IHDT5FM1Portable Celluar CDMA Tranceiver

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5FM1 INSTRUCTION MANUAL An English version preliminary draft copy of the Users Manual follows: EXHIBIT 8 DR AFT START HERE > C305 CDMA DR AFT DR AFT 1 Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola C305 CDMA wireless phone. Status Light See incoming call & service status. Vo l u m e B u t t o n s Vo i c e Key Record voice records, contacts, & shortcut names. Microphone Accessory Connector Port Send Key Send & answer calls, view recent dialed calls list. Right Soft Key Perform functions identified by right display prompt. Menu Key Open main menu. Left Soft Key Perform functions identified by left display prompt. Power Key/End Key Turn phone on/off, end phone calls, exit menus. 4-Way Navigation Key Scroll through menus & lists, set feature values. OK Key Open or select the highlighted item. Smart Key DR AFT 2 Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 www.hellomoto.com MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. © Motorola, Inc. 2005. The information contained in Motorola's user's guides is believed to be correct at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice. The contents of Motorola’s user's guides are provided “as is.” Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability, or contents of this guide. Manual number:6809494A17-O DR AFT 3 Contents Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 What’s in the Box? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Battery Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Charging the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Turning On Your Phone. . . . . . . . . . . . . . . . . . . . . . . . . . 11 Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Changing the Call Alert. . . . . . . . . . . . . . . . . . . . . . . . . . 13 Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . . 14 Highlight Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Sending a Multimedia Message . . . . . . . . . . . . . . . . . . . 15 Receiving a New Multimedia Message . . . . . . . . . . . . . . 18 Learning to Use Your Phone. . . . . . . . . . . . . . . . . . . . . . 20 Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Using Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Locking and Unlocking Your Phone . . . . . . . . . . . . . . . . 34 Changing a Code or Password . . . . . . . . . . . . . . . . . . . . 36 If You Forget a Code or Password . . . . . . . . . . . . . . . . . 36 Setting Up Your Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Storing Your Name and Phone Number . . . . . . . . . . . . . 38 Defining the Time and Date Format . . . . . . . . . . . . . . . . 38 Setting an Alert Style . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Turning the Flip Tone On and Off . . . . . . . . . . . . . . . . . . 40 Setting Answer Options . . . . . . . . . . . . . . . . . . . . . . . . . 40 DR AFT 4 Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . 40 Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . 41 Setting Display Color. . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . 43 Hiding or Showing Location Information . . . . . . . . . . . . 43 Calling Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . 45 Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 Using Automatic Redial . . . . . . . . . . . . . . . . . . . . . . . . . 45 Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46 Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . 47 Turning Off a Call Alert . . . . . . . . . . . . . . . . . . . . . . . . . 47 Calling an Emergency Number . . . . . . . . . . . . . . . . . . . 47 Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . 48 Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . 50 Using the Notepad . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 Attaching a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Calling with Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . . 51 Calling with 1-Touch Dial . . . . . . . . . . . . . . . . . . . . . . . . 52 Using Voicemail. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52 Using Your Phone as a Speakerphone . . . . . . . . . . . . . 54 Muting the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54 Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 Phone Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 Calling Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Message Features . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC. FCC ID: IHDT5FM1 SPECIFICATION COMPLIANCE STATEMENT We hereby certify that this transmit and receive equipment (FCC ID: IHDT5FM1) for single band mobile station cellular use is capable of compliance with the IS-2000 Mobile Station-Base Station Compatibility Standards. Yoseb Heo Engineering Section Manager Cellular Subscriber Equipment Jonghwa Lee Engineering Manager Cellular Subscriber Equipment EXHIBIT 2A APPLICANT: MOTOROLA INC. FCC ID: IHDT5FM1 STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duly certified. SIGNATURE: ( ) Yoseb Heo NAME: Yoseb Heo DATE: 5/16/2005 POSITION: Engineering Section Manager I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct. SIGNATURE: ( ) Jonghwa Lee NAME: Jonghwa Lee DATE: 5/16/2005 POSITION: Engineering Manager EXHIBIT 2B

