IHDT6FN1Portable PCS GSM Transceiver

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FN1 INSTRUCTION MANUAL An English version preliminary draft copy of the Users Manual follows. Note: Please disregard reference to “Bluetooth”, which is not applicable for FCC ID: IHDT6FN1. EXHIBIT 8 ENGLISH 1 Introduction Introduction Congratulationson being the owner of a brand new Motorola mobile phone. In addition to making calls, MMS, Email, and Internet access, you can use a good many other functions just like those of a Multimedia Palm, such as multifunction Address Book, Date Book, Note Pad, Audio Recorder, Camera, Paint, Media Center, My Document (File Manager), Bluetooth, Modem and Data Synchronizer. Wireless GPRS downloading will extend your phone functions and close up to your life. The product brings innovative concepts to mobile communication with its colorful touch screen and graphic interfaces, which offer streamlined operation, enhanced functionality, and "One- Touch" information acquisition and processing. It is designed with a unique open display window to deliver you more careful consideration and make your info fetching more convenient and rapid. Either in office or at home, you'll feel more delighted with a distinct function that sends your Date Book in short messages. You'll enjoy your creativeness by composing pictures, photos, animations, and musical pieces in your individual style with the Paint and distributing them in short messages. The new Media Center will provide you with audio and video refreshment in your spare time. The unique Camera function makes it possible to share wonderfulness with your friends any- where and anytime, by taking pictures simply and easily. Although the product is excellently designed for wonderfulness, you can only make perfect use of it with your understanding and imagination. Look into the manual and see how you can enter a splendid world of communication. Introduction ENGLISH Introduction 2 Introduction Copyright Description 1. Java and all other Java-based logos are all trademarks or registered trademarks of SUN Corporation in America or other countries. 2. The product adopts "iType" technology and font of Agfa Monotype Corporation. 3. Refer to the Appendix for GNU copyright information. ENGLISH 3 Contents Contents Contents Introduction Congratulations Safety Information Chapter 1 Getting Started Functions of External Keys SIM Card, Battery Charging the Battery Turning on Your Phone Turning off Your Phone Screen Display and Operation Functions of External Display (when flip closed) About terms and pictures used in the manual to describe operations Chapter 2 Entry Methods Handwriting Pinyin Board English Board Numeric Pad Functional Buttons ENGLISH Contents 4 Contents Chapter 3 Phone Function Sending a Phone Call Dialing an Emergency Number Receiving a Phone Call Dialing an International Call Directly Dialing Extension or Voicemail Dialing an Extension Number In-Call Functions Turbo Dial Dialing a Number Stored in SIM Card Multiparty Conversation (Making a Conference Call) Transferring a Call Calls Record Call Cost My Tel. Number Network Setup Chapter 4 Address Book Showing Address Book List Adding New Contacts Copying Contact Data Information ENGLISH 5 Contents Contents Deleting a Contact Searching for a Contact Viewing Owner's Information Sending Vcards Chapter 5 Message Center Inbox Viewing Messages Writing a Short Message Signature Setup Sending a Message Outbox Drafts Trash SIM Card Private Folder MMS Chapter 6 Email Mailbox Setup Writing and Sending Emails ENGLISH Contents 6 Contents Receiving, Viewing, Reading a Mail or Sorting Mails Private Folder Chapter 7 Browser Activating WAP Browser Browsing Information and Using Access Function Downloading Files Chapter 8 Camera View-Finding Shoot Preview or Delete Video or Photo Effects Setup Options Chapter 9 Media Center Playing Audio and Video Files Chapter 10 Picsel Browser View Special Functions Preferred Setting ENGLISH 7 Contents Contents Chapter 11 Date Book Month View Day View Week View Adding a New Event Editing an Event Deleting an Event Date Book Setup Chapter 12 Tasks Viewing Tasks Creating, Editing, and Saving a Task Chapter 13 Note Pad Chapter 14 Paint Chapter 15 Recorder Chapter 16 My Document Editing Files and Folders Creating a New Folder Viewing by ENGLISH Contents 8 Contents Sorting Searching Folder Tree Chapter 17 Share Receiving Data Sending Data Chapter 18 Alarm Clock and Worldwide Clock Alarms Worldwide Clock Chapter 19 Calculator Chapter 20 Bluetooth Turning on Bluetooth Viewing, Adding, and Setting Bluetooth Devices Using Bluetooth for Information Transmission Chapter 21 STK Application Chapter 22 Network Network ENGLISH 9 Contents Contents Profiles Chapter 23 Security Chapter 24 Theme Selecting a theme Configuring a theme Chapter 25 Setup Language Time and Date Volume Setup Entry Setup Touch Screen Calibration Backlight Setup Voice Recognition Setup Infrared Receiving Power Management Master Reset Master Clear ENGLISH Contents 10 Contents Chapter 26 Voice Instruction Loading Voice Recognition Using Voice Recognition Reciting List of Voice Instruction and Functions Chapter 27 Data Synchronization Chapter 28 Modem Chapter 29 VPN (Virtual Private Network) Creating New Policy Logging into the VPN Chapter 30 Troubleshooting Chapter 31 Specific Absorption Rate This model phone meets the international requirements for exposure to radio waves. Chapter 32 Appendix Note:The functions available on this mobile phone may vary in different regions and nations. Please contact your local customer service centers, agencies or retailers if you have any question about the mobile phone functions. Motorola reserves all rights to revise and change this user's manual without obligation to notify any person of such revisions or changes. 11 Safety Information Safety Information IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS INFOR- MATION BEFORE USING YOUR PHONE. The information provided in this document supersedes the gener…

