IHDT56QA3Multi-Band GSM/ EDGE/ WCDMA/ CDMA LTE Portable Handset with WLAN, Bluetooth and RFID

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 8 - 1 Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3) and RSP100, Section 5. The attached User’s Manual is the final production-intended version of the generic Motorola International English User Manual. This guide will be adapted to carrier-specific versions i , but the key information herein will be retained. Translations into other languages will also be done to support the needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to, placing this product onto the market. Selected portions of the User Guide can be found as indicated below: 8.1 Safety and Regulatory Section: Page 62 8.2 Specific Absorption Rate (SAR) Data: Page 64 8.3 Guidance for use with Hearing Aids (Pursuant to 47 CFR 20.19(f)(1): Page 25, 67 i Motorola Mobility attests that the User’s Guide provided with product shipping into Canada will provide any required Industry Canada notices and/or statements in both English and French, per the requirements of RSS-Gen. C alls C ontact s C ontrol & customize St ar t Home screen & app s At a glanc e Soc i a liz e B r o w se Ph o t os & vi deos T yp e M essages Locate & navigat e P ro t ec t Or g anize Connect & transfer Book s Hot to p ic s Search to p ics Want more ? Troubleshoot M usic G ames Safet y E mai l St t & Pt t Moto GMotorola XT109 3 / XT1094 23 MAY 2014 FCC SUBMIT Back Next Menu More At a glancea quick look First lookYour new XT109 3/4 has a big, bright, high-definition display that goes from one side all the way to the other. Its curved body fits in your hand. Note: Your phone may look a little different. 11:35 GoogleGo og le Play Store 11:35 WED, JULY 16 T HU 7:00 AM WALLPAPER TBDWALLPAPER TBD HeadphoneJack VolumeKeys Power Key Micro USB/ Charger Microphone FrontCamera BackHomeRecent Apps Microphone Nano SIM Card Tray Speaker Ti p s & t r i c k s •Start: Ready to start? See “ Start ”. •Top topics: Just want a quick list of what your phone can do? See “ Top topics ”. •Help: All your questions about your new phone answered right on your phone. Touch Apps > Help . Want even more? See “ Get help & more ”. Note: Certain apps and features may not be available in all countries.Note: Motorola Shells are sold separately and availability varies by country. This product meets the applicable national or international RF exposure guidance (SAR guideline) when used normally against your head or, when worn or carried, at a distance of 1.5 cm from the body. The SAR guideline includes a considerable safety margin designed to assure the safety of all persons, regardless of age and health. Caution: Before using your phone, please read the safety, regulatory and legal information provided with your product. At a glance First look Top topics 23 MAY 2014 FCC SUBMIT Back Next Menu More At a glance Top topicsCheck out what your phone can do. • Personalize your home screen: see “ Redecorate your home screen ”. • Make a quick change: see “ Quick settings ”. • Go online: see “ Browse ”. • Explore: see “ Google Play™ ”. • Find apps: see “ Download apps ”. • Be social: see “ Socialize ”. • Find it yourself: see “ Locate & navigate ”. • Take a photo: see “ Take photos ”. • Connect to Wi-Fi: see “ Wi-Fi Networks ”. • Watch a movie: see “ Play Movies & TV ”. • Protect your phone: see “ Screen lock ”. • Walk through interactive tutorials: see “ Help & more ”. • Get all the help you need: see “ Get help & more ”. Ti p s & t r i c k s •Interactive: To get started quickly, touch Apps > Help for interactive tutorials. • Google™ help: In most Google Mobile apps, you can touch Menu > Help . You can also view the Google Help Centers online at www.google.com/support . At a glance First look Top topics 23 MAY 2014 FCC SUBMIT Back Next Menu More Startlet’s get up & running Put in the SIMPut the SIM in, charge up, and power on. (Your SIM may already be in your phone. If it is, just charge up and power on.)Caution: Make sure you use the correct sized SIM card, and don’t use adapters with your SIM card. Use the tool to pop out the SIM tray. Put the nano SIM into the tray. Push the tray back into your phone. 