IHDT5EE1Portable Cellular CDMA Transceiver

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: User Manual C-212 START HERE > 2 3 Welcome Your phone may ot appear exactly as the phone image above. Note that all key locations, sequences, and functions remain the same with any of the covers. Left Soft Key Performs funcions identified by left dis- play prompt. Menu Key Open a menu when is in the display. Power/End Key Press & hold to turn phone on & off. Press & release to end phone calls, exit menu system. Earpiece Antenn a Right Soft Key Performs functions identified by right display prompt. Navigation Keys Scroll through lists, set volume. Send/Answer Key Make and answer calls; press in idle to list recently dialed calls. Microphone . Power Connector Insert charger. 4 Motorola, Inc., Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada) www.motorola.com (United States) www.motorola.ca (Canada) MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. Acrobat and Acrobat Reader are registered trademarks of Adobe Systems Incorporated. © Motorola, Inc. 2003 Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. Actual part numbers to be provided. Manual number: 6809457A28-O Cover number: 8988485L61-O 5 Contents Safety and General Information ............................................... 12 Getting Started........................................................................... 18 What’s in the Box? ................................................................ 18 About This Guide................................................................... 18 Optional Features.................................................................. 19 Optional Accessories ............................................................ 19 Installing the Battery.............................................................. 19 Charging the Battery ............................................................. 20 Charging time ........................................................................ 21 Battery Use............................................................................ 22 Changing Your SIM Card ...................................................... 24 Resetting Your Phone ........................................................... 26 Turning Your Phone On ............................................................ 26 Adjusting the Volume ............................................................ 27 Making a Call......................................................................... 28 Answering a Call ................................................................... 29 Dialing Menu ......................................................................... 29 Active Call Menu ................................................................... 29 1. Mute ........................................................................... 29 2. My Phone Number ..................................................... 30 3. Outgoing Calls ........................................................... 30 4. Incoming Calls ........................................................... 30 5. New Message ............................................................ 31 6. Voice Privacy ............................................................. 31 7. Tone Lenght ............................................................... 31 Learning to Use Your Phone .................................................... 32 Using the Display ................................................................. 32 Using the 4-Way Navigation Keys ........................................ 35 Using Menus ........................................................................ 36 6 Selecting a Feature Option ................................................... 37 Entering Text ........................................................................ 37 Choosing a Text Entry Method ............................................. 39 Using the TAP Method ......................................................... 40 Using the iTAP Method ........................................................ 42 Using Symbol Method .......................................................... 45 Symbol Chart ........................................................................ 45 Browse (Canned message or Quick Title) ............................ 46 Quick Title ............................................................................ 47 Recent Calls Outgoing Calls ...................................................................... 48 Incoming Calls ...................................................................... 50 Missed Calls ......................................................................... 51 Erase History ........................................................................ 51 1. Out…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 Exhibit 2A SPECIFICATION COMPLIANCE STATEMENT Engineer-in-Charge Equipment Authorization Branch Federal Communications Commission We hereby certify that this transmit and receive equipment (FCC ID IHDT5EE1) is capable of compliance with the TIA/EIA-98-D Mobile Station-Base Station Compatibility Standards for Single-Mode Spread Spectrum Systems. GILSON DE LIMA RAEDER Engineering Manager Cellular Subscriber Equipment December 15, 2004 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 Exhibit 2B STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duly certified. GILSON DE LIMA RAEDER Engineering Manager Cellular Subscriber Equipment December 15, 2004 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 Exhibit 2C 911 Call Processing Method Compliance Statement Method Used Pursuant to 47 CFR Sec. 22.921, this Motorola CDMA phone at the time of commercial distribution will use a call completion method for 911 calls that is approved or endorsed by the FCC. At this time Motorola intends that this phone will incorporate either the Automatic A/B Intelligent Retry method or the Automatic A/B-Intelligent Retry, Version 2 method for providing 911 emergency calling support.

