IN9-ICS-01-RFIDRFID module used to identify consumables used in Sealed Air protective packaging inflation systems

Sealed Air Corporation

RFID module used to identify consumables used in Sealed Air protective packaging inflation systems - FCC ID IN9-ICS-01-RFID - Sealed Air Corporation

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Apr 19, 2021
Application Purpose: Original Equipment
Date of Application: Apr 19, 2021
Equipment Note: RFID module used to identify consumables used in Sealed Air protective packaging inflation systems
Frequency Range: 13.56000000 - 13.56000000
Company: Sealed Air Corporation
Country: United States

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

8 7 6 5 4 3 2 1 REV CHANGE NO DESCRIPTION CHANGED BY DATE 8 7 6 5 4 3 2 1 D C B A D C B A PART TITLE SHEET REV. PART MUST BE RoHS COMPLIANT PER SEALED AIR POLICY 5080AA-01 UNLESS OTHERWISE SPECIFIED TOLERANCE OF DIMENSIONS (INCHES) FRACTIONS: ± 1/32 1 PLACE .X ± .05 2 PLACE .XX ± .01 3 PLACE .XXX ± .005 ANGLES ± 1º Color Codes provided for inspection purposes only: 5010AAF A – Initial Release TSCHUDKO DESIGN 11/4/19 C 0000000 Multiple revieions; add 24 translations. TSCHUDKO DESIGN 2/21/20 B 0000000 Add U.S. patent numbers: 8,978,345, 8,991,141, and TSCHUDKO DESIGN 1/27/20 9,540,162; add USB, RJ45, and RJ14 ports. PMS Black Specifications Size: Open - 2 @ 22.0" x 31.16" / 55.9cm x 79.2cm Accordion Folded - 2 @ 5.5" x 7.79" / 14.0cm x 19.8cm Type: Process - 1/1 flexo or digital. Material - HP 18 lb Translucent Bond Paper (.003” thk.) Ink - Black - PMS Black. Note: 1. 2 sheets / 4 sides 2. One color, printed two side, accordion folded each. 3. Materials must be RoHS compliant. 1 OF 2 C Languages and Electric Standards 01 English Speaking United States US 120VAC 50/60Hz Great Britain GB 230VAC 50Hz Australia AU 230VAC 50Hz New Zealand NZ 230VAC 50Hz 02 Brazil (Portuguese) BR 127 / 220VAC 60Hz 03 Netherlands NL 230VAC 50Hz 04 Germany DE 230VAC 50Hz 05 Spain ES 230VAC 50Hz 06 France FR 230VAC 50Hz 07 Italy IT 230VAC 50Hz 08 Portugal PT 230VAC 50Hz 09 Japan JP 100VAC 50/60Hz 10 Czech Rep / Slovakia CZ / SK 230VAC 50Hz 11 Poland PO 230VAC 50Hz 12 Hungary HU 230VAC 50Hz 13 Sweden SE 230VAC 50Hz 14 Denmark DK 230VAC 50Hz 15 Norway NO 230VAC 50Hz 16 Finland FI 230VAC 50Hz 17 Romania RO 230VAC 50Hz 18 Russia RU 220VAC 50Hz 19 Slovenia SI 230VAC 50Hz 20 Serbia RS 230VAC 50Hz 21 China CN 220VAC 50Hz 22 Turkey TR 230VAC 50Hz 23 Croatia HR 230VAC 50Hz 24 Greece GR 230VAC 50Hz MANUAL, USERS, ICS FOLDFOLDFOLD FOLDFOLDFOLD FOLDFOLD FOLDFOLD FOLDFOLD FOLDFOLDFOLD FOLDFOLDFOLD FOLDFOLD FOLDFOLD FOLDFOLD Inflatable Cushioning System User's Guide Original Instructions Info from Kris Swanson needed Description needed PATENT PENDING Bubble Wrap® IB Med Bubble Wrap® Brand Inflator IBW-10001 / 12,010 ft +1 800 243 1102 +31 (0)24 371 0150 [email protected] XL Premium XL Regular L Premium L Prem. Pouch 8”x12” L Regular JetStream Stack Light Footswitch Photoeye Bin Sensor Language: English - US Batch: 10 ft Seal: 268 ºF Speed: 30 fpm Blower: 85% Bub ble Wra p® I B M ed Bubble Wrap® IB Med Bubb le Wrap ® I B M ed Bu bble Wrap® I B M ed Bu bb le Wrap® I B M ed 4 ft S 10 ft M 100 ft L 500 ft ∞ Bubb le Wrap ® I B M ed Bu bb le Wra p® I B M ed Bubb le Wrap® I B Me d Bubble Wra p® I B M ed P.N. 2104XXX-00 Mad e in USA Serial #: ICS-10001 Elec trical: 100-2 40V~ 5. 