IYG602XLink Wireless Telephone

SpectraLink Corporation 2 Link 6020 Wireless Telephone < * 2 ABC 1 4 GHI 7 PQRS 3 DEF 0 FCN LINE 6 MNO 9 WXYZ # > 5 JKL 8 TUV Volume Up START FCN Microphone LINE Keypad END Headset jack Softkeys Nav keys Left/Up For messaging applications Right/Down For messaging applications Volume Down Link 6020 Wireless Telephone and Accessories User Guide 3 Introduction Your Link 6020 Wireless Telephone is a state–of-the- art communication device that utilizes radio wave technology to send and receive voice transmissions. It is designed to operate like a cell phone. However, the handset utilizes the private telephone system installed in your facility and will not operate outside the area covered by this system. About This Guide This guide is meant to provide general information about your handset. Contact your phone system administrator for additional information on how your handset functions within your telephone system. This guide includes information about: • The Handset • Getting Started •Advanced Features • Handset Accessories • Handset Administration SpectraLink Corporation 4 Trademark Information SpectraLink The SpectraLink logo LinkPlus Link Are trademarks and registered trademarks of SpectraLink Corporation. All other trademarks used herein are the property of their respective owners. Copyright © 1998 to 2006 SpectraLink Corporation. All rights reserved Information in this document is subject to change without notice and does not represent a commitment on the part of SpectraLink Corporation. The software described in this document is furnished under a license and/or copyright and may only be used with the terms of SpectraLink’s software license agreement as found in this manual or at http://www.spectralink.com/consumer/resources/software_updates.jsp. The software may be used only in accordance with the terms of the agreement. No part of this manual, or the software described herein, may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose except for the sole intent to operate the product or without the express written permission of SpectraLink Corporation. For regulatory information, please see Link Wireless Telephone Regulatory Guide (72-1203-00). Registered Model Numbers This document covers registered handset model: 602X Registered charger models: PCS1850 Registered Battery Pack models: PBP0850, PBP1300, PBP1850 SpectraLink Corporation 5755 Central Avenue Boulder, CO 80301 303 440 5330 800 676 5465 www.spectralink.com Please email questions or comments about this document to [email protected]. Link 6020 Wireless Telephone and Accessories User Guide 5 Table of Contents The Handset ............................................................... 7 Modes of Operation ................................................................ 8 The Display ............................................................................... 8 Status Bar Indicators .............................................................10 Softkey Labels ........................................................................12 Shortcut Keys .........................................................................14 Profiles .....................................................................................14 Speakerphone .........................................................................15 Battery Packs ..........................................................................15 Getting Started ........................................................ 17 Charging Your Handset ........................................................18 Basic Handset Operation .....................................................18 Advanced Fe atures .................................................. 25 Menu Navigation ...................................................................26 Text Messaging (OAI) Navigation ......................................26 Shortcut Keys .........................................................................27 Data Entry and Editing ........................................................27 Setting User Preferences .......................................................29 Main Menu ..............................................................................30 User Profiles ...........................................................................32 Phone Settings ........................................................................47 Admin Settings .......................................................................54 Menu Grid ..............................................................................64 Advanced Telephony Features ............................................66 SpectraLink Corporation 6 Handset Accessories ................................................ 69 Single Charger ........................................................................ 74 Dual Charger .......................................................................... 75 Quad Charger ......................................................................... 77 Headsets .................................................................................. 78 Carrying Options ................................................................... 79 Handset Administration ........................................... 81 FAQs ....................................................................................... 82 Specifications ......................................................................... 85 About Safe Use of Wireless Telephones ........................... 86 Care of Your Handset .......................................................... 89 Notice ...................................................................................... 91 Link 6020 Wireless Telephone and Accessories User Guide 7 The Handset The Handset Modes of Operation .................................................................8 The Display .…

Text truncated - open the document above for the full version.

