JJ8-11006GPS WATCH

(YP11545 GPS Watch ) USER'S MANUAL GPS I Countdown Timer 30 30M Water Resistant EL Backlight Chime 11 50 Years Calendar Heart Rate 5 Alarms 5 Stopwatch Low voltage indicator World time Holter Table of contents 1.2 Water Resistant 1.1 About GPS 1.3 Watch maintenance Packaging content Getting Started 3.1 Know your watch 3.2 Charge 3.4 Low voltage indicator 3.5 Set your watch 3.6 Acquire Satellite signals 3.7 Pair your Heart Rate Monitor 3.3 Reset the watch General Operations 4.1 Timekeeping mode 4.1.1 GPS time service 4.2 Alarm mode 4.3.1 Activate 4.1.2 Power check 4.3.2 Record 4.3.3 Delete 4.3 Exercise mode 4.4 Stopwatch mode II Overview 1 1 2 2 3 4 4 5 6 6 6 7 7 9 11 11 11 12 14 15 18 20 22 4.9 Setting mode 4.8 World time mode 4.6.1 Activate 4.7 Tracking mode 4.7.1 GPS 4.9.1 Time 5.1 Software installation 5.2 How to use the software PC Software 4.4.3 Delete 4.4.2 Recall 4.4.1 Activate 4.5 Timer mode 4.6 Holter mode 4.6.2 Settings 4.6.3 Record 4.6.4 Delete 4.7.2 Edit 4.7.3 Goto 4.9.2 Alarm 4.9.4 User 4.9.3 Timer 4.9.5 Auto Lap 4.9.6 HR Zone 4.9.7 HR Link 4.9.8 Light Troubleshooting III 23 24 25 27 29 30 32 33 35 37 38 39 41 45 47 48 50 52 54 56 57 59 60 61 61 62 66 Thank you for purchasing a GPS watch, this watch has a GPS adjust time, location and tracking function, and can record exercise during the march of time, speed, pace, distance, calories burned, lap and other relevant date 2.4GHz wireless heartbeat measurement technology can monitor your heart rate changes at any time. And PC communication then convenient to view the training results, connected to the PC can view your location information on Google maps, built-in lithium-ion batteries can also charge via the PC's USB interface. At the same time, the watch has a 12/24 hour, alarm, stopwatch, countdown timer, dual time, check power, low power and other functions. Summarize 1.1 About GPS GPS is global positioning system's abbreviation, by the U.S. department of defense to develop and operate. About 21,000km above the earth, around the earth's rotation three more satellites form a GPS system. The GPS device receives the radio signal, according to the distance of each satellite and orbit, can be calculated present position through the triangulation principle. The satellites continuously transmit the GPS determination of the time required for information, a one second pulse (Coordinated Universal Time), the satellite's orbit information (ephemeris data), all other satellite orbit information (almanac data), and other information, this watch analysis of the data received from GPS satellites to determine the present position, and calculate the distance and direction you move. Tracking and Control Center (TACC) control signal by the U.S. GPS system, the center according to their own judgment to reduce the precision of the signal and stop signal launch. This watch need to receive satellite radio waves, therefore may be subject to environmental interference. Make watches of the following places are subject to interference to GPS signals can not be accepted. 1: From time to time in the building underground;; 2: In the high-rise buildings;; 3: The motor vehicle;; 4: In the forest;; 5: Near power lines; 6: Watch under sleeve;. 1 This watch is a precision electronic navigation aids, but is still possible because the operation of user error, external interference or failure factors and so on, and become unsafe, so use at your own risk. This watch belongs to the general navigation level receiver, does not apply to do a precision measurement work. This watch can enhance the security of users in the wild, but can not completely replace any orientation tool (for example: compass, compass, maps and other navigational instruments, etc.) please notice. 1.2 Water Resistant . . This watch has a 3ATM waterproof design, can resistant to 30 meters depth pressure, when the watch is immersed in water, please dry and Air-dried the watch before use and charging. This watch can't use in the swimming, a long time be submerged in water may cause a short circuit, which may cause minor skin burns and stimulate Don't operation the key underwater 1.3 Watch maintenance Please use a mild detergent solution and a damp cotton cloth and wipe the watch and heart rate belt, and then dry cloth, do not use that may damage the plastic components of chemical cleaning agents or solvents. Don't put the watch in hot place(such as car trunk) or it may cause permanent damage to the product. 2 Packaging content After opening the package, be careful to check the package should contain the following GPS Watch 2.4GHz Heart Rate Monitor Charging clip CD Quick Reference Guide Tip: If the object is missing or broken, please contact. GPS Watch 2.4GHz Heart Rate Monitor Charging clipCDQuick Reference Guide 3 Getting Started 3.1 Know your watch Display K7 -- Quit K1 -- Up/Increase/Fast increase/Start/Lap K3 -- Enter/Confirm/Save/Pause K5 -- Down/Decrease/Fast decrease K11 -- EL Backlight Button Function (EL Backlight) K11 (Quit) K7 K1 (Up/+) K5 (Down/-) K3 (Enter) GPS Key function indicator Score bar 4 Day of week DateMonth Low voltage indicator Hour Seconds Minutes Heart rate Daylight save time Timer Stopwatch Buttons Key function indicator Key function indicator Key function indicator 3.2 Charge You should charge at least 4 hours before first use, the battery charging time will be different according to the actual use conditions, use, it is recommended that regular intervals of 1-2 month on a regular basis to re-charge in order to maintain the good condition of the battery, charging through the PC& USB interface, please follow these steps: 3.2.1 Start PC, connect USB cable into PC USB interface; 3.2.2 Will charge clip and watch the back of the terminal alignment; 3.2.3 Connect the charge clip with watch, watch display shows "Charging"; 3.2.4 when the battery shows full grid, remove the USB cable from PC, at the same remove the charge clip, the watch can be used. 5 3.3 Reset the watch After …

Text truncated - open the document above for the full version.

H.K. Youngs Watch Co., Ltd. Units 1-12, 10/F, Hope Sea Industrial Centre, No.26, Lam Hing St., Kowloon Bay, Kowloon, Hong Kong 2012-05-28 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: JJ8-11006 Product Name: GPS WATCH Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential: • Schematics • Block diagram • Operational Description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Dated this 05/28/2012 By: Fujun Liu Signature Printed Title: Development Manager On behalf of : H.K. Youngs Watch Co., Ltd. Telephone: 0755-28110607

Label Location

Radiated Emission