4A Sing le Phase 50/6 0H z Weight: 28 lb / 12.7kg Thi s equipm ent i s man ufactured by Seal ed Air Corpo ration ( US). U.S . an d o ther p ate nts pending. Inflata ble C ushi oning S ystem Pla ce Mon th & Y ea r Lab el Here P.N. 2 10 4TU -+ Se ale d Air 2415 Cas cade Po inte Blvd. Ch arlotte, NC 28 208 US A sma llbusi ness .seal edair.com P A TE N T P E N D IN G Nov em be r Inflatable Cushioning System User's Guide Original Instructions PATE NT PEND ING Bubb le Wr ap ® I B Me d Bu bble Wr ap ® I B Me d Bubble Wr ap® I B Me d Inflatable Cushioning System User's Guide Original Instructions PATE NT PENDING Bubble Wra p® I B Me d Bubble Wra p® I B Med Bubble Wra p® I B Med Inflatable Cushioning System User's Guide Original Instructions PATEN T PE NDIN G Bub ble Wrap ® I B Med Bubb le Wra p® I B Med Bubbl e Wrap ® I B Med Inflatable Cushioning System User's Guide Original Instructions PATE NT PENDING Bubble Wra p® I B Med Bubble Wr ap® I B Me d Bubble Wra p® I B Med Inflatable Cushioning System User's Guide Original Instructions PATENT PENDING Bubbl e Wrap® I B Med Bubble Wrap® I B Med Bubble Wrap® I B Med Inflatable Cushioning System User's Guide Original Instructions PATENT PENDING Bubbl e Wrap® I B Med Bubble Wrap® I B Med Bubble Wrap® I B Med 1. 2.3. To review warranty information: Call your Sealed Air Representative or distributor for support of your Inflatable Cushioning System. Infl atable Cushion ing System User's Guid e Or iginal In stru cti ons PAT E NT P ENDI N G B ub b l e W r a p ® I B M e d Bu b b l e W rap ® I B M ed B ub b l e W r a p® I B Me d Bubble Wrap ® I B Me d Bu bble Wra p® I B Me d 1 Bubble Wrap® IB Medium 2 XL Regular 3 Extreme Eff. 8” x 5” 4 Quilt Bub ble Wr ap® I B M ed Bu bble Wrap ® I B M ed Bu bbl e Wra p® I B Med Bub ble Wr ap ® I B Me d United States Regulatory Notice: Federal Communications Commission (FCC) Statement: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy, and if it is not installed and used in accordance with the instruction manual, it may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense. Changes and Modifications not expressly approved by Sealed Air can void your authority to operate this equipment under Federal Communications Commission rules. This device has been found to be compliant to the requirements set forth in CFR 47 Sections 2.1091 for an uncontrolled environment. The antenna used for this transmitter is permanently located within the material roll mandrel. The equipment must be installed to provide a separation distance of at least 20 cm from all persons and must n…

