APPLICANT: MOTOROLA, INC.FCC ID: IHDT6NF1 Exhibit 8 INSTRUCTION MANUAL The following is a preliminary draft copy of the instruction manual. Welcome The future of global telecommunications is here—a satellite telephone, providing you with communication all over the world. The company that brought you the world’s first commercially available cellular phone has done it again! Motorola proudly introduces its Satellite Series 9505 Portable Phone for the Iridium ® system. All Motorola wireless phones are designed and manufactured to meet Motorola’s exacting specifications and world-class quality standards. During development, our laboratory testing team took the durable phone through rigorous durability tests including temperature, humidity, shock, dust, vibration, and drop tests—and it still worked! We are confident that the phone you purchased meets your own exacting standards. Thank you for choosing Motorola, a global leader in communications technology. Enjoy your new Satellite Series 9505 Portable Phone! ii iii Contents Safety Information . . . . . . . . . . . . . . . . . . . . . . . . .7 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11 Guide Overview. . . . . . . . . . . . . . . . . . . . . . . . .12 Phone Overview . . . . . . . . . . . . . . . . . . . . . . . .15 Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18 Original Satellite Series Accessories. . . . . . . . .21 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . .27 Attaching the Satellite Antenna . . . . . . . . . . . . .28 What Is a SIM Chip? . . . . . . . . . . . . . . . . . . . . .29 Installing the SIM Chip . . . . . . . . . . . . . . . . . . .30 Removing the Battery Cover . . . . . . . . . . . . . . .31 Installing the Battery . . . . . . . . . . . . . . . . . . . . .32 Charging the Battery . . . . . . . . . . . . . . . . . . . . .36 Checking the Battery. . . . . . . . . . . . . . . . . . . . .38 Battery Information . . . . . . . . . . . . . . . . . . . . . .40 Installing the Cellular Cassette . . . . . . . . . . . . .41 Using Your Phone . . . . . . . . . . . . . . . . . . . . . . . .43 Using Your Phone Feature Overview. . . . . . . . .44 Powering Up the Phone. . . . . . . . . . . . . . . . . . .45 Holding the Phone. . . . . . . . . . . . . . . . . . . . . . .48 Placing a Call . . . . . . . . . . . . . . . . . . . . . . . . . .49 Ending a Call . . . . . . . . . . . . . . . . . . . . . . . . . . .53 What’s My SIM Chip Phone Number? . . . . . . . .54 Receiving a Call . . . . . . . . . . . . . . . . . . . . . . . .55 Adjusting Earpiece Volume . . . . . . . . . . . . . . . .58 Adjusting Ringer Volume . . . . . . . . . . . . . . . . . .59 Using In-Call Features . . . . . . . . . . . . . . . . . . . .61 In-Call Feature Overview . . . . . . . . . . . . . . . . . .62 + Muting a Call . . . . . . . . . . . . . . . . . . . . . . . . .63 Using Call Waiting . . . . . . . . . . . . . . . . . . . . . . .64 Placing a Call on Hold. . . . . . . . . . . . . . . . . . . .66 r Sending a Flash . . . . . . . . . . . . . . . . . . . . . . .68 Using the Menus . . . . . . . . . . . . . . . . . . . . . . . . .69 Using the Options Menus . . . . . . . . . . . . . . . . .70 + Using the Quick Access Menu . . . . . . . . . . .72 iv Using The In-Call Menu . . . . . . . . . . . . . . . . . . 74 Managing the Phone Book . . . . . . . . . . . . . . . . 75 Entering the Phone Book Menu . . . . . . . . . . . . 76 What’s on the Phone Book Menu? . . . . . . . . . . 77 Organizing Your Phone Book . . . . . . . . . . . . . . 79 Storing Names and Numbers . . . . . . . . . . . . . . 81 Entering Names . . . . . . . . . . . . . . . . . . . . . . . . 83 Using Pauses in Numbers . . . . . . . . . . . . . . . . 85 + Using Phone Number Prefixes . . . . . . . . . . . 87 Locating Entries . . . . . . . . . . . . . . . . . . . . . . . . 88 Calling, Modifying, or Erasing an Entry . . . . . . 90 + Checking Phone Book Capacity . . . . . . . . . . 91 + Preventing Access to the Phone Book . . . . . 92 + Restricting Phone Use. . . . . . . . . . . . . . . . . . 93 Viewing the Last Ten Numbers Dialed . . . . . . . 98 Viewing and Modifying Your Phone Numbers . 99 + Using One-Touch Dialing . . . . . . . . . . . . . . 101 Viewing Service Dialing Numbers . . . . . . . . . 102 Using Calling Features . . . . . . . . . . . . . . . . . . 103 Entering the Call Related Features Menu. . . . 104 What’s on the Call Related Features Menu? . . 105 Forwarding Calls When Unavailable . . . . . . . 107 Forwarding All Your Calls . . . . . . . . . . . . . . . . 109 Using Detailed Call Forwarding . . . . . . . . . . . 111 Canceling All Forwarding . . . . . . . . . . . . . . . . 114 + Showing the Battery Meter . . . . . . . . . . . . . 115 + Showing Signal Strength . . . . . . . . . . . . . . . 116 + Deactivating Pending Call Drop Signal. . . . 117 + Activating Call Waiting . . . . . . . . . . . . . . . . 118 Restricting Calls with Call Barring . . . . . . . . . 119 Using Message Services . . . . . . . . . . . . . . . . . 123 Entering the Messages Menu. . . . . . . . . . . . . 124 Messages Services Feature Overview . . . . . . 125 What’s on the Messages Menu?. . . . . . . . . . . 126 + Checking Your Voicemail . . . . . . . . . . . . . . 128 + Storing Your Voicemail Number . . . . . . . . . 129 Managing Your Messages . . . . . . . . . . . . . . . 130 Accessing Messages . . . . . . . . . . . . . . . . . . . 132 Customizing Phone Features . . . . . . . . . . . . . 135 Entering the Phone Setup Menu. . . . . . . . . . . 136 v Phone Setup Feature Overview. . . . . . . . . . . .137 What’s on the Phone Setup Menu? . . . . . . . . .138 Adjusting the Ringer Volume . . . . . . . . . . . . .140 + Setting the Phone to Ring or Vibrate . . . . . .141 + Setting the Ringer Tone . . . . . . . . . . . . . . . .142 + Setting the Keypad Tones . . . . . . . . . . . . . .143 Locking and Unlocking Your Phone . . . . . . . .144 Protecting the SIM chip . . . . . . . . . . . . . .…

