IHDT6DV1Portable PCS GSM Transceiver

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: 1 Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola wireless phone. Headset Jack Left Soft Key Perform function in lower left display Volume Keys Power & End Key Turn phone on/off, end calls, exit menu system Menu Key Right Soft Key Perform function in lower right display Voice Key Record voice names Send Key Make & answer calls 5-Way Navigation Key Scroll through & select menu items Accessory Connector Note: Press in on the 5-Way Navigation Key to select highlighted items. 2 Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada) www.motorola.com (United States) www.motorola.ca (Canada) MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. All other product or service names are the property of their respective owners. © Motorola, Inc., 2003. Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. Manual Number: UGXXXX Cover Number: UGCGXXXX 3 Contents Safety and General Information. . . . . . . . . . . . . . . . . . . . 6 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 About This Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 Installing the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . 13 Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Turning Your Phone On . . . . . . . . . . . . . . . . . . . . . . . . . 17 Adjusting Volume. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Making a Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . 19 Highlight Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 Taking and Sending a Photo . . . . . . . . . . . . . . . . . . . . . 20 Sending a Multimedia Message . . . . . . . . . . . . . . . . . . 23 Receiving a Multimedia Message . . . . . . . . . . . . . . . . . 26 Playing Video Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 Using Ring Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Using Event Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28 Learning to Use Your Phone . . . . . . . . . . . . . . . . . . . . . 29 Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 Using the 5-Way Navigation Key . . . . . . . . . . . . . . . . . . 34 Using Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34 Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37 Using the External Display . . . . . . . . . . . . . . . . . . . . . . 47 Changing a Code, PIN, or Password. . . . . . . . . . . . . . . 48 Locking and Unlocking Your Phone. . . . . . . . . . . . . . . . 49 If You Forget a Code, PIN, or Password . . . . . . . . . . . . 50 4 Using the Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 Setting Up Your Phone. . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Storing Your Name and Phone Number . . . . . . . . . . . . . 53 Setting the Time and Date . . . . . . . . . . . . . . . . . . . . . . . 53 Setting a Ring Style . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 Setting Answer Options . . . . . . . . . . . . . . . . . . . . . . . . . 54 Activating Rhythm Lights. . . . . . . . . . . . . . . . . . . . . . . . . 55 Setting a Wallpaper Image . . . . . . . . . . . . . . . . . . . . . . . 56 Setting a Screen Saver Image . . . . . . . . . . . . . . . . . . . . 57 Setting Rotation Sound . . . . . . . . . . . . . . . . . . . . . . . . . . 58 Setting Rotation Animation . . . . . . . . . . . . . . . . . . . . . . . 59 Setting Display Brightness . . . . . . . . . . . . . . . . . . . . . . . 59 Setting Display Color . . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Adjusting the Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . 59 Setting Display Timeout . . . . . . . . . . . . . . . . . . . . . . . . . 59 Calling Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Changing the Active Line . . . . . . . . . . . . . . . . . . . . . . . . 61 Redialing a Number . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61 Using Automatic Redial. . . . . . . . . . . . . . . . . . . . . . . . . . 61 Using Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62 Canceling an Incoming Call . . . . . . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