APPLICANT: MOTOROLA FCC ID: IHDT5FM1 May 20, 2005 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT5FM1. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment has the capability to operate in the Digital CDMA standard in the 800 MHz band. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Personal Communications Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

Date: June 17, 2005 Subject: Request for additional information regarding FCC ID: IHDT5FM1 (Portable Cellular CDMA Transceiver) Reference: Application Received: 5/20/2005 Correspondence Reference Number: 150520A.IHD Confirmation Number: 1505200258 Date of Original Email: 06/16/2005 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois Question: The block diagram that was submitted with the application has an error on the second page, and will not display. Please submit a new block diagram. Response: The block diagram was re-saved for compatibility with an earlier version of Adobe Acrobat (PDF version 5) and resubmitted. 1

August 11, 2005 Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 In re: Motorola Inc FCC ID: IHDT5FM1 731 Confirmation No.: TC825443 Correspondence Reference No.: 21681 Request for Tech. Info.: 07/15/05 Extension of Time Request Gentlemen: Transmitted herewith, on behalf of Motorola Inc is a request for a 30-day extension of time in regards to the FCC OET questions for the Motorola application (FCC ID: IHDT5FM1). Motorola would like more time to respond to the CDMA 2000 inquiries. Should you have any questions or comments concerning the above, please contact the undersigned. cc: Motorola Inc

September 8, 2005 Federal Communications Commission Equipment Approval Services 7435 Oakland Mills Road Columbia, MD 21046 Attn: Mr. Tim Harrington SUBJECT: MOTOROLA Inc. FCC ID: IHDT5FM1 731 Confirmation No.: TC825443 Correspondence Reference No.: 22636 Request for Tech. Info.: 08/25/05 Dear Tim: Transmitted herewith, on behalf of MOTOROLA Inc. is an amendment provided in response to the request for technical information dated August 25, 2005. 1. The response to the requested additional information for the above referenced FCC ID has been uploaded under Supplemental SAR Response per CRN22636. We trust this information is sufficient to resolve FCC questions in this application. If you have any further questions, please do not hesitate to contact us. cc: MOTOROLA Inc.

EXHIBIT 3 Rear View with Battery Cover Removed Showing ID Label Rear View Front View Flip Open d Front View APPLICANT: MOTOROLAFCC ID: IHDT5FM1

APPLICANT: MOTOROLA INC. FCC ID: IHDT5FM1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID : IHDT5FM1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC.FCC ID: IHDT5FM1 EXHIBIT 9 Front View Rear View Rear Viewwithout shields

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5FM1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report IHDT5FM1 Date of test: Date of Report: 5/9/2005-5/10/2005 5/18/2005 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Paul Ma RF Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE 1528, IEC 62209-1 FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT5FM1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2005 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT5FM1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION ...................................................................................................................................................3 2. DESCRIPTION OF THE DEVICE UNDER TEST.............................................................................................3 2.1 Antenna description ..............................................................................................................................................3 2.2 Device description..................................................................................................................................................3 3. TEST EQUIPMENT USED....................................................................................................................................3 3.1 Dosimetric System .................................................................................................................................................3 3.2 Additional Equipment...........................................................................................................................................4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID ..................................................4 5. SYSTEM ACCURACY VERIFICATION............................................................................................................4 6. TEST RESULTS......................................................................................................................................................5 6.1 Head Adjacent Test Results..................................................................................................................................6 6.2 Body Worn Test Results .......................................................................................................................................7 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION .......9 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR PHANTOM HEAD ADJACENT USE ..........................10 APPENDIX 3: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION ..............................11 APPENDIX 4: PROBE CALIBRATION CERTIFICATE ..................................................................................12 APPENDIX 5: MEASUREMENT UNCERTAINTY BUDGET..........................................................................13 APPENDIX 6: PHOTOGRAPHS OF DEVICE UNDER TEST...........................................................................16 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5FM1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1 Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT5FM1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2 Description of the Device Under Test 2.1 Antenna description Type Stubby Location Upper Right Corner Length 21mm Dimensions Width 8mm Configuration Helix 2.2 Device description FCC ID Number IHDT5FM1 Serial number 3DE0E098 Serial number 2488215B Mode(s) of Operation 800 CDMA Modulation Mode(s) CDMA Maximum Output Power Setting 25.00dBm Duty Cycle 1:1 Transmitting Frequency Rang(s) 824.70-848.31 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled 3 Test Equipment Used 3.1 Dosimetric System The Motorola Personal Communications Sector Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy4™ v4.4) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. All …

