IHDT56UC2WCDMA/GSM/LTE Transceiver with WLAN, BT, and NFC

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 8 - 1 Exhibit 8: Draft User’s Manual -- 47 CFR 2.1033(b)(3) and RSP100, Section 5. The attached User’s Manual is the final production-intended version of the generic Motorola International English User Manual. This guide will be adapted to carrier-specific versions i , but the key information herein will be retained. Translations into other languages will also be done to support the needs of other markets. Minor revisions may be made to these manuals, prior to and subsequent to, placing this product onto the market. Selected portions of the User Guide can be found as indicated below: 8.1 Safety and Regulatory Section: Page 5 8.2 Specific Absorption Rate (SAR) Data: Page 2, 3, 8 8.3 Guidance for use with Hearing Aids (Pursuant to 47 CFR 20.19(f)(1): Page 11 8.4 Instructions to User on accessing Electronic Labeling (per KDB784748 D02): Page 3 i Motorola Mobility attests that the User’s Guide provided with product shipping into Canada will provide any required Industry Canada notices and/or statements in both English and French, per the requirements of RSS-Gen. en read me Caution: Before using your phone, please read the safety, regulatory and legal information provided with your product. XT1575 motorola.com This product meets the applicable national or international RF exposure guidance (SAR guideline) when used normally against your head or, when worn or carried, at a distance of 1.5 cm from the body. The SAR guideline includes a considerable safety margin designed to assure the safety of all persons, regardless of age and health. At a glance Let’s get started! We'll guide you through startup and tell you a bit about your phone’s features. Note: Software updates happen frequently, so your phone may look a little different. Google Play Store 11:35 Volume Buttons Power Button Micro USB/ Charger Microphone Front Camera & Flash Headset Jack Nano SIM & MicroSD Memory Card Tray Press: Display on/off. Press & hold: Phone on/off. Back Home Overview Camera & Flash (on back) Put in the cards & power on Caution: Make sure you use the correct size SIM cards, don’t cut the SIM cards, and don’t use adapters with your SIM cards. Dual SIM phone settings To set up a dual SIM phone, insert both nano SIM cards, turn on your phone, and follow the prompts. Then swipe down the status bar at the top of the home screen and tap Welcome to your dual SIM. Push the tray back into your phone with gold contacts facing up. PPPPu 2 1 Put the nano SIM and memory cards in. Nano SIM SIM 2 microSD (on back & optional) SIM 1 Use the tool to pop out the tray. Put the SIM cards into the tray with gold contacts facing up. Turn tray over to put in memory card. Power on. Press & hold Power until the screen lights up. PP 3 Start Sign in Just follow the screen prompts to get started. If you use Gmail™, you already have a Google™ account—if not, you can create an account during setup. Signing into your Google account lets you access, sync, and backup your stuff. See your Google apps, contacts, calendar, photos, and more. Enter your email Or create a new account Add your account SKIP 11:35 i Sign in to get the most out of your device. Sign in to access and sync your contacts, calendar, and photos. Motorola Migrate Copying your personal stuff from your old phone to your new phone is easy. If you did not migrate during set up you can do it anytime. Note: If your old phone is an Android™ phone, download the Motorola Migrate app on Google Play™ on your old phone before you get started. Find it: On your new phone, tap Apps > Migrate Migrate your stuff Copy stuff from your old phone to this one in just a few minutes. You may be able to transfer photos, videos, music, call history, messages, contacts and more. Select your old phone type EXITNEXT Send data TO this device Send data FROM this device 11:35 Select your old phone type. Home screen & apps Home screen & settings From the home screen, you can explore apps, check notifications, speak commands, and more. •Add a shortcut: Tap Apps , tap and hold an app, then drag it to your home screen. •Settings: To change your Wi-Fi, display brightness, and more, swipe the status bar down with two fingers. To open more settings, tap . •Share your phone: To add a guest user, swipe the status bar down with two fingers and tap . 11:35 Google Play Store 11:35 Google Play Store 11:35 Search by typing or say "OK, Google". Tap Apps to see all your apps. Swipe down with one finger for notifications or with two fingers for profiles and settings. Touch and hold an empty spot to change widgets, wallpaper, and more. Volume & interruptions Press the side volume button up or down to select a ringer volume from high to vibrate . Or, tap an option: •All: Receive all interruptions and alarms. •Priority: Tap to select which interruptions to receive and more. You will always hear alarms. •None: Turn off all sounds and alarms. Override sound settings from other apps. 11:35 Google Play Store 11:35 Google Play Store 11:35 NonePriorityAll Set the volume using the side Volume Buttons. Change interruptions settings. Change to vibrate or back to ring. 4 JUNE 2015 Discover your Moto apps Find it: Apps > Moto •Assist: Set your phone to adapt to what you're doing, where you are. •Actions: Turn the flashlight on/off with a chopping motion or silence calls with a wave of your hand. •Voice: Set your custom launch phrase and control your Moto X with your voice. •Display: See messages, calls, and other notifications—even if your phone is asleep. Note: Your phone may not have all features. 11:35 See what I can do. Assist I adjust automatically Actions I react to motion Voice I listen and respond Display I notify you at a glance Tap an option to learn more. Browse Photos With two twists of the wrist and a tap on the screen, take crisp, clear photos w…

Text truncated - open the document above for the full version.

FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 22 June 2015 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT56UC2. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. IHDT56UC2_Ex_04 (Block Diagrams).pdf Schematic Diagrams. IHDT56UC2 _Ex_05 (Schematics).pdf Parts List and Tune Up Procedures. IHDT56UC2 _Ex_10 (Parts List and Tune- up).pdf Transmitter Characteristics. IHDT56UC2 _Ex_12 (Transceiver Characteristics).pdf Motorola Mobility LLC requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility LLC understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 2 SHORT TERM ONFIDENTIALITY REQUEST – 180 DAYS Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, and the guidance in KDB Publication 726920 D01, Motorola Mobility LLC is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility LLC temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. IHDT56UC2 _Ex_03 (External_Photos).pdf Test set-up photographs. IHDT56UC2 _Ex_07B (various EMC Test Set- up Photos) – 9 files. IHDT56UC2 _Ex_07B (NII DFS Test Set-up Photographs).pdf IHDT56UC2 _Ex_07C (SAR Test Set-up Photos) 1 IHDT56UC2 _Ex_07D (RFE HAC Test Set-up Photos) 1 IHDT56UC2 _Ex_07D (Telecoil HAC Test Set-up Photos) 1 User’s Manual. IHDT56UC2 _Ex_08 (User Guide).pdf Internal product photographs. IHDT56UC2 _Ex_09 (Internal Photos).pdf 1 This exhibit not applicable to the JBP application, per 47 CFR 2.1031 Please contact me if you require any additional information. Regards, Distinguished Member of Technical Staff Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 1 9 June 2015 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of transmitter with FCC ID: IHDT56UC2, UMTS Handsets, with LTE, Wi-Fi, Bluetooth, and NFC. Gentlemen; Motorola Mobility LLC; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT56UC2. The transceiver operates in the 850 MHz Public Mobile Service (PMS) and the 1900 MHz Personal Communications Service (PCS), supporting GSM (employing GPRS Class 12 and EDGE Class 12 capabilities), and WCDMA signaling in these bands. The primary transceiver in this composite device operates in the 850 MHz Public Mobile Service (PMS), the 1700 MHz Advanced Wireless Service (AWS), and the 1900 MHz Personal Communications Service (PCS). It supports GSM signaling, and employs GPRS Class 12 and EDGE Class 12 capabilities. This transceiver also operates in the WCDMA mode in these bands. This mobile device is also equipped with an LTE transceiver. This LTE transceiver supports high-speed wireless data communications within LTE Bands 2, 4, 5, 7, 12, 17, 25, 29, and 41, with channels up to 20 MHz in bandwidth. The LTE device complies with Part 22 (Subpart H), Part 24 (Subpart E), Part 27 (Subpart C), Part 22 (Subpart H), and Part 27 (Subpart C). Note: This device also contains functions, and operates within frequency bands, that are not authorized within the United States or its territories. This filing is only applicable to supported US operations. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 2 This radio product is also equipped with a Wi-Fi (802.11a/b/g/n/ac) transceiver. Wi-Fi supports both voice and data for short range wireless communications. The Wi-Fi Bands of Operation are 2400 – 2483.5 MHz ISM band, 5150 – 5250 MHz U-NII Band 1, 5250 – 5350 MHz U-NII Band 2A band, 5470 – 5725 MHz U-NII Band 2C, and 5725 – 5850 MHz U-NII Band 3 for 802.11a/b/g/n/ac operation. The Wi-Fi device complies 15.247, 15.407, 15.205 and 15.209. This radio product is equipped with a Bluetooth (BT) transceiver. BT supports both voice and data for short range wireless communications. The Bluetooth Band of Operation is 2.402 - 2.480 GHz. The BT device complies with the requirements of FCC Rule Parts 15.247, 15.205 and 15.209. This product also supports NFC operation as a low-power itinerant transmitter. All transmitters contained in this radio product have been subjected to routine environmental evaluation (as applicable) according to 47 CFR Part 2.1093 (c) for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1093(d)(2). This radio product features an integrated GPS receiver, and is designed to function as a computer peripheral device when functioning as an RF modem, while connected to a computer via a data cable, as described in 47 CFR Part 15.3(r). A Part 15B test report is included for certification. Enclosed is a complete Certification Application. Contact me at (954) 590-0254 if you require any additional information. Regards, Distinguished Member of Technical Staff Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 1 Exhibit 2. Statements of Certification -- Pursuant to 47 CFR 2.907. 