APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DF1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: 1 D R A FT Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola C210 wireless phone. Headset Jack Insert headset accessory for hands-free use. Send Key Send and answer calls, view recent calls list. STO Key Store numbers & names, select menu item. Menu Key CLR Key Power Key Microphone RF Connector Port Scroll Key Move through menus and lists, adjust earpiece and keypad volume Antenna Power Connector Port 2 D R A F T Personal Communications Sector 600 North U.S. Highway 45 Libertyville, Illinois 60048 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada) www.motorola.com (United States) www.motorola.ca (Canada) MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. All other product or service names are the property of their respective owners. © 2003 Motorola, Inc. All rights reserved. Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. Manual number: 6809459A32-O Cover number:8988485L51-O 3 D R A FT Menu Map Main Menu • Message •Text msg •Voice msg • Page msg • Phonebook • Find name • Find location • Find group • Memory Status • Viewing my number • Call Log • Missed •Received • Dialed • Call timer • Tone Control • Silent Mode • Ring or vibrate • Ring style • Key tone • Service tones • Earpiece volume • Ringer volume • Message tone • Reminder • DTMF tones* •Settings •Call •Display • Security • System • Voice privacy •PIMS •Alarm Clock • To-Do List *Not available on all phone models. Note: This is the standard phone menu layout. You or your service provider may have changes some feature names. Not all features may be available for all users. 4 D R A F T 5 D R A FT Contents Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Safety and General Information. . . . . . . . . . . . . . . . . . . . 8 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 What’s in the Box?. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Turning Your Phone On and Off . . . . . . . . . . . . . . . . . . 18 Adjusting Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . 20 Learning to Use Your Phone . . . . . . . . . . . . . . . . . . . . . 21 Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 How to Enter Text on Your Phone . . . . . . . . . . . . . . . . . 24 Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 25 Changing Your Phone’s Codes . . . . . . . . . . . . . . . . . . . 26 If You Forget a Code . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Locking and Unlocking the Keypad . . . . . . . . . . . . . . . . 28 Setting Up Your Phone. . . . . . . . . . . . . . . . . . . . . . . . . . 29 Managing Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Setting Answer Options . . . . . . . . . . . . . . . . . . . . . . . . . 30 Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . 32 6 D R A F T Calling Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 Using Automatic Redial. . . . . . . . . . . . . . . . . . . . . . . . . 33 Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Canceling an Incoming Call . . . . . . . . . . . . . . . . . . . . . 34 Calling an Emergency Number . . . . . . . . . . . . . . . . . . . 34 Viewing Recent Calls . . . . . . . . . . . . . . . . . . . . . . . . . . 35 Returning an Unanswered Call . . . . . . . . . . . . . . . . . . . 38 Using Pause Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 Calling With Speed Dial . . . . . . . . . . . . . . . . . . . . . . . . 40 Calling With 1-Touch Dial . . . . . . . . . . . . . . . . . . . . . . . 41 Using Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41 Muting the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Using Call Waiting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43 Forwa…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC FCC ID: IHDT6DF1 SPECIFICATION COMPLIANCE STATEMENT Engineer-in-Charge Equipment Authorization Branch Federal Communications Commission We hereby certify that this transmit and receive equipment (FCC ID: IHDT6DF1) for Single-Mode mobile station US PCS use id capable of compliance with the TIA/EIA-98-D Mobile Station-Base Station Compatibility Standards for Single-Mode Spread Spectrum Systems, July 2003. (Signed ) Gilson de Lima Raeder Engineering Section Manager Cellular Subscriber Equipment Exhibit 2

Date: October 2, 2003 Subject: Request for additional information (FCC ID: IHDT6DF1) Reference: Correspondence Reference Number: 9444 Confirmation Number: TC658299 Date of Original Email: 9/22/2003 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois The FCC question and corresponding response from Motorola follows: New radiated spurious data using the Substitution method. Please note that the attenuation requirement for spurious emissions is 43 + 10Log(P). This is referenced to the desired signal yielding dBc. The attenuation specification is not XX uV/M, or derived from absolute value of the field strength. The dBc is determined from a substitution method such as described in the ANSI/TIA/EIA-603-1992 document. What is needed is a determination of the actual power levels necessary to reproduce these field strength levels. Those power levels (from a signal generator source and a dipole antenna replacing the EUT) are then compared to the power output of the transmitter to determine dBc. That is the basis of the "substitution method". Also, note that pursuant to Section 2.1057(c), emissions more than 20 dB below the specification do not need to be reported. Response: Motorola confirms submission of radiated spurious data, measured in accordance with the substitution method described in ANSI/TIA/EIA-603-1992.

