JFZT220BDHANDHELD WIRELESS MICROPHONE

2000 Series Frequency-agile True Diversity UHF Wireless System Installation and Operation 2000_Series_UM_V8_EN_200129.indd 12020/01/29 12:52 2000 Series Installation and Operation 2 This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. This device complies with INDUSTRY CANADA R.S.S. 210, en conformité avec IC: RSS-210/CNR210. Operation is subject to the following conditions: 1) This device may not cause harmful interference and 2) this device must accept any interference received, including interference which may cause undesired operation. Hereby Audio-Technica declares that this device complies with the essential requirements and other relevant provisions of the Radio Equipment Directive 2014/53/EU. FCC Notice Caution You are cautioned that any changes or modifications not expressly approved in this manual could void your authority to operate this equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. A copy of the user manual and DOC can be found at www.audio-technica.com. Contact: Responsible Company: Audio-Technica U.S., Inc. Address: 1221 Commerce Drive, Stow, Ohio 44224, USA Tel: 330-686-2600 CAUTION! Electrical shock can result from removal of the receiver cover. Refer servicing to qualified service personnel. No user- serviceable parts inside. • To prevent fire or shock hazard, do not expose this appliance to rain or moisture. • To prevent fire, do not place any naked flame sources (such as lighted candles) on the apparatus. • To prevent fire, do not cover the ventilation of the apparatus with newspaper, tablecloths, curtains etc. • Do not expose this apparatus to drips or splashes. • Do not place any objects filled with liquids, such as vases, on the apparatus. • Do not install this apparatus in a confined space such as a bookcase or similar unit. • The apparatus should be located close enough to the AC outlet so that you can easily grasp the AC adapter at any time. In case of emergency, disconnect the AC adapter quickly. • Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. • Always consider environmental issues and follow your local regulations when disposing of batteries. Do not expose batteries to excessive heat. The circuits inside the receiver and transmitter have been precisely adjusted for optimum performance and compliance with federal regulations. Do not attempt to open the receiver or transmitter. To do so will void the warranty, and may cause improper operation. Notice to individuals with implanted cardiac pacemakers or AICD devices: Any source of RF (radio frequency) energy may interfere with normal functioning of the implanted device. All wireless microphones have low-power transmitters (less than 0.05 watts output) which are unlikely to cause difficulty, especially if they are at least a few inches away. However, since a “body-pack” mic transmitter typically is placed against the body, we suggest attaching it at the belt, rather than in a shirt pocket where it may be immediately adjacent to the medical device. Note also that any medical-device disruption will cease when the RF transmitting source is turned off. Please contact your physician or medical-device provider if you have any questions, or experience any problems with the use of this or any other RF equipment. RF Interference Please note that wireless frequencies are shared with other radio services. According to Federal Communications Commission regulations, “Wireless microphone operations are unprotected from interference from other licensed operations in the band. If any interference is received by any Government or non Government operation, the wireless microphone must cease operation...” If you need assistance with operation or frequency selection, please contact your dealer or Audio-Technica. Extensive wireless information also is available at www.audio-technica.com. Thank you for choosing an Audio-Technica professional wireless system. You have joined thousands of other satisfied customers who have chosen our products because of their quality, performance and reliability. This Audio-Technica wireless microphone system is the successful result of years of design and manufacturing experience. Each 2000 Series wireless system provides a choice of 10 PLL synthesized UHF frequencies in one of five UHF frequency ranges, available for flexible performance in a wide variety of regions worldwide: Frequency Range Band D 656.125 – 678.500 MHz Band E 795.500 – 805.875 MHz Band F 854.900 – 864.900 MHz Band G 722.125 – 744.500 MHz Band I 487.125 – 506.500 MHz Band U 606.500 – 629.900 MHz The band letter reference at the end of 2000 Series Stock Numbers indicates what band system/component operates in. For simplicity, model numbers used throughout this manual will reference only the basic model number without the band indications. Each wireless system includes a…

Text truncated - open the document above for the full version.

The following statements will be added as an addendum to the user manual and will be added to the user manual during the next printing: This device complies with part 15 of the FCC rules. Operation Is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must Accept any interference received, including interference that may cause undesired operation.

Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Federal Communications Commission Authorization and Evaluation Division Audio-Technica Corp. 2-46-1, Nishi-Naruse, Machida, Tokyo 194-8666, Japan Tel. +81-42-739-9128 Fax. +81-42-739-9129 www.audio-technica.co.jp Confidentiality Request regarding application for certification of FCC ID: JFZT220BD Pursuant to Sections 0.457 and 0.459 of the Commission's Rules, we hereby request confidential treatment of information accompanying this application as outlined below: Exhibit Type Block Diagram Schematic Parts List Operational Description Tuning Procedure The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Sincerely, Furnia Kamimura General Manager, Engineering Division Audio-Technica Corp. audio-technica

APPLICANT: AUDIO-TECHNICA CORPORATION FCC ID: JFZT220BD IC: 1752B-T220BD EXTERNAL PHOTOS F RONT VIEW TO P VIEW B OTTOM VIEW

APPLICANT: AUDIO-TECHNICA CORPORATION FCC ID: JFZT220BD IC: 1752B-T220BD INTERNAL PHOTOS

© 2020 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. 802 N. Twin Oaks Valley Road, Suite 105 • San Marcos, CA 92069 • U.S.A. TEL (760) 471-2100 • FAX (760) 471-2121 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Audio-Technica Corporation Dates of Test: June 19, 2020 2- 46-1 Nishi-naruse, Machida Test Report Number: SAR.20200224 Tokyo, 194-8666 Japan Revision A This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and IEC 62209-2:2010 (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application is subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Testing Cert. # 2387.01 FCC ID: JFZT220BD IC Certificate: 1752B-T220BD Model(s): ATW-T220bD Test Sample: Engineering Unit Same as Production Serial Number: Eng 1 Equipment Type: Wireless Handheld Microphone Classification: Portable Transmitter Next to Extremity TX Frequency Range: 656.125 – 662.125 MHz Frequency Tolerance: ± 2.5 ppm Maximum RF Output: 13.01 dBm Conducted Signal Modulation: FM Antenna Type: Whip Antenna Application Type: Certification FCC Rule Parts: Part 2, 74 KDB Test Methodology: KDB 447498 D01 v06 Industry Canada: RSS-102 Issue 5, Safety Code 6 Maximum SAR Value: 0.30 W/kg Separation Distance: 0 mm Report Number: SAR.20200224 © 2020 RF Exposure Lab, LLC Page 2 of 54 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Table of Contents 1. Introduction ........................................................................................................................ 4 SAR Definition [5] ................................................................................................................... 5 2. SAR Measurement Setup ................................................................................................... 6 Robotic System ...................................................................................................................... 6 System Hardware ................................................................................................................... 6 System Electronics ................................................................................................................. 7 Probe Measurement System .................................................................................................. 7 3. Probe and Dipole Calibration .............................................................................................15 4. Phantom & Simulating Tissue Specifications .....................................................................16 Head & Body Simulating Mixture Characterization ................................................................16 5. ANSI/IEEE C95.1 – 1992 RF Exposure Limits [2] ..............................................................17 Uncontrolled Environment .....................................................................................................17 Controlled Environment .........................................................................................................17 6. Measurement Uncertainty .................................................................................................18 7. System Validation..............................................................................................................19 Tissue Verification .................................................................................................................19 Test System Verification ........................................................................................................19 8. SAR Test Data Summary ..................................................................................................20 Procedures Used To Establish Test Signal ...........................................................................20 Device Test Condition ...........................................................................................................20 SAR Data Summary – 600 MHz Body ...................................................................................22 9. Test Equipment List ...........................................................................................................23 10. Conclusion ....................................................................................................................24 11. References ....................................................................................................................25 Appendix A – System Validation Plots and Data .......................................................................26 Appendix B – SAR Test Data Plots ...........................................................................................29 Appendix C – SAR Test Setup Photos ......................................................................................31 A ppendix D – Probe Calibration Data Sheets ............................................................................33 Appendix E – Dipole Calibration Data Sheets ...........................................................................43 Appendix F – Phantom Calibration Data Sheets ....................................................................…

Text truncated - open the document above for the full version.

