JFZT210DTransmitter

TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: Test Report Product Name: TRANSMITTER FCC ID: JFZT210D Applicant: AUDIO TECHNICA CORPORATION 2206 NARUSE, MACHIDA TOKYO, 194 JAPAN Date Receipt: OCTOBER 20, 2004 Date Tested: OCTOBER 27, 2004 JFZT210D REPORT #: A\AudioTechnica_JFZ\1722UT4\1722UT4TestReport.doc COVER SHEET TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: JFZT210D TABLE OF CONTENTS LIST TEST REPORT CONTAINING: PAGE 1........GENERAL INFORMATION & TECHNICAL DESCRIPTION PAGE 2........TECHNICAL DESCRIPTIONS CONT. RF POWER OUTPUT PAGE 3........MODULATION CHARACTERISTICS AUDIO FREQUENCY RESPONSE GRAPH AUDIO LOW PASS FILTER PAGE 4........MODULATION LIMITING PLOT PAGE 5-6......OCCUPIED BANDWIDTH PAGE 7........RADIATED SPURIOUS EMISSIONS TEST DATA PAGE 8........METHOD OF MEAUSRING RADIATED SPURIOUS EMISSIONS PAGE 9........FREQUENCY STABILITY TEST DATA PAGE 10-11....EQUIPMENT LIST EXHIBITS CONTAINING: CONFIDENTIALITY LETTER BLOCK DIAGRAM SCHEMATICS PARTS LIST LABEL SAMPLE LABEL LOCATION USERS MANUAL EXTERNAL PHOTOGRAPHS INTERNAL PHOTOGRAPHS ALIGNMENT PROCEDURE OPERATIONAL DESCRIPTION TEST SET UP PHOTOGRAPH JFZT210D REPORT #: A\AudioTechnica_JFZ\1722UT4\1722UT4TestReport.doc TABLE OF CONTENTS TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: GENERAL INFORMATION REQUIRED FOR TYPE ACCEPTANCE 2.1033(c)(1) AUDIO TECHNICA CORPORATION will manufacture the T210D 2.1033(c)(2) in quantity, for use under FCC RULES PART 74.801, LOW POWER AUXILIARY STATIONS. AUDIO TECHNICA CORPORATION 2206 NARUSE, MACHIDA TOKYO, 194 JAPAN 2.1033 TECHNICAL DESCRIPTION (c)(1) Maximum Output Power Rating: 1 Watt into 50 ohms resistive load. (c)(3) Instruction book. The instruction manual is included in the exhibits. (c)(4) Type of Emission: 100K0F3E Bn = 2M + 2DK M = 20 kHz D = 30 kHz K = 1 Bn = 2(20k) + 2(30k)(1) = 100k 74.861 (e)(5) ALLOWED AUTHORIZED BANDWIDTH = 200 kHz. (c)(6) Frequency Range: 655-680 MHz (c)(7) Power Range and Controls: UNIT has no controls. (c)(9) DC Voltages and Current into Final Amplifier: FINAL AMPLIFIER ONLY High Vce = 3.0 VDC Ice = 0.3 A Pin = 0.9 Watts (c)(10) Tune-up procedure. The tune-up procedure is included in the exhibits. (c)(11) Complete Circuit Diagrams: The circuit diagram and block diagram are included in the exhibits. JFZT210D REPORT #: A\AudioTechnica_JFZ\1722UT4\1722UT4TestReport.doc Page 1 of 11 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: 2.1033(c)(12) Photo or Drawing of Label and sketch of location: Please see the exhibits. 2.1033(c)(13) Photos of Equipment: Please see the exhibits. (c)(14) Description of all circuitry and devices provided for determining and stabilizing frequency. Description of any circuits or devices employed for suppression of spurious radiation, for limiting modulation, and for limiting power. This circuitry is included in the exhibits. Limiting Modulation: The transmitter audio circuitry is contained in IC101, IC102 and IC103. Limiting Power: There is no provision for limiting power. (15) Digital modulation. This unit does not use digital modulation. 2.1033(c)(16) The data required by 2.1046 through 2.1057 is submitted below. 2.1046 RF power output RF power measured is: OUTPUT POWER: 0.025 WATTS ERP R.F. POWER OUTPUT TEST PROCEDURE JFZT210D REPORT #: A\AudioTechnica_JFZ\1722UT4\1722UT4TestReport.doc Page 2 of 11 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: 2.1047(a)(b) Modulation characteristics: AUDIO_FREQUENCY_RESPONSE The audio frequency response was measured in accordance with TIA/EIA Specification 603. The audio frequency response curve is shown below. Audio Frequency Response -0 +5 +1 +2 +3 +4 d B 100 20k 200 500 1k 2k 5k 10k Hz AUDIO_LOW_PASS_FILTER The audio low pass filter is not required in this unit. JFZT210D REPORT #: A\AudioTechnica_JFZ\1722UT4\1722UT4TestReport.doc Page 3 of 11 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: 2.1047(b) Audio input versus modulation A plot of the audio input versus deviation is shown in the following plots. Modulation Limiting Plots: 15KHz (Green), 2.5KHz (Blue), and 300 Hz (Yellow) 30 k H z -30 +10-25 -20 -15-10-5+0 +5 dBu JFZT210D REPORT #: A\AudioTechnica_JFZ\1722UT4\1722UT4TestReport.doc Page 4 of 11 TIMCO ENGINEERING INC. 849 NW State Road 45 Newberry, Florida 32669 http://www.timcoengr.com 888.472.2424 F 352.472.2030 email: [email protected] APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: 2.1049 Occupied bandwidth: Data in the plots show that all sidebands between 50 & 100% for the authorized bandwidth are attenuated by at least 25dB. From 100 to 250% of the authorized bandwidth they are attenuated by at least 35 dB and beyond 250% 43 + log(Po) dB. The plot show the transmitter modulated with 15000 Hz(the highest modulation frequency), adjusted for 50% modulation plus 16 dB. The spectrum analyzer was set with the un-modulated carrier at the top of the screen. The test procedure diagram and occupied bandwidth plots follow. Microphone transmitter Test procedure diagram OCCUPIED BANDWIDTH MEASUREMENT REQUIREMENT: 200kHz EMISSION BANDWIDTH JFZT210D REPORT #: A\AudioTechnica_JFZ\1722UT4\1722UT4TestReport.doc …

Text truncated - open the document above for the full version.
