APPLICANT: MOTOROLA, INC.FCC ID: IHDT5BB1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: Note: No body worn accessory has been developed for this device. 000893-O DIGITAL CELLULAR TELEPHONE Model 182c CDMA 800 MHz User's Guide 010200-O 1037B75-English.book Page -1 Tuesday, April 24, 2001 11:41 AM 1037B75-English.book Page 0 Tuesday, April 24, 2001 11:41 AM Welcome 1 PRELIMINARY WelcomeThank you for choosing the Motorola Talkabout 182c from a global leader incommunications technology.All Motorola phones are designed and manufactured to meet Motorola's exactingspecifications and world-class quality standards. We are confident that this phone willmeet your own exacting standards.We hope you enjoy your new wireless digital phone! 1037B75-English.book Page 1 Tuesday, April 24, 2001 11:41 AM Welcome 2 PRELIMINARY MOTOROLA, the Stylized M Logo, and all other trademarks indicated as such herein aretrademarks of Motorola, Inc.®Reg.U.S.Pat.&Tm.Off.All other product or service names are the property of their respective owners.© 2001 Motorola, Inc. All rights reserved.Personal Communications Sector1500 Gateway Blvd., Boynton Beach, FL 33426-8292PrintedinUSA05/016881037B75-O 1037B75-English.book Page 2 Tuesday, April 24, 2001 11:41 AM Contents Welcome ............................................1Safety and General Information .......7Getting Started ................................17 Low Battery Indicator .....................18Changing The Battery ....................21Control Buttons ..............................22How to Use the Control Buttons ....23Features .........................................23Shortcut Keys ................................24Indicators .......................................25Power-up Display ...........................27Turning Your Phone On and Off ....27Testing Your Motorola Talkabout 182C Phone ................................29 Making and Ending Calls ...............29 Making a call ..................................29Ending a call ..................................30Redialing Numbers ........................30Receiving Calls ..............................31 Answering a Call ............................ 32Caller ID ......................................... 32Unanswered Call Indicator ............ 33Call Waiting ................................... 33To make a call by using stored numbers ...................................... 34 Pause Dialing ................................ 35Using Pause Dialing ...................... 36Storing Names and Numbers ........ 36Entering Names ............................. 38To send your own number ............. 41Scratchpad .................................... 41Muting the Microphone .................. 42Short Key Menu ............................. 42 Main Menu ....................................... 42 Last Call ......................................... 42Message ........................................ 43Battery ........................................... 43Key Lock ........................................ 44 1037B75-English.book Page 3 Tuesday, April 24, 2001 11:41 AM Mute .............................................. 44Ring Option ................................... 44 Menu Features ................................ 45 Phone Book ................................... 45Phone Book Status ....................... 48Viewing My Number ...................... 48Number Preference ....................... 48Last Calls List ................................ 49Incoming Calls List ........................ 49Unanswered Calls List .................. 50 Timers ............................................. 50 Individual Timer ............................. 51Resettable Timer ........................... 51Cumulative Timer .......................... 52One Minute Audible Timer ............ 52World Clock ................................... 53View Time ..................................... 53 Alarm ............................................... 54 Setting the Alarm ........................... 54Release (Disabling the Alarm): ..... 54 Tone Control ................................... 55 Silent Mode ....................................55Ringer or Vibrator selection ...........55Selecting a Ringer Style ................56Keypad Tones ................................57Transmit (DTMF) Tones ................57Service Tones ................................58Earpiece Volume ...........................58Ringer Volume ...............................59Setup Message Tones ...................59Reminder Tones Setup ..................60 Lock/Security ..................................60 Auto Lock .......................................60Locking The Phone ........................61Unlocking the Phone ......................61Priority Call ....................................61Security Options ............................62Service Level .................................64Master Reset .................................65Master Clear ..................................66 Phone Options ................................66 Change Number ............................66 1037B75-English.book Page 4 Tuesday, April 24, 2001 11:41 AM Contents Call Options ...................................67Display Options ..............................70System Options .............................72 Personal Information Management System (PIMS) ..............................74Schedule Setting ............................74Schedule Searching .......................75 Message ...........................................75 Receiving Messages ......................75Voice Message ..............................78Text Message ................................78Send a Message ............................81Delete Messages ...........................84 Use and Care ..................................86Garantía ...........................................87Computer Program Copyrights .....95Index .................................................96Personal Numbers ........................…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC.FCC ID: IHDT5BB1 EXHIBIT 2A SPECIFICATION COMPLIANCE STATEMENT Engineer-in-Charge Equipment Authorization Branch Federal Communications Commission We hereby certify that this transmit and receive equipment (FCC ID: IHDT5BB1) for Dual-Mode mobile station cellular use has shown, by the tests done in a FCC listed lab ( Certificate NO. 824-01), to be in compliance with the TIA/EIA-95-A Mobile Station-Base Station Compatibility Standards for Dual-Mode Spread Spectrum Systems, March 2001. J. Ramon Chaidez Jose Ramon Chaidez Engineering Manager Personal Communication Sector Motorola Inc. APPLICANT: MOTOROLA, INC.FCC ID: IHDT5BB1 EXHIBIT 2B STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken by a FCC Listed Lab ( Certificate No. 824-01) is duly certified. SIGNATURE: J Ramon Chaidez NAME: Jose Ramon Chaidez DATE: 4/18/01 POSITION: Engineering Manager Personal Communication Sector Motorola Inc.

APPLICANT: MOTOROLAFCC ID: IHDT5BB1 Exhibit 13 April 19, 2001 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization (FCC Form 731-October 1992 with integrated Fee Processing Form, Fee Codes EFT and EBC), application fee in the amount of $640, and Exhibits, for Type Acceptance of a Cellular Transceiver; FCC ID: IHDT5BB1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 12 Operational Description Description: This equipment has the capability to operate in both the conventional Analog Cellular standard and the Digital CDMA standard in the 800 MHz cellular band, as outlined in EIA/TIA IS-95-A "Mobile Station – Base Station Compatibility Standard for Dual-Mode Wideband Spread Spectrum Cellular System”. Technical details for this alternate cellular technology (permitted under the cellular service option provisions in Section 22.901(d) of the Commission's rules) related to Type Acceptance of this equipment, as noted in paragraphs 31 and 32 of the Report and Order in FCC GEN. Docket No. 87- 390, are detailed in Exhibit 12. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ([email protected]), if there are any further questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Cellular Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 EXHIBIT 3 Front View Rear View, with Battery Removed to Show Equipment ID Label

APPLICANT: MOTOROLA, INC.FCC ID : IHDT5BB1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the radio telephone as shown in Exhibit 3. Other information may also be included on this label. FCC ID: IHDT5BB1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 EXHIBIT 9 Front View (Shields Removed) Rear View (Shields Removed)

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 EXHIBIT 10 TRANSCEIVER ADJUSTMENTS/TUNE-UP PROCEDURE There are no user accessible adjustments or tuning in this portable cellular transceiver. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service or repair are done as part of that process as special equipment is required to perform such adjustments.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report: IHDT5BB1 Date of test:03/21/2001-03/26/2001 Laboratory: Motorola Personal Communications Sector Product Safety Laboratory 2001 N. Division Room: AS228 Harvard, Illinois 60033 Test Responsible:Steven Hauswirth Staff Engineer Accreditation:ISO Guide 25 Accredited Lab, A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT5BB1 to which this declaration relates, is in conformity with the appropriate RF exposure standards, recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: ©Motorola This test report shall not be reproduced in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1) Introduction.........................................................................................................................3 2) Description of the Device Under Test.....................................................................................3 Antenna description.............................................................................................................3 