Link Wireless Telephone System Regulatory Guide P/N 72-1203-00-A Draft 4 SpectraLink Corporation 2 Trademark Information SpectraLink The SpectraLink logo LinkPlus Link Are trademarks and registered trademarks of SpectraLink Corporation. All other trademarks used herein are the property of their respective owners. Copyright © 1998 to 2006 SpectraLink Corporation. All rights reserved Information in this document is subject to change without notice and does not represent a commitment on the part of SpectraLink Corporation. The software described in this document is furnished under a license and/or copyright and may only be used with the terms of SpectraLink’s software license agreement as found in this manual or at http://www.spectralink.com/consumer/resources/software_updates.jsp. The software may be used only in accordance with the terms of the agreement. No part of this manual, or the software described herein, may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying and recording, for any purpose except for the sole intent to operate the product or without the express written permission of SpectraLink Corporation. SpectraLink Corporation 5755 Central Avenue Boulder, CO 80301 303 440 5330 800 676 5465 www.spectralink.com Please email questions or comments about this document to [email protected]. Link Wireless Telephone System Regulatory Guide 3 Introduction Your Link Wireless Telephone System (Link WTS) is a state–of- the-art business communication system that provides wireless tele- phone communication with the advanced features of your private telephone system. Base Stations installed throughout the facility transmit signals between the wireless telephones (handsets) and the Master Control Unit (MCU). The MCU routes calls between the Base Stations and the PBX. Handsets will not operate outside the area covered by this system. About This Guide This guide is meant to provide regulatory information about the Link WTS. Additional documents are available for information about the Link WTS. Registered Model Numbers Link 150: SCA416, SCA408, SCA516, SCC408, SCC416, SCD408, SCD416, SCE408, SCE416, SCF408, SCF416, SCI408, SCI416, SCJ408, SCJ416, SCK408, SCK416, SCL408, SCL416, SCM408, SCM416, SCN408, SCN416, SCO416, SCS416, SCT416, SCX416 Link 3000: JPI300, MCS300 Link Wireless Telephone: 602X Link Base Stations: RCC400, RCO400, RCU100, RCU200, RCU201 Link OAI Gateway: MOG400 Chargers: PCS1850, PCD1850, PCQ1850 Battery Packs: PBP0850, PBP1300, PBP1850  Please visit spectralink.com to view regulatory declarations. SpectraLink Corporation 4 Link Wireless Telephone System Regulatory Guide 5 Table of Contents Link 3000 MCU .......................................................... 7 FCC Information ..................................................................... 7 Industry Canada (IC) Notice ................................................. 8 Link 150 MCU .......................................................... 11 FCC Information ...................................................................11 Industry Canada (IC) Notice ...............................................12 Base Stations .......................................................... 15 Link 6020 Wireless Telephones ................................ 17 FCC Information ...................................................................17 International Certification Marks .............................. 19 Specific Absorption Rate (SAR) Information ...................20 Chargers .................................................................. 23 SpectraLink Corporation 6 Link Wireless Telephone System Regulatory Guide 7 Link 3000 MCU FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undes- ired operation. FCC Registration Numbers: Link 3000: IYGUSA-33400-PX-E Ringer Equivalence: Link 3000: 0.3B SpectraLink Corporation Link 3000 Made in the USA This equipment complies with Part 68 of the FCC Rules. On the back of this equipment is a label that contains, among other infor- mation, the FCC Registration Number and Ringer Equivalence Number (REN) for this equipment. If requested, this information must be given to the telephone company. This equipment uses RJ-21 connectors. The REN is useful to determine the quantity of devices you may connect to your telephone line and still have all of those devices ring when your number is called. In most, but not all, areas, the sum of the RENs of all devices connected to one line should not exceed five (5.0). To be certain of the number of devices you may connect to your line, as determined by the REN, you should con- tact your local telephone company to determine the maximum REN for your calling area. SpectraLink Corporation 8 If your telephone equipment causes harm to the telephone net- work, the telephone service may discontinue your service tempo- rarily. If possible, they will notify you in advance. But if advance notice isn’t practical, you will be notified as soon as possible. You will be informed of your right to file a complaint with the FCC. If you experience trouble with this telephone equipment, please contact SpectraLink Corporation for information on obtaining service or repairs. SpectraLink Corporation 5755 Central Avenue Boulder, CO 80301 303 440 5330 800 775 5330 [email protected] The telephone company may ask that you disconnect this equip- ment from the network until the problem has been corrected or until you are sure that the equipment is not malfunctioning. There are no user serviceable parts in this equipment. This equipment may not be used on coin service provided by the telephone company. Connection to party lines is subject to state tariffs. Industry Canada (IC) Notice The Industry Canada…

Text truncated - open the document above for the full version.