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT5FM1 August 15, 2005 Supplement to SAR Test Report for Motorola portable cellular phone (FCC ID IHDT5FM1) Prepared by: Steven Hauswirth Motorola Personal Communications Sector Product Safety Laboratory Libertyville, Illinois Exhibit 11 Page 1 of 2 APPLICANT: MOTOROLA, INC. FCC ID: IHDT5FM1 Summary of FCC request for additional information There was a request for additional information regarding Motorola’s SAR Test Report for Motorola portable cellular phone (FCC ID IHDT5FM1). The requested information is addressed below in the same numbering sequence received. 1 . What is the CDMA MS Protocol Revision number. RESPONSE: Protocol revision 6 (complaint to IS-2000 Rev 0). 2 . Please address the applicability of test codes to simulate the required test conditions, as defined in 3GPP2, TIA, and other standards. RESPONSE: All phones are tested using a base station simulator, not in test mode as stated in section 6 Test Results in the SAR report. Future reports will have this section edited to properly reflect the configuration of the phone during testing. 3 . Please specify the base station simulator and test device configuration info and procedures used to establish maximum output in all applicable modes, including code domain channels, power & relative gain levels. RESPONSE: To test voice calls on the DUT, the test equipment was configured to use “all up bits” for RC1 / SO2 on J-STD-008 for CDMA 1900MHz and TSB-74 for CDMA 800MHz on the Agilent E8285A CDMA Mobile Station test set. 4. Please identify the CDMA Radio Configurations, Service Options, multiplex options, voice/data, code channel combinations and options used for the SAR tests. RESPONSE: Please see answer to inquiry #5 below. 5. Because of the different RC's, SO's, data rates, channel combinations and modulations, the filing should include justification for the selection of applicable configurations used to establish and maintain maximum output in order to demonstrate SAR compliance for other configurations that were not tested. Please provide the justification for the specific combination(s) used during the SAR tests. RESPONSE: Motorola IS2000 CDMA cellular phones does not use different data rates or concurrent channels (supplemental channels) while in the voice mode, thus testing voice modes using RC1 is applicable. Motorola IS2000 CDMA products do use supplemental channels and different data rates for data mode. The output power of the DUT is controlled by a power control loop within the DUT. This power control loop measures the total RF power supplied into the antenna match network for emission. This output power measurement will include the power from different data rates and concurrent channels. The measured power level is controlled and limited to the maximum output power setting for the phone. Motorola performs SAR tests of IS2000 CDMA phones at this maximum power level using RC1 / SO2, thus the output power under this test setup is equivalent to the maximum output power for any data rate and/or concurrent channel capability of the DUT. The Motorola IS2000 CDMA cellular phones were measured in voice calls only. Exhibit 11 Page 2 of 2

