JFZT220BIHANDHELD WIRELESS MICROPHONE

2000 Series Frequency-agile True Diversity UHF Wireless System Installation and Operation 2000 Series Installation and Operation 2 This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. This device complies with INDUSTRY CANADA R.S.S. 210, en conformité avec IC: RSS-210/CNR210. Operation is subject to the following conditions: 1) This device may not cause harmful interference and 2) this device must accept any interference received, including interference which may cause undesired operation. Hereby Audio-Technica declares that this device complies with the essential requirements and other relevant provisions of the R&TTE directive 1999/5/EC CAUTION! Electrical shock can result from removal of the receiver cover. Refer servicing to qualified service personnel. No user- serviceable parts inside. • To prevent fire or shock hazard, do not expose this appliance to rain or moisture. • To prevent fire, do not place any naked flame sources (such as lighted candles) on the apparatus. • To prevent fire, do not cover the ventilation of the apparatus with newspaper, tablecloths, curtains etc. • Do not expose this apparatus to drips or splashes. • Do not place any objects filled with liquids, such as vases, on the apparatus. • Do not install this apparatus in a confined space such as a bookcase or similar unit. • The apparatus should be located close enough to the AC outlet so that you can easily grasp the AC adapter at any time. In case of emergency, disconnect the AC adapter quickly. • Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. • Always consider environmental issues and follow your local regulations when disposing of batteries. Do not expose batteries to excessive heat. The circuits inside the receiver and transmitter have been precisely adjusted for optimum performance and compliance with federal regulations. Do not attempt to open the receiver or transmitter. To do so will void the warranty, and may cause improper operation. Notice to individuals with implanted cardiac pacemakers or AICD devices: Any source of RF (radio frequency) energy may interfere with normal functioning of the implanted device. All wireless microphones have low-power transmitters (less than 0.05 watts output) which are unlikely to cause difficulty, especially if they are at least a few inches away. However, since a “body-pack” mic transmitter typically is placed against the body, we suggest attaching it at the belt, rather than in a shirt pocket where it may be immediately adjacent to the medical device. Note also that any medical-device disruption will cease when the RF transmitting source is turned off. Please contact your physician or medical-device provider if you have any questions, or experience any problems with the use of this or any other RF equipment. RF Interference Please note that wireless frequencies are shared with other radio services. According to Federal Communications Commission regulations, “Wireless microphone operations are unprotected from interference from other licensed operations in the band. If any interference is received by any Government or non Government operation, the wireless microphone must cease operation...” If you need assistance with operation or frequency selection, please contact your dealer or Audio-Technica. Extensive wireless information also is available at www.audio-technica.com. Thank you for choosing an Audio-Technica professional wireless system. You have joined thousands of other satisfied customers who have chosen our products because of their quality, performance and reliability. This Audio-Technica wireless microphone system is the successful result of years of design and manufacturing experience. Each 2000 Series wireless system provides a choice of 10 PLL synthesized UHF frequencies in one of five UHF frequency ranges, available for flexible performance in a wide variety of regions worldwide: Frequency Range Band D 656.125 – 678.500 MHz Band E 800.550 – 813.150 MHz Band F 854.900 – 864.900 MHz Band G 722.125 – 744.500 MHz Band I 487.125 – 506.500 MHz Band U 606.500 – 629.900 MHz The band letter reference at the end of 2000 Series Stock Numbers indicates what band system/component operates in. For simplicity, model numbers used throughout this manual will reference only the basic model number without the band indications. Each wireless system includes a receiver and either a body-pack or handheld transmitter. UniPak ® body-pack transmitter systems include accessory microphones for particular applications. All A-T Wireless Essentials ® microphones and cables, available separately, are pre- terminated for use with any Audio-Technica 2000 Series wireless system. The ATW-R2100a receiver features true diversity reception. Two antennas feed two completely independent RF sections on the same frequency; automatic logic circuitry continuously compares and selects the superior received signal, providing better sound quality and reducing the possibility of interference and dropouts. The receiver also offers a switchable output attenuator to reduce the level of the output signal by 12 dB for flexible use with a variety of system configurations. Switchable antenna power is also provided. Soft-touch controls provide convenient access to selection of operating frequency and automatic scanning, while an LCD information display provides constant monitoring of system operation. The receiver is half-width for a standard 1U 19" rack mount; rack-mount adapters are included. Two receivers can be mounted side by side, using an optional AT8630 joining-plate kit. The versatile ATW-T210a UniPak ® body-pack transmitter has both low- and high-impedance inputs plus a bias connection, for use with dynamic and electret condenser microphones, as well as Hi-Z instrument pickups. The UniPak ® transmitter also offers separate trim controls for instrument and mi…

Text truncated - open the document above for the full version.

