IHDT6FD1Portable PCS GSM Transceiver with Bluetooth

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FD1 EXHIBIT 8 INSTRUCTION MANUAL A preliminary draft copy of the Users Manual follows: motorola.com E1070 3G 1 HELLOMOTO Introducing your new Motorola E1070 3G wireless phone. Here’s a quick anatomy lesson. Left Soft Key Scroll up, down, left, or right. Select. Volume Keys Charge up or go handsfree. Go online. Right Soft Key Camera Key Turn on & off, hang up, exit menus. Make & answer calls. Clear/Back Key Smart Key Make video calls. 2 Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196 www.hellomoto.com Certain mobile phone features are dependent on the capabilities and settings of your service provider’s network. Additionally, certain features may not be activated by your service provider, and/or the provider's network settings may limit the feature’s functionality. Always contact your service provider about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user's guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation. MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. The Bluetooth trademarks are owned by their proprietor and used by Motorola, Inc. under license. Java and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. All other product or service names are the property of their respective owners. © Motorola, Inc., 2005. Caution: Changes or modifications made in the radio phone, not expressly approved by Motorola, will void the user’s authority to operate the equipment. Software Copyright Notice The Motorola products described in this manual may include copyrighted Motorola and third-party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third-party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or 3 reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third-party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product. Manual Number: 68XXXXX110-O 4 contents contents menu map . . . . . . . . . . . 6 Safety Information . . . . 8 EU Conformance . . . . . 15 Recycling Information. 16 essentials. . . . . . . . . . . 17 about this guide. . . . . 17 SIM card . . . . . . . . . . 17 battery . . . . . . . . . . . . 18 turn it on & off . . . . . . 21 make a call . . . . . . . . 21 answer a call . . . . . . . 21 store a phone number 21 call a stored phone number . . . . . . . . . . . 22 your phone number . . 23 main attractions . . . . . 24 audio player . . . . . . . . 24 digital audio player. . . 25 take & send a photo . 26 record & send a video 29 video calls . . . . . . . . . 30 memory card . . . . . . . 31 cable connections . . . 34 Bluetooth® wireless . 34 basics . . . . . . . . . . . . . . 41 display . . . . . . . . . . . . 41 menus . . . . . . . . . . . . 44 text entry . . . . . . . . . 46 volume . . . . . . . . . . . 51 navigation key . . . . . . 51 smart key . . . . . . . . . 52 external display . . . . . 52 handsfree speaker . . 52 codes & passwords . 52 lock & unlock phone . 53 customize . . . . . . . . . . 54 ring style . . . . . . . . . . 54 time & date . . . . . . . . 55 wallpaper. . . . . . . . . . 55 screen saver . . . . . . . 56 themes . . . . . . . . . . . 57 display appearance . . 57 answer options . . . . . 58 calls . . . . . . . . . . . . . . . 59 turn off a call alert . . . 59 recent calls . . . . . . . . 59 redial . . . . . . . . . . . . . 60 return a call . . . . . . . . 61 caller ID . . . . . . . . . . . 61 emergency calls . . . . 61 voicemail . . . . . . . . . . 62 other features . . . . . . . 63 advanced calling . . . . 63 phonebook . . . . . . . . 67 5 contents messages . . . . . . . . . . 70 instant messaging. . . . 74 personalizing . . . . . . . . 75 call times & costs . . . . 77 handsfree . . . . . . . . . . 78 data calls . . . . . . . . . . . 79 network. . . . . . . . . . . . 80 personal organizer. . . . 80 security . . . . . . . . . . . . 82 fun & games . . . . . . . . 83 service and repairs . . . . 86 SAR Data . . . . . . . . . . . . 87 Warranty . . . . . . . . . . . . 89 WHO Information . . . . . 95 index . . . . . . . . . . . . . . . 96 6 menu map menu map main menu ICamera ÉTools • SIM Tool Kit * • Calculator • Datebook •Alarm Clock • Dialing Services • Fixed Dial * •Quick Dial • Activation List tRing Styles •Style •style Detail QGames & Apps hMultimedia •Themes •Camera •Pictures • Sounds • Videos • Video Camera áWeb Access •Browser • Web Shortcuts • Stored Pages •History •Go To URL •Browser Setup • Web Sessions * eMessages • Create Message •Call Voicemail • Inbox • Create Postcard * • Send to My Album * •EmailInbox • Messenger * •Browser Msgs • Info Services * •Outbox •Drafts • Templates nPhonebook sRecent Calls • Received Calls • Dialed Calls • Notepad •Call Times* • Call Cost * w Settings • (see next page) EBluetooth Link • Audio Devices • Device History •Setup ãIM * optional features This is the standard main menu layout. Your phone’s menu may be a little different. 7 menu map settings menu lPersonalize • Home Screen • Main Menu •Skins •Greeting • Wallpaper • Screen Saver •Quick Dial LConnection •Sync…

