IHDT56QG1UMTS/LTE Transceiver with BT & WLAN

Motorola Mobility LLC

Click to zoom

Application Details

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Date of Grant: May 28, 2015
Application Purpose: Original Equipment
Date of Application: May 28, 2015
Equipment Note: UMTS/LTE Transceiver with BT & WLAN
Frequency Range: 2402.00000000 - 2480.00000000
Company: Motorola Mobility LLC
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / IC ID: 109O-T56QG1 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 8 - 1 Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3) and RSP100, Section 5. The attached User’s Manual is the final production-intended version of the generic Motorola International English User Manual. This guide will be adapted to carrier-specific versions i , but the key information herein will be retained. Translations into other languages will also be done to support the needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to, placing this product onto the market. Selected portions of the User Guide can be found as indicated below: 8.1 Safety and Regulatory Section: Page 5 8.2 Specific Absorption Rate (SAR) Data: Page 2, 3, 8 8.3 Guidance for use with Hearing Aids (Pursuant to 47 CFR 20.19(f)(1): Page 11 i Motorola Mobility attests that the User’s Guide provided with product shipping into Canada will provide any required Industry Canada notices and/or statements in both English and French, per the requirements of RSS-Gen. en read me Caution: Before using your phone, please read the safety, regulatory and legal information provided with your product. XT1551 motorola.com This product meets the applicable national or international RF exposure guidance (SAR guideline) when used normally against your head or, when worn or carried, at a distance of 1.5 cm from the body. The SAR guideline includes a considerable safety margin designed to assure the safety of all persons, regardless of age and health. At a glance Let’s get started! We'll guide you through startup and tell you a bit about your phone’s features. Note: Software updates happen frequently, so your phone may look a little different. Google Play Store 11:35 Volume Buttons Power Button Micro USB/ Charger Microphone Front Camera & Flash Headset Jack Nano SIM & MicroSD Memory Card Tray Press: Display on/off. Press & hold: Phone on/off. Back Home Overview Camera & Flash (on back) Put in the cards & power on Caution: Make sure you use the correct size SIM cards, don’t cut the SIM cards, and don’t use adapters with your SIM cards. Dual SIM phone settings To set up a dual SIM phone, insert both nano SIM cards, turn on your phone, and follow the prompts. Then swipe down the status bar at the top of the home screen and tap Welcome to your dual SIM. Push the tray back into your phone with gold contacts facing up. PPPPu 2 1 Put the nano SIM and memory cards in. Nano SIM SIM 2 microSD (on back & optional) SIM 1 Use the tool to pop out the tray. Put the SIM cards into the tray with gold contacts facing up. Turn tray over to put in memory card. Power on. Press & hold Power until the screen lights up. PP 3 Start Sign in Just follow the screen prompts to get started. If you use Gmail™, you already have a Google™ account—if not, you can create an account during setup. Signing into your Google account lets you access, sync, and backup your stuff. See your Google apps, contacts, calendar, photos, and more. Enter your email Or create a new account Add your account SKIP 11:35 i Sign in to get the most out of your device. Sign in to access and sync your contacts, calendar, and photos. Motorola Migrate Copying your personal stuff from your old phone to your new phone is easy. If you did not migrate during set up you can do it anytime. Note: If your old phone is an Android™ phone, download the Motorola Migrate app on Google Play™ on your old phone before you get started. Find it: On your new phone, tap Apps > Migrate Migrate your stuff Copy stuff from your old phone to this one in just a few minutes. You may be able to transfer photos, videos, music, call history, messages, contacts and more. Select your old phone type EXITNEXT Send data TO this device Send data FROM this device 11:35 Select your old phone type. Home screen & apps Home screen & settings From the home screen, you can explore apps, check notifications, speak commands, and more. •Add a shortcut: Tap Apps , tap and hold an app, then drag it to your home screen. •Settings: To change your Wi-Fi, display brightness, and more, swipe the status bar down with two fingers. To open more settings, tap . •Share your phone: To add a guest user, swipe the status bar down with two fingers and tap . 11:35 Google Play Store 11:35 Google Play Store 11:35 Search by typing or say "OK, Google". Tap Apps to see all your apps. Swipe down with one finger for notifications or with two fingers for profiles and settings. Touch and hold an empty spot to change widgets, wallpaper, and more. Volume & interruptions Press the side volume button up or down to select a ringer volume from high to vibrate . Or, tap an option: •All: Receive all interruptions and alarms. •Priority: Tap to select which interruptions to receive and more. You will always hear alarms. •None: Turn off all sounds and alarms. Override sound settings from other apps. 11:35 Google Play Store 11:35 Google Play Store 11:35 NonePriorityAll Set the volume using the side Volume Buttons. Change interruptions settings. Change to vibrate or back to ring. 4 JUNE 2015 Discover your Moto apps Find it: Apps > Moto •Assist: Set your phone to adapt to what you're doing, where you are. •Actions: Turn the flashlight on/off with a chopping motion or silence calls with a wave of your hand. •Voice: Set your custom launch phrase and control your Moto X with your voice. •Display: See messages, calls, and other notifications—even if your phone is asleep. Note: Your phone may not have all features. 11:35 See what I can do. Assist I adjust automatically Actions I react to motion Voice I listen and respond Display I notify you at a glance Tap an option to learn more. Browse Photos With two twists of the wrist and a tap on the screen, take crisp, clear photos with the 21 megapixel camera. •Launch it: Even when your phone is …

