INO-2-400-0001DETECT IV Portable handheld covert Tx detector

DETECTIV User Manual Part No: 2-400-0001 2 AUDIOTEL INTERNATIONAL MN400872 Issue 1 (08/04) DETECTIV User Manual AUDIOTEL INTERNATIONAL MN400872 Issue 1 (08/04) 3 © 2004 Audiotel International Ltd Under the copyright laws, this manual may not be copied, in whole or part, without the written consent of Audiotel International Ltd. Every effort has been made to ensure the accuracy of this manual. The instructions and descrip- tions are accurate at the time of publication. However, succeeding versions of the equipment and manuals are subject to change without notice. Audiotel assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between the equipment described and the manual. If you have any comments or suggestions on improving this manual please contact Audiotel at the following address: Audiotel International Corby Road Weldon CORBY Northants NN17 3AR Fax: +44 (0)1536 266711 or Email us at: [email protected] DETECTIV ™ is a registered trademark of Audiotel International Ltd AUDIOTEL ™ is a registered trademark of Audiotel International Ltd 2 AUDIOTEL INTERNATIONAL MN400872 Issue 1 (08/04) DETECTIV User Manual AUDIOTEL INTERNATIONAL MN400872 Issue 1 (08/04) 3 How to use this manual..................................................................................4 CE MARK EMC COMPLIANCE AND RADIO TYPE APPROVAL......5 INTRODUCTION.................................................................6 GETTING STARTED - ........................................................8 Charging the battery.......................................................................................9 Switching the unit ON (and Off)...................................................................10 Using the controls and selecting options.....................................................11 Setting time & date......................................................................................12 BASIC OPERATING METHODOLOGY.....................................13 DETECT........................................................................................................13 IDENTIFY......................................................................................................13 LOCATE........................................................................................................13 DETECT MODE............................................................14 Selecting a Detector.....................................................................................15 Setting the unit Volume................................................................................16 Transmitter Detector Alarms........................................................................16 NLJD Display................................................................................................17 Enabling / Disabling the NLJD......................................................................17 IDENTIFY MODE..........................................................18 Broadband CW Identify screen.....................................................................18 Broadband Burst IDENTIFY screen..............................................................19 Harmonic Receiver IDENTIFY screen...........................................................20 NLJD & Metal Detector IDENTIFY screen...................................................22 LOCATE MODE............................................................25 EVENT LOG...................................................................26 Alarms..........................................................................................................27 Snapshots.....................................................................................................27 References...................................................................................................28 CONNECTION, DOWNLOAD TO A PC..................................29 ACCESSORY..................................................................30 APPENDIX A - BATTERY & I/O........................................32 APPENDIX B - MENU STRUCTURE.....................................33 Contents 4 AUDIOTEL INTERNATIONAL MN400872 Issue 1 (08/04) DETECTIV User Manual AUDIOTEL INTERNATIONAL MN400872 Issue 1 (08/04) 5 How to use this manual This manual is divided into a number of sections. The following brief description shows the type of information presented in each section: Introduction to DETECTIV – a brief description of DETECTIV and how it works. Getting Started - Setting up and looking after your DETECTIV – contains a packing list of the DETECTIV system. Details of the power requirements and battery care. How to set up DETECTIV ready for operation. Basic Operation – describes the basic procedures for using DETECTIV. This is not meant to be an exhaustive description of DETECTIV's capabilities or functionality, merely a quick guide to allow basic searches to be carried out. The following Mode sections give more details of the various modes and their use, in relation to the different detectors. Detect Mode – describes operating in this mode, which uses all of DETECTIV's detectors simultaneously, and interpreting the multi-detector display. Identify Mode – describes how to navigate through the different detector's Identify screens and how to use them to identify whether or not a detected response is a possible threat. Locate Mode – this section describes how to use DETECTIV to locate accurately the source of any identified threat. Event log – Gives details of the three Logs available within DETECTIV - Alarms, Snapshots and Reference. How entries are generated and what they are used for. Connection, download to a PC - gives details of how to connect to a PC and download Event log information. Appendices - Reference information about the DETECTIV unit, its component parts, controls and menu structure. 4 AUDIOTEL INTERNATIONAL MN400872 Issue 1 (0…

Text truncated - open the document above for the full version.