Text truncated - open the document above for the full version.

APPLICANT MOTOROLA INC. FCC ID: IHDT6FD1 SPECIFICATION COMPLIANCE STATEMENT Transceiver type FCC ID: IHDT6FD1 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at: Motorola Mobile Devices Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 NAME: Paolo Balducci TITLE: Engineering Manager Mobile Device Business Date: September 13, 2005 Exhibit 2A APPLICANT MOTOROLA INC. FCC ID: IHDT6FD1 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (FCC ID: IHDT6FD1) is in compliance with all applicable parts of the FCC Rules. NAME: Gian Luigi Madonna TITLE: EE Lead Engineer Mobile Device Business Date: September 13, 2005 Exhibit 2B

APPLICANT: Motorola, Inc. FCC ID: IHDT6FD1 September 27, 2005 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Mobile Device Business 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of PCE Transceiver, FCC ID: IHDT6FD1. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), confidentiality is requested for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains trade secrets and confidential information not customarily released to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in the 1900 MHz PCS band. This unit also contains a 2.4 GHz Bluetooth transmitter. Note: This device contains 900 MHz & 1800 MHz GSM, and 2100 MHz WCDMA functions that are not operational in U.S. Territories. Contact Information: Please contact me by telephone at (847) 523-6167or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Motorola Mobile Device Business 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FD1 EXHIBIT 3A Front View Flip Opened Rear View Flip Opened APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FD1 EXHIBIT 3B Rear View with Battery Cover Removed Showing ID Label Rear View Front View

APPLICANT: MOTOROLA INC. FCC ID: IHDT6FD1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT6FD1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

FrontView RearView Key Pad without popples APPLICANT: MOTOROLA FCC ID: IHDT6FD1 EXHIBIT 9 1 0F 3 FrontView without shields Flip Board without shields RearViewwithoutshields APPLICANT: MOTOROLA FCC ID: IHDT6FD1 EXHIBIT 9 2 0F 3