Text truncated - open the document above for the full version.

Attestation Statements

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / 109O-T56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 1 Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907. 2.1. Specification Compliance Transceiver type described herein (IHDT56QG1 and 109O-T56QG1) has been tested in accordance with the requirements contained in the appropriate regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Peter Yeh SIGNATURE: /s/Peter Yeh DATE: 27 May 2015 TITLE: Fellow of the Technical Staff 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56QG1) is in compliance with all applicable parts of the FCC Rules. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (109O-T56QG1) is in compliance with all applicable Industry Canada Rules and Procedures. NAME: John Lewczak SIGNATURE: DATE: 27 May 2015 TITLE: Distinguished Member of Technical Staff, Product Safety and Compliance APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / 109O-T56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 2 2.3. Attestation Statement (Equipment Class DTS and DSS - Bluetooth/Wi-Fi) This device contains an embedded Bluetooth device, Wi-Fi device, and MOTOtalk capabilities that Motorola Mobility confirms are compliant with the applicable Part 15C regulations. Personal Hotspot operation is only supported in the 2.4 GHz band for this equipment class. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Peter Yeh SIGNATURE: /s/Peter Yeh DATE: 27 May 2015 TITLE: Fellow of the Technical Staff APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / 109O-T56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 3 2.4. Attestation Statement (Equipment Class PCE –LTE MPR/A-MPR Implementation ) Motorola Mobility hereby declares that MPR and A-MPR for LTE is permanently implemented in the DUT architecture, per 3GPP TS 36.101, as detailed in Section 12.3.10 of the Operational Description, and as stated in Section 2.2.1 of the SAR report. It is not controllable in any way by the user. The MPR is always on, but if a Hotspot power-reduced limit doesn't allow the DUT power to get up to or above that value, the MPR itself essentially has no effect. A-MPR was disabled for testing purposes. NAME: Peter Yeh SIGNATURE: /s/Peter Yeh DATE: 27 May 2015 TITLE: F ellow of the Technical Staff 2.5. Hearing Aid Compatibility Attestation Statement (Equipment Class PCE – GSM (850/1900 MHz), WCDMA (850/1700/1900 MHz), and LTE (Bands 2, 4, 5, 7, 12, and 17) Motorola Mobility hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance. The device features a HAC-mode software setting. This mode HAC mode activates unique audio gains and shaping, tailored to HAC operation. It does not affect any RF parameter (such as power). This device does not implement any HAC-related power reductions, permitted under 47 CFR 20.19(e)(1)(c) and KDB Publication 285076 D01. Features List: GSM GPRS/EDGE WCDMA Wi-Fi (b/g/n) Bluetooth (Stereo) Location-Based Services Voice Commands Talking Phone Photo Camera Video Camera Video Player Hands Free Speaker Phone Music Player HTML Browser Text Messaging NAME: Peter Yeh SIGNATURE: /s/Peter Yeh DATE: 27 May 2015 TITLE: Fellow of the Technical Staff APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / 109O-T56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 4 2.6. Hearing Aid Compatibility RFE Evaluation MIF Determination Statement (Equipment Class PCE – GSM (850/1900 MHz), WCDMA (850/1700/1900 MHz), and LTE (Bands 2, 4, 5, 7, 12, and 17). This device, carrying FCC ID: IHDT56QG1, is being certified for Hearing Aid Compatibility under the ANSI C63.19-2011 standard, per Part 20.19. For Radio Frequency Interference, neither Speag’s Audio Interference Analyzer (AIA) nor any other indirect or direct measurement was used to determine the M-rating. Rather, the M-rating was determined by measuring the maximum steady state average E-field values in dB (V/m) or average antenna input power (as documented in HAC test report) and adding the applicable MIF value in dB. The MIF values below for the worst-case operation mode for all air interfaces are the pre-determined values provided by Speag: UID Air Interface MIF (dB) 10021 GSM-FDD(TDMA,GMSK) 3.63 10011 UMTS-FDD(WCDMA) -27.23 10169 LTE-FDD (SC-FDMA, 1RB, 20 MHz, QPSK) -15.63 10170 LTE-FDD (SC-FDMA, 1RB…