The following statements will be added as an addendum to the user manual and will be added to the user manual during the next printing: This device complies with part 15 of the FCC rules. Operation Is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must Accept any interference received, including interference that may cause undesired operation. Note: the grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment.

English: This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Français: Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. 232901000-01-01 ver.1 2020.04.01

APPLICANT: AUDIO-TECHNICA CORPORATION FCC ID: JFZT220BI IC: 1752B-T220BI EXTERNAL PHOTOS FRONT VIEW TOP VIEW BOTTOM VIEW

APPLICANT: AUDIO-TECHNICA CORPORATION FCC ID: JFZT220BI IC: 1752B-T220BI INTERNAL PHOTOS

© 2020 RF Exposure Lab, LLC This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. 802 N. Twin Oaks Valley Road, Suite 105 • San Marcos, CA 92069 • U.S.A. TEL (760) 471-2100 • FAX (760) 471-2121 http://www.rfexposurelab.com CERTIFICATE OF COMPLIANCE SAR EVALUATION Audio-Technica Corporation Dates of Test: February 19-20, 2020 2- 46-1 Nishi-naruse, Machida Test Report Number: SAR.20200217 Tokyo, 194-8666 Japan Revision A This wireless mobile and/or portable device has been shown to be compliant for localized specific absorption rate (SAR) for uncontrolled environment/general exposure limits specified in ANSI/IEEE Std. C95.1-1992 and had been tested in accordance with the measurement procedures specified in IEEE 1528-2013 and IEC 62209-2:2010 (See test report). I attest to the accuracy of the data. All measurements were performed by myself or were made under my supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the qualifications of all persons taking them. RF Exposure Lab, LLC certifies that no party to this application is subject to a denial of Federal benefits that includes FCC benefits pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Jay M. Moulton Vice President Testing Cert. # 2387.01 FCC ID: JFZT220BI IC Certificate: 1752B-T220BI Model(s): ATW-T220bl Test Sample: Engineering Unit Same as Production Serial Number: Eng 1 Equipment Type: Wireless Handheld Microphone Classification: Portable Transmitter Next to Extremity TX Frequency Range: 487.125 – 506.50 MHz Frequency Tolerance: ± 2.5 ppm Maximum RF Output: 14.77 dBm Conducted Signal Modulation: FM Antenna Type: Whip Antenna Application Type: Certification FCC Rule Parts: Part 2, 74 KDB Test Methodology: KDB 447498 D01 v06 Industry Canada: RSS-102 Issue 5, Safety Code 6 Maximum SAR Value: 0.06 W/kg Separation Distance: 0 mm Report Number: SAR.20200217 © 2020 RF Exposure Lab, LLC Page 2 of 55 This report shall not be reproduced except in full without the written approval of RF Exposure Lab, LLC. Table of Contents 1. Introduction ........................................................................................................................ 4 SAR Definition [5] ................................................................................................................... 5 2. SAR Measurement Setup ................................................................................................... 6 Robotic System ...................................................................................................................... 6 System Hardware ................................................................................................................... 6 System Electronics ................................................................................................................. 7 Probe Measurement System .................................................................................................. 7 3. Probe and Dipole Calibration .............................................................................................15 4. Phantom & Simulating Tissue Specifications .....................................................................16 Head & Body Simulating Mixture Characterization ................................................................16 5. ANSI/IEEE C95.1 – 1992 RF Exposure Limits [2] ..............................................................17 Uncontrolled Environment .....................................................................................................17 Controlled Environment .........................................................................................................17 6. Measurement Uncertainty .................................................................................................18 7. System Validation..............................................................................................................19 Tissue Verification .................................................................................................................19 Test System Verification ........................................................................................................19 8. SAR Test Data Summary ..................................................................................................20 Procedures Used To Establish Test Signal ...........................................................................20 Device Test Condition ...........................................................................................................20 SAR Data Summary – 450 MHz Body ...................................................................................22 9. Test Equipment List ...........................................................................................................23 10. Conclusion ....................................................................................................................24 11. References ....................................................................................................................25 Appendix A – System Validation Plots and Data .......................................................................26 Appendix B – SAR Test Data Plots ...........................................................................................29 Appendix C – SAR Test Setup Photos ......................................................................................31 A ppendix D – Probe Calibration Data Sheets ............................................................................33 Appendix E – Dipole Calibration Data Sheets ...........................................................................44 Appendix F – Phantom Calibration Data Sheets ..............................................................…

Text truncated - open the document above for the full version.