SpectraLink Corporation MODEL: 602X Report #R0601092S SAR Evaluation Report Page 51 of 95 Date/Time: 1/12/2006 7:17:11 PM Test Laboratory: Bay Area Compliance Lab Corp. 060111-Spectralink-602X-Body(800mAH) PTH200 DUT: 602X; Type: Sample; Serial: Communication System: Spectralink 900MHz Hopping System; Frequency: 914.737 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 914.737 MHz; σ = 1.04 mho/m; ε r = 55.2; ρ = 1000 kg/m 3 Phantom section: Flat Section DASY4 Configuration: • Probe: ET3DV6 - SN1604; ConvF(6.27, 6.27, 6.27); Calibrated: 3/18/2005 • Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE3 Sn456; Calibrated: 6/1/2004 • Phantom: SAM with CRP; Type: Twin SAM; Serial: TP-1032 • Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 1.5cm Body position (PTH200)/Area Scan (51x91x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.223 mW/g 1.5cm Body position (PTH200)/Zoom Scan (5mmx5mmx5mm): Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 7.32 V/m; Power Drift = 0.087 dB Peak SAR (extrapolated) = 0.270 W/kg SAR(1 g) = 0.208 mW/g; SAR(10 g) = 0.150 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.222 mW/g Plot #5 SpectraLink Corporation MODEL: 602X Report #R0601092S SAR Evaluation Report Page 52 of 95 Date/Time: 1/11/2006 7:17:22 PM Test Laboratory: Bay Area Compliance Lab Corp. 060111-Spectralink-602X_Left Head(800mAH) TOUCH DUT: 602X; Type: Sample; Serial: Communication System: Spectralink 900MHz Hopping System; Frequency: 914.737 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 914.737 MHz; σ = 0.959 mho/m; ε r = 40.6; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: • Probe: ET3DV6 - SN1604; ConvF(6.62, 6.62, 6.62); Calibrated: 3/18/2005 • Sensor-Surface: 4mm (Mechanical And Optical Surface Detection) • Electronics: DAE3 Sn456; Calibrated: 6/1/2004 • Phantom: SAM with CRP; Type: SAM; • Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 Touch position - Middle/Area Scan (51x71x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.435 mW/g Touch position - Middle/Zoom Scan (5mmx5mmx5mm): Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 16.7 V/m; Power Drift = -0.080 dB Peak SAR (extrapolated) = 0.579 W/kg SAR(1 g) = 0.412 mW/g; SAR(10 g) = 0.279 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.439 mW/g Plot #6 SpectraLink Corporation MODEL: 602X Report #R0601092S SAR Evaluation Report Page 53 of 95 Date/Time: 1/11/2006 7:32:13 PM Test Laboratory: Bay Area Compliance Lab Corp. 060111-Spectralink-602X_Left Head(800mAH) TILT DUT: 602X; Type: Sample; Serial: Communication System: Spectralink 900MHz Hopping System; Frequency: 914.737 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 914.737 MHz; σ = 0.959 mho/m; ε