2.1. Specification Compliance Transceiver type described herein (IHDT56UC2) has been tested in accordance with the requirements contained in the appropriate regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards, and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured, imported, or marketed will conform to the samples tested herein, within the statistical variations that can be expected due to high volume production and test measurement error. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 19 June 2015 TITLE: RF Engineering Manager 2.2. Statement of Certification I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (IHDT56UC2) is in compliance with all applicable parts of the FCC Rules. NAME: John Lewczak SIGNATURE: DATE: 19 June 2015 TITLE: Distinguished Member of Technical Staff, Product Safety and Compliance APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 2 2.3. Attestation Statement (Equipment Class DTS and DSS - Bluetooth/Wi-Fi) This device contains an embedded Bluetooth device, Wi-Fi device, and MOTOtalk capabilities that Motorola Mobility confirms are compliant with the applicable Part 15C regulations. Personal Hotspot operation is only supported in the 2.4 GHz band for this equipment class. 15.247(a)(1) • The hopping sequence must be pseudorandom. • All Channels are used equally on average. • The receiver input bandwidth is approximately equal to the transmit bandwidth. • The receiver hops in sequence with the transmitted signal. 15.247(g) The system is designed to comply with all of the regulations in Section 15.247 when the transmitter is presented with a continuous data (or information). 15.247(h) The system does not coordinate its channel selection/hopping sequence with other frequency hopping systems for the express purpose of avoiding the simultaneous occupancy of individual hopping frequencies by multiple transmitters. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 19 June 2015 TITLE: RF Engineering Manager APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 3 2.4. Attestation Statement (Equipment Class NII - U-NII Wi-Fi) This device contains an embedded U-NII Wi-Fi device that Motorola Mobility confirms to be compliant with the applicable Part 15E regulations. Note that Personal Hotspot Wi-Fi Direct operation is supported only in the U-NII-1 spectrum (5.150-5.250 GHz) and U-NII Band 3 (5.725 – 5.850 GHz), and not supported elsewhere for this equipment class. 15.407(c) The device will automatically discontinue transmission in case of either the absence of information to transmit or operational failure. 15.407(h)(1) This device does operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, but the device’s EIRP is less than 500 mW, and as such Transmit Power Control (TPC) is not required. 15.407(h)(2) This device does operate in the bands between 5.25 – 5.35 GHz and 5.47 – 5.725 GHz, and as such implements Dynamic Frequency Selection (DFS) as a client device. This device, including the client software and associated drivers, will not initiate any transmission on any DFS frequencies without initiation by a master. This includes restriction on transmissions for beacons and support for ad-hoc peer-to-peer modes. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 19 June 2015 TITLE: RF Engineering Manager APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 2 - 4 2.5. Attestation Statement (Equipment Class PCE –LTE MPR/A-MPR Implementation ) Motorola Mobility hereby declares that MPR and A-MPR for LTE is permanently implemented in the DUT architecture, per 3GPP TS 36.101, as detailed in Section 12.3.10 of the Operational Description, and as stated in Section 2.2.1 of the SAR report. It is not controllable in any way by the user. The MPR is always on, but if a Hotspot power-reduced limit doesn't allow the DUT power to get up to or above that value, the MPR itself essentially has no effect. A-MPR was disabled for testing purposes. NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 19 June 2015 TITLE: RF Engineering Manager 2.6. Hearing Aid Compatibility Attestation Statement (Equipment Class PCE – GSM (850/1900 MHz), WCDMA (850/1700/1900 MHz), and LTE (Bands 2, 4, 7, 12, 17, 25, and 41) Motorola Mobility hereby declares that typical production units were evaluated for Hearing Aid Compatibility (HAC) compliance. The device features a HAC-mode software setting. This mode HAC mode activates unique audio gains and shaping, tailored to HAC operation. It does not affect any RF parameter (such as power). This device does not implement any HAC-related power reductions, permitted under 47 CFR 20.19(e)(1)(c) and KDB Publication 285076 D01. Features List: GSM/ GPRS/EDGE WCDMA LTE Wi-Fi (b/g/n/ac) Bluetooth (Stereo) Location-Based Services Voice Commands Talking Phone Photo