JNZ212106Cordless Mouse

•Federal Communication Commission Interference Statement•This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures:•Reorient or relocate the receiving antenna.•Increase the separation between the equipment and receiver.•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.•Consult the dealer or an experienced radio/TV technician for help.•FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.•This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

M-RBN114

JNZ212106

(Fig.1) FCC ID: JNZ212106 FCC LABEL LOCATION The label will be permanently affixed at a conspicuous location on the device. 1.2 cm 2.2 cm Label

Page 1 CONSTRUCTION PHOTOS OF EUT

Rating:1.5V ,100mA M/N:M-RBN114 CANADA 310 Made in China CMII ID:2006DJ0000 ADT095LPD0000 0000/POSTEL/2006 0000

Page 2 Page 3 Page 4 Page 5

FCC ID: JNZ212106 Report No.: RF941223H041 Report Format Version 2.0.3 FCC TEST REPORT REPORT NO.: RF941223H04 MODEL NO.: M-RBN114 RECEIVED: Dec. 12, 2005 TESTED: Dec. 27, 2005 ISSUED: Jan. 02, 2006 APPLICANT:LOGITECH FAR EAST LTD. ADDRESS:#2 Creation Rd. 4, Science-Based Ind. Park Hsinchu Taiwan, R.O.C. ISSUED BY:Advance Data Technology Corporation LAB LOCATION:No. 81-1, Lu Liao Keng, 9 Ling, Wu Lung Tsuen, Chiung Lin Hsiang, Hsin Chu Hsien, Taiwan, R.O.C. This test report consists of 17 pages in total. It may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CNLA, A2LA or any government agencies. The test results in the report only apply to the tested sample. 0536 No. 2177-01 ILAC MRA FCC ID: JNZ212106 Report No.: RF941223H04 2Report Format Version 2.0.4 Table of Contents 1CERTIFICATION..............................................................................................3 2SUMMARY OF TEST RESULTS .....................................................................4 3GENERAL INFORMATION ..............................................................................5 3.1GENERAL DESCRIPTION OF EUT ................................................................5 3.2DESCRIPTION OF TEST MODES ..................................................................6 3.3GENERAL DESCRIPTION OF APPLIED STANDARDS..................................6 3.4DESCRIPTION OF SUPPORT UNITS ............................................................6 4EMISSION TEST .............................................................................................7 4.1RADIATED EMISSION & OCCUPIED BANDWIDTH MEASUREMENT..........7 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT .....................................7 4.1.2 TEST INSTRUMENT .......................................................................................8 4.1.3 TEST PROCEDURE........................................................................................9 4.1.4 DEVIATION FROM TEST STANDARD..........................................................10 4.1.5 TEST SETUP (RADIATED EMISSION) ......................................................... 11 4.1.6 EUT OPERATING CONDITION..................................................................... 11 4.1.7 TEST RESULT (RADIATED EMISSION) .......................................................12 4.1.8 TEST RESULT (RADIATED EMISSION) .......................................................13 4.1.9 TEST RESULTS (BAND EDGES MEASUREMENT).....................................14 5PHOTOGRAPHS OF THE TEST CONFIGURATION ....................................15 6INFORMATION ON THE TESTING LABORATORIES...................................16 APPENDIX-A.................................................................................................... A-1 FCC ID: JNZ212106 Report No.: RF941223H04 3Report Format Version 2.0.4 1 CERTIFICATION PRODUCT : Cordless Mouse BRAND NAME : Logitech MODEL NO : M-RBN114 TESTED:Dec. 27, 2005 APPLICANT : LOGITECH FAR EAST LTD. STANDARDS : 47 CFR Part 15, Subpart C(Section 15.227) ANSI C63.4: 2003 The above equipment (Model: M-RBN114) has been tested by Advance Data Technology Corporation, and found compliance with the requirement of the above standards. The test record, data evaluation & Equipment Under Test (EUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s EMC characteristics under the conditions specified in this report. PREPARED BY : , DATE:Jan. 02, 2006 ( Midoli Peng ) TECHNICAL ACCEPTANCE :, DATE:Jan. 02, 2006 Responsible for RF ( Hank Chung ) APPROVED BY :, DATE:Jan. 02, 2006 ( May Chen, Deputy Manager ) FCC ID: JNZ212106 Report No.: RF941223H04 4Report Format Version 2.0.4 2 SUMMARY OF TEST RESULTS The EUT has been tested according to the following specifications: APPLIED STANDARD: 47 CFR Part 15, Subpart C STANDARD PARAGRAPH TEST TYPERESULTREMARK 15.207Conducted Emission TestNA Power supply is 1.5 VDC from batteries 15.227 / 15.209Radiated Emission TestPASS Minimum passing margin is –15.20 dB at 41.79 MHz 15.227Band Edges TestPASS Meet the requirement of limit NOTE: The receiver part to communicate with the EUT has been verified to comply with FCC Part 15, Subpart B, Class B (DoC). The test report can be provided upon request. FCC ID: JNZ212106 Report No.: RF941223H04 5Report Format Version 2.0.4 3 GENERAL INFORMATION 3.1 GENERAL DESCRIPTION OF EUT PRODUCTCordless Mouse MODEL NO.M-RBN114 POWER SUPPLY1.5 VDC from batteries MODULATION TYPEFSK CARRIER FREQUENCY OF EACH CHANNEL 27.045 MHz, 27.195MHz NUMBER OF CHANNEL2 ANTENNA TYPELoop antenna DATA CABLE NA I/O PORTSNA ASSOCIATED DEVICESNA NOTE: 1. The EUT is the transmitter part of Cordless Mouse. 2. The above EUT information was declared by the manufacturer and for more detailed features description, please refer to the manufacturer's specifications or User's Manual. FCC ID: JNZ212106 Report No.: RF941223H04 6Report Format Version 2.0.4 3.2 DESCRIPTION OF TEST MODES There are two channels have been pre-tested in our facility as following: Pre-test ModeFrequency 127.045MHz 227.195MHz NOTE: 27.045MHz, the worst case was chosen for final test and its data was recorded in this report. 3.3 GENERAL DESCRIPTION OF APPLIED STANDARDS The EUT is the transmitter part of a Cordless Mouse. According to the specifications of the manufacturer, it must comply with the requirements of the following standards: 47 CFR Part 15, Subpart C (Section 15.227) ANSI C63.4-2003 All tests have been performed and recorded as per the above standards. 3.4 DESCRIPTION OF SUPPORT UNITS The EUT has been tested as an independent unit. FCC ID: JNZ212106 Report No.: RF941223H04 7Report Format Version 2.0.4 4 EMISSION TEST 4.1 RADIATED EMISSION & OCCUPIED BANDWIDTH MEASUREMENT 4.1.1 LIMITS OF RADIATED EMISSION MEASUREMENT According…

Text truncated - open the document above for the full version.

FCC ID: JNZ212106 Report No.: RF941223H04 15Report Format Version 2.0.4 5 PHOTOGRAPHS OF THE TEST CONFIGURATION RADIATED EMISSION TEST