Text truncated - open the document above for the full version.

Cover Letter(s)

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 1 20 April 2015 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of transmitter with FCC ID: IHDT56QG1, UMTS/GSM PCS Handsets, with LTE, Wi-Fi, and Bluetooth. Gentlemen; Motorola Mobility LLC; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT56QG1. The primary transceiver in this composite device operates in the 850 MHz Public Mobile Service (PMS), the 1700 MHz Advanced Wireless Service (AWS), and the 1900 MHz Personal Communications Service (PCS). It supports GSM signaling, and employs GPRS Class 12 and EDGE Class 12 capabilities. This transceiver also operates in the WCDMA mode in these bands. Note: This device also contains functions, and operates within frequency bands, that are not authorized within the United States or its territories. This filing is only applicable to supported US operations. This mobile device is also equipped with an LTE transceiver. This LTE transceiver supports high-speed wireless data communications within LTE Bands 2, 4, 5, 7, 12, and 17, with channels up to 20 MHz in bandwidth. The LTE device complies with Part 22 (Subpart H), Part 24 (Subpart E), Part 27 (Subpart C), Part 22 (Subpart H), and Part 27 (Subpart C). This radio product is also equipped with a Wi-Fi (802.11 b/g/n) transceiver. Wi-Fi supports both voice and data for short range wireless communications. The Wi-Fi Band of Operation is 2400 – 2483.5 MHz ISM band, supporting 802.11b/g/n operation. The Wi-Fi device complies 15.247, 15.205 and 15.209. This radio product is equipped with a Bluetooth (BT) transceiver. BT supports both voice and data for short range wireless communications. The Bluetooth Band of Operation is 2.402 - 2.480 GHz (1 MHz channel bandwidth). The BT device complies with the requirements of FCC Rule Parts 15.247, 15.205 and 15.209. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 2 All transmitters contained in this radio product have been subjected to routine environmental evaluation (as applicable) according to 47 CFR Part 2.1093 (c) for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). This radio product features integrated GPS and FM broadcast receivers, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR Part 15.3(r). A Part 15B test report is included for certification. Enclosed is a complete Certification Application. Contact me at (954) 590-0254 if you require any additional information. Regards, Distinguished Member of Technical Staff Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

Cover Letter(s)