Text truncated - open the document above for the full version.

Cover Letter(s)

Date: April 15, 2021 RE: IN9-ICS-01-RFID To Whom It May Concern: This letter is to attest that the Sealed Air 1164AAG NFC card reader, FCC ID: IN9-ICS-01-RFID is a Limited Single-Module transmitter that complies with FCC Part 15.212(a)(1). When installed in Sealed Air inflatable packaging host equipment the following requirements are met: MODULAR APPROVAL REQUIREMENT STATEMTNE OF COMPLIANCE (a) The radio elements must have the radio frequency circuitry shielded. Physical components and tuning capacitor(s) may be located external to the shield, but must be on the module assembly The radio element of the transmitter contained within a ST25R3911B RFID IC. Shielding is provided on the PCB by a top layer ground plane which is guarded using via stitching to a low-ohmic mid-layer DC path. (b) The module must have buffered modulation/data inputs to ensure that the device will comply with Part 15 requirements with any type of input signal Buffered modulation inputs are provided on the ST25R3911B RFID IC. Data is sent to the RFID IC via a clocked SPI bus, preventing data overrun from impacting the transmitter. (c) The module must contain power supply regulation on the module Regulated power is supplied to the 1164AAG module from the Sealed Air main control PCB. In addition, the ST25R3911B IC contains internal local voltage regulators for the data interface, analog circuitry, RF transmitter and receiver. (d) The module must contain a permanently attached antenna, or contain a unique antenna connector, and be marketed and operated only with specific antenna(s), per Sections 15.203, 15.204(b), 15.204(c), 15.212(a), 2.929(b) The module contains a fixed antenna etched directly onto the PC board. No provision is provided for attachment of an external antenna. (e) The module must demonstrate compliance in a stand-alone configuration The module was tested in stand-alone configuration and complies with Part 15 emissions limits. (f) The module must be labelled with its permanently affixed FCC ID label, or use an electronic display (See KDB Publication 784748 about labelling requirements) The module includes a label with FCC ID: IN9-ICS-01-RFID. Since the module is used as a component internal to the inflatable packaging equipment and is not visible to the user, the equipment is also labeled with the statement ‘This device contains FCC ID: IN9- ICS-01-RFID’. (g) The module must comply with all specific rules applicable to the transmitter. The grantee must provide comprehensive instructions to explain compliance requirements The module is intended as a component of the inflatable packaging equipment and therefore does not have its own operating manual. Instructions, including specific FCC rules and operating requirements applicable to the module are provided in the operating manual for the machine. A copy of the instructions are included in the application for equipment authorization. (h) The module must comply with RF exposure requirements The module complies with applicable SAR and RF exposure limits of Part 15. Steven Maston Manager, Electrical Engineering Sealed Air 100 Westford Rd Ayer MA 01432

External Photos

Sealed Air Application for Certification of IC: 25875-ICS-01-RFID EXHIBIT: EXTERNAL PHOTOS FILE NAME: 25875-ICS-01-RFID ExtPho.pdf

ID Label/Location Info

Sealed Air Application for Certification of IC: 25875-ICS-01-RFID EXHIBIT: HOST PRODUCT LABEL FILE NAME: 25875-ICS-01-RFID ProdLbl.pdf

Internal Photos

Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 1 of 4 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Internal Photographs Swanson Associates Inflatable Bubble Top View Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 2 of 4 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble Bottom View Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 3 of 4 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble Resistor - Top View Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 4 of 4 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble Ferrite in place on AC power line to DC power supply

Parts List/Tune Up Info

Sealed Air Application for Certification of IC: 25875-ICS-01-RFID EXHIBIT: PART LIST FILE NAME: 25875-ICS-01-RFID PrtLst.pdf

