IHDT6ES1Licensed Portable with Bluetooth

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6ES1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: DR AFT 1 Welcome Welcome to the world of Motorola digital wireless communications! We are pleased that you have chosen the Motorola E398 series GSM wireless phone. Note: Your phone may not appear exactly as shown above. All key locations, sequences, and functions remain the same regardless of your phone’s appearance. Left Soft Key Perform function in lower left display. Headset Jack Stereo Speakers (both sides) Camera Key Activate camera & take photos. Volume Key Smart Key 5-Way Navigation Joystick with Center Select Scroll through menus, press in to select items. Menu Key Accessory Connector Port Insert charger & phone accessories. Right Soft Key Perform function in lower right display. Power & End Key Turn phone on/off, end calls, exit menu system. Send Key Make & answer calls. DR AFT 2 Check It Out! FeatureDescription Use Memory Card Set the memory location you want to use to store and retrieve files: Go to a multimedia menu (such as Pictures or Sounds), then press M>Switch Storage Device >device name. Play Music Play a song on your phone: M >Multimedia >Sounds>song name Create Playlist Create a playlist of songs to play on your phone: M >Multimedia >Sounds>[New Playlist] 032385o.eps Camera Key Activate camera & take photos. Mirror Aim camera lens for self portraits. Camera Lens Integrated Short- Range Flash Stereo Speakers (both sides) DR AFT 3 Rhythm Lights Activate rhythm lights to flash in sync with the sounds around you: M >Settings >Personalize >Rhythm Lights Ring Lights Choose ring lights for incoming calls: M >Settings >Ring Styles >Ring Lights >light pattern Wireless Connection Set up a Bluetooth ® wireless connection to a headset accessory, car kit, or external device: M >Settings >Connection >Bluetooth Link > Handsfree >[Look For Devices] Take Photo (With Flash) Press the camera key to activate the camera. Press M>Flash >On to activate the flash. Point lens at subject, then press the camera key to take a photo. Send Photo Send a photo to a phone number or email address: Press STORE(+) >Send In Message. Phone Skin Apply a different skin to the phone display: M >Settings >Personalize >Skin >skin Send Multimedia Message Send a multimedia message with pictures, animations, sounds, and videos: M >Messages >Create Message > New Multimedia Msg Play Video Clip Play a video clip: M >Multimedia >Videos >video clip FeatureDescription DR AFT 4 Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 1-800-331-6456 (United States) 1-888-390-6456 (TTY/TDD United States) 1-800-461-4575 (Canada) www.motorola.com (United States) www.motorola.ca (Canada) MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. All other product or service names are the property of their respective owners. © Motorola, Inc. 2004. The information contained in Motorola’s user’s guides is believed to be correct at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice. The contents of Motorola’s user’s guides are provided “as is.” Except as required by applicable law, no warranties of any kind, either express or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose, are made in relation to the accuracy, reliability, or contents of this guide. Caution: Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment. Manual number: 68XXXXXX32-O DR AFT 5 Contents Getting Started. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Installing the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Installing a Memory Card . . . . . . . . . . . . . . . . . . . . . . . . 10 Battery Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11 Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 Charging the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Turning Your Phone On. . . . . . . . . . . . . . . . . . . . . . . . . . 15 Adjusting Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 Viewing Your Phone Number . . . . . . . . . . . . . . . . . . . . . 17 Locking and Unlocking the Keypad. . . . . . . . . . . . . . . . . 18 Highlight Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 Using a Removable Memory Card . . . . . . . . . . . . . . . . . 19 Creating a Music Playlist . . . . . . . . . . . . . . . . . . . . . . . . 20 Activating Rhythm Lights . . . . . . . . . . . . . . . . . . . . . . . . 21 Setting Ring Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22 Setting Up a Bluetooth ® Wireless Connection . . . . . . . . 23 Taking and Sending a Photo. . . . . . . . . . . . . . . . . . . . . . 24 Changing Phone Skin . . . . . . . . . . . . . . . . . . . . . . . . . . . 27 Sending a Multimedia Message . . . . . . . . . . . . . . . . . . . 27 Playing Video Clips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 Learning to Use Your Phone. . . . . . . . . . . . . . . . . . . . . . 32 Using the Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32 Using the 5-Way Navigation Joystick . . . . . . . . . . . . . . . 37 Using Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38 E…

Text truncated - open the document above for the full version.