Date: October 2, 2003 Subject: Request for additional information (FCC ID: IHDT6DF1) Reference: Correspondence Reference Number: 9444 Confirmation Number: TC658299 Date of Original Email: 9/22/2003 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois The FCC question and corresponding response from Motorola follows: New radiated spurious data using the Substitution method. Please note that the attenuation requirement for spurious emissions is 43 + 10Log(P). This is referenced to the desired signal yielding dBc. The attenuation specification is not XX uV/M, or derived from absolute value of the field strength. The dBc is determined from a substitution method such as described in the ANSI/TIA/EIA-603-1992 document. What is needed is a determination of the actual power levels necessary to reproduce these field strength levels. Those power levels (from a signal generator source and a dipole antenna replacing the EUT) are then compared to the power output of the transmitter to determine dBc. That is the basis of the "substitution method". Also, note that pursuant to Section 2.1057(c), emissions more than 20 dB below the specification do not need to be reported. Response: Motorola confirms submission of radiated spurious data, measured in accordance with the substitution method described in ANSI/TIA/EIA-603-1992.

APPLICANT: MOTOROLA FCC ID: IHDT6DF1 July 28, 2003 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT6DF1. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 12 Operational Description Description: This equipment has the capability to operate using the Digital CDMA standards in the 1900 MHz PCS band. Contact Information: Please contact me by telephone at (847) 523-6167,or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Cellular Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT : MOT O ROLA, INC. FCC ID: IHDT6 D F1 Equipme n t ID Label Location j F r o n t V i e w R e a r V i e w R e ar V i ew (Battery Re moved) Showing ID Label EXHIBIT 3

APPLICANT: MOTOROLA INC. FCC ID: IHDT6DF1 EXHIBIT 1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. IHDT6DF1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DF1 Exhibit 9A Front ViewRear View APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DF1 Exhibit 9B Front Housing (Internal View) Rear Housing Internal View

APPLICANT: MOTOROLA, INC FCC ID: IHDT6DF1 TRANSCEIVER ADJUSTMENTS/TUNE-UP PROCEDURE There are no user adjustments or tuning in this mobile cellular transceiver. EXHIBIT 10 1 APPLICANT: MOTOROLA, INC FCC ID: IHDT6DF1 Parts List REFERENCE SYMBOL PART NUMBER DESCRIPTION J104 6201019300 BATTERY CONNECTOR J103 3721100067 DC JACK CONNECTOR J401 3721100012 ANTENNA CONNECTOR J301 3550700019 BUZZER J101 3721100068 CARKIT Y201 3530200019 SLEEP CRYSTAL U201 3200100230 MSM5010FBGA U601 3200100400 RFT3100-3 U504 3200100102 IFR3000 D159,D170 3411100027 VARISTOR D176,D340 3411100022 VARISTOR D173 3411100036 VARISTOR U102 3200100237 INNER CHARGER U202 3200100425 FLASH MEMORY U203 3200100427 SRAM F401 3520700148 DUPLEXER U701 3200100163 PLL IC U703 3530500025 VCTCXO FIL502 