JNZ211610Wireless Keyboard

Setup Logitech ® Cordless Keyboard ©2002 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice. Part number: 623060-0403 Logitech ® on the world wide web: www.logitech.com English To enjoy all the features of the keyboard and mouse, you must install the software. For Macintosh®, use the F12 key to eject (open) the CD tray for systems that use keyboard ejection. Español Français Português 5 Software Le logiciel El Software O Software Features Funciones Fonctions Recursos English Keyboard/mouse do not work: 1. Check the receiver's cable connections. 2. Press the connect button on the receiver; press the connect button on the bottom of keyboard and mouse. 3. Refer to the help system on the hard disk. Español Français Português Troubleshooting Dépannage Resolución de problemas Solução de Problemas ~ ` ! 1 @ 2 # 3 $ 4 % 5 ^ 6 E R T Q W T a b C a p s L oc k S h i f t C t rl A S D F G Z X C V B A l t & 7 8 ( 9 ) 0 + = _ F6 F7 F8 F9 F1 0 F11 F12 B a c k s p a c e Y U I O P { [ } ] | \ H J K L : ; " ' E n t er N M < , > . ? / Sh i ft C trl A l t D el et e WA RN I N G : T o a voi d r i sks as s oc i at e d w i t h k ey b oar di ng, s e e t he b ac k o f t hi s k eyb oar d. E n d P a ge D o wn Ins ert Home P a ge U p Num L oc k P r i nt S cr een S cr ol l L oc k P a u s e Br ea k S ys R q – + E n t er Home P g U p 9 8 7 6 5 4 E n d P g D n 3 2 1 Ins 0 D el . / E s c F 1 He l p F 2 F 3 F 4 F 5 English 1. Suspend key 2. Internet keys 3. Multi- media keys. For more information, refer to the online help system located on your hard disk. Español Français Português English Turn on computer. After system boot is finished, press connect button on re- ceiver , and then press connect but- ton on mouse . Next, press connect button on receiver again and press connect button on keyboard . Español Français Português 4 Connect Connect Connect Connect iTouch ™ 1.6 For Microsoft ® Windows ® 95 Windows ® 98 Windows NT ® 4.0 Windows ® 2000 Installation: Insert CD into CD-ROM drive and follow on-screen instructions. Part #: 601691-0902 Pat. Pend. www.logitech.com Logitech a a b c PC: USB PC: PS/2 Macintosh®: USB 1 2 3 5 4 b d a c b d a c a c b ~ ` ! 1 @ 2 # 3 $ 4 % 5 ^ 6 E R T Q W Tab C ap s Lo c k S h i f t C trl A S D F G Z X C V B A lt & 7 8 ( 9 ) 0 + = _ F6 F7 F8 F9 F1 0 F1 1 F12 B ac k sp ac e Y U I O P { [ } ] | \ H J K L : ; " ' E nte r N M < , > . ? / S h if t C t r l A lt D e le t e W ARNI N G : To a v oi d ri sk s a s s o ci a te d w i th k e y b o a r di n g, s e e th e b a c k o f th i s k e y b o a r d. E n d P a g e D o w n In se r t H o m e P a g e U p Nu m L o c k P r in t S c r e e n S c r o ll L o c k P a u se B r e a k S y s R q – + E n t e r H o m e P g U p 9 8 7 6 5 4 E n d P g D n 3 2 1 In s 0 D e l . / Es c F1 H e l p F2 F3 F4 F5 1 2 3 Important Ergonomic Information Información sanitaria importante Informations importantes relatives au confort Importantes informações sobre Conforto English Important Ergonomic Information. Long periods of repetitive motions using an improperly set-up workspace, incorrect body position, and poor work habits may be associated with physical discomfort and injury to nerves, tendons, and muscles. If you feel pain, numbness, weakness, swelling, burning, cramping, or stiff- ness in your hands, wrists, arms, shoulders, neck, or back, see a quali- fied health professional. For more in- formation, please read the Comfort Guidelines located in the iTouch ® help system and on the Logitech ® web site at http://www.logitech.com/comfort Español Français Português English Package Contents: 1. Receiver and PS/2 adapter 2. Batteries 3. Software 4. Keyboard 5. Mouse Español Français Português 1Contents Contents Contents Contents English Turn off the computer. For PCs, connect the receiver to the desktop via the PS/2 ports , or to the notebook via the USB port only . (Use PS/2 connec- tions when possible.) NOTE: For any USB connection, DO NOT use the PS/2 mouse connector. For Macintosh®, connect receiver to a single USB port only . Place receiver away from electronic devices . Español Français Português 2 Receiver Receiver Receiver Receiver English Install the batteries. Refer to the battery diagram inside the battery compart- ment. Note where the positive and negative ends of the batteries are to be inserted. Español Français Português 3 Batteries Batteries Batteries Batteries d 8 in 20 cm d

Page 1 ANNEX PHOTOGRAPHS OF EUT Page 2

LABEL LOCATION FOR FCC ID

Page 3 Page 4 Page 5 Page 6

FCC ID: JNZ211610 ADT No.910816R03 Operational Description The transmitter of the EUT (Wireless Keyboard) is powered by 3V Battery. Both transmitter and receiver use Integral antenna. Because the room inside the housing is very limited, so the size of the antenna is far smaller than one wavelength (27MHz) which means the radiation efficiency is very low. But under normal use condition, the transmitter and the receiver is quite close, so high EIRP power is not needed and neither not allowed because of interference.