Text truncated - open the document above for the full version.

SYN0089 1 SYN7391 SAF5350 TITLE ENG. ISSUE LETTER MEMO NO. PART NO. DRN. BY DEPT. NO. LIBVIL SCHM ARL.HTS ARIZ J SCHMITZ PACKAGE INSERT QA888 MARY MORGAN 9-10-99 68-88303K01 When attached to your phone properly, the antenna adapter/ portable auxiliary antenna system complies with the standards and recommendations for the protection of public exposure to RF electromagnetic energy outlined in the phone's user manual. Compliance with these standards is contingent on the following: To assure that radio frequency (RF) energy exposure to bystanders is lower than that recommended by the adopted standard, operate the phone with an attached auxiliary antenna only when the antenna is positioned at least 20 cm (8 inches) away from the user or bystanders. DO NOT operate the telephone unless all RF connectors are secure and open connectors are properly terminated. DO NOT operate the phone near electrical blasting caps, or in an explosive atmosphere. SAF5340 SAF2040 3 2 SYN7910 SKN6121

APPLICANT: MOTOROLA, INC.FCC ID: IHDT6NF1 Exhibit 2 STATEMENT OF CERTIFICATION The technical data supplied with this application, having been taken under my supervision is hereby duly certified. The is a statement of my qualifications: BSEE 1984 Northwestern University, Evanston, Illinois MSEE 1991 Illinois Institute of Technology, Chicago, Illinois 15 years experience in engineering design, 8 years experience in Cellular Radiotelephone and Systems Design SIGNATURE: NAME:John D. Pradal DATE:8/30/99 POSITION:Engineering Manager I hereby certify that the above application was prepared under my direction and that to the best of my knowledge and belief, the facts set forth in the application and accompanying technical data are true and correct. SIGNATURE: NAME:Martin Seitz DATE:8/30/99 POSITION:Director of Engineering