FCC ID: IHDT56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 27 May 2015 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56QG1. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. IHDT56QG1_Ex_04 (Block Diagrams).pdf Schematic Diagrams. IHDT56QG1 _Ex_05 (Schematics).pdf Parts List and Tune Up Procedures. IHDT56QG1 _Ex_10 (Parts List and Tune- up).pdf Transmitter Characteristics. IHDT56QG1 _Ex_12 (Transceiver Characteristics).pdf Motorola Mobility LLC requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility LLC understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 2 SHORT TERM ONFIDENTIALITY REQUEST – 180 DAYS Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, and the guidance in KDB Publication 726920 D01, Motorola Mobility LLC is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility LLC temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. IHDT56QG1 _Ex_03 (External_Photos).pdf Test set-up photographs. IHDT56QG1 _Ex_07B (various EMC Test Set-up Photos) – 6 files. IHDT56QG1 _Ex_07B (NII DFS Test Set-up Photographs).pdf IHDT56QG1 _Ex_07C (SAR Test Set-up Photos) 1 IHDT56QG1 _Ex_07D (RFE HAC Test Set-up Photos) 1 IHDT56QG1 _Ex_07D (Telecoil HAC Test Set-up Photos) 1 User’s Manual. IHDT56QG1 _Ex_08 (User Guide).pdf Internal product photographs. IHDT56QG1 _Ex_09 (Internal Photos).pdf 1 This exhibit not applicable to the JBP application, per 47 CFR 2.1031 Please contact me if you require any additional information. Regards, Distinguished Member of Technical Staff Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

Cover Letter(s)

FCC ID: IHDT56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 SUPERSEDE EXHIBITS REQUEST 17 June 2015 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56QG1. Dear Sir or Madam: Motorola Mobility LLC would like to present new exhibits for the above filing, which will supersede those originally submitted. Design optimization efforts that occurred after the hardware/software version evaluated for this filing have resulted in some changes to reported parameters. The updated test reports reflect these changes. Apart from these test reports, and the other exhibits being superseded, all exhibits previously submitted for this device remain applicable. The affected exhibits are shown below. Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: No Confidentiality Requested New Exhibit Type File Name RF Exposure Report. IHDT56QG1_Ex_11 (RF Exposure Test Report - Part 1 of 4) Rev A (4-files) RF Exposure Supplemental Report. IHDT56QG1_Ex_11A (SAR Supplemental Test Report) Rev A PCE RF Test Reports. IHDT56QG1_Ex_06A (PCE UMTS RF Test Report) Rev A IHDT56QG1_Ex_06B (PCE LTE RF Test Report - Part 1 of 19) Rev A (19-files) FCC ID: IHDT56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 2 Motorola Mobility LLC requests the following exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Permanent Confidentiality Requested New Exhibit Type File Name Transmitter Characteristics. IHDT56QG1_Ex_12 (Transceiver Characteristics) Rev A Motorola Mobility LLC understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. SHORT TERM ONFIDENTIALITY REQUEST – to 11/25/2015 Pursuant to the Commission’s public notice DA 04-1705 (June 15, 2004), Motorola Mobility LLC is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility LLC temporary confidentiality prior to product launch. Short Term Confidentiality Requested New Exhibit Type File Name User’s Manual. IHDT56QG1_Ex_08 (User Guide) Rev A Please contact me if you require any additional information. Regards, Distinguished Member of Technical Staff Motorola Mobility LLC 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 E-mail: [email protected]

External Photos

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / IC: 109O-T56QG1 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 1 Exhibit 3. External Photographs -- Pursuant to 47 CFR 2.1033(c)(12) and RSP100, Section 5.2. The radio product colors, housings/bezels may vary, but only consistent with the requirements of FCC Class I Permissive Change rules and guidance (47 CFR 2.1043 and KDB 178919 D01). Figure 3-1. Front of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / IC: 109O-T56QG1 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 2 Figure 3-2. Back of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / IC: 109O-T56QG1 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 3 Figure 3-3. Button Side of device Figure 3-4. Opposite Side of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / IC: 109O-T56QG1 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 4 Figure 3-5. Top of radio Figure 3-6. Bottom of radio APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / IC: 109O-T56QG1 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 5 Figure 3-7. Interior Compartment of radio FCC Label Location. See Exhibit 1 for details.