3520700149 RX IF SAW FIL601 3520700150 TX RF SAW FIL501 3520700151 RX RF SAW U502 3115000018 LNA+MIXER U604 3200100164 RF SWITCH U602 3012000065 PAM U702 3530600037 VCO U704 3200100012 NOT GATE U111,U112 3200100170 REGULATOR U115 3200100171 REGULATOR L701 3540200013 BEAD(600OHM) EXHIBIT 10 2 APPLICANT: MOTOROLA, INC FCC ID: IHDT6DF1 L202,L203,L204,L501,L521,L522,L528,L605,L606,L607, L608,L609 3540200006 BEAD(1000OHM) TH601 3411200005 THERMISTOR Q320 3110100015 TRANSISTOR Q101,Q108,Q109,Q112,Q604 3110100002 TRANSISTOR U114,U603 3110100016 TRANSISTOR U152 3116000001 TRANSISTOR U153,U154 3114000040 P-CH FET U109 3114000018 FET U151 3200100392 VOLTAGE DETECTOR U107,U108 3520100001 ESD FILTER D121 3101000007 ZENER DIODE D120 3101000009 ZENER DIODE F102 3620200009 FUSE F101 3620200004 FUSE U113 3200100393 LDO D301 3100500013 DIODE D178 3104100019 SCHOTTKY DIODE D101,D102,D171,D172,D177 3104100011 SCHOTTKY DIODE U119 3200100147 RESET LDO D501,D502 3100500037 VARIABLE DIODE D601 3104000007 VARIABLE DIODE 3042000092 MAIN PCB U605 HIGH POWER DETECTOR C520,C532 2125080001 CAPACITOR C568 2120100002 CAPACITOR C529 2121290004 CAPACITOR C547 2121590001 CAPACITOR C717 2123090001 CAPACITOR C533 2123390003 CAPACITOR C524.C654,C655 2120400001 CAPACITOR C574,C663 2124790001 CAPACITOR EXHIBIT 10 3 APPLICANT: MOTOROLA, INC FCC ID: IHDT6DF1 C609 2128080001 CAPACITOR C526,C577,C656,C657 2121000002 CAPACITOR C527 2121500001 CAPACITOR C537,C538,C546,C596 2121800001 CAPACITOR C635,C658,C659,C665 2122200001 CAPACITOR C534,C544,C545 2122700001 CAPACITOR C158,C225,C226 2123000002 CAPACITOR C610,C773 2123300001 CAPACITOR C618,C619 2123900002 CAPACITOR C613,C614 2125600002 CAPACITOR C250,C403,C625,C627,C629,C637,C639,C643,C644,C653, C666 2121010002 CAPACITOR C651,C652 2122210001 CAPACITOR C675 2123310004 CAPACITOR C186,C622,C636 2124710001 CAPACITOR C104,C540,C562,C650,C661,C676,C701,C702,C712,C713, C781 2121020004 CAPACITOR C757 2122720002 CAPACITOR C634 2123320002 CAPACITOR C539,C602 2124720006 CAPACITOR C707 2125620003 CAPACITOR C103,C129,C201,C202,C204,C229,C231,C239,C241,C245, C247,C301,C550,C551,C552,C554,C555,C556,C557,C563, C603,C633,C641,C714,C715,C716,C786,C787,C788,C789 2121030003 CAPACITOR C211,C212 2121230001 CAPACITOR C213,C218,C220,C253 2122230006 CAPACITOR C528,C531,C553,C566,C567,C569,C571,C572,C576 2123330002 CAPACITOR C705,C706 2126830001 CAPACITOR C102,C105,C115,C116,C120,C122,C125,C127,C128,C131, C170,C184,C205,C206,C207,C209,C210,C214,C215,C227, C228,C230,C232,C233,C237,C238,C240,C243,C244,C246, C254,C541,C542,C624,C626,C628,C632,C703,C704,C711, C780 2121040003 CAPACITOR C124,C216,C219,C221,C222 2121050008 CAPACITOR EXHIBIT 10 4 APPLICANT: MOTOROLA, INC FCC ID: IHDT6DF1 C621 2124720003 CAPACITOR C203,C708,C756 2126840002 CAPACITOR C559 2121050009 CAPACITOR C135,C136,C137 2122250002 CAPACITOR C121,C123 2122250006 CAPACITOR C208,C530,C536,C548,C560,C573,C575,C642,C645,C647, C660,C680,C683,C684,C686,C688,C698,C699,C782 CAPACITOR CT174 2031090001 TANTAL CAPACITOR CT102,CT201,CT203,CT702 2034750002 TANTAL CAPACITOR CT101,CT202,CT551,CT552,CT601,CT602,CT701,CT742 