIM tray & tool: The SIM tray is on the side of your phone. Push the key-like tool that came in your phone’s box into the small hole in the SIM tray to open it. Put your nano SIM into the tray. (Make sure the angled corner of the SIM card matches the angled corner of the SIM tray.) Align the tray and gently put it back into the phone. •Power Key: To make the screen sleep or wake up, press the Power key. To turn your phone on or off, press and hold it. • Battery: Squeeze every bit of juice out of your battery, see “ Battery life ”. Warning: Don't try to remove or replace the battery yourself—doing so may damage the battery and could cause burning and injury. If your phone becomes unresponsive, try a reboot—press and hold both the Power and the Volume Down keys until the screen goes dark, and your phone restarts. Start Put in the SIM Battery life Sign in Old phone to new phone Google Play™ 23 MAY 2014 FCC SUBMIT Back Next Menu More Start Battery lifeYour phone is like a small computer, giving you tons of information and apps, at lightning fast speed. Depending on what you use, that can take a lot of power.To see what’s using up battery power, touch Apps > Settings > Battery . Ti p s & t r i c k sTo save even more battery life between charges, you could reduce: • Wi-Fi and Bluetooth® use: Touch Apps > Settings , then touch the switch next to Wi-Fi or Bluetooth to turn them when you don’t need them. • GPS use: Touch Apps > Settings > Location > Mode > Battery saving to turn off GPS tracking. • Display brightness: To…

Text truncated - open the document above for the full version.

Attestation Statements

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 / 109O-T56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 1 Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907. 2.1. Specification Compliance Transceiver type described herein (IHDT56QA1 and 109O-T56QA1) has been tested in accordance with the requirements contained in the appropriate regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 24 June 2013 TITLE: RF Engineering Manager 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56QA1) is in compliance with all applicable parts of the FCC Rules. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (109O-T56QA1) is in compliance with all applicable Industry Canada Rules and Procedures. NAME: John Lewczak SIGNATURE: DATE: 24 June 2014 TITLE: Engineering Manager, Product Safety and Compliance APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 / 109O-T56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 2 2.3. Attestation Statement (Equipment Class DTS and DSS - Bluetooth/Wi-Fi) This device contains an embedded Bluetooth device, Wi-Fi device, and MOTOtalk capabilities that Motorola Mobility confirms are compliant with the applicable Part 15C regulations. Personal Hotspot operation is only supported in the 2.4 GHz band. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 24 June 2013 TITLE: RF Engineering Manager APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 / 109O-T56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 3 2.4. Attestation Statement (Equipment Class NII - U-NII Wi-Fi) This device contains an embedded U-NII Wi-Fi device that Motorola Mobility confirms to be compliant with the applicable Part 15E regulations. Note that neither Personal Hotspot nor Wi-Fi Direct operation is supported within this equipment class. 15.407(c) The device will automatically discontinue transmission in case of either the absence of information to transmit or operational failure. 15.407(h)(1) This device does operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, but the device’s EIRP is less than 500 mW, and as such Transmit Power Control (TPC) is not required. 15.407(h)(2) This device does operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, and as such implements Dynamic Frequency Selection (DFS) as a client device. This device cannot initiate transmissions nor does it support ad-hoc networking in this band. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 24 June 2013 TITLE: RF Engineering Manager APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 / 109O-T56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 4 2.5. Attestation Statement (Equipment Class PCE – GSM 850/1900 MHz ; WCDMA 850/1700/1900 MHz - Hearing Aid Compatibility) Motorola Mobility hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance. Features List: GSM/ GPRS/EDGE LTE WCDMA Wi-Fi (a/b/g/n/ac) Bluetooth (Stereo) Location-Based Services Voice Commands Talking Phone Photo Camera Video Camera Video Player Hands Free Speaker Phone Music Player HTML Browser Text Messaging NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 24 June 2013 TITLE: RF Engineering Manager APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 / 109O-T56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 5 2.6. Hearing Aid Compatibility RFE Evaluation MIF Determination Statement (Equipment Class PCE – GSM (850/1900 MHz) andWCDMA (850/1700/1900 MHz). This device, carrying FCC ID: IHDT56QA1, is being certified for Hearing Aid Compatibility under the ANSI C63.19-2011 standard, per Part 20.19. For Radio Frequency Interference, neither Speag’s Audio Interference Analyzer (AIA) nor any other indirect or direct measurement was used to determine the M-rating. Rather, the M-rating was determined by measuring the maximum steady state average E-field values in dB (V/m) or average antenna input power (as documented in HAC test report) and adding the applicable MIF value in dB. The MIF values below for the worst-case operation mode for all air interfaces are the pre-determined values provided by Speag: UID Air Interface MIF (dB) 10021 GSM-FDD(TDMA,GMSK) 3.63 10011 UMTS-FDD(WCDMA) -27.23 We…

Text truncated - open the document above for the full version.

