JFZT801T3BODY PACK WIRELESS MICROPHONE

System 8 VHF Wireless System Installation and Operation ATW-801 UniPak ® Transmitter System ATW-801/G Guitar System ATW-801/H Headworn Microphone System ATW-801/H92 Miniature Headworn Microphone System ATW-801/H92-TH Miniature (beige) Headworn Microphone System ATW-801/L Lavalier Microphone System ATW-802 Handheld Microphone System POWER PEAKRF SYSTEM 8 System 8 Installation and Operation 2 This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not cause harmful interference. A copy of the declaration of conformity can be found on the internet at www.audio-technica.com. This device complies with INDUSTRY CANADA R.S.S. 210, en conformité avec IC: RSS-210/CNR210. Operation is subject to the following conditions: 1) This device may not cause harmful interference and 2) this device must accept any interference received, including interference which may cause undesired operation. Changes or modifications not expressly approved by Audio-Technica could void your authority to operate this equipment. CAUTION! Electrical shock can result from removal of the receiver cover. Refer servicing to qualified service personnel. No user- serviceable parts inside. Do not expose to rain or moisture. The circuits inside the receiver and transmitter have been precisely adjusted for optimum performance and compliance with federal regulations. Do not attempt to open the receiver or transmitter. To do so will void the warranty, and may cause improper operation. Notice to individuals with implanted cardiac pacemakers or AICD devices: Any source of RF (radio frequency) energy may interfere with normal functioning of the implanted device. All wireless microphones have low-power transmitters (less than 0.05 watts output) which are unlikely to cause difficulty, especially if they are at least a few inches away. However, since a “body-pack” mic transmitter typically is placed against the body, we suggest attaching it at the belt, rather than in a shirt pocket where it may be immediately adjacent to the medical device. Note also that any medical-device disruption will cease when the RF transmitting source is turned off. Please contact your physician or medical-device provider if you have any questions, or experience any problems with the use of this or any other RF equipment. Thank you for choosing an Audio-Technica professional wireless system. You have joined thousands of other satisfied customers who have chosen our products because of their quality, performance and reliability. This wireless microphone system is the successful result of years of design and manufacturing experience. Each System 8 professional VHF wireless system includes a receiver and either a body-pack transmitter or a handheld microphone/ transmitter on a specific crystal-controlled frequency. ATW-801 UniPak ® body-pack transmitter systems include models pre-packaged with either an AT-GCW guitar cable (/G), a PRO 8HEcW headworn microphone (/H), a PRO 92cW headworn microphone (/H92), a PRO 92cW-TH headworn microphone (/H92-TH), or a lavalier mic (/L) for particular applications. All A-T Wireless Essentials ® microphones and cables, available separately, are pre-terminated for use with any ATW-801 system. Because System 8 packaging is designed to hold all versions of the system, some compartments in the carton may be intentionally left empty. The ATW-R800 receiver includes a switching power supply that automatically adapts to changes in mains voltage. The versatile ATW-T801 UniPak body-pack transmitter has both a high-impedance input for instruments, and a low-impedance input with bias connection for use with dynamic and electret condenser microphones. The ATW-T802 handheld transmitter features a unidirectional dynamic microphone element. Both the body-pack and handheld transmitters use internal AA batteries and have Power/Mute switches and input Trim (level) adjustments. Receiver Installation Location For best operation the receiver should be at least 3' (1 m) above the ground and at least 3' (1 m) away from a wall or metal surface to minimize reflections. Keep the receiver antennas away from noise sources such as digital equipment, motors, automobiles and neon lights, as well as away from large metal objects. In multi-channel systems, position receivers at least 3' (1 m) apart and keep operating transmitters at least 6' (2 m) from the receivers to help assure maximum RF performance. Output Connection The receiver provides unbalanced, aux-level output from a 1 / 4 " TS (“mono”) phone jack; an output cable is not included. Use a shielded audio cable with 1 / 4 " phone plug to connect the receiver’s AF Out jack to the mixer/amplifier’s aux-level input. Power Connection Connect the DC plug on the included AC power adapter to the DC power input on the back of the receiver. Secure the cord over the cord hook on the back of the receiver, to keep the plug from being detached by an accidental tug on the cord. Then plug the adapter into a standard 120 Volt 60 Hz AC power outlet. (Note that the receiver has no power Off/On switch. The receiver will be energized whenever the power adapter is connected and plugged into the AC outlet. Unplug the power supply from the AC outlet when the system is not in use — both for safety, and to conserve energy.) Antennas A novel “dipole” antenna system on the receiver improves operation by providing a “ground” element in addition to the usual “signal” element. Position the two antennas at 90° in the form of a “V,” or position the left (“signal”) antenna vertically and the right (“ground”) antenna horizontally, in the shape of an “L” (Fig. A). Use the position that performs better in your operating environment. Be certain to extend both antennas to their full 15" (38 cm) length by holding them at their bases and pulling out on their caps. Both antenna elements may be swiveled to the left and right, but do not attempt to rotate them in a screwing/unscrewing motion. To d…