APPLICANT: MOTOROLA FCC ID: IHDT5EE1 December 14, 2004 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT5EE1. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the Digital CDMA standard in the 800 MHz band. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Personal Communications Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC FCC ID: IHDT5EE1 Front View EXHIBIT 3 1 APPLICANT: MOTOROLA, INC FCC ID: IHDT5EE1 Back View (Battery included) EXHIBIT 3 2 APPLICANT: MOTOROLA, INC FCC ID: IHDT5EE1 Back View (Battery removed) Equipment ID Label Location EXHIBIT 3 3 APPLICANT: MOTOROLA, INC FCC ID: IHDT5EE1 EXHIBIT 3 4

APPLICANT: MOTOROLA INC. FCC ID: IHDT5EE1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT5EE1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 LCD & PCB Front View EXHIBIT 9 1 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 PCB Front View EXHIBIT 9 2 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 PCB Rear View (Shield Can removed) EXHIBIT 9 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 PCB Rear View (Shield Can included) EXHIBIT 9 4

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 E E x x h h i i b b i i t t 1 1 1 1 Exhibit 11: SAR Test Report IHDT5EE1 Date of test: Date of Report: 23 & 24 November, 2004 10 December, 2004 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Steven Hauswirth Principal Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE P1528 (DRAFT) FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT5EE1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2004 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION...................................................................................................................................... 3 2. DESCRIPTION OF THE DEVICE UNDER TEST.................................................................................... 3 2.1 Antenna description ..............................................................................................................................................3 2.2 Device description..................................................................................................................................................3 3. TEST EQUIPMENT USED........................................................................................................................ 3 3.1 Dosimetric System .................................................................................................................................................3 3.2 Additional Equipment...........................................................................................................................................4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID............................................. 4 5. SYSTEM ACCURACY VERIFICATION.................................................................................................. 4 6. TEST RESULTS........................................................................................................................................ 5 6.1 Head Adjacent Test Results..................................................................................................................................5 6.2 Body Worn Test Results .......................................................................................................................................7 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION...... 8 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR PHANTOM HEAD ADJACENT USE......................... 9 APPENDIX 3: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION........................... 10 APPENDIX 4: PROBE CALIBRATION CERTIFICATE.......................................................................... 11 APPENDIX 5: DIPOLE CHARACTERIZATION CERTIFICATE............................................................ 12 APPENDIX 6: MEASUREMENT UNCERTAINTY BUDGET................................................................... 13 APPENDIX 7: PHOTOGRAPHS OF DEVICE UNDER TEST ................................................................... 16 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1 Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT5EE1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2 Description of the Device Under Test 2.1 Antenna description Type External Location Upper Right Corner Length 25 mm Dimensions Width 8 mm Configuration Helix 2.2 Device description FCC ID Number IHDT5EE1 Serial number 32551E24 Mode(s) of Operation CDMA800 Modulation Mode(s) CDMA Maximum Output Power Setting 25.00dBm Duty Cycle 1:1 Transmitting Frequency Rang(s) 824-849MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled 3 Test Equipment Used 3.1 Dosimetric System The Motorola Personal Communications Sector Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy3™ v3.1d) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzer…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 Exhibit 11 Page 1 of 2 December 28, 2004 Supplement to SAR Test Report for Motorola portable cellular phone (FCC ID IHDT5EE1) Prepared by: Albert Patapack Motorola Personal Communications Sector Product Safety Laboratory Libertyville, Illinois APPLICANT: MOTOROLA, INC. FCC ID: IHDT5EE1 Exhibit 11 Page 2 of 2 Summary of FCC request for additional information There was a request for additional information regarding Motorola’s SAR Test Report for Motorola portable cellular phone (FCC ID IHDT5EE1). The requested information is addressed below in the same numbering sequence received. 3. Several items in the SAR report (p.3) are listed as being past their cal due date. Please address. Response: There were typos in the calibration dates of the dosimetric system equipment listed in the table on p.3 of the SAR report. Here is the corrected table. Description Serial Number Cal Due Date DASY3 DAE V1 SN385 22-Apr-05 E-Field Probe ET3DV6 SN1501 27-Apr-05 Dipole Validation Kit, D900V2 SN094 2-Apr-05 S.A.M. Phantom used for 800MHz TP-1168 4. In the SAR data table for touch position, the power drift was not used to calculate the extrapolated SAR levels. While the FCC does not require that this be done, it has been normal Motorola practice in the past (and was done for the tilt and body-worn positions). This would potentially affect the maximum SAR level, as well as the level listed in the User's Manual. Please address. Response: Five of the six SAR data entries in the table for touch position have positive drift values. A positive drift value would actually result in a lower extrapolated SAR value so the reported drift values are not used for calculating extrapolated SAR values. For the one SAR data entry that does have a negative drift value, the drift is so small as to not appreciably affect the SAR, to two significant figures, thus resulting in the measured and extrapolated SAR values being the same. The extrapolated SAR values, as stated in the table for the touch position, are correct.