Text truncated - open the document above for the full version.

APPLICANT MOTOROLA INC. FCC ID: IHDT6FN1 ATTESTATION STATEMENTS Transceiver type FCC ID: IHDT6FN1 has been tested in accordance with the requirements contained in the appropriate Commission regulations. To the best of my knowledge, these tests were performed using measurement procedures consistent with industry or Commission standards and demonstrate that this equipment complies with the appropriate standards. Each unit manufactured imported or marketed, will conform to the sample tested within the variations that can be expected due to quantity production and testing on a statistical basis. I further certify that the necessary measurements were made at Motorola, located at 600 N. US Highway 45, Libertyville, Illinois. NAME: BOB CHAN TITLE: VP OF ENGINEERING, MOBILE DEVICE EXHIBIT 2A APPLICANT MOTOROLA INC. FCC ID: IHDT6FN1 STATEMENT OF CERTIFICATION I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in this application and accompanying technical data are true and correct. The technical data supplied with this application was taken under my supervision and is hereby duly certified. I also certify that this transmit equipment (FCC ID: IHDT6FN1) is in compliance with all applicable parts of the FCC Rules. NAME: LUO HONG YONG TITLE: SR. RF ENGINEER, MOBILE DEVICE Date: 5/13/2005 EXHIBIT 2B

APPLICANT: MOTOROLA FCC ID: IHDT6FN1 May 9, 2005 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Cellular/PCS Transceiver Certification Gentlemen: Application: Motorola, Inc., Personal Communications Sector, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization for Certification of a Cellular Transceiver, FCC ID: IHDT6FN1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 10 Parts List • Exhibit 12 Operational Description Description: This equipment is a GSM portable transceiver, which operates in 1900 MHz PCS band. Note: This device contains 900 MHz and 1800 MHz GSM, functions which are not operational in U.S. territories. Contact Information: Please contact me by telephone at (847) 523-6167, or by e-mail ( [email protected]), if there are questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Personal Communications Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343 Exhibit 13

Date: June 21, 2005 Subject: Request for additional information regarding FCC ID: IHDT6FN1 (Portable PCS GSM transceiver) Reference: Application Received: 05/18/2005 Correspondence Reference Number: 250519A.IHD Date of Original Email: 05/19/05 Prepared by: Andrew Bachler, Principal Staff Engineer Motorola Personal Communications Sector Libertyville, Illinois Questions and responses follow: 1. No EMC Test Report was submitted- please do so. RESPONSE: The EMC report was submitted on 6-21-05. 2. The Operational Description lists multi-slot GPRS operation (2U/4D), however, the SAR report only includes single-slot GPRS data (crest factor = 8). Please submit SAR data for multi-slot GPRS operation. RESPONSE: This phone model, FCC ID: IHDT6FN1, does not include multi-slot operation (2U/4D). The SAR Report is correct. 3. The Operational Description mentions EDGE. Does the EUT have EDGE operation available to it? If so, SAR data for this mode must be submitted. RESPONSE: This phone, FCC ID: IHDT6FN1, does not include EDGE operation. 4. The external photos attachment appears to have been corrupted, and will not display the photos. Please resubmit. RESPONSE: External photographs were resubmitted on 5-19-05. 5. The internal photos are very fuzzy- please submit clearer internal photos. RESPONSE: Internal photographs were resubmitted on 5-19-05. 6. The SAR test report has been locked such that it may not be printed. Please submit a new SAR report (and the EMC report) for which printing has not been locked out. RESPONSE: The SAR report was resubmitted on 5-19-05 with printing properties enabled. 1

