IHDT6UA3Inductive Wireless Charger

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13a - 1 17 April 2015 Authorization & Evaluation Division Federal Communications Commission Laboratory 7435 Oakland Mills Road Columbia, MD 21046 Subject: Application for Certification of WPC-Compliant Wireless Charger; with FCC: IHDT6UA3. Gentlemen; Motorola Mobility LLC; 8000 W. Sunrise Blvd.; Plantation, FL 33322 herein submits its application for certification of the multi-mode handset with FCC ID: IHDT6UA3. This device is a wireless charging device, implementing the Wireless Power Consortium (WPC) protocol, and is intended for use with the Moto 360 wrist-worn device. It complies with the requirements of 15.205, 15.207, and 15.209. The device has been evaluated (as applicable) according to 47 CFR Part 2.1091 for RF exposure and found to be compliant with the limits specified in 47 CFR 2.1091(d)(4). Enclosed is a complete Certification Application. Contact me at (954) 590-0254 if you require any additional information. Regards, Distinguished Member of Technical Staff Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

FCC ID: IHDT6UA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 1 CONFIDENTIALITY REQUEST 17 April 2015 Federal Communications Commission Laboratory Authorization & Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Confidentiality Request Regarding Application for Certification of FCC ID: IHDT6UA3. Dear Sir or Madam: Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, we hereby respectfully request confidential treatment of information accompanying this application as outlined below: Exhibit Type File Name Block Diagrams. IHDT6UA3_Ex_04 (Block Diagrams).pdf Schematic Diagrams. IHDT6UA3 _Ex_05 (Schematics).pdf Parts List and Tune Up Procedures. IHDT6UA3 _Ex_10 (Parts List and Tune- up).pdf Transmitter Characteristics. IHDT6UA3 _Ex_12 (Transceiver Characteristics).pdf Motorola Mobility LLC requests that these exhibits be held as Permanently Confidential, and not be made routinely available for public inspection. Motorola considers that the information in these exhibits should be classified as trade secrets, pursuant to 47 CFR Section 0.457(d) and Section 552(b)(4) of the Freedom of Information Act. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Motorola Mobility LLC understands that, pursuant to Section 0.457 of the Rules, disclosure of this application and all accompanying documentation will not be made before the date of the Grant for this application. FCC ID: IHDT6UA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 13b - 2 SHORT TERM ONFIDENTIALITY REQUEST – 180 DAYS Pursuant to Sections 0.457 and 0.459 of the Commission’s Rules, and the guidance in KDB Publication 726920 D01, Motorola Mobility LLC is also requesting Temporary Confidentiality treatment of information accompanying this application as outlined below. This provision will give Motorola Mobility LLC temporary confidentiality prior to product launch. Exhibit Type File Name External product photographs. IHDT6UA3 _Ex_03 (External_Photos).pdf Test set-up photographs. IHDT6UA3 _Ex_07B (DCD Test Set-up Photographs) User’s Manual. IHDT6UA3 _Ex_08 (User Guide).pdf Internal product photographs. IHDT6UA3 _Ex_09 (Internal Photos).pdf 1 This exhibit not applicable to the JBP application, per 47 CFR 2.1031 Please contact me if you require any additional information. Regards, Distinguished Member of Technical Staff Motorola Mobility LLC 8000 W. Sunrise Blvd.; Suite A Mail Stop 52-5JJ Plantation, FL 33322 E-mail: [email protected]

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 / IC ID: 109O-T6UA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 1 Exhibit 3. External Photographs -- Pursuant to 47 CFR 2.1033(c)(12) and RSP100, Section 5.2. The radio product colors, housings/bezels may vary, but only consistent with the requirements of FCC Class I Permissive Change rules and guidance (47 CFR 2.1043 and KDB 178919 D01). Figure 3-1. Front of device (Pocket) APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 / IC ID: 109O-T6UA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 2 Figure 3-2. Back Side of device APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 / IC ID: 109O-T6UA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 3 - 3 Figure 3-3. Bottom of Device (Marking Surface/Power Supply Input Port)