849 NW STATE ROAD 45 PHONE: 352.472.5500 NEWBERRY, FL 32669 USA EMAIL: [email protected] WEB: HTTP://WWW.TIMCOENGR.COM An IIA Company FCC Part 15.236 Test Report APPLICANT AUDIO-TECHNICA CORPORATION 2-46-1 Nishi-Naruse, Machida Tokyo 194-8666 JAPAN FCC ID JFZT220BI MODEL NUMBER ATW-T220bI PRODUCT DESCRIPTION HANDHELD WIRELESS MICROPHONE DATE SAMPLE RECEIVED 1/3/2020 DATE TESTED 1/21/2020 TESTED BY Tim Royer APPROVED BY Franklin Rose TEST RESULTS PASS FAIL Report Number Report Version Description Issue Date 31BUT20_PT15_TestReport ---- Initial Issue 2/17/2020 Rev1 Clerical updates 5/27/2020 THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. This report relates only to the Equipment Under Test (EUT) sample(s) tested. TABLE OF CONTENTS GENERAL REMARKS ........................................................................................................ 2 GENERAL INFORMATION ................................................................................................ 3 RESULTS SUMMARY ........................................................................................................ 4 RF POWER OUTPUT ........................................................................................................ 5 TEST DATA: MEAN OUTPUT MEASUREMENT TABLE, 600 MHZ GUARD BAND & DUPLEX GAP ........................ 5 FREQUENCY SELECTION ................................................................................................. 6 OCCUPIED BANDWIDTH ................................................................................................. 7 OCCUPIED BANDWIDTH (26 DB) .................................................................................... 8 TEST DATA: 487.13 MHZ ..................................................................................................... 8 TEST DATA: 494.38 MHZ .................................................................................................... 9 TEST DATA: 506.5 MHZ ..................................................................................................... 10 TEST DATA: 487.13 MHZ 99% OBW PLOT ............................................................................ 11 TEST DATA: 494.38 MHZ 99% OBW PLOT ............................................................................ 12 TEST DATA: 506. 5 MHZ 99% OBW PLOT ............................................................................. 13 EMISSION MASK .......................................................................................................... 14 TEST DATA: 487.13 MHZ EMISSION MASK PLOT ........................................................................ 16 TEST DATA: 494.38 MHZ EMISSION MASK PLOT ........................................................................ 17 TEST DATA: 506.5 MHZ EMISSION MASK PLOT ....................................................................... 18 FIELD STRENGTH OF SPURIOUS EMISSIONS ................................................................ 19 TEST DATA: 487.13 MHZ.................................................................................................. 20 TEST DATA: 494.38 MHZ.................................................................................................. 21 TEST DATA: 506.5 MHZ ................................................................................................... 22 FREQUENCY STABILITY ................................................................................................ 23 STATEMENT OF MEASUREMENT UNCERTAINTY ............................................................. 24 EMC EQUIPMENT LIST .................................................................................................. 25 Report: 31BUT20TestReport_Rev1 Page 2 of 25 GENERAL REMARKS Summary The device under test does: Fulfill the general approval requirements as identified in this test report and was selected by the customer. Not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. I attest that the necessary measurements were made at: Timco Engineering Inc. 849 NW State Road 45 Newberry, FL 32669 Designation #: US1070 Tested by: Name and Title Tim Royer, Project Manager / EMC Testing Engineer Date 2/17/2020 Reviewed and Approved by: Name and Title Franklin Rose, Project Manager / EMC Testing Technician Date 2/17/2020 Report: 31BUT20TestReport_Rev1 Page 3 of 25 GENERAL INFORMATION EUT Description BODY-PACK WIRELESS MICROPHONE TRANSMITTER FCC ID JFZT220BI Model Number ATW-T220bI Operating Frequency 487.125 – 506.500 MHz Test Frequencies 487.130, 494.380, 506.500 EUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Antenna Connector BNC Test Conditions The temperature was 26ºC Relative humidity of 50%. Modification to the EUT No Modification to EUT. Test Exercise The EUT was placed in continuous transmit and was operated in “Test Mode” for digital emissions tests. Applicable Standards FCC CFR 47 Part 2, & 15, KDB 206256 D01 v02, ANSI C63.10- 2013, ANSI C63.4 2014, ANSI C63.26 2015 Test Facility Timco Engineering Inc. at 849 NW State Road 45 Newberry, FL 32669 USA. Designation #: US1070 Report: 31BUT20TestReport_Rev1 Page 4 of 25 RESULTS SUMMARY FCC Rule Part Requirement Test Item Result PART 2.1046(a), 15.236(d)(1) Conducted Power RF Power Output PASS PART 15.236(g), ETSI EN 300-422-1 s. 8.3.2 Unwanted Emissions Emission Mask PASS Note: The EUT is only marketed and sold to “Professional Users” a…

Text truncated - open the document above for the full version.

TEST SETUP PHOTOGRAPHS Applicant: AUDIO-TECHNICA CORPORATION FCC ID: JFZT220BI Power Output , Emission Mask TEST SETUP PHOTOGRAPHS FIELD STRENGTH OF SPURIOUS EMISSIONS TEST SETUP PHOTOGRAPHS Frequency Stability