EXHIBIT3 RearViewwithBatteryCover RemovedShowingIDLabel RearView FrontViewFlipOpend FrontView APPLICANT: MOTOROLAFCC ID: IHDT6FN1 APPLICANT: MOTOROLA, INC.FCC ID: IHDT56FN1 EXHIBIT 3A Flip Opened Rear View Flip Opened

APPLICANT: MOTOROLA INC. FCC ID: IHDT6FN1 FCC IDENTIFICATION (NAMEPLATE) INFORMATION FCC ID: IHDT6FN1 The FCC label shown is representative of the label that will appear on the radio when in production. It will be placed on the outside of the equipment as shown in Exhibit 3. Other information may also be included on this label. EXHIBIT 1

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FN1 EXHIBIT 9 Front View Rear View Rear View without shields APPLICANT: MOTOROLA, INC.FCC ID: IHDT56FN1 EXHIBIT 9 Front View Rear View Rear View without shields

APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FN1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 1 1 Exhibit 11: SAR Test Report IHDT6FN1 Date of test: Date of Report: 04/23/2005 to 05/12/2005 05/13/2005 Laboratory: Motorola Personal Communications Sector Product Safety & Compliance Laboratory 600 N. US Highway 45 Room: MW113 Libertyville, Illinois 60048 Test Responsible: Albert Patapack Senior Staff Engineer Accreditation: This laboratory is accredited to ISO/IEC 17025-1999 to perform the following tests: Tests : Procedures: Electromagnetic Specific Absorption Rate ANSI/IEEE C95.1-1992, 1999 (SAR) IEEE C95.3-1991 IEEE 1528, IEC 62209-1 FCC OET Bulletin 65 (including Supplements A, B, C) Australian Communications Authority Radio Communications (Electromagnetic Radiation – Human Exposure) Standard 1999 CENELEC EN 50361 (2001) Simulated Tissue Preparation APP-0247 RF Power Measurement DOI-0876, 0900, 0902, 0904, 0915 On the following products or types of products: Wireless Communications Devices (Examples): Two Way Radios; Portable Phones (including Cellular, Licensed Non-Broadcast and PCS); Low Frequency Readers; and Pagers A2LA certificate #1651-01 Statement of Compliance: Motorola declares under its sole responsibility that portable cellular telephone FCC ID IHDT6FN1 to which this declaration relates, is in conformity with the appropriate General Population/Uncontrolled RF exposure standards, recommendations and guidelines (FCC 47 CFR §2.1093). It also declares that the product was tested in accordance with the appropriate measurement standards, guidelines and recommended practices. Any deviations from these standards, guidelines and recommended practices are noted below: (none) ©Motorola, Inc. 2005 This test report shall not be reproduced except in full, without written approval of the laboratory. The results and statements contained herein relate only to the items tested. The names of individuals involved may be mentioned only in connection with the statements or results from this report. Motorola encourages all feedback, both positive and negative, on this test report. APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FN1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 2 2 Table of Contents 1. INTRODUCTION ...................................................................................................................................................3 2. DESCRIPTION OF THE DEVICE UNDER TEST.............................................................................................3 2.1 Antenna description ..............................................................................................................................................3 2.2 Device description..................................................................................................................................................3 3. TEST EQUIPMENT USED....................................................................................................................................4 3.1 Dosimetric System .................................................................................................................................................4 3.2 Additional Equipment...........................................................................................................................................4 4. ELECTRICAL PARAMETERS OF THE TISSUE SIMULATING