APPLICANT: MOTOROLAFCC ID: IHDT6NF1 Exhibit 13 August 30, 1999 CONFIDENTIALITY REQUEST CONTAINED WITHIN Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, Maryland 21046 Re: Application for Portable Satellite Transceiver Certification Gentlemen: Application: Motorola, Inc., Pan American Cellular Subscriber Group, 600 N. U.S. Highway 45, Libertyville, Illinois 60048-1286 herein submits: Application for Equipment Authorization (FCC Form 731- October 1992 with integrated Fee Processing Form, Fee Codes EFT and EBT), Check Number 04-42489 in the amount of $610 and Exhibits, for Certification of a Portable Satellite Transceiver, FCC ID: IHDT6NF1. Motorola is also the manufacturer of this equipment. Confidentiality: Pursuant to Section 0.459 of the Commission's rules (CFR 47), Motorola requests confidentiality for portions of the material contained in this application and that the identified material be withheld from public inspection following the grant of this authorization. This material contains Motorola's trade secrets and confidential information that Motorola does not customarily release to the public and which is otherwise not generally available to the public. Confidentiality is requested for the following exhibits: • Exhibit 4 Block Diagrams • Exhibit 5 Schematics • Exhibit 12 Operational Description Description: This equipment is a portable transceiver that has the capability to operate in the 1.6 GHz Iridium  Satellite system. Contact Information: Please contact me by telephone at (847) 523-6167, by facsimile at (847) 523-2350, or by e-mail ([email protected]), if there are any further questions or additional information needed concerning this filing. Regards, Andrew J. Bachler FCC Liaison Cellular Subscriber Sector 600 N. U.S. Highway 45 Libertyville, IL 60048-5343

APPLICANT: MOTOROLA INC. FCC ID: IHDT6NF1 Exhibit 9-1 APPLICANT: MOTOROLA INC. FCC ID: IHDT6NF1 Exhibit 9-2

APPLICANT: MOTOROLA FCC ID: IHDT6NF1 Exhibit 3-1 APPLICANT: MOTOROLA INC. FCC ID:IHDT6NF1 Exhibit 3-2

APPLICANT: MOTOROLA, INC.FCC ID: IHDT6NF1 Exhibit 1 FCC ID: IHDT6NF1 The Equipment ID label above is representative (in size and in showing the FCC Identifier as it will appear) of the label that is presently planned to appear on the equipment when in production. Its planned location is shown in Exhibit 3.

APPLICANT: MOTOROLA INC. FCC ID: IHDT6NF1 Exhibit 9-1 APPLICANT: MOTOROLA INC. FCC ID: IHDT6NF1 Exhibit 9-2

APPLICANT: MOTOROLA, INC.FCC ID: IHDT6NF1 Exhibit 10 TRANSCEIVER ADJUSTMENTS There are no user accessible adjustments or tuning in the mobile satellite transceiver. All necessary adjustments and tuning are performed during manufacture of the product. Any adjustments or tuning after service also require special equipment and cannot be performed by the user.