APPLICANT MOTOROLA INC. FCC ID: IHDT6DV1 ATTESTATION STATEMENTS Transceiver type IHDT6DV1 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, located at 12 Ang Mo Kio St.64, Ang Mo Kio Ind. park 3, Singapore 569088 and 600 N. US Highway 45, Libertyville, Illinois. NAME: GAO WILSON TITLE: SR. MANAGER OF ENGINEERING, PERSONAL COMMUNICATIONS SECTOR Page 1 of 2 EXHIBIT 2 APPLICANT MOTOROLA INC. FCC ID: IHDT6DV1 I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (FCC ID: IHDT6DV1) is in compliance with all applicable parts of the FCC Rules. NAME:AMIN JALALI TITLE: SR. RFENGINEER, PCS Development Date: 12/1/03 Page 2 of 2 EXHIBIT 2

Date: December 8, 2003 Subject: Request for additional information (FCC ID: IHDT6DV1) Reference: Applicant Received: 12/03/2003 Correspondence Reference Number: 231208A.IHD Confirmation Number: TC3306 Date of Original Email: 12/08/2003 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois Questions and responses follow: Part 24E application: 1. What analyzer settings (i.e., RBW, VBW, detector function) were used to make spurious conducted and spurious radiated emission measurements? Response: Please refer to the revised test report, Exhibit 6, submitted on 12-8-2003. Part 15.247 application: 2. What analyzer settings (i.e., RBW, VBW, detector function) were used to make spurious radiated emission measurements? Response: Please refer to the revised test report, Exhibit 6A, submitted on 12-8-2003. 1

Date: February 6, 2004 Subject: Request for additional information (FCC ID: IHDT6DV1) Reference: Applicant Received: 12/03/2003 Correspondence Reference Number: 240206A.IHD Confirmation Number: TC3306 Date of Original Email: 12/08/2003 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois Questions and responses follow: 1. While we have received the addendum to the SAR report, I cannot locate the responses to my original email, dated 12/08/03. Please resend, if you have sent them already. Response: The 12-8-03 response for CRN23208A.IHD is re-submitted. 2. Why was the addendum to the original SAR report submitted? What changed, requiring the new body-worn SAR tests? Response: The grounding method for the rotating housing was changed, as illustrated in the following. (Note: This change required complete testing of both EMC and SAR. Degradation is reported only for the body worn SAR.) 1 3. Please correct the max SAR level listed for use at the ear in the user's manual, p.92, to the max level reported (0.24 W/kg). Response: Please replace the user manual, submitted on 2-4-04, with the updated version submitted on 2-6-04. 4. Please correct the following typos, p.5 of the recently submitted SAR addendum: (a) at 1800 MHz, the validation test target SAR level should be 38.1 (the value listed is for 1900 MHz), (b) the conversion factor listed in the table is for the body. It should be 3.4, the value for the head. Response: Please replace the supplemental SAR report, submitted on 2-4-04, with the updated version submitted on 2-6-04. Earlier PCB contact pad Earlier Grounding Gasket Later PCB contact pads Later Grounding Gasket 2

APPLICANT: MOTOROLA FCC ID: IHDT6DV1 November 30, 2003 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT6DV1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in 1900 MHz PCS band. The unit also contains a 2.4 GHz Bluetooth transmitter (Part 15.247). Note: This device contains 900 MHz and 1800 MHz GSM, functions which are not operational in U.S. territories. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Cellular Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 EXHIBIT 3 Rear View with Battery Cover Removed Showing ID Label Rear View Front View Front View (opened)

APPLICANT: MOTOROLA INC. FCC ID: IHDT6DV1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT6DV1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 EXHIBIT 9 Front View Rear View 1 of 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 EXHIBIT 9 Front View (Shields Removed) Rear View (Shields Removed) 2 of 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 EXHIBIT 9 Front Housing Internal View Rear Housing Internal View 3 of 3