2031000003 TANTAL CAPACITOR CT170 2031030001 TANTAL CAPACITOR L526 3500100006 INDUCTOR L541,L555 3500100012 INDUCTOR L616 3500100019 INDUCTOR L545,L617 3500100031 INDUCTOR L549 3500100037 INDUCTOR L403,L543 3500100063 INDUCTOR L655 3500100413 INDUCTOR L542 3500100438 INDUCTOR L520 3500100490 INDUCTOR L603,L604 3500100166 INDUCTOR L611 3500100226 INDUCTOR L517,L525 3500100488 INDUCTOR L535 3500100489 INDUCTOR L523 3500100256 INDUCTOR L544,L602,L625 INDUCTOR R206,R207,R225,R609,R670,R721,R752,R767,R768 2520000001 RESISTOR R605,R606 2523308001 RESISTOR R751 2521009001 RESISTOR R702,R715 2521209001 RESISTOR R571 2523009001 RESISTOR R164,R604 2525109001 RESISTOR EXHIBIT 10 5 APPLICANT: MOTOROLA, INC FCC ID: IHDT6DF1 R532 2529109003 RESISTOR R134,R703,R706,R750,R756,R796 2521000001 RESISTOR R412 2521000007 RESISTOR R171 2522000001 RESISTOR R231 2524700001 RESISTOR R707 2520681001 RESISTOR R201,R202,R523,R602,R633,R640,R716,R717,R718 2521001001 RESISTOR R704 2521201001 RESISTOR R123 2521601004 RESISTOR R203,R232 2520182001 RESISTOR R214,R215,R230 2522201001 RESISTOR R517 2522401003 RESISTOR R161 2523301003 RESISTOR R124 2523301009 RESISTOR R103 2523901001 RESISTOR R129 2524021001 RESISTOR R143,R181 2524701003 RESISTOR R511,R708 2527501004 RESISTOR R502 2520822001 RESISTOR R705 2529101001 RESISTOR R155,R172,R204,R211,R213,R236,R526,R527,R529,R530, R610,R611.R654 2521002001 RESISTOR R607 2521212001 RESISTOR R612 2521602001 RESISTOR R102,R219,R220,R221,R235 2522002003 RESISTOR R101,R135,R141 2520223001 RESISTOR R641 2522202007 RESISTOR R512,R572 2520273001 RESISTOR R106,R130,R142,R167,R173,R174,R182,R183,R184,R205, R218,R617 2525102001 RESISTOR R122,R128,R131,R138,R162,R758 2521003001 RESISTOR R642 2521003008 RESISTOR EXHIBIT 10 6 APPLICANT: MOTOROLA, INC FCC ID: IHDT6DF1 R209,R210 2520184001 RESISTOR R242,R644 2521803002 RESISTOR R224,R643 2522403001 RESISTOR R132 2523003001 RESISTOR R212 2520514001 RESISTOR R411 2520000008 RESISTOR R301 2521508001 RESISTOR R127,R208,R216,R651,R655,R719.R720 RESISTOR SH101 6120014500 SHIELD CASE MSM SH104 6120022300 SHIELD CASE RX SH102 6120022400 SHIELD CASE TX SH108…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DF1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report IHDT6DF1 Date of test: Date of Report: 15-July-2003 21-July-2003 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Steven Hauswirth Principal Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE P1528 (DRAFT) FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT6DF1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2003 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DF1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1) Introduction 3 2) Description of the Device Under Test 3 Antenna description 3 Device description 3 3) Test Equipment 3 3.1 Dosimetric system 3 3.2 Additional equipment used 4 4) Electrical parameters of the tissue simulating liquid 4 5) System Accuracy Verification 4 6) Test Results 5 6.1 Head Adjacent Test Results 6 6.2 Body-Worn Test Results 7 References: Appendix 1: SAR distribution comparison for the system accuracy verification 9 Appendix 2: SAR distribution plots for Phantom Head Adjacent Use 10 Appendix 3: SAR distribution plots for Body Worn Configuration 12 Appendix 4. Probe Calibration Certificate 14 Appendix 5: Measurement Uncertainty Budget 15 Appendix 6. Photographs of the device under test 18 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DF1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1. Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT6DF1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2. Description of the Device Under Test Antenna description Type Helix Location Right Length 25 mm Dimensions Width 8 mm Configuration Stubby Device description FCC ID Number IHDT6DF1 Serial number 3D5FE40A Mode(s) of Operation CDMA1900 Modulation Mode(s) CDMA Maximum Output Power Setting 25.00 dBm Duty Cycle 1:1 Transmitting Frequency Rang(s) 1850 - 1910 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled 3. Test Equipment Used 3.1 Dosimetric System The Motorola Personal Communications Sector Product Safety & Compliance Laboratory utilizes a Dosimetric Assessment System (Dasy3™ v3.1d) manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. All the SAR measurements are taken within a shielded enclosure. The overall RSS uncertainty of the measurement system is ±11.7% (K=1) with an expanded uncertainty of ±23.0% (K=2). The measurement uncertainty budget is given in Appendix 6. Per IEEE 1528, this uncertainty budget is applicable to the SAR range of 0.4 W/kg to 10 W/kg. The list of calibrated equipment used for the measurements is shown below. Description Serial Number Cal Due Date DASY3 DAE V1 SN437 18-Mar-04 E-Field Probe ET3DV6R SN1501 16-Apr-04 Dipole Validation Kit, D1800V2 SN258TR 24-Jun-04 S.A.M. Phantom used for 1900MHz TP-1160 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DF1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 4 4 3.2 Additional Equipment Description Serial Number Cal Due Date Signal Generator HP8648C 3847A04850 2-Feb-2005 Power Meter E4419B GB39510961 5-Nov-2003 Power Sensor #1 - 8481A 2702A59572 5-Nov-2003 Power Sensor #2 - 8481A US37296470 5-Nov-2003 Network Analyzer HP8753ES US39171846 3-Jun-04 Dielectric Probe Kit HP85070B US99360070 N/A 4. Electrical parameters of the tissue simulating liquid Prior to conducting SAR measurements, the relative permittivity, ε r , and the conductivity, σ, of the tissue simulating liquids were measured with the HP85070 Dielectric Probe Kit These values, along with the temperature of the tissue simulate are shown in the table below. The recommended limits for maximum permittivity and minimum conductivity are also shown. These come from the Federal Communication Commission, OET Bulletin 65 Supplement C 01-01. It is seen that the measured parameters are satisfactory for compliance testing. Dielectric Parameters f (MHz) Tissue type Limits / Measured ε r σ (S/m) Temp (°C) Measured, 15-Jul-03 39.1 1.46 20.0 Head Recommended Limits 40.0 1.40 20-25 Measured, 15-Jul-03 51.6 1.57 2…

Text truncated - open the document above for the full version.