August 26, 1999 SAR Test Report for Motorola portable satellite transceiver (FCC ID IHDT6NF1). Prepared by: Paul Moller, Principal Staff Engineer Motorola Personal Communications Sector Product Safety Laboratory Libertyville, Illinois Contents 1) Introduction 2) Applicable Regulations 3) Description of Test Sample 4) Description of Motorola SAR Test Facility 5) Test Sample Conditions 6) Method of Measurement 7) Measurement Uncertainty 8) SAR Test Results 9) Body Worn Configuration Evaluation 10) External Antenna Option Evaluation 11) Battery Options 12) Summary Appendix A: Included Data from Measurements Against Phantom Head Appendix B: Measurement Probe Calibration Certificate Appendix C: Printout from the Dasy measurement system validation test Appendix D: Dasy Users Manual (first page) 1. Introduction The Motorola Personal Communications Sector Product Safety Laboratory has performed measurements of the maximum potential exposure to the user of portable satellite transceiver FCC ID IHDT6NF1. The Specific Absorption Rate (SAR) of this product was measured. This report details the test setup and equipment as well as the results of those tests. 2. Applicable Regulations Federal Communications Commission rule §2.1093(d)(2), the ANSI/IEEE C95.1 1992 and the NCRP Report Number 86 specify the maximum exposure limit of 1.6 W/kg as averaged over any 1 gram of tissue for portable devices being used within 20cm of the user in the uncontrolled environment. 3. Description of Test Sample A prototype unit serial number 081099-2 was measured. This unit is identical in physical construction, maximum radiated power levels and antenna structure to units that will be in production. It transmits in the frequency range of 1616 to 1626 MHz. The unit was tested at its maximum transmitter power. The unit is equipped with a telescoping quadrifilar helix antenna that serves as both a receive and transmit antenna. The operation of the Iridium™ system is such that the subscriber unit must be in communication with satellites in low earth orbit. This means that the subscriber units antenna must have a clear view of the sky above the users head at all times. Thus the antenna is designed so as to have three positions. The first position is the “stowed” position where the antenna is rotated behind the subscriber unit. In this position the user would not be able to place or receive a phone call. This position is available for convenience of storage. The second position is the “retracted” position where the antenna is pointed towards the zenith, but is kept in its shortened telescoping dimension. The third position is were the antenna is also pointed towards the zenith, but is in its long telescoping dimension referred to as the “extended position”. Furthermore, the antenna can rotate to either of two detented positions which are roughly 30 degrees to the left and roughly 30 degrees to the right. These are intended to keep the antenna pointed to the zenith in both the left and right handed talk positions. Figures 1 and 2 show the front and back of the unit respectively. P P a a g g e e 3 3 Figure 1. Front of Transceiver Figure 2. Back of Transceiver Showing Stowed Antenna Figures 3 and 4 show the test unit as it is placed onto the phantom with the antenna in the extended and retracted positions respectively. For the purposes of the actual SAR tests the Motorola phantom head is tilted on its side by 90 degrees so that a vertically oriented measurement probe can easily scan an area where the phone is in close contact with the phantom and the SAR will be the highest. Figure 3. Transceiver Against Head Figure 4. Transceiver Against Head with Antenna Extendedwith Antenna Retracted P P a a g g e e 4 4 4. SAR Test Facility The Motorola test facility utilized for the SAR testing of this product is the Personal Communications Sector Product Safety Laboratory, in Libertyville Illinois. The laboratory utilizes a Dosimetric Assessment System (Dasy™) SAR measurement system manufactured by Schmid & Partner Engineering AG (SPEAG™), of Zurich Switzerland. This system utilizes a computer controlled six axis robot to move a measurement probe to measure the SAR. A photo of the Dasy system with the Motorola phantom is shown in figure 5. Probe serial number 1375 was used for the measurements. It was calibrated at SPEAG™, and has a calibration date July 1, 1999. A copy of the calibration certificate is included as appendix B. Dipole Validation Kit type D1800V2, serial number 226 was used to validate the system accuracy at 1800MHz. The validation SAR value is 39.9 mW/g normalized to 1 Watt, and the Dasy system used for the test phone measured 40.8 mW/g normalized to 1 Watt. This is within the required accuracy, and thus the measured SAR values are considered correct. See appendix C for printout of the validation test from the Dasy measurement system. The measurement methodology is described in IEEE Transactions on Vehicular Technology, vol. 44, no. 3, August 1995, titled Electromagnetic Energy Exposure of Simulated users of Portable Cellular Telephones. The Dasy system is operated per the instructions in the Dasy Users Manual. A copy of the title page of this manual is included as appendix D. The entire manual is available directly from SPEAG. P P a a g g e e 5 5 Figure 5. Dasy System used for measurements 5. Test Sample Conditions For the purposes of these tests the subject phone was positioned on the measurement phantom per the instructions in the Motorola users manual for the subject phone (See figures 3 and 4). The position used for the tests is the 3-point contact position. In this position the test sample contacts the phantom’s ear and cheek and is positioned with a repeatability of better than ±6%. SAR was measured in both the retracted and extended antenna positions. Due to the construction of the phone, the base of the antenna is 65 mm away from the phantom for the phantom head. The test sample is capable of operation in a t…

Text truncated - open the document above for the full version.