Letter of Agency 11 April 2005 TRL Compliance Services Ltd Long Green Forthampton Gloucester GL19 4QH To Whom It May Concern: We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drugs Abuse Act of 1998, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002(b), to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you for your attention to these matters. Yours faithfully Audiotel International Ltd Ian R Powell

Request for Confidentiality 11 April 2005 TRL Compliance Services Ltd Long Green Forthampton Gloucester GL19 4QH RE: Certification Application for Detect IV FCC ID: INO-2-400-0001 To Whom It May Concern: Please be advised that the following information is to be held confidential on behalf of Audiotel International Ltd. • XXXX • XXXX The application contains technical information which Audiotel International Ltd deems to be trade secrets and propriety. If made public, the information might be used to the disadvantage of the applicant in the market place. Thank you for your attention to this matter. Yours faithfully Audiotel International Ltd Ian R Powell

DO NOT SCALE ALL DIMENSIONS IN MILLIMETRES UNLESS OTHERWISE STATED TITLE SIMILAR TO DRAWN 000-FM000 753 MACHINING AND FABRICATION TOLERANCES UNLESS OTHERWISE STATED DIM'S 0.0 ± 0.25DIM'S 0.00 ± 0.10DIM'S 0.000 ± 0.05 ANGULAR 0.25° SURFACE TEXTURE CHKD CORBY ROAD, WELDON, CORBY, NN17 3AR TEL: +44 (0) 1536 266677 FAX: +44 (0) 1536 266711 EMAIL: [email protected] SCALE N/A SHEET PROJECT APPD DRAWING NUMBER 3RD ANGLE PROJECTION DRAWN AT A3 ISS. NO. DATE COMPLETE MCN NO. DRN BY CHANGE DESCRIPTION © THE COPYRIGHT IN THIS DRAWING BEING THE PROPERTY OF AUDIOTEL INTERNATIONAL LTD, SUCH COPYRIGHT MUST NOT BE INFRINGED, AND THE DRAWING MUST BE TREATED AS PRIVATE AND CONFIDENTIAL. THE DRAWING IS NOT TO BE COPIED OR COMMUNICATED TO ANY THIRD PARTY OR USED FOR THE PURPOSE OF MANUFACTURE WITHOUT PRIOR PERMISSION. FM400911 AI400872 AR DAE ABS MAIN UNIT ASSEMBLY I.S.K ORIGINAL ISSUE - AR 24-02-05 1.0 OF 6 BEND CABLE (DO NOT KINK) FRS3M1215 YELLOW BLUE GREEN NOTE MAKE NOTE OF SERIAL NUMBER OF BM400881 BEFORE FITTING AS IT IS ON BACK OF MODULE EN400930 WITH CS020 UNDER CROP COMPONENT PIN TO APPROX 1mm HIGH ADD FRP3M03 TO TOP OF INSERTS 2 31mm SHORT CABLE EN400863 FL5800MHZ-CF POSITION OVER 3 SMALL HOLES WITH 4 X CS020 UNDER FIT FILTER FL990MHZ-CF 1 2 3 1, RAP COPPER TAPE ROUND CONNECTOR 2, PLACE 50mm OF COPPER TAPE OVER CAN & FILTER 3, PLACE 50mm OF COPPER TAPE OVER CAN & FILTER PRESS EDGES TOGETHER TO SEAL NOTE FOR ALL SMA CONNECTORS USE SUHNER TOOL No 103