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 / IC ID: 109O-T6UA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 1 Exhibit 1: Identification Label -- Pursuant to 47 CFR 2.925 and 2.1033(c)(11); and RSP100, Section 5 and RSS Gen, Section 5.2. 1.1 Location The regulatory information will appear on the bottom (back) side of the device, pad- printed onto the housing (see Figure 1.3.2, and also Exhibit 3). 1.2 Type The label will be pad printed onto the bottom of the device housing. 1.3 Markings (Text) The FCC label shown is representative of the label that will appear on the radio when in production. Figure 1.3.1. Representation of FCC Label information. The above label representation is applicable to the following versions/variants of the device that is the subject of this application: Model Number 1 1 Depending upon the device version, or market into which it ships, the Model Number shown on the label may vary. All such variants will be electrically identical, consistent with the requirements of FCC Class I Permissive Change rules and guidance (47 CFR 2.1043 and KDB 178919 D01). This label will be placed on the equipment (within the Battery Compartment) as shown below. Other information may also be included on this label, and other labels may also be present. This information will be permanently etched onto the equipment rear cover as shown below, and in Exhibit 3. Other information may also be present. FCC ID IHDT6UA3 IC: 109O-T6UA3 Model No. MODEL APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 / IC ID: 109O-T6UA3 Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 1 - 2 Figure 1.3.2. Location of FCC Label (position, orientation, and other information shown may vary). Please note that this label and its placement complies with the requirement of FCC Rule 47 CFR 2.925(d) that the label be permanently affixed to the product, and be readily visible to the purchaser at the time of purchase. The product’s Market or Trade Name is indelibly printed on the face of the product, as shown in Exhibit 3. Bottom of Device Regulatory Information appears here.

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 / IC ID: 109O-T6UA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 1 Exhibit 9: Internal Photographs -- Pursuant to 47 CFR 2.1033(c)(12) and RSP100, Section 5. Photograph 9-1: Front side view of the device’s PC Board. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 / IC ID: 109O-T6UA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 2 Photograph 9-2: Back side view of the device’s PC Board. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 / IC ID: 109O-T6UA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 3 Photograph 9-3: Charging Coil on Board. Photograph 9-4: Charging Coil. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 / IC ID: 109O-T6UA3 Temporary Confidentiality Requested Motorola Mobility LLC; 8000 W. Sunrise Blvd, Suite A; Plantation, FL 33322, USA www.motorola.com Page 9 - 1 Photograph 9-5: Housing Components.

July 21, 2015 MPE Test Report for Motorola Wireless Charger (FCC ID IHDT6UA3) Prepared by: Steven Hauswirth, Distinguished Member of the Technical Staff Motorola Mobility, Product Safety & Compliance Laboratory Chicago, Illinois The Motorola Mobility Product Safety & Compliance Laboratory has evaluated the Motorola Wireless Charger (FCC ID IHDT6UA3) as a mobile device per 47 CFR §1.1310 titled “Radiofrequency radiation exposure limits”, generally referred to as MPE limits. In 47 CFR § 2.1091, paragraph (b) defines a mobile device as “a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter’s radiating structure(s) and the body of the user or nearby persons.” This product is intended to be installed into a vehicle such that the unit is physically secured at one location. In the installation guide supplied with the product, Motorola has made the following statement: “IMPORTANT: To meet the FCC’s RF Exposure Guidelines, the antenna should be installed so there is at least 20 cm of separation between the body of the user and nearby persons and the antenna”. Based on the installation of the transceiver and the antenna, the transmitters radiating structure is more than 20 centimeters from the user. Thus, this product is a “mobile device” as defined in section § 2.1091 paragraph (b). Table 1 (B) of 47 CFR §1.1310 lists the limits for MPE for the General Population: The ERP of a radiating structure was measured by coupling a receiver coil to the wireless charger to measure the transmitted power. Measured ERP = 1.07 W The MPE of a radiating structure can be calculated by knowing the transmit ERP and the distance at which MPE is being calculated. In this case MPE will be calculated at 20 cm, which is the minimum separation between the body of the user and nearby persons and the antenna. The calculations for the MPE are: S = ( Ef * ERP ) / [ 4 * Pi * (d^2) ] where: Ef = enhancement factor to account for ground reflections is 2.56 ERP = measured ERP d = distance from antenna (20 cm in our case) Alternatively; the E-field strength can be calculated For 0.16 MHz Operation: The peak transmit power ERP for this product is 1.07 W. The Power Density MPE is 0.545 mW/cm 2 . This is below the limit of 100 mW/cm 2 . Alternatively, the E-field Strength MPE is 28.3 V/m. This is below the limit of 614 V/m. Therefore, by requiring the user and nearby persons to remain at least 20 cm from the antenna, the MPE is not exceeded.

APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 Test Report Number: 26015-1 WC Page 1 of 12 EXHIBIT 6A ADR TESTING SERVICES EMC LABORATORY EMC TEST REPORT Test Report Number – 26015-1 WC The test results and statements contained herein relate only to the model(s) identified and tested. It is the manufacturer’s responsibility to assure that additional production units of this model are manufactured with identical electrical and mechanical characteristics. As the responsible EMC Engineer, I hereby declare that the equipment tested as specified in this report conforms to the requirements indicated. Signature: Name: Thanigaiselvan Palaniswami Title: EMC Engineer Date: July 17, 2015 This report must not be reproduced, except in full, without written approval from this laboratory. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 Test Report Number: 26015-1 WC Page 2 of 12 EXHIBIT 6A Contents TEST REPORT DETAILS ............................................................................................................. 3 APPLICABLE STANDARDS ....................................................................................................... 3 SUMMARY OF TESTING ............................................................................................................ 4 GENERAL AND SPECIAL CONDITIONS .................................................................................. 4 EQUIPMENT AND CABLE CONFIGURATIONS ...................................................................... 4 EQUIPMENT LIST ........................................................................................................................ 5 MEASUREMENT PROCEDURES AND DATA ......................................................................... 6 MEASUREMENT RESULTS ........................................................................................................ 7 AC LINE CONDUCTED EMISSIONS ......................................................................................... 9 APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 Test Report Number: 26015-1 WC Page 3 of 12 EXHIBIT 6A Test Report Details Tests Performed By: ADR Testing Services Motorola Mobility LLC Product Safety and Compliance Group 222 W. Merchandise Mart, Suite 1800 Chicago, IL 60654 Tests Requested By: Motorola Mobility LLC 222 W. Merchandise Mart, Suite 1800 Chicago, IL 60654 Product Type : Wireless Charger Signaling Capability: Part 15 Low Power Transmitter Below 1705 kHz. (DCD) Operating Freq Range: 112 - 205 kHz FCC ID: IHDT6UA3 Serial Numbers: Charger #1, Charger #2, Charger #3 Testing Complete Date: July 17, 2015 Applicable Standards All tests and measurements indicated in this document were performed in accordance with the Code of Federal Regulations Title 47: Part 15 Subpart C – Intentional Radiators Applicable Standards: ANSI 63.4 2009 APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 Test Report Number: 26015-1 WC Page 4 of 12 EXHIBIT 6A Summary of Testing Test # Test Name Pass/Fail 1 Field Strength of Spurious Emissions from Intentional Radiators Pass. See Results 2 AC Line Conducted Emissions from Intentional Radiators Pass. See Results General and Special Conditions The Equipment under Test is a Wireless Charger. Testing was performed while charging a Motorola Smart Watch at 3 different charging levels, 0, 50 and 90 % charge. The test data shown is for the worst case configuration. All testing was done in an indoor controlled environment. The temperature and the relative humidity were maintained within the ANSI C63.4 2009 Standard requirements during the entire duration of testing. Equipment and Cable Configurations The EUT was tested in a configuration as specified by ANSI C63.4 2009 Standard requirements. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 Test Report Number: 26015-1 WC Page 5 of 12 EXHIBIT 6A Equipment List Manufacturer Equipment Type Model No. Serial Number Calibration Due Date Rohde & Schwarz Receiver ESU40 100286 10/04/15 Agilent Signal Generator 83623B 3844A00935 04/03/16 Weinschel Attenuator AS-6 7074 NCR Agilent Attenuator 8491A 50772 02/09/16 ETS-Lindgren LISN 3810/2NM 00023630 09/12/15 ETS-Lindgren Loop Antenna 6507 00049471 03/11/16 Agilent Call Box N1912A MY45100116 04/03/16 All equipment is on a one-year calibration cycle. All testing was performed using equipment that was within calibration at the time that the test was performed. No equipment listed in the table above was used after the specified calibration due date. If, during the course of product testing, a piece of equipment went out of calibration, a similar piece of calibrated equipment was substituted. If a substitution was made, that new piece of equipment would be listed in the above table along with the piece that was removed from service. APPLICANT: MOTOROLA MOBILITY LLC FCC ID: IHDT6UA3 Test Report Number: 26015-1 WC Page 6 of 12 EXHIBIT 6A Measurement Procedures and Data Field Strength of Emissions from Unintentional radiators Measurement Procedure The equipment under test is placed inside the semi-anechoic chamber on a Styrofoam table on the center of the turntable. Initially, for all radiated emissions from 9 kHz to 30 MHz, the turntable is rotated 45 degrees to obtain a maximum reading on the spectrum analyzer using the peak detector function. All final readings are then taken at the worst case EUT orientation. Below 1000 MHz, the final radiated emissions are then measured using an EMI receiver employing a CISPR quasi-peak detector. The receiver used has an average detector function and an RMS detector function. All measurements are done at a 3 meter separation distance. The limit is adjusted using a 40 dB/decade factor as specified in FCC’s 15.31(f) (2). The emissions @ 110 kHz meet the radiated emissions requirement. The zoomed in plot shows measurement data taken at distance closer than the 3 meter test distance. The limit on the plot is for 3 meter test distance. The field strength of each radiated emission is …