Device description...............................................................................................................3 3) Test Results.......................................................................................................................3 4) Test Equipment...................................................................................................................4 4.1 Dosimetric system.........................................................................................................4 4.2 Additional equipment used..............................................................................................5 5) Electrical parameters of the tissue simulating liquid ...............................................................5 6) System Accuracy Verification..............................................................................................5 Reference Notes Appendix 1: SAR distribution comparison for the system accuracy verification................................6 Appendix 2: SAR distribution plots for Phantom Head Adjacent Use..............................................7 Appendix 3: SAR distribution plots for Body Worn Configuration....................................................8 Appendix 4: Photographs of the device under test........................................................................9 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1. Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone FCC ID IHDT5BB1. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with the latest available test guidelines. The SAR values found for the portable cellular phone (FCC ID IHDT5BB1) are below the maximum recommended levels of 1.6 W/kg. Detailed procedures of the test are described in the Motorola Exhibit 11 Reference SAR Test Report. 2. Description of the Device Under Test Antenna description TypeFixed Stub LocationTop Right Side ConfigurationHelix Device description FCC ID NumberIHDT5BB1 Serial number249 Mode(s) of OperationAMPS800CDMA800 Modulation Mode(s)AMPSCDMA Maximum Production Unit Power27.0 dBm24.50 dBm Duty Cycle1:11:1 Transmitting Frequency Rang(s)824-849MHz824-849MHz 3. Test Results The SAR results shown in tables 1 and 2 are maximum SAR values averaged over 1 gram of phantom tissue. Also shown are the measured conducted output powers and the temperature of the test facility during the test. The test sample was operated in a test mode that allows control of the transmitter without the need to place actual phone calls. For the purposes of this test the unit is commanded to test mode and manually set to the proper channel, transmitter power level and transmit mode of operation. The phone was then placed in the SAR measurement system with a fully charged battery. A full data set output of two test conditions with the highest SAR values from the Dasy measurement system is included as appendix 2 and 3. The test conditions included are indicated as bold numbers in the following table. All other test conditions measured lower SAR values than those included. Note that digital mode SAR data was measured only for the test conditions that resulted in the highest analog SAR values. This is because the only difference between analog and digital modes that can impact SAR is the average transmitter power. Since there is no body worn accessory available for this product, SAR body worn compliance is demonstrated keeping the front and back of the phone separated from the flat phantom by one (1) inch as stated in the user manual. APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 4 4 SAR, 1g (W/kg) Left HeadRight Headf (MHz)Description Conducted Output Power (dBm)Ant FixedAnt Fixed Channel 991 26.831.010.835 Channel 384 27.141.471.09 Analog 800MHz Channel 79926.841.411.11 Channel 991 24.62 Channel 398 24.970.87 Digital 800MHz Channel 779 24.94 Table 1: SAR measurement results for the portabl…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report: IHDT5BB1 Date of test: 03/21/2001-03/26/2001 Laboratory: Motorola Personal Communications Sector Product Safety Laboratory 2001 N. Division Room: AS228 Harvard, Illinois 60033 Test Responsible: Steven Hauswirth Staff Engineer Accreditation: ISO Guide 25 Accredited Lab, A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT5BB1 to which this declaration relates, is in conformity with the appropriate RF exposure standards, recommendations and guidelines. It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: ©Motorola This test report shall not be reproduced in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1) Introduction.........................................................................................................................3 2) Description of the Device Under Test.....................................................................................3 Antenna description.............................................................................................................3 