DO NOT SCALE ALL DIMENSIONS IN MILLIMETRES UNLESS OTHERWISE STATED TITLE SIMILAR TO DRAWN 000-FM000 753 MACHINING AND FABRICATION TOLERANCES UNLESS OTHERWISE STATED DIM'S 0.0 ± 0.25DIM'S 0.00 ± 0.10DIM'S 0.000 ± 0.05 ANGULAR 0.25° SURFACE TEXTURE CHKD CORBY ROAD, WELDON, CORBY, NN17 3AR TEL: +44 (0) 1536 266677 FAX: +44 (0) 1536 266711 EMAIL: [email protected] SCALE N/A SHEET PROJECT APPD DRAWING NUMBER 3RD ANGLE PROJECTION DRAWN AT A3 ISS. NO. DATE COMPLETE MCN NO. DRN BY CHANGE DESCRIPTION © THE COPYRIGHT IN THIS DRAWING BEING THE PROPERTY OF AUDIOTEL INTERNATIONAL LTD, SUCH COPYRIGHT MUST NOT BE INFRINGED, AND THE DRAWING MUST BE TREATED AS PRIVATE AND CONFIDENTIAL. THE DRAWING IS NOT TO BE COPIED OR COMMUNICATED TO ANY THIRD PARTY OR USED FOR THE PURPOSE OF MANUFACTURE WITHOUT PRIOR PERMISSION. FM400911 AI400872 AR DAE ABS MAIN UNIT ASSEMBLY I.S.K ORIGINAL ISSUE - AR 24-02-05 1.0 OF 6 OOOOOOO 1 FRR3M1116 SCREWED THROUGH FROM OPPO-SITE SIDE WITH FRS3M0634 BM400865 YELLOW BLUE GREEN RED EN400863 YELLOW UNDER BLUE THREAD OTHER ENDS THROUGH PCB GREEN UNDER RED REMOVE LIDS FROM CANS PLUG BM400896 INTO BM400897 FIT 34mm LONG CABLE EN400863 PLUG RED CABLE INTO BM400896 THREAD CABLE THROUGH PCB FIT PCB’S TOGETHER MAKE SURE ALL PINS ARE CONNECTED CORRECTLY FRS3M0634 FIT LIDS AFTER SCREWS FILTER FITTED LATER NOTE FOR ALL SMA CONNECTORS USE SUHNER TOOL No 103

Detect IV - FCC Certification File MN400928 V1.0 page 1 of Part 9 - RF Exposure Information Audiotel International LTD Detect IV FCC Certification File RF Exposure Information Detect IV - FCC Certification File MN400928 V1.0 page 2 of Part 9 - RF Exposure Information Table of contents RF EXPOSURE INFORMATION 3 Detect IV - FCC Certification File MN400928 V1.0 page 3 of Part 9 - RF Exposure Information RF Exposure Information The FCC limits for Maximum Permissible Exposure (MPE) for Occupational/Controlled Exposure within the NLJD TX frequency band is given below: 300-1500MHz = f/300 The frequency band of operation is 902.2MHz to 927.8MHz, therefore the following limits for MPE are given below: 902.2MHz = 3.007mW/cm 2 927.8MHz = 3.092mW/cm 2 The TX antenna is a wideband Archimedean spiral which has no gain. The peak chassis power is +31dBm. The peak output power including cable losses and circular polarisation is 500mW/M 2 The FCC Limits are given in mW/cm 2 , so peak output power needs to be converted into the correct units. 1M 2 = 10000cm 2 . Peak output power is 0.05mW/cm 2 From the above it can be seen that the unit is well within the limits for MPE. This level will be further reduced by the pulsed duty cycle of 10mS on to 90mS off and the location of the closest body part (the hand) at a minimum distance of 22cm.