Text truncated - open the document above for the full version.

APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: JFZT801T3 IC: 1752B-T801T3 MODEL: ATW-T801-T3 EXTERNAL PHOTOS

APPLICANT: AUDIO TECHNICA CORPORATION FCC ID: JFZT801T3 IC: 1752B-T801T3 MODEL: ATW-T801-T3 INTERNAL PHOTOS

FCC PART 90 AND INDUSTRY CANADA RSS-123 LOW POWER LICENSED TRANSMITTER TEST REPORT APPLICANT AUDIO TECHNICA CORPORATION 2206 NARUSE, MACHIDA TOKYO 194 JAPAN FCC ID JFZT801T3 IC CERT 1752B-T801T3 MODEL NUMBER ATW-T801-T3 PRODUCT DESCRIPTION BODY PACK WIRLESS MICROPHONE DATE SAMPLE RECEIVED 3/5/2012 DATE TESTED 3/12/2012 TESTED BY Nam Nguyen APPROVED BY Mario de Aranzeta TIMCO REPORT NO. 537AUT12TestReport.doc TEST RESULTS PASS FAIL THE ATTACHED REPORT SHALL NOT BE REPRODUCED EXCEPT IN FULL WITHOUT THE WRITTEN APPROVAL OF TIMCO ENGINEERING, INC. 849 NW STATE ROAD 45 NEWBERRY, FL 32669 USA PH: 888.472.2424 OR 352.472.5500 FAX: 352.472.2030 EMAIL: [email protected] HTTP: //WWW.TIMCOENGR.COM Certificate # 0955-01 Applicant: AUDIO TECHNICA CORPORATION FCC ID: JFZT801T3 IC #: 1752B-T801T3 MODEL #: ATW-T801-T3 REPORT: A\AudioTechnica_JFZ\537AUT12\537AUT12TestReport.doc Page 2 of 16 TABLE OF CONTENTS GENERAL REMARKS ......................................................................................................... 3 GENERAL INFORMATION .................................................................................................. 4 TEST PROCEDURES ......................................................................................................... 6 RF POWER OUTPUT .......................................................................................................... 7 MODULATION CHARACTERISTICS .................................................................................... 8 VOICE MODULATED COMMUNICATION EQUIPMENT ....................................................... 9 AUDIO INPUT VERSUS MODULATION ............................................................................. 10 OCCUPIED BANDWIDTH ................................................................................................. 11 SPURIOUS EMISSIONS AT ANTENNA TERMINALS (CONDUCTED) ................................... 13 FIELD STRENGTH OF SPURIOUS EMISSIONS ................................................................. 14 FREQUENCY STABILITY .................................................................................................. 15 EMC EQUIPMENT LIST ................................................................................................... 16 Applicant: AUDIO TECHNICA CORPORATION FCC ID: JFZT801T3 IC #: 1752B-T801T3 MODEL #: ATW-T801-T3 REPORT: A\AudioTechnica_JFZ\537AUT12\537AUT12TestReport.doc Page 3 of 16 GENERAL REMARKS The attached report shall not be reproduced except in full without the written permission of Timco Engineering Inc. The test results relate only to the items tested. Summary The device under test does: fulfill the general approval requirements as identified in this test report not fulfill the general approval requirements as identified in this test report Attestations This equipment