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FD1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report IHDT6FD1 Date of test: Date of Report: 08-Sept-2005 through 18-Sept-2005 29-Sept-2005 Laboratory: Motorola Mobile Devices Business Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Albert Patapack Senior Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE 1528, IEC 62209-1 FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT6FD1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2005 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FD1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION ...................................................................................................................................................3 2. DESCRIPTION OF THE DEVICE UNDER TEST.............................................................................................3 2.1 Antenna description ..............................................................................................................................................3 2.2 Device description..................................................................................................................................................3 3. TEST EQUIPMENT USED....................................................................................................................................4 3.1 Dosimetric System .................................................................................................................................................4 3.2 Additional Equipment...........................................................................................................................................4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID ..................................................4 5. SYSTEM ACCURACY VERIFICATION............................................................................................................5 6. TEST RESULTS......................................................................................................................................................6 6.1 Head Adjacent Test Results..................................................................................................................................6 6.2 Body Worn Test Results .......................................................................................................................................9 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION .....12 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR PHANTOM HEAD ADJACENT USE ..........................13 APPENDIX 3: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION ..............................14 APPENDIX 4: PROBE CALIBRATION CERTIFICATE ..................................................................................15 APPENDIX 5: MEASUREMENT UNCERTAINTY BUDGET..........................................................................16 APPENDIX 6: PHOTOGRAPHS OF DEVICE UNDER TEST...........................................................................19 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FD1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1 Introduction The Motorola Mobile Devices Business Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT6FD1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2 Description of the Device Under Test 2.1 Antenna description Type Internal Location front bottom portion of main transceiver housing Length 39.35mm Dimensions Width 9.10mm Configuration FJA 2.2 Device description FCC ID Number IHDT6FD1 Serial number FB13W2222G Mode(s) of Operation GSM 900 GSM 1800 GSM 1900 GPRS 900 GPRS 1800 GPRS 1900 UMTS 2100 BlueTooth Modulation Mode(s) GMSK GMSK GMSK GMSK GMSK GMSK QPSK GFSK Maximum Output Power Setting 32.00dBm 30.00dBm 30.00dBm 32.00dBm 30.00dBm 30.00dBm 22.00dBm 4.00dBm Duty Cycle 1:8 1:8 1:8 2:8 2:8 2:8 1:1 1:1 Transmitting Frequency Rang(s) 880.2 - 914.8MHz 1710.2 - 1784.8 MHz 1850.2 – 1909.8MHz 824.2 - 848.8MHz 1710.2 - 1784.8MHz 1850.2 – 1909.8MHz 1920.3 - 1979.7MHz 2400 – 2483.5MHz Production Unit or Identical Prototype (47 CFR §2..908) Identica…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FD1 Exhibit 11 Page 1 of 2 October 13, 2005 Supplement to SAR Test Report for Motorola portable cellular phone (FCC ID IHDT6FD1) Prepared by: Albert Patapack Motorola Personal Communications Sector Product Safety Laboratory Libertyville, Illinois APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FD1 Exhibit 11 Page 2 of 2 Summary of FCC request for additional information There was a request for additional information regarding Motorola’s SAR Test Report for Motorola portable cellular phone (FCC ID IHDT6FD1). The requested information is addressed below in the same numbering sequence received. 1. One DASY4 robot is listed as being past its cal due date (p.4 of the SAR report)- please address. Response: Testing began on 08-Sept-2005. At that time, the DASY4 DAE3 with serial number 365 was within calibration. During the testing, the DASY4 DAE3 with serial number 365 went out of calibration and was replaced by the DASY4 DAE4 with serial number 376. All testing was performed using a DASY DAE, either sn365 or sn376, which was within calibration at the time of the test. 2. There appears to be a typo in the frequency ranges listed in the table on p.3 of the SAR report- the GSM850 range is listed for GPRS. Please address. Response: There is a typo in the frequency ranges listed in the Device description table on p.3 of the SAR report. The following table has been corrected. FCC ID Number IHDT6FD1 Serial number FB13W2222G Mode(s) of Operation GSM 900 GSM 1800 GSM 1900 GPRS 900 GPRS 1800 GPRS 1900 UMTS 2100 BlueTooth Modulation Mode(s) GMSK GMSK GMSK GMSK GMSK GMSK QPSK GFSK Maximum Output Power Setting 32.00dBm 30.00dBm 30.00dBm 32.00dBm30.00dBm 30.00dBm 22.00dBm 4.00dBm Duty Cycle 1:8 1:8 1:8 2:8 2:8 2:8 1:1 1:1 Transmitting Frequency Rang(s) 880.2 - 914.8MHz 1710.2 - 1784.8 MHz 1850.2 – 1909.8MHz 880.2 - 914.8MHz 1710.2 - 1784.8MHz 1850.2 – 1909.8MHz 1920.3 - 1979.7MHz 2400 – 2483.5MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled

Date: October 13, 2005 Subject: Request for additional information regarding FCC ID: IHDT6FD1 (Portable PCS GSM transceiver) Reference: Application Received: 09/16/2005 Correspondence Reference Number: 150916A.IHD Confirmation Number: 1509160458/ 0463 Date of Original Email: 10/13/05 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Mobile Device Business Libertyville, Illinois Questions and responses follow: 1. One DASY4 robot is listed as being past its cal due date (p.4 of the SAR report)- please address. RESPONSE: Please reference Supplemental SAR Report submitted on October 13, 2005. 2. There appears to be a typo in the frequency ranges listed in the table on p.3 of the SAR report- the GSM850 range is listed for GPRS. Please address. RESPONSE: Please reference Supplemental SAR Report submitted on October 13, 2005. 3. Please correct the maximum head SAR value listed in the user’s manual to 0.64 (the actual measured level). RESPONSE: The manual has been updated. Please reference Exhibit 8A submitted on October 13, 2005. 1