ID Label/Location Info

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / IC ID: 109O-T56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 1 Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11); and RSP100, Section 5 and RSS Gen, Section 5.2. 1.1 Location On the rear (back) side of the radio product chassis, beneath the Rear Cover (see also Exhibit 3). 1.2 Type The label is of a polyester film laminate with a pressure sensitive adhesive backing. The adhesive is a permanent type acrylic with minimum peel strength of 5 lbs/in. 1.3 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. Figure 1.3.1. Representation of FCC Label information. The above label representation is applicable to the following versions/variants of the device that is the subject of this application: Model Number 1 1 Depending upon the device version, or market into which it ships, the Model Number shown on the label may vary. All such variants will be electrically identical, consistent with the requirements of FCC Class I Permissive Change rules and guidance (47 CFR 2.1043 and KDB 178919 D01). This label will be placed on the equipment (underneath the Rear Cover) as shown below. Other information may also be included on this label, and other labels may also be present. FCC ID IHDT56QG1 IC: 109O-T56QG1 Model No. MODEL APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56QG1 / IC ID: 109O-T56QG1 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 2 Figure 1.3.2. Location of FCC Label (position, orientation, and other information shown may vary). Please note that this label and its placement complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. The FCC ID will also be printed on the device packaging. Further, the placement of the label behind the Rear Cover is done because space is limited on the exterior of the device. The rear compartment also helps to protect the label from getting obliterated or made unreadable through regular handling and use. The product’s Market or Trade Name is indelibly printed on the face of the product, as shown in Exhibit 3. Interior Battery Compartment FCC Label Back of Device

Internal Photos

RF Exposure Info

SPORTON INTERNATIONAL INC. TEL : 886-3-327-3456 / FAX : 886-3-328-4978 Issued Date : Jun. 16, 2015 FCC ID : IHDT56QG1 Page 1 of 57 Form version. : 150415 FCC SAR Test Report Report No. : FA542019A FCC SAR Test Report APPLICANT : Motorola Mobility, LLC EQUIPMENT : Mobile Cellular Phone BRAND NAME : Motorola MODEL NAME : 4247 FCC ID : IHDT56QG1 STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and had been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. No.52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan District, Taoyuan City, Taiwan (R.O.C.) Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager SPORTON INTERNATIONAL INC. TEL : 886-3-327-3456 / FAX : 886-3-328-4978 Issued Date : Jun. 16, 2015 FCC ID : IHDT56QG1 Page 2 of 57 Form version. : 150415 FCC SAR Test Report Report No. : FA542019A Table of Contents 1. Statement of Compliance ............................................................................................................................................. 4 2. Administration Data ...................................................................................................................................................... 4 3. Guidance Standard ....................................................................................................................................................... 5 4. Equipment Under Test (EUT) ....................................................................................................................................... 5 4.1 General Information ............................................................................................................................................... 5 4.2 Maximum Tune-up Limit ......................................................................................................................................... 6 4.3 General LTE SAR Test and Reporting Considerations ........................................................................................... 7 5. RF Exposure Limits....................................................................................................................................................... 8 5.1 Uncontrolled Environment ............................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Jeff Narducci(Director Product Compliance)

[email protected]847-687-6928Fax: 847-687-6928

Test Firm

Sporton International Inc.Alex Chen

[email protected]886-3-327-3456Fax: 886-3-327-0973

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	11.00 mW

Confidentiality

Long Term

Grant Notes

Power listed is conducted. For body-worn operation, this device has been tested and meets the FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 1.5 cm from the users body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values for head, body-worn accessory, product specific (wireless router), and simultaneous transmission conditions are <0.10W/kg, <0.10W/kg, <0.10W/kg, and 1.32W/kg respectively.