APPLICANT: MOTOROLA INC FCC ID: IHDT5EE1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 15413-1 Report Date – December 17, 2004 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature Name: _Mark Sidlow Title: Senior Electrical Engineer Date: December 17, 2004_ This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1846-01 EXHIBIT 6 APPLICANT: MOTOROLA INC FCC ID: IHDT5EE1 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configurations 5 Measuring Equipment and Calibration Information 5 Measurement Procedures and Data RF Power Output 6 Radiated Power (ERP) 7 Occupied Bandwidth 8 CDMA 800 Reference Level Plot 9 CDMA 800 Occupied Bandwidth Plot 10 CDMA 800 Ch128 Lower Band Edge 10 CDMA 800 Ch251 Upper Band Edge 11 Spurious Emissions at Antenna Terminals 12 CDMA 800 Tabular and Graphical Data 13 Field Strength of Spurious Emissions 14 CDMA 800 Tabular and Graphical Data 15 Frequency Stability 16 CDMA 800 Tabular and Graphical Data 17 Field Strength of Spurious Emissions from Unintentional Radiators 18 CDMA 800 Tabular and Graphical Data 19 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 20 Figure A.2 – Substitution Measurement 20 Test Report Number: 15413-1 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT5EE1 Test Report Details Tests Performed By: Motorola Personal Communications Sector Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (561) 739-2179 Fax (561) 739-2131 Motorola PCS FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908 Tests Requested By: Motorola Inc. Personal Communications Sector 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: CDMA 800 Model Number: C212 Version: SJWF0257AA Serial Numbers: 32551E2C, 32551E2D, 32551E2E, 32551E2F Testing Complete Date: December 16, 2004 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators X Part 22 Subpart H - Public Mobile Services X Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 137-A, TIA EIA 98-C, ANSI 63.4 2001, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-133 (PCS) Test Report Number: 15413-1 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT5EE1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) PASS 3 Modulation Characteristics NA 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass 8 Field Strength of Spurious Emissions Pass from Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) 10.86 dBm 3 Modulation Characteristics NA 4 Occupied Bandwidth See Plots 5 Spurious Emissions at Antenna Terminal 19.6 dBm 6 Field Strength of Spurious Emissions 8.1 dBm 7 Frequency Stability 3 Hz 8 Field Strength of Spurious Emissions 3.1 dBuV/m from Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Test Report Number: 15413-1 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT5EE1 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Measuring Equipment and Calibration Information ManufacturerEquipment TypeModel No.Serial NumberCal. Due Date Rohde & SchwarzReceiverESI26838786/0105/17/2005 Hewlett-PackardEMC Analyzer8593EM3536A0011810/2/2005 Hewlett-PackardEMC Analyzer7405US3944019111/13/2005 MiteqPreamplifier 0.1-26.5GHzNSP2650-NF-S9663501/8/2005 ETSDRG Horn Antenna3115622210/4/2005 A.H. Systems Inc.DRG Horn AntennaSAS-2--/57136512/17/2004 ETSLog-Periodic Antenna314811883/5/2005 ETSBiconical Antenna3110B337011/14/2005 AttenuatorWeinschelAS-6667510/14/2005 AttenuatorWeinschelAS-6667711/4/2005 Rohde & SchwarzMobile Test SetCMD 80DE29008N/A Hewlett-PackardSignal Generator83623B3844A011956/20/2005 ThermotronEnvironmental ChamberS-4315801/5/2005 Giga-TronicsPower Meter8651A86505614/8/2005 Hewlett-PackardPre-Amplifier8447F2805A034195/19/2005 All equipment is on a one-year calibration cycle. Test Report Number: 15413-1 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT5EE1 Measurement Procedures and Data RF POWER OUTPUT Measurement Procedure The RF output port of the equipment under test is directly coupled to the input of a HPE4406A Vector Signal Analyzer through a 10dB passive attenuator, adaptor (if needed), and specialized RF connector. The peak power output is measured for all channels. CFR Part 2.1046 Measurement Results CDMA 800 Frequency (MHz) Power (dBm) 824.70 24.98 836.52 25.10 848.31 25.16 Test Report Number: …

Text truncated - open the document above for the full version.