has been tested in accordance with the standards identified in this test report. To the best of my knowledge and belief, these tests were performed using the measurement procedures described in this report. All instrumentation and accessories used to test products for compliance to the indicated standards are calibrated regularly in accordance with ISO 17025 requirements. Certificate # 0955-01 I attest that the necessary measurements were made, under my supervision, at: Timco Engineering Inc. 849 NW State Road 45 Newberry, Fl 32669 Authorized Signatory Name: Mario de Aranzeta C.E.T. Compliance Engineer/ Lab. Supervisor Date: 3/16/2012 Applicant: AUDIO TECHNICA CORPORATION FCC ID: JFZT801T3 IC #: 1752B-T801T3 MODEL #: ATW-T801-T3 REPORT: A\AudioTechnica_JFZ\537AUT12\537AUT12TestReport.doc Page 4 of 16 GENERAL INFORMATION RULES PART 2.1033 DUT TECHNICAL DESCRIPTION DUT Description BODY PACK WIRLESS MICROPHONE FCC ID JFZT801T3 IC Certification 1752B-T801T3 Model Number ATW-T801-T3 Modulation FM Type of Emission 54KOF3E Bn = 2M+2DK M = 18000 D = 10 kHz (Peak Deviation) K = 1 Bn = 2(18k) + 2(9k)(1) = 54k Frequency Range 170.245 MHz Test Frequencies 170.245 MHz Maximum Output Power 0.010 Watts Conducted DUT Power Source 110–120Vac/50– 60Hz DC Power Battery Operated Exclusively Test Item Prototype Pre-Production Production Type of Equipment Fixed Mobile Portable Applicant: AUDIO TECHNICA CORPORATION FCC ID: JFZT801T3 IC #: 1752B-T801T3 MODEL #: ATW-T801-T3 REPORT: A\AudioTechnica_JFZ\537AUT12\537AUT12TestReport.doc Page 5 of 16 GENERAL INFORMATION Test Facility Timco Engineering, Inc. 849 NW State Road 45, Newberry, FL 32669 Test Condition The temperature was 26ºC with a relative humidity of 50%. Modifications None Test Exercise (e.g software description, test signal, etc.) The DUT was placed in continuous transmit mode of operation. Applicable Standards ANSI/TIA 603-C:2004, FCC CFR 47 Parts 2 and 74, RSS- 123 Issue 1, Rev. 2 Applicant: AUDIO TECHNICA CORPORATION FCC ID: JFZT801T3 IC #: 1752B-T801T3 MODEL #: ATW-T801-T3 REPORT: A\AudioTechnica_JFZ\537AUT12\537AUT12TestReport.doc Page 6 of 16 TEST PROCEDURES Power Line Conducted Interference: The procedure used was ANSI/TIA 603-C:2004 using a 50uH LISN. Both lines were observed with the UUT transmitting. The bandwidth of the spectrum analyzer was 10 kHz with an appropriate sweep speed. Bandwidth 20 dB: The measurements were made with the spectrum analyzer's resolution bandwidth (RBW) = 1 MHz and the video bandwidth (VBW) = 3 MHz and the span set as shown on plot. Power Output: For a device with a fixed antenna, RF power is measured as ERP as the antenna is permanently attached. The substitution method was used as described in ANSI/TIA-603-C:2004. Antenna Conducted Emissions: The RBW = 100 kHz, VBW = 300 kHz and the span set to 10.0 MHz and the spectrum was scanned from 30 MHz to the 10 th Harmonic of the fundamental. Above 1 GHz the resolution bandwidth was 1 MHz and the VBW = 3 MHz and the span to 50 MHz. Radiation Interference: The test procedure used was ANSI/TIA 603-C:2004 using an Agilent spectrum receiver with preselector. The bandwidth (RB…