r = 40.6; ρ = 1000 kg/m 3 Phantom section: Left Section DASY4 Configuration: • Probe: ET3DV6 - SN1604; ConvF(6.62, 6.62, 6.62); Calibrated: 3/18/2005 • Sensor-Surface: 4mm (Mechanical Surface Detection) • Electronics: DAE3 Sn456; Calibrated: 6/1/2004 • Phantom: SAM with CRP; Type: SAM; • Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 Tilt position - Middle/Area Scan (51x91x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.273 mW/g Tilt position - Middle/Zoom Scan 1 (5mmx5mmx5mm): Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 15.8 V/m; Power Drift = -0.093 dB Peak SAR (extrapolated) = 0.337 W/kg SAR(1 g) = 0.254 mW/g; SAR(10 g) = 0.184 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.271 mW/g Plot #7 SpectraLink Corporation MODEL: 602X Report #R0601092S SAR Evaluation Report Page 54 of 95 Date/Time: 1/11/2006 12:02:05 PM Test Laboratory: Bay Area Compliance Lab Corp. 060111-Spectralink-602X-Right Head(800mAH) TOUCH DUT: 602X; Type: Sample; Serial: Communication System: Spectralink 900MHz Hopping System; Frequency: 914.737 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 914.737 MHz; σ = 0.959 mho/m; ε r = 40.6; ρ = 1000 kg/m 3 Phantom section: Right Section DASY4 Configuration: • Probe: ET3DV6 - SN1604; ConvF(6.62, 6.62, 6.62); Calibrated: 3/18/2005 • Sensor-Surface: 4mm (Mechanical And Optical Surface Detection)Sensor-Surface: 0mm (Fix Surface) • Electronics: DAE3 Sn456; Calibrated: 6/1/2004 • Phantom: SAM with CRP; Type: Twin SAM; Serial: TP-1032 • Measurement SW: DASY4, V4.6 Build 23; Postprocessing SW: SEMCAD, V1.8 Build 160 Touch position - Middle/Area Scan (51x71x1): Measurement grid: dx=15mm, dy=15mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.445 mW/g Touch position - Middle/Z Scan (1x1x21): Measurement grid: dx=20mm, dy=20mm, dz=10mm Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (interpolated) = 0.314 mW/g Touch position - Middle/Zoom Scan (5mmx5mmx5mm): Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 17.9 V/m; Power Drift = -0.018 dB Peak SAR (extrapolated) = 0.581 W/kg SAR(1 g) = 0.424 mW/g; SAR(10 g) = 0.293 mW/g Info: Interpolated medium parameters used for SAR evaluation. Maximum value of SAR (measured) = 0.454 mW/g Plot #8 SpectraLink Corporation MODEL: 602X Report #R0601092S SAR Evaluation Report Page 55 of 95 Date/Time: 1/11/2006 1:01:40 PM Test Laboratory: Bay Area Compliance Lab Corp. 060111-Spectralink-602X-Right Head(800mAH) tilt DUT: 602X; Type: Sample; Serial: Communication System: Spectralink 900MHz Hopping System; Frequency: 914.737 MHz;Duty Cycle: 1:1 Medium parameters used (interpolated): f = 914.737 MHz; σ = 0.959 mho…

Text truncated - open the document above for the full version.