APPLICANT: MOTOROLA INC FCC ID: IHDT6FD1 MOBILE DEVICES BUSINESS PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 16964-1 Report Date – September 23, 2005 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature Name: _Michael E. Hill Title: Senior Staff Electrical Engineer Date: September 23, 2005 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1846-01 EXHIBIT 6 APPLICANT: MOTOROLA INC FCC ID: IHDT6FD1 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configurations 5 Measuring Equipment and Calibration Information 5 Measurement Procedures and Data RF Power Output 6 Radiated Power (ERP) 7 Occupied Bandwidth 8 GSM 1900 Reference Plot 9 GSM 1900 Occupied Bandwidth Plot 9 GSM 1900 Ch512 Lower Band Edge 10 GSM 1900 Ch810 Upper Band Edge 10 Spurious Emissions at Antenna Terminals 11 GSM 1900 Tabular and Graphical Data 12 Field Strength of Spurious Emissions 13 GSM 1900 Tabular and Graphical Data 14 Frequency Stability 15 GSM 1900 Tabular and Graphical Data 16 Field Strength of Spurious Emissions from Unintentional Radiators 17 GSM 1900 Graphical Data 18 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 20 Figure A.2 – Substitution Measurement 20 Test Report Number: 16964-1 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT6FD1 Test Report Details Tests Performed By: Motorola Mobile Devices business Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 Motorola MDB FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908 Tests Requested By: Motorola Inc. Mobile Devices business 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: GSM 1900 Model Number: Tarazed Version: CFUG1160AA Serial Numbers: 356853000025447, 356853000025520, 356853000025470, 356853000025462 Testing Complete Date: September 23, 2005 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators Part 22 Subpart H - Public Mobile Services X Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 137-A, TIA EIA 98-C, ANSI 63.4 2001, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-133 (PCS) Test Report Number: 16964-1 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT6FD1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) Pass 3 Modulation Characteristics NA 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass 8 Field Strength of Spurious Emissions Pass from Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) 3.32 3 Modulation Characteristics NA 4 Occupied Bandwidth See Plots 5 Spurious Emissions at Antenna Terminal 25.6 dB 6 Field Strength of Spurious Emissions 1.8 dB 7 Frequency Stability 85 Hz 8 Field Strength of Spurious Emissions Below noise floor from Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Test Report Number: 16964-1 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT6FD1 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. ManufacturerEquipment TypeModel No.Serial Number Cal. Due Date Rohde & SchwarzReceiverESI26838786/0102/7/2006 Hewlett-PackardEMC Analyzer8593EM3536A0011810/2/2005 Hewlett-PackardEMC Analyzer7405US3944019111/13/2005 ETSDRG Horn Antenna26524555/25/2006 ETSDRG Horn Antenna311562222/9/2006 ETSLog-Periodic Antenna314811886/14/2006 ETSBiconical Antenna3110B33702/16/2006 AttenuatorWeinschelAS-6667510/14/2005 AttenuatorWeinschelAS-6667711/4/2005 Rohde & SchwarzMobile Test SetCMD 80DE29008N/A Hewlett-PackardSignal Generator83623B3844A011955/23/2006 ThermotronEnvironmental ChamberS-4315801/18/2006 Giga-TronicsPower Meter8651A865050812/27/2005 All equipment is on a one-year calibration cycle. Test Report Number: 16964-1 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT6FD1 Measurement Procedures and Data RF POWER OUTPUT Measurement Procedure The RF output port of the equipment under test is directly coupled to the input of a HPE4406A Vector Signal Analyzer through a 10dB passive attenuator, adaptor (if needed), and specialized RF connector. The peak power output is measured for all channels. CFR47 Part 2.1046 Measurement Results GSM 1900 Frequency (MHz) Power (dBm) 1850.20 30.08 1880.00 30.00 1909.80 30.07 Test Report Number: 16964-1 EXHIBIT 6 6 APPLICANT: MOTOROLA INC FCC ID: IHDT6FD1 RADIATED (ERP) Measurement Procedure The phone was tested in a 16’ anechoic chamber with a 2-axis position sy…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT6FD1 Appendix A – Radiated Emissions Test Setup Photos A.1 Radiated Emissions Measurement A.2 Substitution Measurement End of Test Report Test Report Number: 16964-1 EXHIBIT 6 19