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 TRANSCEIVER ADJUSTMENTS / TUNE-UP PROCEDURE There are no user accessible adjustments or tuning in this portable cellular transceiver. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service or repair are done as part of that process, as special equipment is required to perform such adjustments. EXHIBIT 10 1 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56DR1 PARTS LIST Reference Symbol Part Number Description C1 2113743N18 Capacitor 4.7pF C1000 2113743M24 Capacitor 0.1uF C1001 2113928P04 Capacitor 1.0uF C1010 2113743K15 Capacitor 0.1uF C1011 2113743L13 Capacitor 680pF C1020 2113743M24 Capacitor 0.1uF C1021 2113743M24 Capacitor 0.1uF C1030 2113928Z11 Capacitor 22uF C1033 2113743L41 Capacitor .01uF C1050 2113743M24 Capacitor 0.1uF C1051 2113743M24 Capacitor 0.1uF C1055 2187893N01 Capacitor 1.0uF C1056 2113946D02 Capacitor 1.0uF C1060 2311049A89 Capacitor 22uF C1062 2113741F29 Capacitor 1500pF C1066 2187906N01 Capacitor 4.7uF C1071 2113743M24 Capacitor 0.1uF C11 2113740F39 Capacitor 33pF C1350 2113743M24 Capacitor 0.1uF C150 2113743L05 Capacitor 330pF C151 2113740A75 Capacitor 680pF C152 0888600M24 Capacitor 8200pF C153 2113928C04 Capacitor 4.7uF C154 2113928N01 Capacitor 0.1uF C162 2113743N20 Capacitor 5.6pF C163 0888600M24 Capacitor 8200pF C164 2113743L19 Capacitor 1200pF C165 2113743N52 Capacitor 120pF C166 2113743N52 Capacitor 120pF C167 2113743L09 Capacitor 470pF C170 2113928C03 Capacitor 1.0uF C1701 2113743M24 Capacitor 0.1uF C171 2113743N40 Capacitor 39pF C172 2113743L41 Capacitor .01uF C173 2113743N40 Capacitor 39pF C174 2113743N40 Capacitor 39pF C176 2113928C04 Capacitor 4.7uF C177 2113743N42 Capacitor 47pF C180 2113743L41 Capacitor .01uF C50 2113743F18 Capacitor 2.2uF C51 2113743F18 Capacitor 2.2uF C52 2113743L41 Capacitor .01uF C53 2113743N40 Capacitor 39pF C54 2113743N40 Capacitor 39pF C55 2113743N40 Capacitor 39pF C56 2113743N38 Capacitor 33pF EXHIBIT 10 2 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56DR1 C57 2113743N38 Capacitor 33pF C58 2113743N38 Capacitor 33pF C59 2113743N38 Capacitor 33pF C60 2113743N40 Capacitor 39pF C61 2113743L17 Capacitor 1000pF C62 2113743N40 Capacitor 39pF C63 2113743N40 Capacitor 39pF C64 2113743N40 Capacitor 39pF C65 2113743L41 Capacitor .01uF C700 2113743M24 Capacitor 0.1uF C701 2113743M24 Capacitor 0.1uF C703 2113743M24 Capacitor 0.1uF C704 2113743M24 Capacitor 0.1uF C806 2113946S35 Capacitor 1.0uF C807 2113743M24 Capacitor 0.1uF C810 2187906N01 Capacitor 4.7uF C811 2113743M24 Capacitor 0.1uF C812 2113743M24 Capacitor 0.1uF C813 2113743M24 Capacitor 0.1uF C814 2113743M24 Capacitor 0.1uF C815 2113743M24 Capacitor 0.1uF C816 2113743M24 Capacitor 0.1uF C817 2113743M24 Capacitor 0.1uF C819 2113743M24 Capacitor 0.1uF C820 2113928P04 Capacitor 1.0uF C821 2113928P04 Capacitor 1.0uF C822 2113928P04 Capacitor 1.0uF C823 2113928P04 Capacitor 1.0uF C824 2113928P04 Capacitor 1.0uF C826 2113743M24 Capacitor 0.1uF C827 2113743M24 Capacitor 0.1uF C828 2113743M24 Capacitor 0.1uF C829 2113743M24 Capacitor 0.1uF C840 2113743M24 Capacitor 0.1uF C900 2113743M24 Capacitor 0.1uF C901 2113743L25 Capacitor 2200pF C902 2113743L41 Capacitor .01uF C903 2187906N01 Capacitor 4.7uF C904 2113743M24 Capacitor 0.1uF C905 2113743N30 Capacitor 15pF C906 2113743N30 Capacitor 15pF C910 2187906N01 Capacitor 4.7uF C911 2113743L41 Capacitor .01uF C912 2113743M24 Capacitor 0.1uF C920 2113928Z11 Capacitor 22uF C922 2113928Z11 Capacitor 22uF C924 2113928Z11 Capacitor 22uF C926 2187906N01 Capacitor 4.7uF EXHIBIT 10 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56DR1 C928 2113928S04 Capacitor 0.1uF C929 2187906N01 Capacitor 4.7uF C931 2187906N01 Capacitor 4.7uF C932 2187906N01 Capacitor 4.7uF C933 2113928C13 Capacitor 10uF C934 2113928C13 Capacitor 10uF C935 2187906N01 Capacitor 4.7uF C937 2187906N01 Capacitor 4.7uF C938 2187906N01 Capacitor 4.7uF C939 2113928C13 Capacitor 10uF C940 2113743M24 Capacitor 0.1uF C950 2113743M24 Capacitor 0.1uF C951 2113743L35 Capacitor 5600pF C952 2113928C13 Capacitor 10uF C953 2113928A01 Capacitor 1.0uF C954 2113928C13 Capacitor 10uF C961 2187906N01 Capacitor 4.7uF CR900 4809948D42 Rohm/Toshiba RB751V-40/1SS367 CR920 4809924D18 Rohm RB520S-30 CR921 4809924D18 Rohm RB520S-30 D1055 4809924D18 Rohm RB520S-30 D1450 4809496B18 Panasonic LNJ026X8B0MT WHT LED D1451 4809496B18 Panasonic LNJ026X8B0MT WHT LED D1452 4809496B18 Panasonic LNJ026X8B0MT WHT LED D1453 4809496B18 Panasonic LNJ026X8B0MT WHT LED D1454 4809496B18 Panasonic LNJ026X8B0MT WHT LED D1455 4809496B18 Panasonic LNJ026X8B0MT WHT LED D1456 4809496B18 Panasonic LNJ026X8B0MT WHT LED D1457 4809496B18 Panasonic LNJ026X8B0MT WHT LED D700 4809924D18 Rohm