P P a a g g e e 1 1 October 11, 1999 Supplement to SAR Test Report for Motorola portable cellular phone (FCC ID IHDT6NF1). Prepared by: Paul Moller, Senior Electrical Engineer Motorola Personal Communications Sector Product Safety Laboratory Harvard, Illinois Contents 1) Summary of FCC request for additional information 2) Conductivity value of the simulated tissue 3) Satellite mode SAR evaluation with cellular phone modules installed 4) Summary Appendix A: Included data P P a a g g e e 2 2 1. Summary of FCC request for additional information There was a request for additional information regarding Motorola’s SAR Test Report for Motorola portable satellite transceiver (FCC ID IHDT6NF1) dated August 26, 1999. The requested information may be summarized as follows: A) There is a need to re-confirm the conductivity value of the simulated tissue. B) The need to conduct SAR evaluation with applicable cellular phone modules installed in the portable satellite transceiver. 2. Conductivity value of the simulated tissue. The Motorola portable satellite transceiver (FCC ID IHDT6NF1) was tested against a phantom head that was filled with simulated head tissue. As described in the original report dated August 26, 1999, the simulated head tissue had a relative dielectric constant equal to 41 and a conductivity equal to 1.32 S/m. Also stated was: “The composition of the liquid mixture is as follows: 45.9% water; 53.0% sugar; 0% salt, 1% HEC; and 0.1% bactericide.” A mixture with the same composition was made and measured and found to have a relative dielectric constant of 40 and conductivity of 1.56 S/m. These are slightly different values than were originally found. Since the conductivity is higher than is required by the FCC’s value of 1.07 S/m at 1620 MHz, the measured SAR values are being overstated. 3. Satellite mode SAR evaluation with cellular phone modules installed. The Motorola portable satellite transceiver (FCC ID IHDT6NF1) was tested with three different cellular phone modules installed. The SAR data was taken with the transceiver in satellite mode. The SAR data for Motorola portable cellular phone modules with FCC ID numbers IHDT5NC1 (AMPS/CDMA 800 MHz) and IHDT6NB1 (CDMA 1900 MHz) are pending and will be submitted to the FCC at a later date. The SAR data for the Motorola portable cellular phone module FCC ID IHDT56NA1 (AMPS/TDMA 800/1900 MHz) will be submitted with that report at the time of filing on a future date. The portable satellite transceiver tested in the report dated August 26, 1999 (serial number 081099-2) is not software compatible with the cellular phone modules listed above. Thus a new unit, serial number 00426v, has been used for the SAR data taken in this report. Figure 1 shows the front of the portable satellite transceiver tested. Figure 2 shows the back of the portable satellite transceiver with a portable cellular phone module installed. The antenna has the same retracted and extended antenna positions as does the unit in the August 26, 1999 report. Figure 3 shows the portable satellite transceiver with a portable cellular phone module installed as it is placed onto the phantom. The unit tested is also mechanically and electrically identical to the August 26, 1999 unit except for the software that makes it compatible with cellular phone modules. For the purposes of this report, the portable satellite transceiver was fully tested with one of the cellular phone modules. Then the worst case antenna retracted and the worst case antenna extended positions were duplicated with the remaining two cellular P P a a g g e e 3 3 phone modules. Since all of the SAR values found are very low, this method is sufficient to demonstrate compliance. Figure 1. Front of TransceiverFigure 2. Back of Transceiver Showing Antenna Extended and Cellular Phone Module Installed Figure 3. Portable Satellite Transceiver With Portable Cellular Module Installed Against Phantom Head. P P a a g g e e 4 4 The measurement methods and equipment used for the tests contained in this report are identical to those used in the August 26, 1999 report. Therefore only the test results with the cellular phone modules installed in the portable satellite transceiver are shown in this report. The following table lists the measured SAR values for the portable satellite transceiver with the CDMA 1900 cellular phone module installed. A full data set output of the two test conditions with the highest SAR values from the Dasy measurement system is included as appendix A. The test conditions included are indicated as bold numbers in the following table. All other test conditions measured lower SAR values than those included. Note that a larger scan area was used for these tests than for the data shown in the August 26, 1999 report. This was done to demonstrate compliance in the full scan area and does not reflect any impact on the August 26, 1999 data. SAR values with CDMA 1900 MHz cellular phone module installed Left Side HeadRight Side Head ChannelAnt RetractedAnt ExtendedAnt RetractedAnt Extended 10.13 0.01 0.140.01 1200.150.010.160.01 2400.200.01 0.20 0.01 The channel 1 antenna extended left side head condition and the channel 240 antenna retracted right side head condition were duplicated with the AMPS/CDMA 800 MHz and AMPS/TDMA 800/1900 MHz cellular phone modules installed. Those results are shown in the following two tables: SAR values with AMPS/CDMA 800 MHz cellular phone module installed Left Side HeadRight Side Head ChannelAnt RetractedAnt ExtendedAnt RetractedAnt Extended 10.02 120 2400.21 SAR values with AMPS/TDMA 800/1900 MHz cellular phone module installed Left Side HeadRight Side Head ChannelAnt RetractedAnt ExtendedAnt RetractedAnt Extended 10.02 120 2400.20 4. Summary The SAR values found for the portable satellite transceiver (IHDT6NF1) are below the maximum recommended levels of 1.6 W/kg with all three indicated cellular phone modules installed. P P a a g g e e 5 5 Appendix A The following pages are pr…

Text truncated - open the document above for the full version.