Device description...............................................................................................................3 3) Test Results.......................................................................................................................3 4) Test Equipment...................................................................................................................4 4.1 Dosimetric system.........................................................................................................4 4.2 Additional equipment used..............................................................................................5 5) Electrical parameters of the tissue simulating liquid ...............................................................5 6) System Accuracy Verification..............................................................................................5 Reference Notes Appendix 1: SAR distribution comparison for the system accuracy verification................................6 Appendix 2: SAR distribution plots for Phantom Head Adjacent Use..............................................7 Appendix 3: SAR distribution plots for Body Worn Configuration....................................................8 Appendix 4: Photographs of the device under test........................................................................9 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1. Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone FCC ID IHDT5BB1. The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with the latest available test guidelines. The SAR values found for the portable cellular phone (FCC ID IHDT5BB1) are below the maximum recommended levels of 1.6 W/kg. Detailed procedures of the test are described in the Motorola Exhibit 11 Reference SAR Test Report. 2. Description of the Device Under Test Antenna description Type Fixed Stub Location Top Right Side Configuration Helix Device description FCC ID Number IHDT5BB1 Serial number 249 Mode(s) of Operation AMPS800 CDMA800 Modulation Mode(s) AMPS CDMA Maximum Production Unit Power 27.0 dBm 24.50 dBm Duty Cycle 1:1 1:1 Transmitting Frequency Rang(s) 824-849MHz 824-849MHz 3. Test Results The SAR results shown in tables 1 and 2 are maximum SAR values averaged over 1 gram of phantom tissue. Also shown are the measured conducted output powers and the temperature of the test facility during the test. The test sample was operated in a test mode that allows control of the transmitter without the need to place actual phone calls. For the purposes of this test the unit is commanded to test mode and manually set to the proper channel, transmitter power level and transmit mode of operation. The phone was then placed in the SAR measurement system with a fully charged battery. A full data set output of two test conditions with the highest SAR values from the Dasy measurement system is included as appendix 2 and 3. The test conditions included are indicated as bold numbers in the following table. All other test conditions measured lower SAR values than those included. Note that digital mode SAR data was measured only for the test conditions that resulted in the highest analog SAR values. This is because the only difference between analog and digital modes that can impact SAR is the average transmitter power. Since there is no body worn accessory available for this product, SAR body worn compliance is demonstrated keeping the front and back of the phone separated from the flat phantom by one (1) inch as stated in the user manual. APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 4 4 SAR, 1g (W/kg) Left Head Right Head f (MHz) Description Conducted Output Power (dBm) Ant Fixed Ant Fixed Channel 991 26.83 1.01 0.835 Channel 384 27.14 1.47 1.09 Analog 800MHz Channel 799 26.84 1.41 1.11 Channel 991 24.62 Channel 398 24.97 0.87 Digital 800MHz Channel 779 24.94 Table 1: SAR meas…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC.FCC ID : IHDT5BB1 EXHIBIT 6 SUBMITTED MEASURED DATA INDEX RF Power Output Data.......................................................................................6A Audio Frequency Response...............................................................................6B Post Limiter Low Pass Filter Response - Graph................................................6C Signaling Channel Audio Roll-Off Filter Response - Graph...............................6D Modulation Limiting (Compandor On) - Graph...................................................6E1 Modulation Limiting (Compandor Off) - Graph...................................................6E2 Occupied Bandwidth, Audio - Photograph.........................................................6F1 Occupied Bandwidth, Audio and SAT - Graph..................................................6F2 Occupied Bandwidth, Wideband Data - Graph..................................................6F3 Occupied Bandwidth, Signaling Tone and SAT - Graph....................................6F4 