849 NW STATE ROAD 45 PHONE: 888.472.2424 OR 352.472.5500 NEWBERRY, FL 32669 USA EMAIL: [email protected] WEB: HTTP://WWW.TIMCOENGR.COM An IIA Company FCC Part 74H & ISED RSS-210 Test Report APPLICANT AUDIO-TECHNICA CORPORATION ADDRESS 2-46 -1 Nishi-Naruse, Machida Tokyo 194-8666 JAPAN FCC ID JFZT220BD IC 1752B-T220D MODEL NUMBER ATW-T220bD PRODUCT DESCRIPTION HANDHELD WIRELESS MICROPHONE STANDARD APPLIED CFR 47 Part 74 DATE SAMPLE RECEIVED 1/3/2020 DATE TESTED 1/ 21 /2020 TESTED BY Tim Royer APPROVED BY Franklin Rose TEST RESULTS PASS FAIL Report Number Report Version Description Issue Date 410AUT20_PT74_TestReport_ ----- Initial Issue 2/19/2020 Rev1 Revised spurious emissions, Power output, frequency stability 5/27/2020 Rev2 Added Maximum Deviation Page 3 5/29/2020 Rev3 Updated Page 11 plot 7/13/2020 THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. This report relates only to the Equipment Under Test (EUT) sample(s) tested. TABLE OF CONTENTS GENERAL REMARKS ........................................................................................................................................... 2 GENERAL INFORMATION ................................................................................................................................... 3 RESULTS SUMMARY ........................................................................................................................................... 4 RF POWER OUTPUT ........................................................................................................................................... 5 TEST DATA: MEAN OUTPUT POWER MEASUREMENT TABLE, FCC PART 74 .............................................................................. 6 TEST DATA: MEAN OUTPUT POWER MEASUREMENT TABLE, RSS-210 ANNEX G....................................................................... 6 OCCUPIED BANDWIDTH .................................................................................................................................... 7 TEST DATA: OPERATING BANDWIDTH MEASUREMENT TABLE, FCC PART 74 ..................................................................... 9 TEST DATA: OPERATING BANDWIDTH MEASUREMENT TABLE, RSS-210 ANNEX G .............................................................. 9 TEST DATA: 656.125 MHZ 99% OBW PLOT ....................................................................................................... 10 TEST DATA: 662.125 MHZ 99% OBW PLOT ....................................................................................................... 11 TEST DATA: 656.125 MHZ EMISSION MASK PLOT ....................................................................................................... 12 TEST DATA: 662.125 MHZ EMISSION MASK PLOT ....................................................................................................... 13 FIELD STRENGTH OF SPURIOUS EMISSIONS ................................................................................................... 14 TEST DATA: 656.125 MHZ, FCC PART 74 ......................................................................................................... 16 TEST DATA: 662.125 MHZ, RSS-210 ANNEX G ................................................................................................... 17 FREQUENCY STABILITY ................................................................................................................................... 18 TEST DATA: MEASUREMENT TABLE ..................................................................................................................... 19 TEST DATA: MEASUREMENT GRAPH .................................................................................................................... 20 STATEMENT OF MEASUREMENT UNCERTAINTY ................................................................................................ 21 EMC EQUIPMENT LIST ..................................................................................................................................... 22 Report: 410AUT20_PT74_TestReport_Rev3 Page 2 of 22 GENERAL REMARKS Summary The device under test does: Fulfill the general approval requirements as identified in this test report and was selected by the customer. Not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. I attest that the necessary measurements were made at: Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Designation #: US1070 Tested by: Name and Title Tim Royer, Project Manager / EMC Testing Engineer Date 02/17/2020 Reviewed and Approved by: Name and Title Franklin Rose, Project Manager / EMC Testing Technician Date 02/17/200 Report: 410AUT20_PT74_TestReport_Rev3 Page 3 of 22 GENERAL INFORMATION EUT Description HANDHELD WIRELESS MICROPHONE FCC ID JFZT220BD IC 1752B-T220BD Model Number ATW-T220bD Operating Frequency 653-657 MHz Part 74 653-663 MHz RSS-210 Test Frequencies 656.125 MHz Part 74 662.125 MHz RSS-210 Note: The device is channelized, and testing frequencies were limited to only those frequencies available. Modulation FM Maximum Deviation ±40kHz EUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Antenna Connector n/a (integral antenna) Test Conditions The temperature was 26ºC Relative humidity of 50%. Modification to the EUT A UFL connector was fitted for testing. Test Exercise Normal operation. Applicable Standards FCC CFR 47 Part 2, & 74, RSS-2…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS FCC ID: JFZT220BD IC: 1752B-T220BD Field Strength of Spurious Emissions TEST SETUP PHOTOGRAPHS FCC ID: JFZT220BD IC: 1752B-T220BD Frequency Stability