APPLICANT: MOTOROLA INC FCC ID: IHDT5FM1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 16290-1 Report Date – June 10, 2005 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature: Name: _Michael Hill Title: Senior Staff Electrical Engineer Date: June 10, 2005 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1846-01 EXHIBIT 6 APPLICANT: MOTOROLA INC FCC ID: IHDT5FM1 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configurations 5 Measuring Equipment and Calibration Information 5 Measurement Procedures and Data RF Power Output 6 Radiated Power (ERP) 7 Occupied Bandwidth 9 CDMA 800 Reference Plot 9 CDMA 800 Occupied Bandwidth Plot 10 CDMA 800 Lower Band Edge 11 CDMA 800 Upper Band Edge 12 Spurious Emissions at Antenna Terminals 13 CDMA 800 Tabular and Graphical Data 14 Field Strength of Spurious Emissions 15 CDMA 800 Tabular and Graphical Data 16 Frequency Stability 17 CDMA 800 Tabular and Graphical Data 18 Field Strength of Spurious Emissions from Unintentional Radiators 19 CDMA 800 Tabular and Graphical Data 20 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 21 Figure A.2 – Substitution Measurement 21 Test Report Number: 16290-1 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT5FM1 Test Report Details Tests Performed By: Motorola Personal Communications Sector Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 Motorola PCS FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908 Tests Requested By: Motorola Inc. Personal Communications Sector 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: CDMA 800 Model Number: E305 Version: SJF0273AA Serial Numbers: 242820FC, 2488215F, 2488213B, 2488214B Testing Complete Date: June 10, 2005 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators X Part 22 Subpart H - Public Mobile Services Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 137-A, TIA EIA 98-C, ANSI 63.4 2001, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-133 (PCS) Test Report Number: 16290-1 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT5FM1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) Pass 3 Modulation Characteristics NA 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass 8 Field Strength of Spurious Emissions Pass from Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) 2.81 3 Modulation Characteristics NA 4 Occupied Bandwidth See Plots 5 Spurious Emissions at Antenna Terminal 7.88 dB 6 Field Strength of Spurious Emissions 18.4 dB 7 Frequency Stability 22 Hz 8 Field Strength of Spurious Emissions Below noise floor from Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Test Report Number: 16290-1 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT5FM1 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Measuring Equipment and Calibration Information ManufacturerEquipment TypeModel No.Serial NumberCal. Due Date Rohde & SchwarzReceiverESI26838786/0102/7/2006 Hewlett-PackardEMC Analyzer7405US394401911/27/2006 MiteqPreamplifier 0.1-26.5GHzNSP2650-NF-S966350N/A ETSDRG Horn Antenna311562222/9/2006 A.H. Systems Inc.DRG Horn AntennaSAS-2--/5713655/25/2006 ETSLog-Periodic Antenna314811887/15/2005 ETSBiconical Antenna3110B337011/14/2005 AttenuatorWeinschelAS-6667510/14/2005 AttenuatorWeinschelAS-6667711/4/2005 Hewlett-PackardSignal Generator83623B3844A011956/20/2006 ThermotronEnvironmental ChamberS-4315801/17/2006 AgilentPower MeterEE4418BGB4020638812/5/2005 AgilentPower SensorE4412BUS3848632112/5/2005 Hewlett-PackardPre-Amplifier8447F2805A034193/24/2006 All equipment is on a one-year calibration cycle. Test Report Number: 16290-1 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT5FM1 Measurement Procedures and Data RF POWER OUTPUT Measurement Procedure The RF output port of the equipment under test is directly coupled to the input of a HPE4406A Vector Signal Analyzer through a 10dB passive attenuator, adaptor (if needed), and specialized RF connector. The peak power output is measured for all channels. CFR47 Part 2.1046 Measurement Results CDMA 800 Frequency (MHz) Power (dBm) 824.7 25.00 836.52 25.00 848.31 25.20 Test Report Number: 16290-1 EXHIBIT 6 6 APPLICANT: MOTOROLA INC FCC ID: IHDT5FM1 RADIATED (ERP) Measurem…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT5FM1 Appendix A – Radiated Emissions Test Setup Photos A.1 Radiated Emissions Measurement A.2 Substitution Measurement End of Test Report Test Report Number: 16290-1 EXHIBIT 6 21