Occupied Bandwidth, Digital - Graph.................................................................6F5 Analog Conducted Spurious and Harmonic Emissions - Graph........................6G1 Digital Conducted Spurious and Harmonic - Graph...........................................6G2 Channel 777 CDMA Band Edge........................................................................6G3 Channel 1013 CDMA Band Edge......................................................................6G4 Analog Radiated Spurious and Harmonic Emissions - Graph...........................6H1 Digital Radiated Spurious and Harmonic Emissions - Graph............................6H2 Analog Receiver Radiated Spurious- Graph......................................................6J1 Digital Receiver Radiated Spurious - Graph......................................................6J2 Analog Frequency Change vs. Temperature.....................................................6K1 Digital Frequency Change vs. Temperature,.....................................................6K2 Analog Frequency Change vs. Supply Voltage.................................................6L1 Digital Frequency Change vs. Supply Voltage..................................................6L2 Measurement Techniques.................................................................................6M APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 EXHIBIT 6A RF POWER OUTPUT DATA The input supply to the transmitter was set at 3.6 Volts. The RF power output was measured with the indicated voltage and current applied into the ANT port via 50ohm cable. ANALOG MODE Measured RF output: 27.14 dBm Measured DC voltage: 3.6V Measured DC current: 700mA 800 MHz Digital CDMA In Digital Mode the values measured for RF Output, DC Current and RF Input Power are all average values which reflect a 100% transmit duty cycle in CDMA operation. Measured RF output: 24.97 dBm Measured DC voltage: 3.6V Measured DC current: 600mA EFFECTIVE RADIATED POWER Maximum Effective Radiated Power: Analog Mode 25.9 dBm (0.39 W) Maximum Effective Radiated Power: Digital CDMA Mode 23.8 dBm (0.24 W) APPLICANT: MOTOROLA, INC.FCC ID: IHDT5BB1 EXHIBIT 6B Audio Frequency Response -35 -30 -25 -20 -15 -10 -5 0 5 10 15 100100010000100000 Frequency(Hz) Modulation(dB) Wide Modulation (dB)USLLSL APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 EXHIBIT 6C Post Limiter Low Pass Filter Response Graph APPLICANT: MOTOROLA, INC.FCC ID: IHDT5BB1 EXHIBIT 6D Signaling Channel Audio Roll-Off Filter Response Graph APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 EXHIBIT 6E1 Modulation Limiting (Compander On) Frequency Deviation Characteristic Compander On Amps Mode Channel 384 Power Level 2 0 dB Reference : 1004 Hz , 324mV at Input 8.0KHz Deviation Frequency Deviation Characteristic 0 2 4 6 8 10 12 -50-46-42-38-34-30-26-22-18-14-10 -6-2 26 101418 Audio Level ( dB ) Deviation ( KHz ) 300Hz 1KHz 3KHz APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 EXHIBIT 6E2 Modulation Limiting (Compander Off) Frequency Deviation Characteristic Compander OFF Amps Mode Channel 384 Power Level 2 0 dB Reference : 1004 Hz , 112mV at Input 8.0KHz Deviation Frequency Deviation Characteristic -50-46-42-38-34-30-26-22-18-14-10 -6-2 26 101418 Audio Level ( dB ) Deviation ( KHz ) 300Hz 1KHz 3KHz APPLICANT: MOTOROLA, INC. FCC ID: IHDT5BB1 EXHIBIT 6F1 BANDWIDTH MEASUREMENT DATA FOR TRANSMITTER TYPES F8W DEVIATION OF THE CARRIER WITH 2500 Hz. AUDIO MODULATION HORIZONTAL SCALE = 20 kHz / DIVISION VERTICAL SCALE = 10 dB / DIVISION (REFERENCE LEVEL = 30.5 dBm) RESOLUTION BANDWIDTH =1000 Hz VIDEO BANDWIDTH =1000 Hz AUDIO LEVEL = 16 dB GREATER THAN LEVEL REQUIRED TO PRODUCE + / - 6 kHz POWER LEVEL = 27dBm MEASURED DATA: 1. Instantaneous Deviation Control set for a maximum of +/- 12 kHz 2. Tune and adjust to obtain unmodulated carrier on the spectrum analyzer. Save trace of the unmodulated carrier. 3. Modulate the transmitter with the 2500 Hz. Tone, 16 dB greater than that required to produce +/- 6 kHz modulation. Photograph the sideband display while it is superimposed upon the unmodulated carrier. SPEC LIMITS a. On any frequency removed from the assigned carrier frequency by more than 20 kHz, up to and including 45 kHz, the sideband is at least 26 dB below the carrier. b.On any frequency removed from the assigned carrier frequency by more than 45 kHz, up to the first multiple of the carrier frequency, the sideband is at least 60 dB below the carrier or 63 + 10 log10 (mean output power in Watts) dB, whichever is the smaller attenuation. APPLICANT: MOTOROLA, INCFCC ID : IHDT5BB1 EXHIBIT 6F2 BANDWIDTH MEASUREMENT DATA FOR TRANSMITTER TYPES F8W DEVIATION OF THE CARRIER WITH 2500 Hz AUDIO MODULATION AND SUPERVISORY AUDIO TONE HORIZONTAL SCALE = 20 kHz / DIVISION VERTICAL SCALE = 10 dB / DIVISION (REFERENCE LEVEL = 30.5 dBm) RESOLUTION BANDWIDTH = 1000 Hz VIDEO BANDWIDTH = 1000 Hz POWER LEVEL = 27dBm MEASURED DATA: 1. Instantaneous Deviation Co…