File name AUDIOTEL.478A PAGE 1 OF 62 QMF21 – 8: FCC PART 15 ISSUE 01: - AUG 04 EMC RADIO TEST SERVICES S& RN Electronics FCC Test Report for Detect IV NLJD Report Number 09-478A/2634/6/04 (replaces report number 09-478/2634/6/04) Report Produced by: - R.N. Electronics Ltd. 1 Arnolds Court Arnolds Farm Lane Mountnessing ESSEX CM13 1UT www.rnelectronics.com Telephone 01277 352219 Facsimile 01277 352968 ©2004 RN ELECTRONICS LIMITED REPORT NUMBER 09-478A/2634/6/04 ALL RIGHTS RESERVED 1. Contents 1. Contents................................................................................................................................2 2. Summary of Test Results......................................................................................................3 3. Information about Equipment Under Test............................................................................4 4. Specifications........................................................................................................................5 5. Tests, Methods and Results...................................................................................................6 5.1 CONDUCTED EMISSIONS.........................................................................................................................6 5.2 RADIATED EMISSIONS.............................................................................................................................7 5.3 CARRIER FREQUENCY SEPARATION.......................................................................................................8 5.4 NUMBER OF HOPPING FREQUENCIES......................................................................................................9 5.5 DWELL TIME..........................................................................................................................................10 5.6 20DB BANDWIDTH................................................................................................................................11 5.7 PEAK OUTPUT POWER...........................................................................................................................12 5.8 BAND EDGE COMPLIANCE....................................................................................................................13 5.9 CONDUCTED EMISSIONS.......................................................................................................................14 6. Plots and Results.................................................................................................................15 6.1 CONDUCTED EMISSIONS.......................................................................................................................15 6.2 RADIATED EMISSIONS...........................................................................................................................23 6.3 CARRIER FREQUENCY SEPARATION.....................................................................................................43 6.4 NUMBER OF HOPPING FREQUENCIES....................................................................................................44 6.5 TIME OF OCCUPANCY (DWELL TIME)..................................................................................................45 6.6 20DB BANDWITH................................................................................................................................... 46 6.7 PEAK OUTPUT POWER...........................................................................................................................49 6.8 BAND-EDGE COMPLIANCE....................................................................................................................50 7. Explanatory Notes...............................................................................................................53 7.1 EXPLANATION OF FAIL LIMIT 1 STATEMENT....................................................................................53 7.2 EXPLANATION OF LIMIT LINE CALCULATIONS FOR RADIATED MEASUREMENTS.................................53 8. Photographs.........................................................................................................................54 9. Signal Leads........................................................................................................................58 10. Test Equipment Calibration list...........................................................................................59 11. Auxiliary equipment............................................................................................................60 11.1 AUXILIARY EQUIPMENT SUPPLIED BY AUDIOTEL INTERNATIONAL LTD........................................60 11.2 AUXILIARY EQUIPMENT SUPPLIED BY RN ELECTRONICS LIMITED.................................................60 12. Modifications......................................................................................................................61 13. Compliance information......................................................................................................62 File name AUDIOTEL.478A PAGE 2 OF 62 QMF21 – 8: FCC PART 15 ISSUE 01: - AUG 04 ©2004 RN ELECTRONICS LIMITED REPORT NUMBER 09-478A/2634/6/04 ALL RIGHTS RESERVED 2. Summary of Test Results The Detect IV was tested to the following standards: - FCC Part 15C (effective date March 17, 2004); Class DSS Intentional Radiator (FHSS) Title Reference Results 1. Conducted Emissions FCC Part 15C §15.207 NOT APPLICABLE 2. Radiated Emissions FCC Part 15C §15.209 PASSED 3. Carrier Frequency Separation §15.247 (a) (1) PASSED 4. Number of Hopping Frequencies §15.247 (a) (1) (i) PASSED 5. Dwell Time §15.247 (a) (1) (i) PASSED 6. 20dB Bandwidth §15.247 (a) (1) (i) PASSED 7. Peak Output Power §15.247 (b) (2) PASSED 8. Band Edge Compliance §15.247 (c) PASSED 9. Conducted Emissions §15.247 (c) PASSED 10. RF Exposure §15.247 (b) (5) NOT TESTED 11. Frequency Hopping §15.247 (g) S…

Text truncated - open the document above for the full version.