Camera Video Camera Video Player Hands Free Speaker Phone Music Player HTML Browser Text Messaging NAME: Chilsun Heo SIGNATURE: /s/ Chilsun Heo DATE: 19 June 2015 TITLE: RF Engineering Manager APPLICANT: MOTOROLA MOBILITY LLC …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 1 Exhibit 3. External Photographs -- Pursuant to 47 CFR 2.1033(c)(12) and RSP100, Section 5.2. The radio product colors, housings/bezels may vary, but only consistent with the requirements of FCC Class I Permissive Change rules and guidance (47 CFR 2.1043 and KDB 178919 D01). Figure 3-1. Front of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 2 Figure 3-2. Back of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 3 Figure 3-3. Button Side of device Figure 3-4. Opposite Side of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 4 Figure 3-5. Top of radio Figure 3-6. Bottom of radio

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 1 Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11); and RSP100, Section 5; RSS Gen, Section 5.2; and Notice 2014-DRS1003. 1.1 Electronic Labeling This device will employ electronic labeling for all required FCC and Industry Canada regulatory marks, consistent with the KDB Publication KDB784748 D02 and Notice 2014-DRS1003. 1.2 Accessing Electronic Label Information End users can access electronic labeling of regulatory information using the procedure described below. These instructions are also presented in the User Manual provided with this device (see Exhibit 8): 1. Enter the Settings Menu of the device. 2. Scroll to the bottom of the available options, and select the About Phone option. 3. Select the Regulatory Information option, and scroll as needed to access the desired information. 4. When finished, press the Home Key to return to the device’s home screen. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 2 1.3 Electronic Labeling Regulatory Requirements Checklist The FCC and Industry Canada have established implementation criteria for the use of Electronic Labeling. This device’s implementation is wholly consistent with these requirements, per the checklist below: Required FCC/IC regulatory markings included? Yes Information readily accessible to users via menu? Yes Obtainable from the menu with three or fewer steps? Yes Obtainable without any special accessories, access codes, or SIM card having to be in place? Yes User Guide provides instruction on accessing this information (See Exhibit 08)? Yes If not in the User Guide, are these instructions provided on a product-related web site, and are instructions for accessing this site provided in the device packaging? Yes Devices have physical labels at point of marketing/sale (or in the alternative, on the packaging), and at time of importation? Yes Electronic labeling information is programmed into the device by Motorola at the time of manufacture. Yes Electronic labeling information not modifiable by any third party. Yes All the applicable regulatory information required on the packaging or user instructions is provided according to the rules. Yes APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 3 1.4 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. Figure 1.3.1. Representation of FCC Label information. Other regulatory information may also be displayed. The above label representation is applicable to the following versions/variants of the device that is the subject of this application: Model Number 1 1 Depending upon the device version, or market into which it ships, the Model Number shown on the label may vary. All such variants will be electrically identical, consistent with the requirements of FCC Class I Permissive Change rules and guidance (47 CFR 2.1043 and KDB 178919 D01). Please note that this labeling scheme complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. United States of America FCC ID IHDT56UC2

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 1 Exhibit 9: Internal Photographs -- Pursuant to 47 CFR 2.1033(c)(12) and RSP100, Section 5. Photograph 9-1: Front side view of the device’s PC Board, Shields in place. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 2 Photograph 9-2: Back side view of the device’s PC Board. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 3 Photograph 9-3: Front side view of the device’s PC Board, Shields Removed. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 4 Photograph 9-4: Antenna Locations and Spacings. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 5 Photograph 9-5: Antenna Locations and Spacings. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT56UC2 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 6 Photograph 9-6: Antenna Locations and Spacings.