Cover Letter(s)

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 1 24 June 2014 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of transmitter with FCC ID: IHDT56QA1, PCS Handsets, with Wi-Fi and Bluetooth. Gentlemen; Motorola Mobility LLC; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT56QA1. The primary transceiver in this composite device operates in the 850 MHz Public Mobile Service (PMS), the 1700 MHz Advanced Wireless Service (AWS), and the 1900 MHz Personal Communications Service (PCS). It supports GSM signaling, and employs GPRS Class 12 and EDGE Class 12 capabilities. This transceiver also operates in the WCDMA mode in these bands. Note: This device also contains functions, and operates within frequency bands, that are not authorized within the United States or its territories. This filing is only applicable to supported US operations. This mobile device is also equipped with an LTE transceiver. This LTE transceiver supports high-speed wireless data communications within LTE Bands 2, 4, 5, 17, and 29, with channels up to 20 MHz in bandwidth. The LTE device complies with Parts 22 (Subpart H), 24 (Subpart E), and Part 27 (Subpart C), as applicable. This radio product is also equipped with a Wi-Fi (802.11a/b/g/n/ac) transceiver. Wi-Fi supports both voice and data for short range wireless communications. The Wi-Fi Bands of Operation are 2400 – 2483.5 MHz ISM band, 5150 – 5250 MHz U-NII Band 1, 5250 – 5350 MHz U-NII Band 2A band, 5470 – 5725 MHz U-NII Band 2C, and 5725 – 5850 MHz U-NII Band 3 for 802.11a/b/g/n/ac operation. The Wi-Fi device complies 15.247, 15.407, 15.205 and 15.209. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 2 This radio product is equipped with a Bluetooth (BT) transceiver. BT supports both voice and data for short range wireless communications. The Bluetooth Band of Operation is 2.402 - 2.480 GHz (1 MHz channel bandwidth). The BT device complies with the requirements of FCC Rule Parts 15.247, 15.205 and 15.209. This product also supports NFC operation as a low-power itinerant transmitter. All transmitters contained in this radio product have been subjected to routine environmental evaluation (as applicable) according to 47 CFR Part 2.1093 (c) for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). This radio product features an integrated GPS receiver, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR Part 15.3(r). A Part 15B test report is included for certification. Enclosed is a complete Certification Application. Contact me at (954) 590-0254 if you require any additional information. Regards, FCC Liaison Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

Cover Letter(s)

FCC ID: IHDT56QA1 / IC ID: 109O-T56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 24 June 2014 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56QA1. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. IHDT56QA1_Ex_04 (Block Diagrams).pdf Schematic Diagrams. IHDT56QA1_Ex_05 (Schematic Diagrams).pdf Parts List and Tune Up Procedures. IHDT56QA1_Ex_10 (Active Components).pdf Transmitter Characteristics. IHDT56QA1_Ex_12 (TX Characteristics).pdf Pre-Test KDB Inquiry IHDT56QA1_Ex_12A (Manufacturer PBA FCC ) Motorola Mobility LLC requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility LLC understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56QA1 / IC ID: 109O-T56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 2 SHORT TERM ONFIDENTIALITY REQUEST – 180 DAYS Pursuant to the Commission’s public notice DA 04-1705 (June 15, 2004), Motorola Mobility LLC is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility LLC temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. IHDT56QA1_Ex_03 (External_Photos).pdf Test set-up photographs. IHDT56QA1_Ex_07B ( EMC T est Set-up Photos) – 9 files. IHDT56QA1_Ex_07C (SAR Test Set-up Photos) 1 IHDT56QA1_Ex_07D (RFE HAC Test Set-up Photos) 1 IHDT56QA1_Ex_07D (Telecoil HAC Test Set-up Photos) 1 User’s Manual. IHDT56QA1_Ex_08 (User Guide).pdf Internal product photographs. IHDT56QA1_Ex_09 (Internal Photos).pdf 1 This exhibit not applicable to the JBP application, per 47 CFR 2.1031 Please contact me if you require any additional information. Regards, FCC Liaison Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