Note: This test report is specially limited to the above client company and the product model only. It may not be duplicated without prior written consent of Bay Area Compliance Laboratory Corporation. This report must not be used by the client to claim product certification, approval, or endorsement by NVLAP, NIST or any agency of the U.S. Government. SAR EVALUATION REPORT For SpectraLink Corporation 5755 Central Ave. Boulder, Colorado 80301 MODEL: 602X This Report Concerns: Original Report Equipment Type: 900MHz Phone Test Engineer: Snell Leong Report No.: R0601092S Report Date: 2006-02-06 Reviewed By: Daniel Deng Prepared By: Bay Area Compliance Laboratory Corporation (BACL) 230 Commercial Street Sunnyvale, CA 94085 Tel: (408) 732-9162 Fax: (408) 732 9164 SpectraLink Corporation MODEL: 602X Report #R0601092S SAR Evaluation Report Page 2 of 95 DECLARATION OF COMPLIANCE SAR EVALUATION Rule Part(s): FCC §2.1093 & IEEE 1528 Test Procedure(s): FCC OET Bulletin 65 Supplement C & IEEE 1528 Device Classification: Unlicensed Device Type: 900MHz Phone Model Number: 602X Modulation: GFSK TX Frequency Range: 902.4817- 927.4826 MHz Max. Conducted Power Tested: 22.50 (800mAH) / 22.51 (1100mAH) / 22.52 (1600mAH) dBm Antenna Type(s): Integral Antenna Body-Worn Accessories: Headset Face-Head Accessories: None Max. SAR Level(s) Measured: 0.223 mW/g (1g, 900MHz, Body), 0.463 mW/g (1g, 900MHz, Head) BACL Corp. declares under its sole responsibility that this wireless portable device has been determined to be in compliance for localized specific absorption rate (SAR) for uncontrolled exposure and general population exposure limits has been tested in accordance with the measurement procedures specified in ANSI IEEE C95.3:2002 All measurements reported herein were performed under my supervision and believed to be accurate to the best of my knowledge. I further attest for the completeness of these measurements and vouch for the qualifications any and all personnel performing such measurements. The results and statements contained in this report pertain only to the device(s) evaluated. /signature/ Snell Leong Bay Area Compliance Laboratory Corp. SpectraLink Corporation MODEL: 602X Report #R0601092S SAR Evaluation Report Page 3 of 95 TABLE OF CONTENTS REFERENCE, STANDARDS, AND GUILDELINES ...............................................................................................5 SAR LIMITS.................................................................................................................................................................6 EUT DESCRIPTION ....................................................................................................................................................7 DESCRIPTION OF TEST SYSTEM ..........................................................................................................................8 MEASUREMENT SYSTEM DIAGRAM...........................................................................................................................10 SYSTEM COMPONENTS...............................................................................................................................................12 TESTING EQUIPMENT............................................................................................................................................21 EQUIPMENTS LIST & CALIBRATION INFO...................................................................................................................21 SAR MEASUREMENT SYSTEM VERIFICATION ..............................................................................................22 SYSTEM ACCURACY VERIFICATION...........................................................................................................................22 EUT TEST STRATEGY AND METHODOLOGY .................................................................................................23 SAR EVALUATION PROCEDURE.................................................................................................................................23 CONCLUSION ............................................................................................................................................................24 SAR BODY WORST-CASE TEST DATA.......................................................................................................................24 APPENDIX A – MEASUREMENT UNCERTAINTY ............................................................................................25 APPENDIX B – PROBE CALIBRATION CERTIFICATES .................................................................................27 APPENDIX C – DIPOLE CALIBRATION CERTIFICATES ...............................................................................38 APPENDIX D - TEST SYSTEM VERIFICATIONS SCANS .................................................................................44 LIQUID MEASUREMENT RESULT................................................................................................................................44 APPENDIX E - EUT SCANS .....................................................................................................................................47 APPENDIX F – CONDUCTED OUTPUT POWER MEASUREMENT ...............................................................74 PROVISION APPLICABLE.............................................................................................................................................74 TEST PROCEDURE......................................................................................................................................................74 TEST EQUIPMENT.......................................................................................................................................................74 TEST RESULTS.............................................................................................................................…

Text truncated - open the document above for the full version.