Test Report

Project Number: 2019-289 Testing Cert # 2778.01 April 8, 2021 Page 1 of 44 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Sealed Air Corporation 100 Westford Road Ayer, Massachusetts 01432 Report of FCC and ISED Canada Intentional Radiator Testing Prepared For Kristian Swanson Company Sealed Air Corporation Applicable Models Inflatable Cushioning System Test Laboratory Core Compliance Testing Services, LLC 79 River Road Hudson, NH 03051 Test Dates November 17 – 27, 2019 Tested & Reviewed By Ken MacGrath, Manager George Correia, Test Engineer Signature, Manager Signature, Test Engineer Project Number: 2019-289 Testing Cert # 2778.01 April 8, 2021 Page 2 of 44 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Table of Contents 1.0 GENERAL INFORMATION ............................................................................................................................ 4 1.1 Product Description ................................................................................................................................. 4 1.2 Applicable Documents and Standards ............................................................................................... 5 1.3 Test Dates .................................................................................................................................................... 5 1.4 Test Methodology .................................................................................................................................... 5 1.5 Test Facility ................................................................................................................................................. 5 1.6 Test Equipment List .................................................................................................................................. 6 Table 1: Test Equipment ................................................................................................................................ 6 1.7 Measurement Uncertainty .................................................................................................................... 7 1.8 Equipment Modifications ....................................................................................................................... 7 2.0 SYSTEM TEST CONFIGURATION ................................................................................................................ 8 2.1 EUT Configuration .................................................................................................................................... 8 2.2 EUT Exercise ............................................................................................................................................... 8 3.0 SUMMARY OF TEST RESULTS .................................................................................................................... 9 Table 2: Test Summary .................................................................................................................................... 9 4.0 Field Strength in the 13.110 – 14.010 MHz range .......................................................................... 10 4.1 Applicable Standards ............................................................................................................................ 10 4.2 Measurement Procedure .................................................................................................................... 10 4.3 Measurement Results Summary ...................................................................................................... 11 4.4 10-Meter, 13.110 – 14.010 MHz Field Strength Test Results ................................................. 11 4.5 10-Meter, 13.110 – 14.010 MHz Field Strength Test Conclusion .......................................... 17 5.0 Voltage Variation Frequency Stability ................................................................................................. 18 5.1 Applicable Standards ............................................................................................................................ 18 5.2 Measurement Procedure .................................................................................................................... 18 5.3 Measurement Results Summary ...................................................................................................... 18 5.4 Voltage Variation Frequency Stability Test Results .................................................................... 18 5.5 Voltage Variation Frequency Stability Test Conclusion ............................................................ 20 6.0 Temperature Variation Frequency Stability ...................................................................................... 21 6.1 Applicable Standards ............................................................................................................................ 21 6.2 Measurement Procedure .................................................................................................................... 21 6.3 Measurement Results Summary ...................................................................................................... 21 6.4 Temperature Variation Frequency Stability Test Results ......................................................... 21 6.5 Temperature Variation Frequency Stability Test Conclusion ................................................. 25 7.0 UNINTENTIONAL/SPURIOUS RADIATED EMISSION TEST .............................................................. 26 7.1 Radiated Emissions ............................................................................................................................... 26 7.2 Prescan Radiated Emissions ............................................................................................................... 26 7.3 Prescan Measurement Proced…

Text truncated - open the document above for the full version.

Test Setup Photos

Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 1 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Test Setup Photographs Swanson Associates Inflatable Bubble 3-meter EUT set up in OATS, 9kHz – 30MHz, front Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 2 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble 3-meter EUT set up in OATS, 9kHz – 30MHz, rear Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 3 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble 3-meter EUT set up in OATS, 30-1000MHz, rear Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 4 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble 3-meter EUT set up in OATS, 30-1000MHz, front Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 5 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble 10-meter EUT set up in OATS, 9kHz – 30MHz, front Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 6 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble 10-meter EUT set up in OATS, 9kHz – 30MHz, rear Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 7 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble EUT set up in OATS, 9kHz – 30MHz Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 8 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble EUT set up in OATS, 9kHz – 30MHz, RFID tag Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 9 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble EUT set up in Temperature Chamber for Voltage Variation and Temperature Frequency Stability Testing Project Number: 2019-289 Testing Cert # 2778.01 December 4, 2019 Page 10 of 10 Core Compliance Testing Services, LLC • 79 River Road, Hudson, NH 03051• (603) 889-5545 Swanson Associates Inflatable Bubble EUT set up in Temperature Chamber for Voltage Variation and Temperature Frequency Stability Testing

Contact Information

Applicant

Steven Maston

[email protected]978-487-2175Fax: 978-772-5660

Test Firm

Core Compliance Testing Services, LLCKen MacGrath

[email protected]603-889-5545Fax: 603 892 0620

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	13.56 MHz - 13.56 MHz	-

Modular Type

Limited Single Modular Approval

Confidentiality

Long Term

Grant Notes

Limited Single Modular Approval. This module is limited to Sealed Air inflatable packaging machine. Use of this module in any other host device will require a retesting performance. Co-location of this module with other transmitters that operate simultaneously is required to be evaluated using the FCC multi-transmitter procedures. OEM integrators and end-Users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations with respect to 2.1093 and different antenna configurations.