LIQUID ..................................................5 5. SYSTEM ACCURACY VERIFICATION............................................................................................................5 6. TEST RESULTS......................................................................................................................................................6 6.1 Head Adjacent Test Results..................................................................................................................................7 6.2 Body Worn Test Results .......................................................................................................................................9 APPENDIX 1: SAR DISTRIBUTION COMPARISON FOR SYSTEM ACCURACY VERIFICATION .....11 APPENDIX 2: SAR DISTRIBUTION PLOTS FOR PHANTOM HEAD ADJACENT USE ..........................12 APPENDIX 3: SAR DISTRIBUTION PLOTS FOR BODY WORN CONFIGURATION ..............................13 APPENDIX 4: PROBE CALIBRATION CERTIFICATE ..................................................................................14 APPENDIX 5: MEASUREMENT UNCERTAINTY BUDGET..........................................................................15 APPENDIX 6: PHOTOGRAPHS OF DEVICE UNDER TEST...........................................................................18 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6FN1 E E x x h h i i b b i i t t 1 1 1 1 P P a a g g e e 3 3 1 Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable cellular phone (FCC ID IHDT6FN1). The Specific Absorption Rate (SAR) of this product was measured. The portable cellular phone was tested in accordance with FCC OET Bulletin 65 Supplement C 01-01. 2 Description of the Device Under Test 2.1 Antenna description Type External Location Upper Right Corner Length 24mm Dimensions Width 10mm Configuration Helix 2.2 Device description FCC ID Number IHDT6FN1 Serial number 356483000000073 Mode(s) of Operation GSM 900 GSM 1800 GSM 1900 GPRS 900 GPRS 1800 GPRS 1900 Modulation Mode(s) GSM GSM GSM GSM GSM GSM Maximum Output Power Setting 32.50 dBm 29.50 dBm 29.50 dBm 32.50 dBm 29.50 dBm 29.50 dBm Duty Cycle 1:8 1:8 1:8 1:8 1:8 1:8 Transmitting Frequency Rang(s) 880.2- 914.8MHz 1710.2- 1784.8MHz 1850.20 – 1909.80MHz 880.2- 914.8MHz 1710.2- 1784.8MHz 1850.20 – 1909.80MHz Production Unit or Identical Prototype (47 CFR §2..908) Identical Prototype Device Category Portable RF Exposure Limits General Population / Uncontrolled APPLICANT: MOTOROLA, INC. F…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT6FN1 PERSONAL COMMUNICATIONS SECTOR PRODUCT SAFETY AND COMPLIANCE EMC LABORATORY EMC TEST REPORT Test Report Number – 16187-2 Report Date – June 21, 2005 The test results contained herein relate only to the model(s) identified. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated . Signature: Name: _Michael E. Hill Title: Senior Staff Electrical Engineer Date: June 21, 2005 This report must not be reproduced, except in full, without written approval from this laboratory. THIS REPORT MUST NOT BE USED TO CLAIM PRODUCT ENDORSEMENT BY A2LA OR ANY AGENCY OF THE U.S. GOVERNMENT. A2LA Certificate Number: 1846-01 EXHIBIT 6 APPLICANT: MOTOROLA INC FCC ID: IHDT6FN1 Table of Contents Description Page Test Report Details 3 Applicable Standards 3 Summary of Testing 4 General and Special Conditions 4 Equipment and Cable Configurations 5 Measuring Equipment and Calibration Information 5 Measurement Procedures and Data RF Power Output 6 Radiated Power (ERP) 7 Occupied Bandwidth 8 GSM 1900 Reference Plot 9 GSM 1900 Occupied Bandwidth Plot 9 GSM 1900 Ch512 Lower Band Edge 10 GSM 1900 Ch810 Upper Band Edge 10 Spurious Emissions at Antenna Terminals 11 GSM 1900 Tabular and Graphical Data 12 Field Strength of Spurious Emissions 13 GSM 1900 Tabular and Graphical Data 14 Frequency Stability 15 GSM 1900 Tabular and Graphical Data 16 Field Strength of Spurious Emissions from Unintentional Radiators 17 GSM 1900 Tabular and Graphical Data 18 Appendix A - Radiated Emissions Test Setup Photos Figure A.1 – Radiated Emissions Measurement 19 Figure A.2 – Substitution Measurement 19 Test Report Number: 16187-2 EXHIBIT 6 2 APPLICANT: MOTOROLA INC FCC ID: IHDT6FN1 Test Report Details Tests Performed By: Motorola Mobile Devices Business Product Safety and Compliance Group 600 North US Hwy 45 Libertyville, IL 60048 PH (847) 523-6167 Fax (847) 523-4538 Motorola PCS FRN: 0004321311 FCC Registration Number: 316588 Industry Canada Number: IC3908 Tests Requested By: Motorola Inc. Mobile Devices Business 600 North US Hwy 45 Libertyville, IL 60048 Product Type: Cellular Phone Signaling Capability: GSM 1900 Model Number: A728 Version: CHWF1403AA Serial Numbers: 356483000000347, 356483000000370 Testing Complete Date: June 21, 2005 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47 Part 2, Sub-part J as well as the following parts: X Part 15 Subpart B – Unintentional Radiators Part 22 Subpart H - Public Mobile Services X Part 24 - Personal Communications Services Part 90 - Private Land Mobile Radio Service Applicable Standards: TIA EIA 137-A, TIA EIA 98-C, ANSI 63.4 2001, RSS-118 (AMPS), RSS-128 (TDMA), RSS-129 (CDMA), RSS-133 (PCS) Test Report Number: 16187-2 EXHIBIT 6 3 APPLICANT: MOTOROLA INC FCC ID: IHDT6FN1 Summary of Testing Test Test Name # Pass/Fail 1 RF Power Output NA 2 ERP (Effective Radiated Power) Pass 3 Modulation Characteristics NA 4 Occupied Bandwidth Pass 5 Spurious Emissions at Antenna Terminal Pass 6 Field Strength of Spurious Emissions Pass 7 Frequency Stability Pass 8 Field Strength of Spurious Emissions Pass from Unintentional Radiators Test Test Name Margin with respect # to the Limit_________ 1 RF Power Output NA 2 ERP (Effective Radiated Power) 2.15 3 Modulation Characteristics NA 4 Occupied Bandwidth See Plots 5 Spurious Emissions at Antenna Terminal 29.3 dB 6 Field Strength of Spurious Emissions 0.7 dB 7 Frequency Stability 65 Hz 8 Field Strength of Spurious Emissions Below noise floor from Unintentional Radiators The margin with respect to the limit is the minimum margin for all modes and bands. ( ) indicates the margin at which the product exceeds the limit. General and Special Conditions The EUT was tested using a fully charged battery when applicable. Where a battery could not be used due to the need for a controlled variation of input voltage, an external power supply was utilized. All testing was done in an indoor controlled environment with an average temperature of 22º C and relative humidity of 50%. Test Report Number: 16187-2 EXHIBIT 6 4 APPLICANT: MOTOROLA INC FCC ID: IHDT6FN1 Equipment and Cable Configurations The EUT was tested in a stand-alone configuration that is representative of typical use. Measuring Equipment and Calibration Information ManufacturerEquipment TypeModel No.Serial Number Cal. Due Date Rohde & SchwarzReceiverESI26838786/0102/7/2006 Hewlett-PackardEMC Analyzer7405US394401911/27/2006 MiteqPreamplifier 0.1-26.5GHzNSP2650-NF-S966350N/A ETSDRG Horn Antenna311562222/9/2006 A.H. Systems Inc.DRG Horn AntennaSAS-2--/5713655/25/2006 ETSLog-Periodic Antenna314811887/15/2005 ETSBiconical Antenna3110B337011/14/2005 AttenuatorWeinschelAS-6667510/14/2005 AttenuatorWeinschelAS-6667711/4/2005 Hewlett-PackardSignal Generator83623B3844A011956/20/2006 ThermotronEnvironmental ChamberS-4315801/17/2006 AgilentPower MeterEE4418BGB4020638812/5/2005 AgilentPower SensorE4412BUS3848632112/5/2005 Hewlett-PackardPre-Amplifier8447F2805A034193/24/2006 All equipment is on a one-year calibration cycle. Test Report Number: 16187-2 EXHIBIT 6 5 APPLICANT: MOTOROLA INC FCC ID: IHDT6FN1 Measurement Procedures and Data RF POWER OUTPUT Measurement Procedure The RF output port of the equipment under test is directly coupled to the input of a HPE4406A Vector Signal Analyzer through a 10dB passive attenuator, adaptor (if needed), and specialized RF connector. The peak power output is measured for all channels. CFR47 Part 2.1046 Measurement Results GSM 1900 Frequency (MHz) Power (dBm) 1850.20 29.48 1880.00 29.48 1909.80 29.48 Test Report Number: 16187-2 EXHIBIT 6 6 APPLICANT: MOTOROLA INC FCC ID: IHDT6FN1 RADIATED (ERP) Measureme…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA INC FCC ID: IHDT6FN1 Appendix A – Radiated Emissions Test Setup Photos A.1 Radiated Emissions Measurement A.2 Substitution Measurement End of Test Report Test Report Number: 16187-2 EXHIBIT 6 20
