JNZ211596Wireless Mouse

Logitech Far East Ltd

Click to zoom

Application Details

Equipment Class: DXX - Part 15 Low Power Communication Device Transmitter
Date of Grant: Aug 06, 2002
Application Purpose: Original Equipment
Date of Application: Aug 06, 2002
Equipment Note: Wireless Mouse
Frequency Range: 26.96000000 - 27.28000000
Company: Logitech Far East Ltd
Country: Taiwan

Documents & Files

Select a file to view

Users Manual

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Block Diagram

uP Resonator ADNS 2020 E2PROM Resonator I source & LED Wake-up circuitry RF Switches Roller Reset & connect Charge LED DC/DC Battery Receiver / Charger Charge switch circuit EOL switch LDO VCC Cradle detection 32 KHz 24 MHz Crystal 13.5225MHz Crystal 13.5975MHz

External Photos

Report No.: 026H038FI Page: 1 of 10 Version:1.0 Attachment 2 : EUT Detailed Photographs (1) EUT Photo (2) EUT Photo

ID Label/Location Info

FCC ID.: JNZ211596 #2 Creation Rd., 4, Science-Based Ind. Park, Hsinchu, Taiwan, R.O.C. Tel: 886 3 577 8241 Fax: 886 3 579 2393 LabelLoc The FCC ID and DoC Label will be placed on the equipment as shown in the photograph below. FCC ID Label Sample Wireless Mouse Model No.: M-RY81 F F C C C C I I D D : : J J N N Z Z 2 2 1 1 1 1 5 5 9 9 6 6 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference and (2) this device must accept any interference received, including interference that may cause undesired operation. S/N: Made in Taiwan DoC Wireless Keyboard Logitech Model No.: Y-RH35 TESTED TO COMPLY WITH FCC STANDARDS FOR HOME OR OFFICE USE S/N: Made in Taiwan

ID Label/Location Info

Internal Photos

Report No.: 026H038FI Page: 2 of 10 Version:1.0 (3) EUT Photo (4) EUT Photo Report No.: 026H038FI Page: 3 of 10 Version:1.0 (5) EUT Photo (6) EUT Photo Report No.: 026H038FI Page: 4 of 10 Version:1.0 (7) EUT Photo (8) EUT Photo Report No.: 026H038FI Page: 5 of 10 Version:1.0 (9) EUT Photo (10) EUT Photo Report No.: 026H038FI Page: 6 of 10 Version:1.0 (11) EUT Photo (12) EUT Photo Report No.: 026H038FI Page: 7 of 10 Version:1.0 (13) EUT Photo (14) EUT Photo Report No.: 026H038FI Page: 8 of 10 Version:1.0 (15) EUT Photo (16) EUT Photo Report No.: 026H038FI Page: 9 of 10 Version:1.0 (17) EUT Photo (18) EUT Photo Report No.: 026H038FI Page: 10 of 10 Version:1.0 (19) EUT Photo

Operational Description

1.1. Operation Description The EUT is a 27MHz Wireless Mouse intends to use in household and office PC system. The device adapts FSK modulation. The antenna Soldered on PCB Provides diversity function to improve the transmitting function.