APPLICANT: MOTOROLA, INC.FCC ID: IHDT6NF1 Satellite External Antenna Gain Parameters Magnetic Mounted Patch Antenna (SAF5340) Net Gain dBTx ConductedEIRP (W) Freq(MHz)NotePower Out (dBm) 1616-2.4427.660.333 1621-2.6527.660.317 1626-3.0227.660.291 Permanently Mounted Patch Antenna (SAF2040) Net Gain dBTx ConductedEIRP (W) Freq(MHz)NotePower Out (dBm) 1616-2.0227.660.366 1621-1.8827.660.378 1626-1.927.660.377 Ancillary Patch Antenna (SYN7391) Net Gain dBTx ConductedEIRP (W) Freq(MHz)NotePower Out (dBm) 1616-2.5227.660.327 1621-2.1727.660.354 1626-2.527.660.328 Fixed Sight Helix(SAF5350) Net Gain dBTx ConductedEIRP (W) Freq(MHz)NotePower Out (dBm) 1616-3.7327.660.247 1621-3.8027.660.243 1626-3.8327.660.242 Note: Net gain is the sum of the actual antenna gain and the feedline loss. Exhibit 11a

APPLICANT: MOTOROLA, INC.FCC ID: IHDT6NF1 Exhibit 6 SUBMITTED MEASURED DATA INDEX MEASUREMENTEXHIBIT RF Output Measured Data..................................................................6A Occupied Bandwidth Graph................................................................6B FCC Conducted Spurious Emissions Graphs.......................................6C FCC Radiated Spurious Emissions Graphs..........................................6D Frequency Stability VS Temperature Graph........................................6E Frequency Stability VS Voltage Graph...............................................6F CTR41 Conducted Spurious Emissions Graphs...................................6G CTR41 Radiated Spurious Emissions Graph.......................................6H CTR41 Conducted Emissions, Carrier Off Graphs..............................6I CTR41 In-Band Conducted Emissions................................................6J CTR41 EIRP Density Measurement....................................................6K Measurement Techniques....................................................................6L APPLICANT: MOTOROLA, INC. FCC ID: IHDT6NF1 Exhibit 6A RF Power Output Data The RF power output was measured with the indicated voltage and current applied into the final RF amplifying device(s). The RF output, DC current and RF Input Power are all time-averaged values which reflect a 9.2 % (8.28 ms Tx bursts / 90 ms frame) transmit duty cycle characteristic of transceiver operation. • RF Output Power: 0.584 Watts • DC Voltage: 7.5 Volts • DC Current: 0.404 Amps • RF Input: 0.092 mW Effective Isotropic Radiated Power Since the transceiver is intended for use with a provided antenna (with a nominal 3 dB gain over isotropic and “non-standard” RF connector), EIRP is measured. The antenna substitution method was used. The result indicated is the maximum EIRP found over the channels and transceiver orientations tested. The measured value reported below again takes into account the transmit duty cycle of 9.2 %. Maximum EIRP: +30.73 dBm (1.2W) APPLICANT: MOTOROLA, INC. FCC ID: IHDT6NF1 Exhibit 6B BANDWIDTH MEASUREMENT DATA FOR TRANSMITTER TYPES Q7W DEVIATION OF THE CARRIER WITH QPSK MODULATION HORIZONTAL SCALE = 1 MHz/DIVISION VERTICAL SCALE = 10 dB/DIVISION RESOLUTION BANDWIDTH = 3 kHz POWER LEVEL = .6 W (Mean Output Power) MEASURED DATA: 1. Modulate the transmitter with QPSK modulation, using pseudo random data. Obtain image on spectrum analyzer. COMMENTS: A 3 kHz resolution bandwidth was used instead of the 4 kHz specified in 47 CFR 25.202. A correction factor was included in