COVER PAGE Test of SpectraLink 602X Telephone To: FCC 47 CFR Part15.247 & IC RSS-210 Test Report Serial No.: TUVR89-A7 Rev A TITLE PAGE TEST REPORT FROM Test of SpectraLink 602X Telephone To FCC 47 CFR Part15.247 & IC RSS-210 Test Report Serial No.: TUVR89-A7 Rev A This report supersedes None Manufacturer: SpectraLink Corporation 5755 Central Avenue Boulder Colorado 80301, USA Product Function: 900 MHz Wireless Telephone Copy No:pdf Issue Date: 6th March 06 This Test Report is Issued Under the Authority of; MiCOM Labs, Inc. 3922 Valley Avenue, Suite B Pleasanton, CA 94566 USA Phone: +1 (925) 462-0304 Fax: +1 (925) 462-0306 www.micomlabs.com CERTIFICATE #2381.01 MiCOM Labs is an ISO 17025 Accredited Testing Laboratory This test report may be reproduced in full only. The document may only be updated by MiCOM Labs personnel. Any changes will be noted in the Document History section of the report. Title: To: SpectraLink 602X Telephone FCC 47 CFR Part15.247 & IC RSS-210 Serial #: Issue Date: Page: TUVR89-A7 Rev A 6th March 06 3 of 73 This test report may be reproduced in full only. The document may only be updated by MiCOM This page has been left intentionally blank Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 3922 Valley Avenue, Suite B, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com Title: SpectraLink 602X Telephone To: Serial #: Issue Date: Page: FCC 47 CFR Part15.247 & IC RSS-210 TUVR89-A7 Rev A 6th March 06 4 of 73 This test report may be reproduced in full only. The document may only be updated by MiCOM TABLE OF CONTENTS ACCREDITATION & LISTINGS.........................................................................................5 1. TEST RESULT CERTIFICATE........................................................................8 2. REFERENCES AND MEASUREMENT UNCERTAINTY...............................9 2.1. Normative References............................................................................................9 2.2. Test and Uncertainty Procedures...........................................................................9 3. PRODUCT DETAILS AND TEST CONFIGURATIONS...............................10 3.1. Technical Details..................................................................................................10 3.2. Scope of Test Program.........................................................................................11 3.3. Equipment Model(s) and Serial Number(s)..........................................................13 3.4. Antenna Details....................................................................................................13 3.5. Cabling and I/O Ports...........................................................................................13 3.6. Test Configurations...............................................................................................14 3.7. Equipment Modifications.......................................................................................14 3.8. Deviations from the Test Standard.......................................................................14 3.9. Subcontracted Testing or Third Party Data..........................................................15 4. TEST SUMMARY...........................................................................................16 5. TEST RESULTS.............................................................................................18 5.1. Device Characteristics..........................................................................................18 5.1.1. 20 dB Bandwidth......................................................................................18 5.1.2. Transmitter Channels - Channel Spacing..............................................21 Channel Spacing (continued)................................................................................22 5.1.3. Transmitter Channels...............................................................................23 5.1.4. Output Power...........................................................................................27 5.1.5. Conducted Spurious Emissions...............................................................30 5.1.6. Radiated Emissions.................................................................................40 5.1.7. Radiated Spurious Emissions (30M-1 GHz).............................................52 5.1.8. AC Wireline Conducted Emissions (150 kHz – 30 MHz)..........................64 6. PHOTOGRAPHS............................................................................................68 6.1. General Measurement Test Set-Up......................................................................68 6.2. Radiated Emissions >1 GHz.................................................................................69 6.3. Radiated Emissions (30 MHz-1 GHz)...................................................................70 6.4. AC Wireline Conducted Emissions (150 kHz – 30 MHz)......................................71 Labs personnel. Any changes will be noted in the Document History section of the report. MiCOM Labs, 3922 Valley Avenue, Suite B, Pleasanton, CA 94566 USA, Phone: 925.462.0304, Fax: 925.462.0306, www.micomlabs.com 7. TEST EQUIPMENT DETAILS.......................................................................72 Title: SpectraLink 602X Telephone To: Serial #: Issue Date: Page: FCC 47 CFR Part15.247 & IC RSS-210 TUVR89-A7 Rev A 6th March 06 5 of 73 This test report may be reproduced in full only. The document may only be updated by MiCOM ACCREDITATION & LISTINGS MiCOM Labs, Inc. an accredited laboratory complies with the international standard BS EN ISO/IEC 17025. The company is accredited by the American Association for Laboratory Accreditation (A2LA) www.a2la.org test laboratory number 2381.01. MiCOM Labs test schedule is available at the following URL; http://www.a2la.org/scopepdf/2381-01.pdf Labs…