RB520S-30 FL100 9188668L04 Sawtek 890010 FL1400 4809606E12 STElectronics EMIF11-10002C4 FLTR,EMI J1 0987378K01 Hirose MS147 CONN RF MOD3 J1200 0909195E05 MIC. CONNECTOR J1260 3988194N01 HosidenCorp HPC0890-010010 J1300 2887818K07 CONN,PLG,F,34CONT J1350 3970350D02 CONN HW,SIM,CRD J1400 0987636K06 Motorola 36K06 17 PINS SM J1701 0988252L01 Sanyo 4H-2T SOCKET,COIN CELL BATT L1 2409154M33 Inductor 5.6nH L1000 2409646M13 Inductor 39nH L1030 2409646M13 Inductor 39nH L1050 2409646M13 Inductor 39nH L1200 2409646M13 Inductor 39nH L1241 2409646M13 Inductor 39nH L1260 2409646M13 Inductor 39nH L1261 2409646M13 Inductor 39nH L1300 2409377M17 Inductor 100nH EXHIBIT 10 4 APPLICANT: MOTOROLA, INC. FCC ID: IHDT56DR1 L1400 2409646M13 Inductor 39nH L1401 2409646M13 Inductor 39nH L161 2489970L37 Inductor 270nH L170 2409154M36 Inductor 10.0nH L2 2113743N03 Capacitor 1pF L3 0662057M01 Resistor 0 L4 2409646M13 Inductor 39nH L70 2462587Q65 Inductor 33uH L920 2588866L14 Inductor 47uH L921 2487659M08 Inductor 15uH L950 2409377M17 Inductor 100nH M1700 3988340N01 CONT,BAT,,M,PHBRZ M3 3989013L05 CONT ANT Q1400 4809939C39 Rohm EMD9T2R Q801 4888182N01 Toshiba TPS851 Q924 4809579E24 Toshiba 2SJ347-TE851TSTR FET P-CHAN Q950 4809807C41 FAIRCHILD FDZ299P POWER MOSFET Q951 4809939C39 Rohm EMD9T2R Q952 48…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report IHDT6DV1 Date of test: Date of Report: 11/04/2003 – 11/06/2003 11/25/2003 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Firass Badaruzzaman Senior RF Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE P1528 (DRAFT) FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT6DV1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2003 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION...................................................................................................................................... 3 2. DESCRIPTION OF THE DEVICE UNDER TEST.................................................................................... 3 2.1 Antenna description ..............................................................................................................................................3 2.2 Device description..................................................................................................................................................3 3. TEST EQUIPMENT USED........................................................................................................................ 3 3.1 Dosimetric System .................................................................................................................................................3 3.2 Additional Equipment...........................................................................................................................................4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID............................................. 4 5. SYSTEM ACCURACY VERIFICATION.................................................................................................. 4 6. TEST RESULTS........................................................................................................................................ 5 6.1 Head Adjacent Test Results..................................................................................................................................6 6.2 Body Worn Test Results .......................................................................................................................................7 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION...... 9 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR PHANTOM HEAD ADJACENT USE.......................10 APPENDIX 3: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION...........................12 APPENDIX 4: PROBE CALIBRATION CERTIFICATE..........................................................................14 APPENDIX 5: DIPOLE CHARACTERIZATION CERTIFICATE............................................................15 APPENDIX 6: MEASUREMENT UNCERTAINTY BUDGET................................................................... 16 APPENDIX 7: PHOTOGRAPHS OF DEVICE UNDER TEST ................................................................... 19 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1. Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT6DV1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2. Description of the Device Under Test a. Antenna description Type FICA Antenna Location Back of phone at the bottom Length (max) 40 mm Dimensions Width (max) 25 mm Configuration Internal Patch Antenna b. Device description FCC ID Number IHDT6DV1 Serial number S50SF022H7 Mode(s) of Operation GSM 900 GSM 1800 GSM 1900 GPRS 900 GPRS 1800 GPRS 1900 Blue Tooth Modulation Mode(s) GSM GSM GSM GSM GSM GSM Blue Tooth Maximum Output Power Setting 33.00 dBm 30.00 dBm 30.00 dBm 33.00 dBm 30.00 dBm 30.00 dBm 0.00 - 4.00 dBm Duty Cycle 1:8 1:8 1:8 2:8 2:8 2:8 1:1 Transmitting Frequency Rang(s) 880.2- 914.8 MHz 1710.2- 1784.8 MHz 1850.20 – 1909.80 MHz 880.2- 914.8 MHz 1710.2- 1784.8 MHz 1850.20 – 1909.80 MHz 2400 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Id…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 E E x x h h i i b b i i t t 1 1 1 1 Exhibit 11: SAR Test Report IHDT6DV1 Addendum Date of test: Date of Report: 01/21/04 02/06/04 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Albert Patapack Senior Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE P1528 (DRAFT) FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT6DV1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2004 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION...................................................................................................................................... 3 2. DESCRIPTION OF THE DEVICE UNDER TEST.................................................................................... 3 2.1 Antenna description.................................................................................................................................................3 3. TEST EQUIPMENT USED........................................................................................................................ 3 3.1 Dosimetric System .................................................................................................................................................3 3.2 Additional Equipment...........................................................................................................................................4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID............................................. 4 5. SYSTEM ACCURACY VERIFICATION.................................................................................................. 4 6. TEST RESULTS........................................................................................................................................ 5 6.1 Body Worn Test Results .......................................................................................................................................6 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION...... 7 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION............................. 8 APPENDIX 3: PROBE CALIBRATION CERTIFICATE............................................................................ 9 APPENDIX 4: DIPOLE CALIBRATION CERTIFICATE......................................................................... 10 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6DV1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1. Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT6DV1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2. Description of the Device Under Test a. Antenna description Type FICA Antenna Location Back of phone at the bottom Length (max) 40 mm Dimensions Width (max) 25 mm Configuration Internal Patch Antenna b. Device description FCC ID Number IHDT6DV1 Serial number S50SF022H7 Mode(s) of Operation GSM 900 GSM 1800 GSM 1900 GPRS 900 GPRS 1800 GPRS 1900 Blue Tooth Modulation Mode(s) GSM GSM GSM GSM GSM GSM Blue Tooth Maximum Output Power Setting 33.00 dBm 30.00 dBm 30.00 dBm 33.00 dBm 30.00 dBm 30.00 dBm 0.00 - 4.00 dBm Duty Cycle 1:8 1:8 1:8 2:8 2:8 2:8 1:1 Transmitting Frequency Rang(s) 880.2- 914.8 MHz 1710.2- 1784.8 MHz 1850.20 – 1909.80 MHz 880.2- 914.8 MHz 1710.2- 1784.8 MHz 1850.20 – 1909.80 MHz 2400 - 2483.5 MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Protot…

Text truncated - open the document above for the full version.