1 3 Power on. Press & hold Power until the screen lights up. Put in the SIM card. 3 H Charge up, if you need to.CC 2 SIM TOOL TBDTOOL TBD Ti p s & t r i c k s • SIM tray & tool: The SIM tray is on the side of your phone. Push the key-like tool that came in your phone’s box into the small hole in the SIM tray to open it. Put your nano SIM into the tray. (Make sure the angled corner of the SIM card matches the angled corner of the SIM tray.) Align the tray and gently put it back into the phone. •Power Key: To make the screen sleep or wake up, press the Power key. To turn your phone on or off, press and hold it. • Battery: Squeeze every bit of juice out of your battery, see “ Battery life ”. Warning: Don't try to remove or replace the battery yourself—doing so may damage the battery and could cause burning and injury. If your phone becomes unresponsive, try a reboot—press and hold both the Power and the Volume Down keys until the screen goes dark, and your phone restarts. Start Put in the SIM Battery life Sign in Old phone to new phone Google Play™ 23 MAY 2014 FCC SUBMIT Back Next Menu More Start Battery lifeYour phone is like a small computer, giving you tons of information and apps, at lightning fast speed. Depending on what you use, that can take a lot of power.To see what’s using up battery power, touch Apps > Settings > Battery . Ti p s & t r i c k sTo save even more battery life between charges, you could reduce: • Wi-Fi and Bluetooth® use: Touch Apps > Settings , then touch the switch next to Wi-Fi or Bluetooth to turn them when you don’t need them. • GPS use: Touch Apps > Settings > Location > Mode > Battery saving to turn off GPS tracking. • Display brightness: Touch Apps…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 1 Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907. 2.1. Specification Compliance Transceiver type described herein (IHDT56QA3) has been tested in accordance with the requirements contained in the appropriate regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 25 July 2014 TITLE: RF Engineering Manager 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56QA3) is in compliance with all applicable parts of the FCC Rules. NAME: John Lewczak SIGNATURE: DATE: 25 July 2014 TITLE: Engineering Manager, Product Safety and Compliance APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 2 2.3. Attestation Statement (Equipment Class DTS and DSS - Bluetooth/Wi-Fi) This device contains an embedded Bluetooth device, Wi-Fi device, and MOTOtalk capabilities that Motorola Mobility confirms are compliant with the applicable Part 15C regulations. Personal Hotspot operation is only supported in the 2.4 GHz band. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 25 July 2014 TITLE: RF Engineering Manager APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 3 2.4. Attestation Statement (Equipment Class NII - U-NII Wi-Fi) This device contains an embedded U-NII Wi-Fi device that Motorola Mobility confirms to be compliant with the applicable Part 15E regulations. Note that neither Personal Hotspot nor Wi-Fi Direct operation is supported within this equipment class. 15.407(c) The device will automatically discontinue transmission in case of either the absence of information to transmit or operational failure. 15.407(h)(1) This device does operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, but the device’s EIRP is less than 500 mW, and as such Transmit Power Control (TPC) is not required. 15.407(h)(2) This device does operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, and as such implements Dynamic Frequency Selection (DFS) as a client device. This device cannot initiate transmissions nor does it support ad-hoc networking in this band. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 25 July 2014 TITLE: RF Engineering Manager 2.5. Attestation Statement (Equipment Class PCE –LTE MPR/A-MPR Implementation ) Motorola Mobility hereby declares that MPR and A-MPR for LTE is permanently implemented in the DUT architecture, per 3GPP TS 36.101, as detailed in Section 12.4.13 of the Operational Description, and as stated in Section 2.2.1 of the SAR report. It is not controllable in any way by the user. The MPR is always on, but if a Hotspot power-reduced limit doesn't allow the DUT power to get up to or above that value, the MPR itself essentially has no effect. A-MPR was disabled for testing purposes. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 25 July 2014 TITLE: RF Engineering Manager APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 4 2.6. Attestation Statement (Equipment Class PCE – CDMA (800/850/1900 MHz), GSM (850/1900 MHz), and WCDMA (850/1900 MHz). Equipment Class DTS/NII – Wi-Fi (2.4 and 5 GHz)) Motorola Mobility hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance. The device features a HAC-mode software setting. This mode HAC mode activates unique audio gains and shaping, tailored to HAC operation. It does not affect any RF parameter (such as power). This device does not implement any HAC-related power reductions, permitted under 47 CFR 20.19(e)(1)(c) and KDB Publication 285076 D01. Features List: CDMA CDMA 1X CDMA EVDO GSM/ GPRS/EDGE LTE WCDMA Wi-Fi (a/b/g/n/ac) Bluetooth (Stereo) Location-Based Services Voice Commands Talking Phone Photo Camera Video Camera Video Player Hands Free Speaker Phone Music Player HTML Browser Text Messaging NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 25 July 2014 TITLE: RF Engineering Manager APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 5 2.7. Hearing Aid Compatibility RFE Evaluation MIF Determination Statement (Equipment Class PCE – CDMA (800/850/1900 MHz), GSM (850/1900 MHz), and WCDM…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 1 5 August 2014 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of transmitter with FCC ID: IHDT56QA3, PCS Handsets, with LTE, Wi-Fi, and Bluetooth. Gentlemen; Motorola Mobility LLC; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT56QA3. The primary transceiver in this composite device operates in the 800 MHz Land Mobile Service, the 850 MHz Public Mobile Service (PMS), and the 1900 MHz Personal Communications Service (PCS). It supports CDMA signaling, and employs CDMA 1X and EV-DO operating capabilities. The transceiver also operates in the 850 MHz Public Mobile Service (PMS), the 1700 MHz Advanced Wireless Service (AWS), and the 1900 MHz Personal Communications Service (PCS), employing GSM signaling, and employs GPRS Class 12 and EDGE Class 12 capabilities. This transceiver also operates in the WCDMA mode in these bands. Note: This device also contains functions, and operates within frequency bands, that are not authorized within the United States or its territories. This filing is only applicable to supported US operations. This mobile device is also equipped with an LTE transceiver. This LTE transceiver supports high-speed wireless data communications within LTE Bands 2, 4, 5, 12, 17, 25, 26, and 41, with channels up to 20 MHz in bandwidth. The LTE device complies with Part 22 (Subpart H), Part 24 (Subpart E), Part 27 (Subpart C), Part 22 (Subpart H), and Part 27 (Subpart C). APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 2 This radio product is also equipped with a Wi-Fi (802.11a/b/g/n/ac) transceiver. Wi-Fi supports both voice and data for short range wireless communications. The Wi-Fi Bands of Operation are 2400 – 2483.5 MHz ISM band, 5150 – 5250 MHz U-NII Band 1, 5250 – 5350 MHz U-NII Band 2A band, 5470 – 5725 MHz U-NII Band 2C, and 5725 – 5850 MHz U-NII Band 3 for 802.11a/b/g/n/ac operation. The Wi-Fi device complies 15.247, 15.407, 15.205 and 15.209. This radio product is equipped with a Bluetooth (BT) transceiver. BT supports both voice and data for short range wireless communications. The Bluetooth Band of Operation is 2.402 - 2.480 GHz (1 MHz channel bandwidth). The BT device complies with the requirements of FCC Rule Parts 15.247, 15.205 and 15.209. This product also supports NFC operation as a low-power itinerant transmitter. All transmitters contained in this radio product have been subjected to routine environmental evaluation (as applicable) according to 47 CFR Part 2.1093 (c) for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). This radio product features an integrated GPS receiver, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR Part 15.3(r). A Part 15B test report is included for certification. Enclosed is a complete Certification Application. Contact me at (954) 590-0254 if you require any additional information. Regards, FCC Liaison Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 25 July 2014 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56QA3. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. IHDT56QA3_Ex_04 (Block Diagrams).pdf Schematic Diagrams. IHDT56QA3_Ex_05 (Schematics).pdf Parts List and Tune Up Procedures. IHDT56QA3_Ex_10 (Parts List and Tune- up).pdf Transmitter Characteristics. IHDT56QA3_Ex_12 (Transceiver Characteristics).pdf Motorola Mobility LLC requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility LLC understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 2 SHORT TERM ONFIDENTIALITY REQUEST – 180 DAYS Pursuant to the Commission’s public notice DA 04-1705 (June 15, 2004), Motorola Mobility LLC is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility LLC temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. IHDT56QA3_Ex_03 (External_Photos).pdf Test set-up photographs. IHDT56QA3_Ex_07B ( various EMC Test Set- up Photos) – 7 files. IHDT56QA3_Ex_07B (NII DFS Test Set-up Photographs).pdf IHDT56QA3_Ex_07C (SAR Test Set-up Photos) 1 IHDT56QA3_Ex_07D (RFE HAC Test Set-up Photos) 1 IHDT56QA3_Ex_07D (Telecoil HAC Test Set-up Photos) 1 User’s Manual. IHDT56QA3_Ex_08 (User Guide).pdf Internal product photographs. IHDT56QA3_Ex_09 (Internal Photos).pdf 1 This exhibit not applicable to the JBP application, per 47 CFR 2.1031 Please contact me if you require any additional information. Regards, FCC Liaison Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 1 Exhibit 3. External Photographs -- Pursuant to 47 CFR 2.1033(c)(12) and RSP100, Section 5.2. The radio product colors, housings/bezels may vary, but only consistent with the requirements of FCC Class I Permissive Change rules and guidance (47 CFR 2.1043 and KDB 178919 D01). Figure 3-1. Front of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 2 Figure 3-2. Back of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 3 Figure 3-3. Button Side of device Figure 3-4. Opposite Side of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 4 Figure 3-5. Top of radio Figure 3-6. Bottom of radio

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 1 Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11); and RSP100, Section 5 and RSS Gen, Section 5.2. 1.1 Location On the bottom edge of the mobile device, laser etched into the trim band (see Figure 1.3.2). 1.2 Type The label information will be laser etched. 1.3 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. Figure 1.3.1. Representation of FCC Information. This information will be permanently etched onto the equipment trim band as shown below. Other information may also be present. Figure 1.3.2. Location of FCC Label (Viewed from Bottom Edge of Device). Please note that this label and its placement complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. The product’s Market or Trade Name is indelibly printed on the face of the product. FCC ID IHDT56QA3 FCC ID

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 1 Exhibit 9: Internal Photographs -- Pursuant to 47 CFR 2.1033(c)(12) and RSP100, Section 5. Photograph 9-1: Front side view of the device’s PC Board, Shields in place. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 2 Photograph 9-2: Front side view of the device’s PC Board, Shields Removed. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 3 Photograph 9-3: Back side view of the device’s PC Board. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 4 Photograph 9-4: Antenna Locations. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 5 Photograph 9-5: Antenna Spacing (mm).

SPORTON INTERNATIONAL INC. Page Number : 1 of 5 TEL : 886-3-327-3456 Report Issued Date : Jul. 24, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA3 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR453017D FCC RF Test Report APPLICANT : Motorola Mobility, LLC EQUIPMENT : Mobile Cellular Phone BRAND NAME : Motorola Mobility, LLC MODEL NAME : 3606 FCC ID : IHDT56QA3 STANDARD : FCC Part 15 Subpart C §15.225 CLASSIFICATION : (DXX) Low Power Communication Device Transmitter The product was received on May 30, 2014. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by: Jones Tsai / Manager SPORTON INTERNATIONAL INC. No. 52, Hwa Ya 1 st Rd., Hwa Ya Technology Park, Kwei-Shan Hsiang, Tao Yuan Hsien, Taiwan, R.O.C. SPORTON INTERNATIONAL INC. Page Number : 2 of 5 TEL : 886-3-327-3456 Report Issued Date : Jul. 24, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA3 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR453017D Table of Contents 1. GENERAL INFORMATION ...................................................................................................................................... 4 1.1 Applicant .......................................................................................................................................................................... 4 1.2 Manufacturer ..................................................................................................................................................................... 