mtu301 Owner’s Manual Page 1 of 6 mtu301 Owner’s Manual Cover: SpectraPulse® Ultra Wideband Wireless Microphone System mtu301 Body‐pack Transmitter Set‐up and Operation Inside: This device complies with Part 15 of the FCC rules. Operation is subject to the condition that device does not cause harmful interference. This device complies with INDUSTRY CANADA R.S.S. 220 en conformite avec IC:RSS‐220/CNR220 Operation is subject to the following conditions: 1) This device may not cause harmful interference and 2) this device must accept any interference received, including interference which may cause undesired operation. Changes or modifications not expressly approved by Audio‐Technica could void your authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate ra dio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is unlikely to cause harmful interference. However, if the equipment does cause harmful interference, the user will be require d to correct the interference at own expense. CAUTION! Electrical shock can result from removal of SpectraPulse® components' covers. Refer servicing to qualified service personnel. No user‐serviceable parts inside. Do not expose to rain or moisture. The circuits inside the SpectraPulse® components have been precisely adjusted for optimum performance and compliance with federal regulations. Do not attempt to open the rcu104 Receiver Coordinator Unit, drm141 Digital Receiver Module (main assembly), aci707 Audio Control Interface, mtu101 Boundary Microphone Transmitter, mtu201 XLR Desk Stand Transmitter, mtu301 Body‐pack Transmitter, or cei007 Charger Encryption Interface. To do so will void the warranty, and may cause improper operation. Notice to individuals with implanted cardiac pacemakers or AICD devices: Any source of RF (radio frequency) energy may interfere with normal functioning of the implanted device. All wireless microphones have low‐power transmitters (less than 0.05 watts output) which are unlikely to cause difficulty, especially if they are at least a few inches away. Note also that any medical‐ device disruption will cease when the RF transmitting source is turned off. Please contact your physician or medical‐device provider if you have any questions, or experience any problems with the use of this or any other RF equipment. Please note that your SpectraPulse® system operates in a frequency band in a way which may make its use subject to certain FCC and other regulatory agency restrictions and licensing requirements. No changes or modifications may be made to this equipment except by the expressly approved responsible party for compliance. Changes or modifi cations could void the user’s authority to operate the mtu301 Owner’s Manual Page 2 of 6 equip ment, and will also void Audio‐Technica warranty coverage. For further information, Please contact your local office of the FCC as applicable. Battery precautions  Each mtu301 Body‐pack Transmitter is powered by 2 AA batteries: AA 1.5V alkaline batteries (included) or rechargeable SANYO brand AA Nickel Metal Hydride.  When using rechargeable batteries, always use rechargeable AA NiMH batteries.  Rechargeable batteries must be charged before initial use or after prolonged non‐use.  When inserting batteries into the mtu301, observe correct polarity as marked.  Do not use a leaking battery. If battery leakage occurs, avoid contact with skin. If skin contact occurs, immediately wash the affected skin area thor oughly with soap and water. If battery leakage comes into contact with your eyes, immediately flush with water and seek medical attention.  Do not expose the batteries to fire. Do not heat, deform, solder, disassemble or modify.  Do not peel off or damage the outer tube of a battery.  If batteries become damaged, dispose of properly.  Please recycle rechargeable batteries.  Do not use these batteries together with dry cells, other types of batteries, new and old batteries together, or batteries with different charge levels. Note: This SpectraPulse® system is approved for indoor use only. Note: See Sp ectraPulse® Owner’s Manual for full system specifications. Contents What’s in the box Page x mtu301 Body‐pack Transmitter Installation & Operation Page x mtu301 Body‐pack Transmitter Controls and Functions Page x mtu301 Body‐pack Transmitter Specifications Page x What’s in the box:  SpectraPulse® mtu301 Body‐pack Transmitter  AA 1.5V alkaline batteries (2 batteries per transmitter) Note: For SpectraPulse® system operation, see SpectraPulse® Owners Manual. mtu301 Body‐pack Transmitter Installation & Operation Thank you for purchasing the mtu301 Body‐pack Transmitter, a component of Audio‐Technica’s award‐ winning SpectraPulse® Ultra Wideband Wireless Microphone System. Please follow the information containe d in this manual closely, and refer to the SpectraPulse® Owners Manual for system operating instructions. The mtu301 Body‐pack Transmitter is optimized to work with a number of Audio‐Technica lavalier and headworn microphones pre‐terminated with a compatible input connector; these wireless microphone product numbers end with the desig nation “cW”. The cable connector latches automatically when inserted into the microphone input jack. To unlatch and remove the connector, pull up on the connector’s knurled metal collar. mtu301 Owner’s Manual Page 3 of 6 The unit provides bias voltage for electret condenser microphones and features 9‐hour battery life. It also offers an on/off switch, a mute switch, and LEDs indicating power/mute and l…