SPORTON INTERNATIONAL INC. TEL : 886-3-327-3456 / FAX : 886-3-328-4978 Issued Date : May 28, 2015 FCC ID : IHDT56UC2 Page 1 of 82 Form version. : 150415 Exhibit 11 Report No. : FA541573A FCC SAR Test Report APPLICANT : Motorola Mobility, LLC EQUIPMENT : Mobile Cellular Phone BRAND NAME : Motorola MODEL NAME : 5137 FCC ID : IHDT56UC2 STANDARD : FCC 47 CFR Part 2 (2.1093) ANSI/IEEE C95.1-1992 IEEE 1528-2003 We, SPORTON INTERNATIONAL INC., would like to declare that the tested sample has been evaluated in accordance with the procedures and had been in compliance with the applicable technical standards. The test results in this report apply exclusively to the tested model / sample. Without written approval of SPORTON INTERNATIONAL INC., the test report shall not be reproduced except in full. SPORTON INTERNATIONAL INC. No.52, Hwa Ya 1st Rd., Hwa Ya Technology Park, Kwei-Shan District, Taoyuan City, Taiwan (R.O.C.) Approved by: Jones Tsai / Manager Reviewed by: Eric Huang / Deputy Manager SPORTON INTERNATIONAL INC. TEL : 886-3-327-3456 / FAX : 886-3-328-4978 Issued Date : May 28, 2015 FCC ID : IHDT56UC2 Page 2 of 82 Form version. : 150415 Exhibit 11 Report No. : FA541573A Table of Contents 1. Statement of Compliance ............................................................................................................................................. 4 2. Administration Data ...................................................................................................................................................... 5 3. Guidance Standard ....................................................................................................................................................... 5 4. Equipment Under Test (EUT) ....................................................................................................................................... 6 4.1 General Information ............................................................................................................................................... 6 4.2 General LTE SAR Test and Reporting Considerations ........................................................................................... 7 5. RF Exposure Limits......................................................................................................................................................10 5.1 Uncontrolled Environment .....................................................................................................................................10 5.2 Controlled Environment .........................................................................................................................................10 6. Specific Absorption Rate (SAR) ..................................................................................................................................11 6.1 Introduction ........................................................................................................................................................... 11 6.2 SAR Definition ....................................................................................................................................................... 11 7. System Description and Setup ...................................................................................................................................12 8. Measurement Procedures ...........................................................................................................................................13 8.1 Spatial Peak SAR Evaluation ................................................................................................................................13 8.2 Power Reference Measurement............................................................................................................................14 8.3 Area Scan .............................................................................................................................................................14 8.4 Zoom Scan ............................................................................................................................................................15 8.5 Volume Scan Procedures ......................................................................................................................................15 8.6 Power Drift Monitoring ...........................................................................................................................................15 9. Test Equipment List .....................................................................................................................................................16 10. System Verification ....................................................................................................................................................17 10.1 Tissue Verification ...............................................................................................................................................17 10.2 System Performance Check Results ...........................................................................…