Date: August 19, 2003 Subject: Request for additional information (FCC ID: IHDT6DF1) Reference: Applicant Received: 7/28/2003 Correspondence Reference Number: 230819.IHD Confirmation Number: TC3187 Date of Original Email: 8/19/2003 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois 1. Please provide the following missing Exhibit’s: a) Exhibit 9 – Internal Photos b) Exhibit 6 – EMC Test Report c) Exhibit 5 – Schematics Response: The exhibits listed above are resubmitted on 8-19-03. 2. Please correct page 3 of the SAR report with the 800 MHz frequency band listed. Response: A replacement SAR report is submitted on 8-19-03. 1

APPLICANT: MOTOROLA INC FCC ID: IHDT6DF1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 11559-1 Report Date – July 22, 2003 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature Name: _Mark Kien_____ Title: Electrical Engineer Date : _ 07/22/03____ This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1651.01 EXHIBIT 6 APPLICANT: MOTOROLA INC FCC ID: IHDT6DF1 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configurations 4 Measuring Equipment and Calibration Information 5 Measurement Procedures and Data RF Power Output 6 Effective Radiated Power (ERP/EIRP) 7 Occupied Bandwidth 8 CDMA 1900 Reference Plot 9 CDMA 1900 Mid Band Plot 9 CDMA 1900 Lower Band Edge 10 CDMA 1900 Upper Band Edge 10 Spurious Emissions at Antenna Terminals 11 CDMA 1900 Tabular and Graphical Data 12 Field Strength of Spurious Emissions 13 CDMA 1900 Tabular and Graphical Data 14 Frequency Stability 15 CDMA 1900 Tabular and Graphical Data 16 Field Strength of Spurious Emissions From Unintentional Radiators 17 CDMA 1900 Tabular and Graphical Data 18 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 19 Figure A.2 – Substitution Measurement 19 Test Report Number: 11559-1 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT6DF1 Test Report Details Tests Performed By: Motorola Personal Communications Sector Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-3642 Fax (847) 523-8274 FCC Registration Number: 316588 Industry Canada Number: 46405-3908 Tests Requested By: Motorola Inc. Personal Communications Sector 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: CDMA 1900 Model Number: C210 Serial Numbers: 3D5FE456, 3D5FE44F, 3D5FE3E7 3D5FE3ED Received Date: 7/14/2003 Testing Start Date: 7/16/2003 Testing Complete Date: 7/21/2003 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators Part 22 Subpart H - Public Mobile Services X Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 98-C, ANSI 63.4 2000, RSS-118, RSS-129, RSS- 133 Test Report Number: 11559-1 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT6DF1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Occupied Bandwidth Pass 4 Spurious Emissions at Antenna Terminal Pass 5 Field Strength of Spurious Emissions Pass 6 Frequency Stability Pass 7 Field Strength of Emissions From Pass Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) NA 3 Occupied Bandwidth See Plots 4 Spurious Emissions at Antenna Terminal 10.7 dB 5 Field Strength of Spurious Emissions 6.4 dB 6 Frequency Stability 71.4 Hz 7 Field Strength of Emissions From 1.2 dB Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Test Report Number: 11559-1 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT6DF1 Measuring Equipment and Calibration Information Manufacturer Name Item Name Description Model # Serial Number Calibration Due Date Agilent EMC Analyzer E7405A US40240219 04/04/2004 Agilent EMC Analyzer E7405A US39440191 06/11/2003 Rohde & Schwarz S/A ESI26838786/010 04/29/2004 ETS Horn Antenna 1-18GHz31156222 09/30/2003 A.H. System Horn Antenna 1-18GHzSAS-200/571265 04/29/2004 ETS Bi-Con Antenna 30-300MHz3110B3370 10/25/2003 ETS Log-Periodic Antenna31481189 04/29/2004 Weinschel Attenuator Kit – 10, 6 dB2AS6-6677 10/09/2003 Weinschel Attenuator Kit – 10, 6 dB2AS6-6675 10/11/2003 Thermotron Environmental Chamber S4 31580 12/19/2003 Hewlett Packard 1 – 26.5 GHz Preamplifier8449B3008A00535 10/11/2003 Hewlett Packard 1 – 26.5 GHz Preamplifier8449B3008A01442 06/18/2004 Hewlett Packard 0.1 - 1300 MHz Amplifier8447F2805A03419 06/19/2004 Hewlett Packard CDMA Mobile Test Set8924CUS38513585 05/02/2004 Hewlett Packard System DC Power Supply66311BUS38447252 10/18/2003 Hewlett Packard PCS Interface 83236B3711J04427 05/02/2004 Agilent Wireless Communication Test Set 8960 Series 10GB42360906 09/10/2003 Giga-tronics Universal Power Meter8652A8650494 1/7/2004 Giga-tronics Power Sensor 80701A1833992 12/12/2003 Test Report Number: 11559-1 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT6DF1 Measure…