FCC ID: JNZ211610Logitech P/N AGY-733290-0000 Rev.A Report No.: RF910816R031Issued: August 29, 2002 FCC TEST REPORT REPORT NO.: RF910816R03 MODEL NO.: Y-RJ7 RECEIVED: August 16, 2002 TESTED: August 19 ~ August 27, 2002 APPLICANT:LOGITECH FAR EAST LTD. ADDRESS: #2, Creation Rd. 4, Science-Based Ind. Park Hsinchu, Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:47 14th Lin, Chia Pau Tsuen, Linkou Hsiang, Taipei, Taiwan, R.O.C. This test report consists of 14 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by NVLAP or any U.S. government agencies. The test results in the report only apply to the tested sample. Lab Code: 200102-0 0528 ILAC MRA FCC ID: JNZ211610Logitech P/N AGY-733290-0000 Rev.A Report No.: RF910816R032Issued: August 29, 2002 Table of Contents 1CERTIFICATION.............................................................................................3 2SUMMARY OF TEST RESULTS.....................................................................4 3GENERAL INFORMATION.............................................................................5 3.1GENERAL DESCRIPTION OF EUT...............................................................5 3.2DESCRIPTION OF TEST MODES.................................................................6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS.................................6 3.4DESCRIPTION OF SUPPORT UNITS............................................................6 4TEST PROCEDURE AND RESULT................................................................7 4.1CONDUCTED EMISSION MEASUREMENT..................................................7 4.2RADIATED EMISSION MEASUREMENT.......................................................7 4.2.1LIMITS OF RADIATED EMISSION MEASUREMENT....................................7 4.2.2TEST INSTRUMENT......................................................................................8 4.2.3TEST PROCEDURE.......................................................................................9 4.2.4TEST SETUP................................................................................................10 4.2.5EUT OPERATING CONDITION....................................................................10 4.2.6TEST RESULT...............................................................................................11 5PHOTOGRAPHS OF THE TEST CONFIGURATION...................................13 6INFORMATION ON THE TESTING LABORATORIES..................................14 FCC ID: JNZ211610Logitech P/N AGY-733290-0000 Rev.A Report No.: RF910816R033Issued: August 29, 2002 1 CERTIFICATION PRODUCT : Wireless Keyboard BRAND NAME : Logitech MODEL NO : Y-RJ7 APPLICANT :LOGITECH FAR EAST LTD. STANDARDS : 47 CFR Part 15, Subpart C(15.227) ANSI C63.4-1992 We, Advance Data Technology Corporation, hereby certify that one sample of the designation has been tested in our facility on August 19 ~ August 27, 2002. The test record, data evaluation and Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample's EMC characteristics under the conditions herein specified. FCC ID: JNZ211610Logitech P/N AGY-733290-0000 Rev.A Report No.: RF910816R034Issued: August 29, 2002 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestN/A Power supply is 3VDC from batteries 15.227Radiated Emission TestPASS Minimum passing margin is –12.50dBuV at 54.40MHz NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: JNZ211610Logitech P/N AGY-733290-0000 Rev.A Report No.: RF910816R035Issued: August 29, 2002 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCTWireless Keyboard MODEL NO.Y-RJ7 POWER SUPPLY3VDC from battery MODULATION TYPEFSK CARRIER FREQUENCY OF EACH CHANNEL 27.145MHz & 27.095MHz NUMBER OF CHANNEL2 ANTENNA TYPEIntegral antenna DATA CABLE NA I/O PORTSNA ASSOCIATED DEVICESNA NOTE: 1. The EUT is the transmitter part of Wireless Keyboard. 2. For more detailed features description of the EUT, please refer to the manufacturer's specifications or the User's Manual. FCC ID: JNZ211610Logitech P/N AGY-733290-0000 Rev.A Report No.: RF910816R036Issued: August 29, 2002 3.2 DESCRIPTION OF TEST MODES Two channels were provided to this EUT. ChannelFrequency 127.145MHz 227.095MHz 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Wireless Keyboard. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: FCC CFR 47 Part 15, Subpart C (15.227) ANSI C63.4-1992 All tests have been performed and recorded as per the above standards. 3.4 DESCRIPTION OF SUPPORT UNITS NA FCC ID: JNZ211610Logitech P/N AGY-733290-0000 Rev.A Report No.: RF910816R037Issued: August 29, 2002 4 TEST PROCEDURE AND RESULT 4.1 CONDUCTED EMISSION MEASUREMENT NA 4.2 RADIATED EMISSION MEASUREMENT 4.2.1 LIMITS OF RADIATED EMISSION MEASUREMENT According to 15.227 the field strength of emissions from intentional radiators operated under these frequencies bands shall not exceed the following: Fundamental Frequency (MHz) Field Strength of Fundamental (dBuV/m) PeakAverage 26.96-27.28 10080 Field strength limits are at the distance of 3 meters, emissions radiated outside of the specified bands, shall be according to the general radiated limits in 15.209 as following: Field Strength of Fundamental Other Frequencies (MHz) uV/meterdBuV/meter 30-8810040.0 88-21615043.5 216-96020046.0 Above 96050054.0 As shown in 15.35(b), for frequencies above 1000MHz, the field stre…

Text truncated - open the document above for the full version.

FCC ID: JNZ211610Logitech P/N AGY-733290-0000 Rev.A Report No.: RF910816R0313Issued: August 29, 2002 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