the limit for the bandwidth difference. APPLICANT: MOTOROLA, INC. FCC ID: IHDT6NF1 Exhibit 6C-1 TRANSMITTER CONDUCTED EMISSIONS, CHANNEL #3 Carrier Power: 7 W max (+38.45 dBm), .645 W average (+28 dBm) Carrier Frequency: 1616 to 1626.5 MHz (240 Channels) Channels Tested: Channels #3, #120, and #238 *All other emissions greater than 20 dB below the spec were not reported *2 nd harmonic was highest emission level measured and also more than 20 dB below the specSSG EMC Group *Spectrum search performed from 30 MHz to 16.3 GHz (10X Carrier Frequency)8/23/99 4:45 PM -80 -70 -60 -50 -40 -30 -20 -10 0 100010000100000 Frequency (MHz) Spurious Level (dBc) Spec Limit (7W) = -51.45 dBc (-14.25 dBm) (2nd Harmonic, -72.6 dBc) CARRIER 1616.1 MHz 3232.2 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6NF1 Exhibit 6C-2 TRANSMITTER CONDUCTED EMISSIONS, CHANNEL #120 Carrier Power: 7 W max (+38.45 dBm), .645 W average (+28 dBm) Carrier Frequency: 1616 to 1626.5 MHz (240 Channels) Channels Tested: Channels #3, #120, and #238 *All other emissions greater than 20 dB below the spec were not reportedSSG EMC Group *Spectrum search performed from 30 MHz to 16.3 GHz (10X Carrier Frequency)8/23/99 4:48 PM -80 -70 -60 -50 -40 -30 -20 -10 0 100010000100000 Frequency (MHz) Spurious Level (dBc) Spec Limit (7W) = -51.45 dBc (-14.25 dBm) (2nd Harmonic, -69.5 dBc) CARRIER 1620.9 MHz 3241.8 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6NF1 Exhibit 6C-3 TRANSMITTER CONDUCTED EMISSIONS, CHANNEL #238 Carrier Power: 7 W max (+38.45 dBm), .645 W average (+28 dBm) Carrier Frequency: 1616 to 1626.5 MHz (240 Channels) Channels Tested: Channels #3, #120, and #238 *All other emissions greater than 20 dB below the spec were not reportedSSG EMC Group *Spectrum search performed from 30 MHz to 16.3 GHz (10X Carrier Frequency)8/23/99 4:49 PM -80 -70 -60 -50 -40 -30 -20 -10 0 100010000100000 Frequency (MHz) Spurious Level (dBc) Spec Limit (7W) = -51.45 dBc (-14.25 dBm) (2nd Harmonic, -69.6 dBc) CARRIER 1625.9 MHz 3251.8 APPLICANT: MOTOROLA, INC. FCC ID: IHDT6NF1 Exhibit 6C-4 GPS/GLONASS NARROWBAND EMISSION SCANS Channels Tested: Channels #3, #120, and #238 *Data measured in accordance with Part 25.200 (c) *The data was similar for all three channels and only the worst case scans are included in this reportSSG EMC Group *A 1 kHz resolution bandwidth was used for the narrowband measurement instead of 700 Hz 8/23/99 4:49 PM APPLICANT: MOTOROLA, INC. FCC ID: IHDT6NF1 Exhibit 6C-5 GPS/GLONASS WIDEBAND EMISSION SCANS Channels Tested: Channels #3, #120, and #238 *Data measured in accordance with Part 25.200 ( c )SSG EMC Group *The data was similar for all three channels and only the worst case scans are included in this report8/23/99 4:49 PM APPLICANT: MOTOROLA, INC. FCC ID: IHDT6NF1 Exhibit 6D TRANSMITTER RADIATED EMISSIONS, MAX LEVELS OF CHANNELS #3, 120, 238 Carrier Power: 7 W max (+38.45 dBm), .645 W average (+28 dBm) Carrier Frequency: 1616 to 1626.5 MHz (240 Channels) Channels Tested: Channels #3, #120, and #238 (worst case emission presented) *All other emissions greater than 20 dB below the spec were not reportedSSG EMC Group *Spectrum search performed from 30 MHz to 16.3 GHz (10X Carrier Frequency)8/24/99 4:28 PM -80 -70 -60 -50 -40 -30 -20 -10 0 100100010000100000 Frequency (MHz) Spurious Level (dBc) Spec Limit (7W) = -51.45 dBc (-14.25 dBm) (2nd, -60.4 dBc) CARRIER 337.5 - 377.5 (6th, -73.8…