External Photos

ID Label/Location Info

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 / IC ID: 109O-T56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 1 Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11); and RSP100, Section 5 and RSS Gen, Section 5.2. 1.1 Location On the bottom edge of the mobile device, laser etched into the trim band (see Figure 1.3.2, and also Exhibit 3). 1.2 Type The label information will be laser etched. 1.3 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. Figure 1.3.1. Representation of FCC Information. This information will be permanently etched onto the equipment trim band as shown below, and in Exhibit 3. Other information may also be present. Figure 1.3.2. Location of FCC Label (Viewed from Bottom Edge of Device). Please note that this label and its placement complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. FCC ID IHDT56QA1 Model Number FCC ID APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA1 / IC ID: 109O-T56QA1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 2 The product’s Market or Trade Name is indelibly printed on the face of the product, as shown in Exhibit 3.

Internal Photos

Test Report

SPORTON INTERNATIONAL INC. Page Number : 1 of 18 TEL : 886-3-327-3456 Report Issued Date : Jul. 11, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA1 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR442943D FCC RF Test Report APPLICANT : Motorola Mobility, LLC EQUIPMENT : Mobile Cellular Phone BRAND NAME : Motorola Mobility, LLC FCC MODEL NAME : 3578 FCC ID : IHDT56QA1 STANDARD : FCC Part 15 Subpart C §15.225 CLASSIFICATION : (DXX) Low Power Communication Device Transmitter The product was received on Apr. 29, 2014 and testing was completed on Jun. 17, 2014. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 18 TEL : 886-3-327-3456 Report Issued Date : Jul. 11, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA1 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR442943D Table of Contents 1. SUMMARY OF THE TEST RESULT ....................................................................................................................... 4 2. GENERAL INFORMATION ...................................................................................................................................... 5 2.1 Applicant ......................................................................................................................................................................... 5 2.2 Manufacturer ................................................................................................................................................................... 5 2.3 Feature of Equipment Under Test .................................................................................................................................... 5 2.4 Product Specification of Equipment Under Test ............................................................................................................... 6 2.5 Modification of EUT ......................................................................................................................................................... 6 2.6 Testing Location .............................................................................................................................................................. 6 2.7 Applicable Standards ....................................................................................................................................................... 7 2.8 Test Modes ...................................................................................................................................................................... 7 2.9 Test Configurations ......................................................................................................................................................... 8 2.10 Table for Supporting Units............................................................................................................................................... 9 3. CONDUCTED EMISSION TEST ............................................................................................................................ 10 3.1 Measuring Instruments .................................................................................................................................................. 10 3.2 Test setup ..................................................................................................................................................................... 10 3.3 Test Result of Conducted Emission Test ........................................................................................................................ 10 3.4 AC Power Line Conducted Emissions Measurement........................................................................................................ 11 4. CONDUCTED TEST ITEMS .................................................................................................................................. 12 4.1 Measuring Instruments .................................................................................................................................................. 12 4.2 Test Setup ..................................................................................................................................................................... 12 4.3 Test Result of Conducted Test Items ............................................................................................................................. 12 4.4 20dB Spectrum Bandwidth Measurement ....................................................................................................................... 13 4.5 Frequency Stability Measurement .................................................................................................................................. 13 5. RADIATED TEST ITEMS ....................................................................................................................................... 14 5.1 Measuring Instruments .................................................................................................................................................. 14 5.2 Test Setup ..................................................................................................................................................................... 14 5.3 Test Result of Radiated Test Items…

Text truncated - open the document above for the full version.

Test Setup Photos

SPORTON INTERNATIONAL INC. Page Number : 1 of 2 TEL : 886-3-327-3456 Report Issued Date : Jul. 10, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA1 Report Template No.: BU5-FR15CNFC Version 1.0 Exhibit 7 Report No. :FR442943D Short-Term Confidentiality Requested RF NFC Test Setup Photos <Conducted Emission> SPORTON INTERNATIONAL INC. Page Number : 2 of 2 TEL : 886-3-327-3456 Report Issued Date : Jul. 10, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA1 Report Template No.: BU5-FR15CNFC Version 1.0 Exhibit 7 Report No. :FR442943D <Radiated Emission> Z Plane 9K~30MHz 30MHz-1GHz