Text truncated - open the document above for the full version.

Audio-Technica U.S., Inc. 1221 Commerce Drive, Stow, Ohio 44224 March 11, 2011 MET Laboratories, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: CONFIDENTIALITY REQUEST FOR SPECTRAPULSE MTU301 IC1752B To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the SpectraPulse UWB wireless products including MTU301 and documents eligible for confidentiality: Schematics, Block Diagrams, Operational Description, PCBs, Parts Lists/BOMs, Tune up Procedures required to be submitted with this application be permanently withheld from public review. This is requested as a required condition of a proprietary exclusive technology licensing agreement, and to ensure that our intellectual property, expertise and know-how do not become known or possessed by our competitors now or in the future. Please contact me if there is any information you may need. Sincerely, Jacquelynn Green V.P. R&D/Engineering Audio-Technica U.S., Inc. 1221 Commerce Dr. Stow, OH 44224

P13407-DEV02 10/28/2010 P13407-DEV02 10/28/2010 P13407-DEV02 10/28/2010

MTU301 Antenna Specifications Specifications Part number 701-1020-000 REV:A Antenna Type Cylindrical Monopole Center Frequency 6.35GHz Bandwidth 500MHz Directivity 5.16 dB Pattern Omnidirectional Impedance 50 ohm VSWR Less than 1: 1.5 over the working bandwidth Polarization Vertical Maximum Power 5 Watts Connector Solder mounted to PCB Dimensions 0.395" L 0.186" DIA (max) Weight 0.02 oz.

MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE ! BALTIMORE, MARYLAND 21230-3432 ! PHONE (410) 354-3300 ! FAX (410) 354-3313 33439 WESTERN AVENUE ● UNION CITY, CALIFORNIA 94587 ● PHONE (510) 489-6300 ● FAX (510) 489-6372 3162 BELICK STREET ● SANTA CLARA, CALIFORNIA 95054 ● PHONE (408 748-3585 ● FAX (510) 489-6372 The Nation’s First Licensed Nationally Recognized Testing Laboratory Audio-Technica November 12, 2010 1221 Commerce Drive Stow, Ohio 44224-1760 Dear Chris Henderson, Enclosed is the EMC test report for compliance testing of the Audio-Technica, SpectraPulse Beltpack, MTU301, tested to the requirements of Title 47 of the Code of Federal Regulations (CFR), Part 15 Subpart B and ICES-003, Issue 4 February 2004 for a Class A Digital Device. Thank you for using the services of MET Laboratories, Inc. If you have any questions regarding these results or if MET can be of further service to you, please feel free to contact me. Sincerely yours, MET LABORATORIES, INC. Jennifer Warnell Documentation Department Reference: (\Audio-Technica\EMC30074-FCC) Certificates and reports shall not be reproduced except in full, without the written permission of MET Laboratories, Inc. This letter of transmittal is not a part of the attached report. MET Laboratories, Inc. Safety Certification - EMI - Telecom Environmental Simulation 914 WEST PATAPSCO AVENUE ! BALTIMORE, MARYLAND 21230-3432 ! PHONE (410) 354-3300 ! FAX (410) 354-3313 33439 WESTERN AVENUE ● UNION CITY, CALIFORNIA 94587 ● PHONE (510) 489-6300 ● FAX (510) 489-6372 3162 BELICK STREET ● SANTA CLARA, CALIFORNIA 95054 ● PHONE (408 748-3585 ● FAX (510) 489-6372 Electromagnetic Compatibility Test Report For the Audio-Technica SpectraPulse Beltpack, MTU301 Tested under Title 47 of the Code of Federal Regulations (CFR), Part 15 Subpart B & ICES-003 for a Class A Digital Device 0 MET Report: EMC30074-FCC November 12, 2010 Prepared For: Audio-Technica 1221 Commerce Drive Stow, Ohio 44224-1760 Prepared By: MET Laboratories, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 DOC-EMC700 8/22/2005 Audio-Technica Electromagnetic Compatibility SpectraPulse Beltpack, MTU301 CFR Title 47, Part 15, Subpart B Electromagnetic Compatibility Test Report For the Audio-Technica SpectraPulse Beltpack, MTU301 Tested under Title 47 of the Code of Federal Regulations (CFR), Part 15 Subpart B & ICES-003 for a Class A Digital Device 1 MET Report: EMC30074-FCC Dusmantha Tennakoon Jennifer Warnell Project Engineer, Electromagnetic Compatibility Lab Documentation Department Engineering Statement: The measurements shown in this report were made in accordance with the procedures indicated, and the emissions from this equipment were found to be within the applicable limits. I assume full responsibility for the accuracy and completeness of these measurements, and for the qualifications of all persons taking them. It is further stated that upon the basis of the measurements made, the equipment tested is capable of operation in accordance with the requirements of Title 47 of the CFR, Part 15, Subpart B and Industry Canada standards ICES-003, Issue 4 February 2004 for a Class A Digital Device under normal use and maintenance. Shawn McMillen, Wireless Manager, Electromagnetic Compatibility Lab MET Report: EMC30074-FCC © 2010, MET Laboratories, Inc. Page ii of vi DOC-EMC700 8/22/2005 Audio-Technica Electromagnetic Compatibility SpectraPulse Beltpack, MTU301 CFR Title 47, Part 15, Subpart B & ICES-003 Report Status Sheet Revision Report Date Reason for Revision Ø November 12, 2010 Initial Issue. MET Report: EMC30074-FCC © 2010, MET Laboratories, Inc. Page iii of vi DOC-EMC700 8/22/2005 Audio-Technica Electromagnetic Compatibility SpectraPulse Beltpack, MTU301 CFR Title 47, Part 15, Subpart B & ICES-003 MET Report: EMC30074-FCC © 2010, MET Laboratories, Inc. Page iv of vi DOC-EMC700 8/22/2005 Table of Contents 1.0 Testing Summary ........................................................................................................................................................ 1 2.0 Equipment Configuration........................................................................................................................................... 2 2.1 Overview................................................................................................................................................................. 2 2.2 Test Site .................................................................................................................................................................. 3 2.3 Description of Test Sample ..................................................................................................................................... 3 2.4 Equipment Configuration........................................................................................................................................ 3 2.5 Support Equipment ................................................................................................................................................. 4 2.6 Ports and Cabling Information ................................................................................................................................ 4 2.7 Mode of Operation .................................................................................................................................................. 6 2.8 Modifications .......................................................................................................................................................... 6 2.8.1 Modifications to EUT .......................................................................................................................... 6 2.8.2 Modifications to Test Standard ............................................................................................................ 6 2.9 Disposition of EUT .......................…

Text truncated - open the document above for the full version.

Photograph 1. Conducted Emissions, Charging Mode Photograph 2. Conducted Emissions, Peripheral Mode Photograph 3. Radiated Emissions, Peripheral Mode Photograph 4. Radiated Emissions, Charging Mode Photograph 5. Radiated Emissions, Running on Batteries Photograph 6. Spurs below 960 MHz Photograph 7. Spurs above 960 MHz