4 1.3 Feature of Equipment Under Test ........................................................................................................................................ 4 1.4 Product Details .................................................................................................................................................................. 4 1.5 Modification of EUT ............................................................................................................................................................ 5 APPENDIX A. ORIGINAL REPORT SPORTON INTERNATIONAL INC. Page Number : 3 of 5 TEL : 886-3-327-3456 Report Issued Date : Jul. 24, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA3 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR453017D REVISION HISTORY REPORT NO. VERSION DESCRIPTION ISSUED DATE FR453017D Rev. 01 The NFC circuitry of this variant model (3606) is identical to that of the parent product (3578), based on the product equality declaration by the manufacturer Jul. 24, 2014 SPORTON INTERNATIONAL INC. Page Number : 4 of 5 TEL : 886-3-327-3456 Report Issued Date : Jul. 24, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA3 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR453017D 1. GENERAL INFORMATION 1.1 Applicant Motorola Mobility, LLC 222 W Merchandise Mart Plaza, Suite 1800, Chicago, IL 60654, United States 1.2 Manufacturer Motorola Mobility, LLC 222 W Merchandise Mart Plaza, Suite 1800, Chicago, IL 60654, United States 1.3 Feature of Equipment Under Test Product Feature Equipment Mobile Cellular Phone Brand Name Motorola Mobility, LLC Model Name 3606 FCC ID IHDT56QA3 EUT supports Radios application GSM/EGPRS/CDMA/EV-DO/WCDMA/HSPA/LTE/NFC WLAN 11b/g/n HT20 WLAN 11a/n HT20/HT40 WLAN 11ac VHT20/VHT40/VHT80 Bluetooth v3.0 + EDR Bluetooth v4.0 - LE HW Version P2 SW Version KXE21.116-VICTARA-SHA1 EUT Stage Identical Prototype 1.4 Product Details Items Description Tx/Rx Frequency Range 13.553 ~ 13.567MHz Channel Number 1 Antenna Type Loop Antenna Type of Modulation ASK Remark: The above EUT's information was declared by manufacturer. Please refer to the specifications or user's manual for more detailed description. SPORTON INTERNATIONAL INC. Page Number : 5 of 5 TEL : 886-3-327-3456 Report Issued Date : Jul. 24, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA3 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR453017D 1.5 Modification of EUT No modifications are made to the EUT during all test items. SPORTON INTERNATIONAL INC. Page Number : A1 of A1 TEL : 886-3-327-3456 Report Issued Date : Jul. 24, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA3 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR453017D Appendix A. Original Report Please refer to Sporton report number FR442943D as below. SPORTON INTERNATIONAL INC. Page Number : 1 of 18 TEL : 886-3-327-3456 Report Issued Date : Jul. 11, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA1 Report Template No.: BU5-FR15CNFC Version 1.0 FCC RF Test Report Report No. : FR442943D FCC RF Test Report APPLICANT : Motorola Mobility, LLC EQUIPMENT : Mobile Cellular Phone BRAND NAME : Motorola Mobility, LLC FCC MODEL NAME : 3578 FCC ID : IHDT56QA1 STANDARD : FCC Part 15 Subpart C §15.225 CLASSIFICATION : (DXX) Low Power Communication Device Transmitter The product was received on Apr. 29, 2014 and testing was completed on Jun. 17, 2014. We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the test procedures and has been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. Reviewed by: Joseph Lin / Supervisor Approved by…

Text truncated - open the document above for the full version.

SPORTON INTERNATIONAL INC. Page Number : 1 of 2 TEL : 886-3-327-3456 Report Issued Date : Jul. 24, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA3 Report Template No.: BU5-FR15CNFC Version 1.0 Exhibit 7 Report No. :FR453017D Short-Term Confidentiality Requested RF NFC Test Setup Photos <Conducted Emission> Note: The 453017 report reuses setup photo from the 442943 report. SPORTON INTERNATIONAL INC. Page Number : 2 of 2 TEL : 886-3-327-3456 Report Issued Date : Jul. 24, 2014 FAX : 886-3-328-4978 Report Version : Rev. 01 FCC ID : IHDT56QA3 Report Template No.: BU5-FR15CNFC Version 1.0 Exhibit 7 Report No. :FR453017D <Radiated Emission> Z Plane 9K~30MHz 30MHz-1GHz Note: The 453017 report reuses setup photo from the 442943 report.