APPLICANT MOTOROLA INC. FCC ID: IHDT6ES1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type FCC ID: IHDT6ES1 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, located at 3301 Quantum Boulevard, Boynton Beach, Florida and 600 N. US Highway 45, Libertyville, Illinois. NAME: ROSS RIPLEY TITLE: ENGINEERING MANAGER PERSONAL COMMUNICATIONS SECTOR Page 1 of 2 EXHIBIT 2 APPLICANT MOTOROLA INC. FCC ID: IHDT6ES1 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (FCC ID: IHDT6ES1) is in compliance with all applicable parts of the FCC Rules. NAME: EDWARD RIOS TITLE: SR. RF ENGINEER PERSONAL COMMUNICATIONS SECTOR Page 2 of 2 EXHIBIT 2

APPLICANT: MOTOROLA FCC ID: IHDT6ES1 April 8, 2004 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT6ES1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in 1900 MHz PCS band. The unit also contains a 2.4 GHz Bluetooth transmitter (Part 15.247). Note: This device contains 900 MHz and 1800 MHz GSM, functions which are not operational in U.S. territories. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Cellular Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6ES1 EXHIBIT 3 Rear View with Battery Cover Removed Showing ID Label Rear View Front View

APPLICANT: MOTOROLA INC. FCC ID: IHDT6ES1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT6ES1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6ES1 EXHIBIT 9 Front View (Shields Removed) Rear View (Shields Removed) 1 of 3 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6ES1 EXHIBIT 9 2 of 3 Rear View with Shields Front View with Shields EXHIBIT 9 3 of 3 Front Housing Internal View Rear Housing Internal View APPLICANT: MOTOROLA, INC. FCC ID: IHDT6ES1

APPLICANT: MOTOROLA INC FCC ID: IHDT6ES1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT - Addendum Test Report Number –13878 -1BT Report Date – May 5, 2004 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature: Name: Michael E. Hill Title: Senior Electrical Engineer Date :2004-05-05 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1846-01 EXHIBIT 6A APPLICANT: MOTOROLA INC FCC ID: IHDT6ES1 Table of Contents Test Report Details.............................................................................................................4 Applicable Standards..........................................................................................................5 Summary of Testing............................................................................................................6 General and Special Conditions..........................................................................................6 Equipment and Cable Configurations.................................................................................7 Measuring Equipment and Calibration Information...........................................................7 Description of Bluetooth Transmitter.................................................................................8 Measurement Procedures and Data.....................................................................................9 CARRIER FREQUENCY SEPARATION....................................................................9 Measurement Procedure..............................................................................................9 Measurement Results..................................................................................................9 Carrier Frequency Separation...............................................................................10 NUMBER OF HOPPING FREQUENCIES.................................................................11 Measurement Procedure............................................................................................11 Measurement Results................................................................................................11 Number of Hopping Frequencies (Channels 2 – 42)............................................12 Number of Hopping Frequencies (Channels 42 – 80)..........................................12 TIME OF OCCUPANCY (DWELL TIME).................................................................13 Measurement Procedure............................................................................................13 Measurement Results................................................................................................13 Dwell Time...........................................................................................................14 20dB Bandwidth...........................................................................................................15 Measurement Procedure............................................................................................15 Measurement Results................................................................................................15 20 dB BandwidthFIELD STRENGTH OF SPURIOUS EMISSIONS.............................16 FIELD STRENGTH OF SPURIOUS EMISSIONS.........................................................17 Measurement Procedure............................................................................................17 Measurement Results................................................................................................17 30 -1000MHz Low Channel Dual Polarization (Radiated Plot 1)........................18 30-1000MHz Mid Channel Dual Polarization (Radiated Plot 2)..........................19 30-1000MHz High Channel Dual Polarization (Radiated Plot 3)........................20 1-3GHz Low Channel X-Orientation....................................................................21 1-3GHz Low Channel Y-Orientation....................................................................22 1-3GHz Low Channel Z-Orientation....................................................................23 1-3GHz Mid-Channel Z-Orientation....................................................................28 1-3GHz High-Channel X-Orientation...................................................................29 1-3GHz High-Channel Y-Orientation...................................................................30 1-3GHz High-Channel Z-Orientation...................................................................31 3-12GHz Low-Channel X-Orientation.................................................................32 3-12GHz Low-Channel Y-Orientation.................................................................33 3-12GHz Low-Channel Z-Orientation..................................................................34 3-12GHz Mid-Channel Y-Orientation..................................................................36 3-12GHz Mid-Channel Y-Orientation..................................................................37 3-12GHz Mid-Channel Z-Orientation..................................................................38 12-18GHz Low-Channel X-Orientation...............................................................39 Test Report Number: 13878-1 EXHIBIT 6A 2 APPLICANT: MOTOROLA INC FCC ID: IHDT6ES1 12-18GHz Low-Channel Y-Orientation.........................................................…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT6ES1 Appendix A – Radiated Emissions Test Setup Photos A.1 Radiated Emissions Measurement A.2 Substitution Measurement End of Test Report Test Report Number: 13878-1 EXHIBIT 6 20
